Headlight - Adjustment: Adjustments Volvo S60 I

Adjustment, USA

1. Ignition and low beam on
2. Check the current. Check that the power supply is sufficient for the desired beam level
3. Remove the guard over the adjustment screw. Adjust the beam horizontally (X) by pulling the adjustment screw upwards
4. CAUTION: Always adjust the beam with low beam switched on.

Scheme 1

1. Adjust the beam vertically (Y) using an Allen screw, as shown in the illustration
2. Adjust the beam horizontally (X) using an Allen screw, as shown in the illustration
3. HINT: Use a Ø6 mm Allen screw.

Adjustment, United Kingdom

1. Ignition and low beam on
2. Check the button that controls the lighting level. Set the button to the 0 position
3. Check the current. Check that the power supply is sufficient for the desired beam level
4. CAUTION: Always adjust the beam with low beam switched on.

Scheme 2

1. Adjust the beam vertically (Y) using an Allen screw, as shown in the illustration
2. Adjust the beam horizontally (X) using an Allen screw, as shown in the illustration
3. HINT: Use a Ø6 mm Allen screw.

Adjustment, Japan

1. Ignition and low beam on
2. Check the button that controls the lighting level. Set the button to the 0 position
3. Check the current. Check that the power supply is sufficient for the desired beam level
4. CAUTION: Always adjust the beam with low beam switched on.

Scheme 3

1. Adjust the beam vertically (Y) using an Allen screw, as shown in the illustration
2. Adjust the beam horizontally (X) using an Allen screw, as shown in the illustration
3. HINT: Use a Ø6 mm Allen screw.
