Calibration Function
During calibration, the software of the Sun Roof Module (SRM) detects the sun roof's zero position. The zero position serves as a reference point for the Sun Roof Module (SRM) when the sun roof is operated. This reference point helps the Sun Roof Module (SRM) determine where the main positions of the glass panel should be.
Once calibration is complete, pinch protection is activated. The Sun Roof Module (SRM) then detects if the closing speed of the glass panel decreases, that is to say if something is in the path of the glass panel. Pinch protection is then triggered.
During calibration, glass panel speed is also detected by two light sensors that measure how many revolutions and at what speed the gear wheels of the sun roof motor rotate. The light sensors (1) are located within the sun roof motor. The sun roof motor can handle a drop in voltage down to 9 Volts during calibration and still maintain precision.
Scheme 310
If the sun roof stops in the open position when it should be closed, you can pull on the sun roof while holding the switch depressed.
| CAUTION | If for some reason the sun roof is blocked and the switch is held in when the sun roof is tiled/open, the Sun Roof Module (SRM) will calibrate its zero position as the position at which the sun roof is blocked. This means that the main positions of the glass panel will be incorrectly programmed. |
This problem is remedied by recalibration of the sun roof. First hold the switch pressed in for 5 seconds when in the tiled/open position. Then open the sun roof to the end position and recalibrate.
If the sun roof should seize, there will not be a diagnostic trouble code in the control module.
| WARNING | If the Sun Roof Module (SRM) is not calibrated, the sun roof safety functions (specifically the pinch protection function) and the programmed main positions will not be operational. |
| CAUTION | In the event of mechanical blockage, which is normally prevented by the Sun Roof Module (SRM), the motor can produce a maximum torque of 6.8 Nm. This can damage drive wheels and cables. If the sun roof has been blocked, all sun roof components must be checked and, if necessary, replaced before recalibration. |
Calibration is carried out following the information in the appropriate diagnostics tool under Repairing/Cleaning, checking and adjusting.
Scheme 311
The main task to the sun roof is to allow light and ventilation in the passenger compartment. This, in turn, makes the vehicle feel even more luxurious. The glass panel provides extra light to the driver and passengers, while vehicle ventilation can be regulated by opening or closing the sun roof. The sun roof has four preprogrammed positions
- Closed
- Tilted
- Comfort
- Completely open.
Other positions can be set manually as desired.
The glass is tinted to protect the driver and passengers from strong sunlight. This tinting also protects against heat. The sunshade can also be used for these purposes.
Scheme 312
| WARNING | The battery must be disconnected before any work is carried out on the supplemental restraint system (SRS). Otherwise the airbags could accidentally deploy. |
The primary task of the supplemental restraint system module (SRS) is to minimize injuries to the driver and passengers in different types of accident. To do this, the control module validates incoming pulsed collision signals (acceleration signals generated by a collision) and then determines the required action. The control module uses internal sensors as well as external collision sensors. Using the data collected from the sensors, the system determines which of the following will be activated
- front airbags
- side impact protection (SIPS) bags
- inflatable curtains
- seat belt tensioners
The collision sensor in the control module registers the longitudinal mechanical stress that occurs in a frontal collision. A side impact may also be registered in the collision sensor. The longitudinal stresses are measured using two acceleration sensors. On vehicles with front impact sensors, these are used to register stresses in the event of a head-on collision. If the longitudinal stresses exceed a certain level, the stress will be calculated (the collision pulse). The calculation evaluates whether the collision pulse was sufficient to activate the airbags and/or the seat belt tensioners. Airbags and seat belt tensioners can be activated individually.
For certain models, depending on the market, the following are also used
- an occupant weight sensor (OWS) located under the seat cushion on the front passenger seat
- two seat position sensors located on the rail under the driver's seat and front passenger seat.
The driver and passenger airbags and the seat belt tensioners are designed to deploy in the event of a frontal collision as necessary.
No seat belt tensioners or airbags will be activated in the event of a collision from the rear.
Two requirements need to be fulfilled in order for the side impact protection system to be activated
- that the collision pulse is sufficiently high that a trigger signal is sent from the side impact sensor to the control module
- the control module or another collision sensor transmits a confirmation signal which allows the collision protection system to be deployed.
The side impact protection system is deployed when the control module has received both an activation and a confirmation signal.
If the side impact occurred at the front of the vehicle the side airbags and the inflatable curtains are deployed on the side that received the impact. If the side impact is towards the rear of the car, only the inflatable curtains are deployed on that side.
The control module has a collision recording function. This records certain system information in the event of a collision. If necessary, this information can be analyzed and used after a collision. This data is used in ongoing development of collision safety systems.
In the event of a frontal collision, side on collision or rear collision a collision signal is transmitted from the supplemental restraint system module (SRS) to the phone module (PHM) and the central electronic module (CEM) using a directly connected cable. The purpose of this signal is to
- switch off the fuel pump (FP)
- light the interior lighting
- unlock the doors
- if the vehicle is equipped with Volvo On Call (Plus), send an automatic alarm to CSC (Customer Service Center) when the accident has occurred.
A collision signal is also sent to the phone module (PHM) and the central electronic module (CEM) via the Controller area network (CAN).
The supplemental restraint system module (SRS) decides to deploy the airbags and/or the seat belt tensioners in the event of a frontal collision. This depends on information such as
- if the driver and front passenger are wearing seat belts or not
- if there is a fault in the seat belt buckles
- if there is a fault in the controller area network (CAN) communication.
As a result of the above conditions, in the event of a low impact collision the seat belt tensioner may deploy on the driver's side while the airbag is deployed on the passenger side.
The SRS indicator lamp lights when the ignition is switched on. If no faults are registered by the control module, either internally or from the sensors, wiring or igniters, a signal is transmitted on the controller area network (CAN) to the driver information module (DIM) confirming that the SRS indicator lamp can be switched off. If there is a fault, the supplemental restraint system module (SRS) transmits information to the driver information module (DIM) indicating which lamp should be lit and the text to be displayed in the combined instrument panel.
The driver information module (DIM) continuously transmits information to the supplemental restraint system (SRS) control module via the controller area network (CAN) about the status of the SRS indicator lamp.
If the SRS indicator lamp stops working, the general warning lamp is used instead.
Note that after a collision, it may be necessary to replace the cable harness for the components of the collision protection system which have deployed. This is because the connectors may melt at the moment of deployment. If a connector has melted, the cable harness adjacent to the connector must be replaced.
| WARNING | The battery must be disconnected before any work is carried out on the supplemental restraint system (SRS). Otherwise the airbags could accidentally deploy. |
Scheme 313
The side impact sensors in the vehicle are used to measure the collision pulses.
The four sensors which are used in the car are
- 1 side impact sensor in each left and right B post
- 1 side impact sensor in each left and right C post.
The side impact sensors have integrated logic. In the event of a collision, they determine whether the impact was large enough to warrant transmitting an activation signal to the control module to deploy the side impact airbag. Only the side impact protection on the side from which the activation signal was sent can be deployed.
The side impact sensors transmit continuous signals to the control module to indicate that they are working. In the event of a fault in the side impact sensor, a fault signal is transmitted to the control module which then stores a diagnostic trouble code (DTC). A diagnostic trouble code (DTC) is stored when the communication between the control module and one of the side impact sensors does not function. Each side impact sensor has a software ID. The ID is used to check that the correct side impact sensor is installed. This is because the activation level of the signal which is transmitted to the control module is not necessarily the same for the different side impact sensors.
The front (B-post) and rear (C-post) side impact sensors are a different color and have different coding on their connectors to simplify installation.
The front side impact sensors cannot be installed in the position for the rear side impact sensors and vice versa.
Data is transmitted on the same cable used for power supply.
Scheme 314
The frontal impact sensors are used to provide the supplemental restraint system module (SRS) with advance information about the collision pulse. This enables the control module to determine more accurately the components to be activated.
The frontal impact sensors have integrated logic which transmits acceleration data to the supplemental restraint system module (SRS).
The front impact sensors transmit continuous signals to the control module to indicate that they are working. In the event of a fault in a frontal impact sensor, a fault signal is transmitted to the control module which then stores a diagnostic trouble code (DTC). A diagnostic trouble code (DTC) is also stored if the communication between the control module and one of the frontal impact sensors does not function. Each frontal impact sensor has a software ID. The ID is used to check that the correct frontal impact sensor is installed.
Data is transmitted on the same cable used for power supply.
The two frontal impact sensors are inside the left and right-hand headlamps.
Scheme 315
The occupant weight sensor (OWS) consists of three interactive components
- The pressure sensor, installed under the front passenger seat
- The seatbelt force sensor, mounted in the seat frame on the outside of the front passenger seat
- Occupant weight sensor module, installed under the front passenger seat.
The pressure sensor and occupant weight sensor are linked via a hose. The pressure sensor registers the pressure the seat is exposed to, for example when someone is sitting in the car. Information from the seat belt force sensor is also used to ensure the good performance of the system. The seatbelt force sensor informs the occupant weight sensor module what force the belt is tensioned with. This is done because the pressure measured by the pressure sensor can be affected by the passenger fastening the seatbelt tightly. This means that the passenger exerts greater pressure on the seat than during normal seatbelt use. The passenger is then interpreted as being heavier than he or she is. The occupant weight sensor module uses the information from both the pressure sensor and seatbelt force sensor to calculate the actual weight of the passenger. The occupant weight sensor (OWS) transmits continuous signals to the supplemental restraint system module (SRS) and occupant weight sensor (OWS) on the LIN bus. If the occupant weight sensor (OWS) does not function correctly the supplemental restraint system module (SRS) will
- deactivate the front passenger airbag
- light the warning lamp for passenger airbag disconnected (PAD) in the upper electronic module (UEM)
- light the SRS (supplemental restraint system) indicator lamp and display the alert message in the driver information module (DIM).
If a fault occurs in any of the components the following should be noted
- The pressure sensor and occupant weight sensor module must be replaced at the same time
- The seatbelt force sensor is replaced separately.
Note. The on/off switch for the front passenger airbag and occupant weight sensor (OWS) must not be installed in the vehicle together.
Scheme 316
This switch is used to activate or deactivate the front passenger airbag. The switch is on the side of the dashboard on the passenger side. The switch can only be accessed with the front passenger door open. The ignition key is used to change the position of the switch. When the switch is in the OFF position, all the stages of the passenger airbag are deactivated and the passenger airbag disconnected (PAD) warning lamp lights. When the switch is moved between OFF and ON, the two Hall sensors detect the position of the switch. The Hall sensors for the switch are directly connected to the supplemental restraint system module (SRS). Each Hall sensor is individually connected to the control module. The signal which is transmitted from the Hall sensors has two different current levels, depending on the position of the switch.
A diagnostic trouble code (DTC) is stored if the signal from the Hall sensors cannot be correctly interpreted. The control module may, depending on the fault, deactivate the passenger airbag. The PAD (passenger airbag disconnected) warning lamp lights if the passenger airbag is deactivated. If a fault is detected and the passenger airbag is not deactivated, the SRS warning lamp lights and a text message is displayed in the driver information module (DIM).
Note. The on/off switch for the front passenger airbag and occupant weight sensor (OWS) must not be installed in the vehicle together.
Calibration Of Occupant Weight Sensor (OWS) (Certain Markets And Models Only)
The occupant weight sensor (OWS) can be calibrated using this function.
Calibration
To check that Four-C is working correctly, adaptive data must be calibrated in the suspension module (SUM) after repair or if the control module has been repaired. Calibration is carried out according to the appropriate diagnostics vehicle communication tool.
Calibrating The Gear Position Indicator
When checking or replacing the control module the gear position indicator must be calibrated so that the gear position indicator adopts the correct gear position.
