Automatic Transaxle (U151E) (Diagnostics - Introduction): Diagnosis Toyota RAV4 IV

HOW TO PROCEED WITH TROUBLESHOOTING

HINT

1. The ECM of this system is connected to the CAN and multiplex communication system. Therefore, before starting troubleshooting, make sure to check that there is no trouble in the CAN and multiplex communication systems.
2. *: Use Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS Refer to How to Troubleshoot ECU Controlled Systems in the Introduction section.Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-493289-S22966865862012081000000) . NEXT: Go to next step
3. INSPECT BATTERY VOLTAGE Standard voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding. NEXT: Go to next step
4. CONNECT TECHSTREAM TO THE DLC3* NEXT: Go to next step
5. CHECK AND CLEAR DTCS AND FREEZE FRAME DATA* Refer to the DTC CHECK / CLEAR.Refer to «DTC CHECK / CLEAR»(ref-493476-S04213857672012081000000) . NEXT: Go to next step
6. VISUAL INSPECTION NEXT: Go to next step
7. SETTING CHECK MODE DIAGNOSIS* Refer to the CHECK MODE PROCEDURE.Refer to «CHECK MODE PROCEDURE»(ref-493476-S42496677502012081000000) . NEXT: Go to next step
8. PROBLEM SYMPTOM CONFIRMATION Refer to the ROAD TEST.Refer to «ROAD TEST»(ref-493476-S04666969572012081000000) . Result Result Proceed to Symptom does not occur A Symptom occurs B B --> GO TO STEP 10 A: Go to next step
9. SYMPTOM SIMULATION Refer to the ELECTRONIC CIRCUIT INSPECTION PROCEDURE.Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-493289-S18206983812012081000000) . NEXT: Go to next step
10. DTC CHECK* Refer to the DTC CHECK / CLEAR.Refer to «DTC CHECK / CLEAR»(ref-493476-S04213857672012081000000) . Result Result Proceed to DTC is not output A DTC is output B B --> GO TO STEP 18 A: Go to next step
11. BASIC INSPECTION Refer to the PARK/NEUTRAL POSITION SWITCH.Refer to «INSPECTION»(ref-493418-S23199416552012081000000) . Refer to the FLOOR SHIFT ASSEMBLY.Refer to «REMOVAL»(ref-493418-S20428028832012081000000) . NG --> GO TO STEP 21 OK: Go to next step
12. MECHANICAL SYSTEM TESTS Refer to the MECHANICAL SYSTEM TESTS.Refer to «MECHANICAL SYSTEM TESTS»(ref-493476-S16359675942012081000000) . NG --> GO TO STEP 17 OK: Go to next step
13. HYDRAULIC TEST Refer to the HYDRAULIC TEST.Refer to «HYDRAULIC TEST»(ref-493476-S36581288242012081000000) . NG --> GO TO STEP 17 OK: Go to next step
14. MANUAL SHIFTING TEST Refer to the MANUAL SHIFTING TEST.Refer to «MANUAL SHIFTING TEST»(ref-493476-S32460014292012081000000) . NG --> GO TO STEP 16 OK: Go to next step
15. PROBLEM SYMPTOMS TABLE CHAPTER 1 Refer to the PROBLEM SYMPTOMS TABLE.Refer to «PROBLEM SYMPTOMS TABLE»(ref-493476-S16219880842012081000000) . NG --> GO TO STEP 19 OK: Go to next step
16. PROBLEM SYMPTOMS TABLE CHAPTER 2 Refer to the PROBLEM SYMPTOMS TABLE.Refer to «PROBLEM SYMPTOMS TABLE»(ref-493476-S16219880842012081000000) . NEXT: Go to next step
17. PART INSPECTION NG --> GO TO STEP 21 OK: Go to next step
18. DTC CHART Refer to the DIAGNOSTIC TROUBLE CODE CHART.Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493476-S33470625122012081000000) . NEXT: Go to next step
19. CIRCUIT INSPECTION NEXT: Go to next step
20. IDENTIFICATION OF PROBLEM NEXT: Go to next step
21. REPAIR OR REPLACE NEXT: Go to next step
22. CONFIRMATION TEST NEXT --> END

ROAD TEST

1. PROBLEM SYMPTOM CONFIRMATION Based on the result of the customer problem analysis, try to reproduce the symptoms. If the problem is that the transmission does not shift up or down, or that the shift point is too high or too low, conduct the following road test referring to the automatic shift schedule and attempt to duplicate the problem symptoms.
2. ROAD TEST Perform a road test. WARNING: Check for safety before performing any tests. NOTE: Be sure to inspect and adjust the engine before performing these tests. Perform the road test with the engine coolant temperature between 60 and 100°C (140 and 212°F) and the ATF temperature between 50 and 100°C (122 and 212°F). Perform these tests with the air conditioning and cruise control off. Inspection Procedure Transmission Control Switch Test With the vehicle stationary and the shift lever in D (2), move the shift lever to 4 (L) and return it to D (2). Check that the meter display changes from D (2) to the appropriate 4 (L) and then back again. D Position Shift Test While driving the vehicle normally, check that the transmission shifts up and down through each gear properly. Lock-up Function While driving on a level surface at a constant speed in the lock-up range (75 km/h (47 mph) or more) with the shift lever in D, lightly depress the accelerator pedal and check that the engine speed does not change abruptly. P Position Test Stop the vehicle on an incline (approximately 5° or more). Then move the shift lever to P and release the parking brake. Check that the parking lock pawl holds the vehicle in place. Abnormal Noise and Vibration Check for abnormal noise and vibration while driving the vehicle forward and backward, and during shift operations. Fluid Leakage After performing all other road test inspections, check for fluid leakage.

PROBLEM SYMPTOMS TABLE

1. Use the table below to help determine the cause of the problem symptom. The potential causes of the symptoms are listed in order of probability in the "Suspected area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
2. The Matrix Chart is divided into 2 chapters. When troubleshooting, check Chapter 1 first. If instructions are given in Chapter 1 to proceed to 2, proceed as instructed.
3. If the instruction "Proceed to next circuit inspection shown in problem symptoms table" is given in the flowchart for each circuit, proceed to the next suspected area in the table.
4. If the problem still occurs even though there are no malfunctions in any of the circuits, check the ECM and replace it if necessary.
5. *: When the circuit is defective, a DTC may be output.

1. CHAPTER 1: ELECTRONIC CIRCUIT MATRIX CHART

2. CHAPTER 2: ON-VEHICLE REPAIR AND OFF-VEHICLE REPAIR

Scheme 1882

Scheme 1883

Scheme 1884

Scheme 1885

1. CHECK ECM Measure the voltage of the ECM connector. HINT: Each ECM terminal's standard voltage is shown in the table below. In the table, first follow the information under "Condition". Look under "Symbols (Terminal No.)" for the terminals to be inspected. The standard voltage between the terminals is shown under "Specified Condition". Use the illustration above as a reference for the ECM terminals. Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition P (B30-2) - E1 (B30-81) R - BR P shift position switch signal Ignition switch ON and shift lever on P 11 to 14 V P (B30-2) - E1 (B30-81) R - BR P shift position switch signal Ignition switch ON and shift lever not on P Below 1 V R (B30-26) - E1 (B30-81) B - BR R shift position switch signal Ignition switch ON and shift lever on R 11 to 14 V R (B30-26) - E1 (B30-81) B - BR R shift position switch signal Ignition switch ON and shift lever not on R Below 1 V N (B30-25) - E1 (B30-81) L-B - BR N shift position switch signal Ignition switch ON and shift lever on N 11 to 14 V N (B30-25) - E1 (B30-81) L-B - BR N shift position switch signal Ignition switch ON and shift lever not on N Below 1 V D (B30-27) - E1 (B30-81) L - BR D shift position switch signal Ignition switch ON and shift lever on D or 3 11 to 14 V D (B30-27) - E1 (B30-81) L - BR D shift position switch signal Ignition switch ON and shift lever not on D or 3 Below 1 V 4 (A9-25) - E1 (B30-81) P - BR 4 shift position switch signal Ignition switch ON and shift lever on 4 11 to 14 V 4 (A9-25) - E1 (B30-81) P - BR 4 shift position switch signal Ignition switch ON and shift lever not on 4 Below 1 V 3 (B30-48) - E1 (B30-81) LG - BR 3 shift position switch signal Ignition switch ON and shift lever on 3 11 to 14 V 3 (B30-48) - E1 (B30-81) LG - BR 3 shift position switch signal Ignition switch ON and shift lever not on 3 Below 1 V 2 (B30-47) - E1 (B30-81) V - BR 2 shift position switch signal Ignition switch ON and shift lever on 2 and L 11 to 14 V 2 (B30-47) - E1 (B30-81) V - BR 2 shift position switch signal Ignition switch ON and shift lever not on 2 and L Below 1 V L (A9-26) - E1 (B30-81) V - BR L shift position switch signal Ignition switch ON and shift lever on L 11 to 14 V L (A9-26) - E1 (B30-81) V - BR L shift position switch signal Ignition switch ON and shift lever not on L Below 1 V STP (A9-36) - E1 (B30-81) L - BR Stop light switch signal Brake pedal is depressed Between 11 V and 14 V STP (A9-36) - E1 (B30-81) L - BR Stop light switch signal Brake pedal is released Below 1 V SL1+ (B30-10) - SL1- (B30-11) P - LG SL1 solenoid signal Engine is idling Pulse generation SL2+ (B30-12) - SL2- (B30-13) BR - R SL2 solenoid signal Engine is idling Pulse generation SL3+ (B30-14) - SL3- (B30-15) GR - G-R SL3 solenoid signal Engine is idling Pulse generation DSL (B30-3) - E01 (B30-43) V - BR DSL solenoid signal Vehicle speed 65 km/h (40 mph), lock-up (ON to OFF) Below 1 V DSL (B30-3) - E01 (B30-43) V - BR DSL solenoid signal Vehicle driving under lock-up position Pulse generation (see waveform 1) SLT+ (B30-9) - SLT- (B30-8) L - W SLT solenoid signal Engine is idling Pulse generation SR (B30-6) - E01 (B30-43) G - BR SR solenoid signal Ignition switch ON Below 1 V SR (B30-6) - E01 (B30-43) G - BR SR solenoid signal 3rd, 4th or 5th gear 11 to 14 V SR (B30-6) - E01 (B30-43) G - BR SR solenoid signal 1st or 2nd gear Below 1 V S4 (B30-4) - E01 (B30-43) L-B - BR S4 solenoid signal Ignition switch ON Below 1 V S4 (B30-4) - E01 (B30-43) L-B - BR S4 solenoid signal 5th gear 11 to 14 V S4 (B30-4) - E01 (B30-43) L-B - BR S4 solenoid signal Not on 5th gear Below 1 V THO1 (B30-122) - ETHA (B30-98) Y - G-R ATF temperature sensor signal ATF temperature 115°C (239°F) or higher Below 1.5 V NT+ (B30-101) - NT- (B30-100) B - G Speed sensor (NT) signal Vehicle speed 20 km/h (12 mph) Pulse generation (see waveform 2) NC+ (B30-124) - NC- (B30-123) W - Y Speed sensor (NC) signal Vehicle speed 30 km/h (19 mph) (3rd gear) Engine speed 1, 400 rpm Pulse generation (see waveform 3) Using an oscilloscope, check waveform 1. Waveform 1 (Reference) Item Content Symbols (Terminal No.) DSL (B30-3) - E01 (B30-43) Tool Setting 10 V/DIV., 100 msec./DIV. Condition Vehicle speed 65 km/h (40 mph), lock-up (ON to OFF) Using an oscilloscope, check waveform 2. Waveform 2 (Reference) Item Content Symbols (Terminal No.) NT+ (B30-101) - NT- (B30-100) Tool Setting 5 V/DIV., 0.5 msec./DIV. Condition Vehicle speed 20 km/h (12 mph) Using an oscilloscope, check waveform 3. Waveform 3 (Reference) Item Content Symbols (Terminal No.) NC+ (B30-124) - NC- (B30-123) Tool Setting 1 V/DIV., 1 msec./DIV. Condition Vehicle speed 30 km/h (19 mph) (3rd gear) Engine speed 1, 400 rpm

Scheme 1886

Scheme 1887

Scheme 1888

1. DESCRIPTION When troubleshooting On-Board Diagnostic (OBD II) vehicles, the vehicle must be connected to the OBD II scan tool (complying with SAE J1987). Various data output from the vehicle's ECM can then be read. OBD II regulations require that the vehicle's on-board computer illuminates the Malfunction Indicator Lamp (MIL) on the instrument panel when the computer detects a malfunction in: The emission control system/components The powertrain control components (which affect vehicle emissions) The computer In addition, the applicable Diagnostic Trouble Codes (DTCs) prescribed by SAE J2012 are recorded in the ECM memory. When the malfunction does not reoccur, the MIL stays illuminated until the ignition switch is turned off, and the MIL turns OFF when the engine is started. However, the DTCs remain recorded in the ECM memory. To check DTCs, connect Techstream to the Data Link Connector 3 (DLC3) of the vehicle. The Techstream displays DTCs, the freeze frame data and a variety of the engine data. The DTCs and freeze frame data can be erased with the Techstream.Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493476-S33470625122012081000000) .
2. NORMAL MODE AND CHECK MODE The diagnosis system operates in "normal mode" during normal vehicle use. In normal mode, "2 trip detection logic" is used to ensure accurate detection of malfunctions. "Check mode" is also available to technicians as an option. In check mode, "1 trip detection logic" is used for simulating malfunction symptoms and increasing the system's ability to detect malfunctions, including intermittent malfunctions.
3. 2 TRIP DETECTION LOGIC When a malfunction is first detected, the malfunction is temporarily stored in the ECM memory (1st trip). If the same malfunction is detected during the next drive cycle, the MIL is illuminated (2nd trip).
4. FREEZE FRAME DATA Freeze frame data records the engine conditions (fuel system, calculated load, engine coolant temperature, fuel trim, engine speed, vehicle speed, etc.) when a malfunction is detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred. Techstream records freeze frame data in 5 different instances: 1) 3 times before the DTC is set, 2) once when the DTC is set, and 3) once after the DTC is set. These data can be used to simulate the vehicle's condition around the time when the malfunction occurred. The data may help find the cause of the malfunction, or judge if the DTC is being caused by a temporary malfunction or not.
5. DATA LINK CONNECTOR 3 (DLC3) The vehicle's ECM uses the ISO 15765-4 for communication protocol. The terminal arrangement of the DLC3 complies with SAE J1962 and matches the ISO 15765-4 format. TERMINAL OF DLC3 Symbols (Terminal No.) Terminal Description Condition Specified Condition SIL (7) - SG (5) Bus "+" line During transmission Pulse generation CG (4) - Body ground Chassis ground Always Below 1 ohms SG (5) - Body ground Signal ground Always Below 1 ohms BAT (16) - Body ground Battery positive Always 11 to 14 V CANH (6) - CANL (14) CAN bus line Ignition switch off* 54 to 69 ohms CANH (6) - Battery positive HIGH-level CAN bus line Ignition switch off* 6 kohms or higher CANH (6) - CG (4) HIGH-level CAN bus line Ignition switch off* 200 ohms or higher CANL (14) - Battery positive LOW-level CAN bus line Ignition switch off* 6 kohms or higher CANL (14) - CG (4) LOW-level CAN bus line Ignition switch off* 200 ohms or higher NOTE: *: Before measuring the resistance, leave the vehicle as is for at least 1 minute and do not operate the ignition switch, any other switches or the doors. If the result is not as specified, the DLC3 may have a malfunction. Repair or replace the harness and connector. HINT: Connect the cable of Techstream to the DLC3, turn the ignition switch to ON and attempt to use the Techstream. If the screen displays UNABLE TO CONNECT TO VEHICLE, a problem exists in the vehicle side or the Techstream side. If communication is normal when the Techstream is connected to another vehicle, inspect the DLC3 on the original vehicle. If communication is still not possible when the Techstream is connected to another vehicle, the problem is probably in the Techstream itself. Consult the Service Department listed in the Techstream's instruction manual.
6. CHECK MIL Check that the MIL illuminates when turning the ignition switch to ON. If the MIL does not illuminate, there is a problem in the MIL circuit.Refer to «MIL Circuit»(ref-493463-S41260471082012081000000) . When the engine is started, the MIL should turn off.
7. ALL READINESS For this vehicle, using Techstream allows readiness codes corresponding to all DTCs to be read. When the diagnosis (normal or malfunctioning) has been completed, readiness codes are set. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.

DTC CHECK / CLEAR

Note. When the diagnosis system is changed from normal mode to check mode or vice versa, all DTCs and freeze frame data recorded in normal mode are cleared. Before changing modes, always check and make a note of DTCs and freeze frame data.

HINT

1. DTCs which are stored in the ECM can be displayed on the Techstream. The Techstream can display the current, pending and permanent DTCs.
2. If a malfunction is detected during the current driving cycle, current and permanent DTCs are stored.
3. Some DTCs are not stored if the ECM does not detect the same malfunction again during a second consecutive driving cycle. However, such malfunctions, detected on only one occasion, are stored as pending DTCs.
4. Current and pending DTCs can be cleared by using the Techstream or by disconnecting the cable from the negative battery terminal. However, permanent DTCs cannot be cleared using either of these two methods.
5. After clearing current DTCs using the Techstream (or by disconnecting the cable from the negative battery terminal), permanent DTCs can be cleared when the system is determined to be normal for the relevant DTCs and then the universal trip is performed.

2-TRIP DETECTION EXAMPLES

Scheme 1889

Scheme 1890

Scheme 1891

1. CHECK DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check the DTC(s) and freeze frame data, and then write them down. Check the details of the DTC(s).Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493476-S33470625122012081000000) .
2. CLEAR DTC (Pending and Current DTC) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Clear the DTCs.
3. CLEAR DTC (Pending and Current DTC without using Techstream) Perform either of the following operations: Disconnect the cable from the negative (-) battery terminal for more than 1 minute. Remove the EFI MAIN and ETCS fuses from the engine room relay block No. 1 located inside the engine compartment for more than 1 minute.
4. CLEAR PERMANENT DTC HINT: Even if the following procedure is not performed, permanent DTCs are cleared if no malfunction is detected during 3 consecutive driving cycles. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check if permanent DTCs are stored. HINT: If permanent DTCs are not output, it is not necessary to continue this procedure. Clear DTCs. Perform the universal trip. Idle the engine for 30 seconds or more. Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more. HINT: It is possible to complete the drive pattern even if the vehicle decelerates to less than 40 km/h (25 mph) during the driving cycle provided that the vehicle is driven at 40 km/h (25 mph) or more for a total of 5 minutes. When accelerating through the gears, make sure the vehicle is driven so all gears are used in order and no gears are skipped. Allow 10 minutes or more to elapse from the time the engine is started. Turn the ignition switch off. Wait 15 seconds. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check that the permanent DTCs have been cleared. HINT: If the permanent DTCs have not been cleared, perform the universal trip again. The permanent DTCs are cleared when the universal trip is completed.

Scheme 1892

1. DESCRIPTION Check mode has a higher sensitivity to malfunctions and can detect malfunctions that normal mode cannot detect. Check mode can also detect all the malfunctions that normal mode can detect. In check mode, DTCs are detected with 1 trip detection logic.
2. CHECK MODE PROCEDURE Make sure that the following conditions below are met: Battery positive voltage 11 V or more Throttle valve fully closed Transaxle in the P or N position A/C off Turn the ignition switch off. Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / Check Mode. Change the ECM to check mode. Make sure the MIL flashes as shown in the illustration. NOTE: All DTCs and freeze frame data will be erased if: 1) Techstream is used to change the ECM from normal mode to check mode or vice versa; or 2) during check mode, the ignition switch is turned from ON to ACC or off. Before check mode, make notes of the DTCs and freeze frame data. Start the engine. The MIL should turn off after the engine starts. Perform "MONITOR DRIVE PATTERN" for the ECT test.Refer to «MONITOR DRIVE PATTERN»(ref-493476-S07469109742012081000000) . (Or, simulate the conditions of the malfunction described by the customer.) After simulating the malfunction conditions, use the Techstream to check the DTC and freeze frame data.

DATA LIST / ACTIVE TEST

1. READ DATA LIST HINT: Using Techstream's Data List allows switch, sensor, actuator, and other item values to be read without removing any parts. Reading the Data List early in troubleshooting is one way to save time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List. Follow the instructions on the Techstream and read the Data List. ECM: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Neutral Position SW Signal PNP switch status/ ON or OFF Shift lever is: On P or N: ON Not on P or N: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705.Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-493507-S13314103412012081000000) Stop Light Switch Stop light switch status/ ON or OFF Brake pedal is depressed: ON Brake pedal is released: OFF - SPD (NT) Input turbine speed/ Min.: 0 rpm Max.: 12, 750 rpm Lock-up ON (after warming up engine): Input turbine speed (NT) is equal to engine speed. Lock-up OFF (idling with shift lever on N): Input turbine speed (NT) is nearly equal to engine speed. Data is displayed in increments of 50 rpm SPD (NC) Counter gear speed/ Min.: 0 rpm Max.: 12, 750 rpm 3rd gear with shift lever on D (after warming up the engine): Intermediate shaft speed (NC) becomes close to the engine speed Data is displayed in increments of 50 rpm Shift SW Status (P Range) PNP switch status/ ON or OFF Shift lever is: On P: ON Not on P: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705.Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-493507-S13314103412012081000000) Shift SW Status (R Range) PNP switch status/ ON or OFF Shift lever is: On R: ON Not on R: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705.Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-493507-S13314103412012081000000) Shift SW Status (2 Range) PNP switch status/ ON or OFF Shift lever is: On 2 or L: ON Not on 2 or L: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705.Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-493507-S13314103412012081000000) Shift SW Status (L Range) PNP switch status/ ON or OFF Shift lever is: On L: ON Not on L: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705.Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-493507-S13314103412012081000000) Shift SW Status (N Range) PNP switch status/ ON or OFF Shift lever is: On N: ON Not on N: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705.Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-493507-S13314103412012081000000) Shift SW Status (D Range) PNP switch status/ ON or OFF Shift lever is: On 4 or D: ON Not on 4 or D: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705.Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-493507-S13314103412012081000000) Shift SW Status (4 Range) PNP switch status/ ON or OFF Shift lever is: On 4: ON Not on 4: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705.Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-493507-S13314103412012081000000) Shift SW Status (3 Range) PNP switch status/ ON or OFF Shift lever is: On 3: ON Not on 3: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705.Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-493507-S13314103412012081000000) A/T Oil Temperature 1 ATF temperature sensor value/ Min.: -40°C (-40°F) Max.: 215°C (419°F) After stall test: Approximately 80°C (176°F) Equal to ambient temperature while engine is cold If value is -40°C (-40°F) or 150°C (302°F) or more, ATF temperature sensor circuit is open or short circuited Lock Up Lock-up status/ ON or OFF Lock-up: ON Not in lock-up: OFF - Shift Status ECM gearshift command/ 1st, 2nd, 3rd, 4th or 5th Shift lever position is: On L: 1st On 2: 1st or 2nd On 3: 1st, 2nd or 3rd On 4: 1st, 2nd, 3rd or 4th On D: 1st, 2nd, 3rd, 4th or 5th - SLT Solenoid Status Shift solenoid SLT status/ ON or OFF Accelerator pedal is depressed: OFF Accelerator pedal is released: ON - DSL Solenoid Status Shift solenoid DSL status/ ON or OFF Shift solenoid DSL is: Operating: ON Not operating: OFF - AT Fluid Flex lock-up judder judgment/ ON or OFF Judder judgment occurs: ON Judder judgment does not occur: OFF
2. PERFORM ACTIVE TEST HINT: Performing Techstream's Active Test allows relays, VSVs, actuators and other items to be operated without removing any parts. Performing the Active Test early in troubleshooting is one way to save time. The Data List can be displayed during the Active Test. Warm up the engine. Turn the ignition switch off. Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. Perform the Active Test. ECM: Tester Display Test Part Control Range Diagnostic Note Activate the Solenoid (SLT)* [Test Details] Operate shift solenoid SLT and raise line pressure [Vehicle Condition] Vehicle stopped IDL: ON HINT: OFF: Line pressure up (when Active Test "Activate the Solenoid (SLT)" is performed, ECM commands SLT solenoid to turn OFF) ON: No action (normal operation) ON / OFF - Activate the Solenoid (S4) [Test Details] Operate shift solenoid S4 [Vehicle Condition] Vehicle stopped Shift lever P or N position ON / OFF - Activate the Lock Up [Test Details] Control shift solenoid DSL to set automatic transaxle to lock-up [Vehicle Condition] Throttle valve opening amount: Less than 35% Vehicle speed: 60 km/h (36 mph) or more ON / OFF Possible to check shift solenoid valve DSL operation Control the Shift Position [Test Details] Operate shift solenoid valve and set each shift lever position [Vehicle Condition] IDL: ON Vehicle speed: 50 km/h (31 mph) or less [Other information] Press "-->" button: Shift up Press "<--" button: Shift down 1st / 2nd / 3rd / 4th / 5th Possible to check operation of shift solenoid valves Activate the Solenoid (SR) [Test Details] Operate shift solenoid SR [Vehicle Condition] Vehicle stopped Shift lever P or N position ON / OFF - Activate the Solenoid (DSL) [Test Details] Operate shift solenoid DSL [Vehicle Condition] Vehicle stopped Shift lever P or N position ON / OFF - Activate the Solenoid (SL1) [Test Details] Operate shift solenoid SL1 [Vehicle Condition] Vehicle stopped Shift lever P or N position ON / OFF - Activate the Solenoid (SL2) [Test Details] Operate shift solenoid SL2 [Vehicle Condition] Vehicle stopped Shift lever P or N position ON / OFF - Activate the Solenoid (SL3) [Test Details] Operate shift solenoid SL3 [Vehicle Condition] Vehicle stopped Shift lever P or N position ON / OFF - HINT: *: "Activate the Solenoid (SLT)" in the Active Test is performed to check the line pressure changes by connecting SST to the automatic transaxle, which is used in the HYDRAULIC TEST.Refer to «HYDRAULIC TEST»(ref-493476-S36581288242012081000000) as well. Please note that the pressure values in the Active Test and HYDRAULIC TEST are different.

DIAGNOSTIC TROUBLE CODE CHART

HINT

1. If a DTC is displayed during the DTC check, check the circuit listed in the table below and proceed to the "See" given.
2. *1: "Comes on" means the Malfunction Indicator Lamp (MIL) illuminates.
3. *2: "DTC stored" means the ECM memorizes the malfunction code if the ECM detects the DTC detection condition.
4. These DTCs may be output when the clutch, brake, gear components, etc, inside the automatic transaxle are damaged.

AUTOMATIC TRANSAXLE SYSTEM
