Engine Control System (Diagnostic Codes (P1604-U0101) & Circuit Tests)) (2AR-FE): Other Toyota Camry XV50

MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

TYPICAL MALFUNCTION THRESHOLDS

CONFIRMATION DRIVING PATTERN

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the Techstream off.
5. Turn the ignition switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) battery terminal.
9. Connect the Techstream to the DLC3.
10. Turn the ignition switch to ON and turn the Techstream on.
11. Wait 16 seconds or more.
12. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
13. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
15. Input the DTC: P1607.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

PROCEDURE

1. READ OUTPUT DTC (DTC P1607) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P1607 is output B B --> See step 3 A --> See step 2
2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-507772-S06236680232012100900000) .
3. REPLACE ECM. Refer to «REMOVAL»(ref-507932-S06201290982012100900000) .

P2004

P2006

Scheme 148

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on [A].
7. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. HINT: Check for DTC P2004 at a engine coolant temperature of 30°C (86°F) or less. Check for DTC P2006 at a engine coolant temperature of 80°C (176°F) or higher.
8. Turn the ignition switch off.
9. Turn the ignition switch to ON, wait approximately 10 seconds, and then turn the ignition switch off. Repeat this procedure 3 times [B].
10. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
11. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
13. Input the DTC: P2004 or P2006.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
15. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 149

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2004 OR P2006) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P2004 or P2006 is output A DTC P2004 or P2006 and other DTCs are output B HINT: If any DTCs other than P2004 or P2006 are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
2. INSPECT INTAKE AIR CONTROL VALVE ACTUATOR (FOR TUMBLE CONTROL VALVE) Inspect the intake air control valve actuator (for tumble control valve). Refer to «INSPECTION - Step 1»(ref-507935-S29696171552012100900000) . NG --> See step 7 OK: Go to next step
3. INSPECT INTAKE MANIFOLD (TUMBLE CONTROL VALVE OPERATION) Inspect the intake manifold for the tumble control valve operation. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-507934-S31467281272012100900000) . NG --> See step 10 OK: Go to next step
4. CHECK HARNESS AND CONNECTOR (INTAKE AIR CONTROL VALVE ACTUATOR - ECM) Disconnect the ECM connector. Disconnect the intake air control valve actuator connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Y4-4 (M-) - E26-21 (IA1-) Always Below 1 ohms Y4-5 (M+) - E26-22 (IA1+) Always Below 1 ohms Y4-4 (M-) or E26-21 (IA1-) - Body ground Always 10 kohms or higher Y4-5 (M+) or E26-22 (IA1+) - body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
5. CHECK WHETHER DTC OUTPUT RECURS (DTC P2004 OR P2006) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P2004 or P2006 is output A DTC is not output B B --> See step 8 A --> See step 9
6. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-507772-S10021867342012100900000) .
7. REPLACE INTAKE AIR CONTROL VALVE ACTUATOR (FOR TUMBLE CONTROL VALVE). Refer to «REMOVAL»(ref-507935-S20777780342012100900000) .
8. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-507772-S06236680232012100900000) .
9. REPLACE ECM. Refer to «REMOVAL»(ref-507932-S06201290982012100900000) .
10. REPLACE INTAKE MANIFOLD. Refer to «REMOVAL»(ref-507935-S15256544302012100900000) .

ALL

P2009

P2010

P2009

P2010

COMPONENT OPERATING RANGE

P2009

P2010

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp.
8. Check that the engine coolant temperature is 60°C (140°F) or higher.
9. Wait approximately 10 seconds.
10. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
11. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
13. Input the DTC: P2009 or P2010.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
15. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. INSPECT INTAKE AIR CONTROL VALVE ACTUATOR (FOR TUMBLE CONTROL VALVE) Inspect the intake air control valve actuator (for tumble control valve). Refer to «INSPECTION»(ref-507935-S28273704102012100900000) . NG --> See step 5 OK: Go to next step
2. INSPECT INTAKE MANIFOLD (TUMBLE CONTROL VALVE OPERATION) Inspect the intake manifold for the tumble control valve operation. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-507934-S31467281272012100900000) . NG --> See step 8 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (INTAKE AIR CONTROL VALVE ACTUATOR - ECM). See step 4 . NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. CHECK WHETHER DTC OUTPUT RECURS (DTC P2009 OR P2010) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Wait approximately 10 seconds. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P2009 or P2010 is output A DTC is not output B B --> See step 6 A --> See step 7
5. REPLACE INTAKE AIR CONTROL VALVE ACTUATOR (FOR TUMBLE CONTROL VALVE). Refer to «REMOVAL»(ref-507935-S20777780342012100900000) .
6. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-507772-S06236680232012100900000) .
7. REPLACE ECM. Refer to «REMOVAL»(ref-507932-S06201290982012100900000) .
8. REPLACE INTAKE MANIFOLD. Refer to «REMOVAL»(ref-507935-S15256544302012100900000) .

P2014

P2016

P2017

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 0.5 seconds or more.
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P2014, P2016 or P2017.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

ALL

P2102

P2103

P2102

P2103: (CASE 1)

P2103: (CASE 2)

Scheme 150

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. With the vehicle stationary, fully depress the accelerator pedal and quickly release it [B].
8. Check that 16 seconds or more have elapsed from the instant when the accelerator pedal is first depressed.
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P2102 or P2103.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

FAIL-SAFE

When either of these DTCs or other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue running at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.

Scheme 151

1. INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY (RESISTANCE OF THROTTLE ACTUATOR) Inspect the throttle with motor body assembly. Refer to «INSPECTION»(ref-507932-S06057287362012100900000) . HINT: Perform "Inspection After Repair" after replacing the throttle with motor body assembly. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> See step 5 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (THROTTLE WITH MOTOR BODY ASSEMBLY - ECM) Disconnect the throttle with motor body assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E16-2 (M+) - E26-60 (M+) Always Below 1 ohms E16-1 (M-) - E26-30 (M-) Always Below 1 ohms E16-2 (M+) or E26-60 (M+) - Body ground Always 10 kohms or higher E16-1 (M-) or E26-30 (M-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for foreign objects between the throttle valve and the housing. OK No foreign objects between the throttle valve and housing. HINT: Perform "Inspection After Repair" after cleaning the throttle with motor body assembly. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> REMOVE FOREIGN OBJECT AND CLEAN THROTTLE WITH MOTOR BODY ASSEMBLY OK: Go to next step
4. INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY (THROTTLE VALVE) Check if the throttle valve opens and closes smoothly. OK Throttle valve opens and closes smoothly. HINT: Perform "Inspection After Repair" after replacing the throttle with motor body assembly. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> See step 6 OK --> See step 7
5. REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY. Refer to «REMOVAL»(ref-507932-S05487718332012100900000) .
6. REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY. Refer to «REMOVAL»(ref-507932-S05487718332012100900000) .
7. REPLACE ECM. Refer to «REMOVAL»(ref-507932-S06201290982012100900000) .

ALL

P2111: THROTTLE ACTUATOR STUCK OPEN

P2112: THROTTLE ACTUATOR STUCK CLOSED

P2111: THROTTLE ACTUATOR STUCK OPEN

P2112: THROTTLE ACTUATOR STUCK CLOSED

Scheme 152

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and fully depress and release the accelerator pedal quickly (to fully open and close the throttle valve).
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P2111 or P2112.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

When either of these DTCs or other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue running at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2111 OR P2112) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P2111 or P2112 is output A DTC P2111 or P2112 and other DTCs are output B HINT: If any DTCs other than P2111 or P2112 are output, troubleshoot those DTCs first. B --> See step 8 A: Go to next step
2. INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and housing. If necessary, clean the throttle with motor body assembly. Also check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. HINT: Perform "Inspection After Repair" after cleaning the throttle with motor body assembly. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> See step 5 OK: Go to next step
3. READ VALUE USING TECHSTREAM (THROTTLE POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Throttle / Throttle Position No. 1, Throttle Position No. 2 and Throttle Position Command. Read the values displayed on the Techstream while wiggling the ECM wire harness. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to Value in Data List changes when wire harness is wiggled, or DTC is output A Other than above B B --> See step 6 A: Go to next step
4. REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - THROTTLE WITH MOTOR BODY ASSEMBLY) As the DTC was stored due to a change in the contact resistance of the connector, repair or replace the wire harness or connector. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-507751-S08160859722012100900000) . NEXT --> END
5. REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Replace the throttle with motor body assembly. Refer to «REMOVAL»(ref-507932-S05487718332012100900000) . HINT: Perform "Inspection After Repair" after replacing the throttle with motor body assembly. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NEXT: Go to next step
6. CHECK WHETHER DTC OUTPUT RECURS (DTC P2111 OR P2112) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P2111 or P2112 is output B B --> See step 7 A --> END
7. REPLACE ECM. Refer to «REMOVAL»(ref-507932-S06201290982012100900000) .
8. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-507772-S10021867342012100900000) .

Scheme 153

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. Slowly depress the accelerator pedal, raise the engine speed to approximately 3000 rpm over approximately 5 seconds, and then idle the engine [B].
8. Check that 16 seconds or more have elapsed since the engine was started.
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P2118.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

When this DTC or other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.

1. READ VALUE USING TECHSTREAM (+BM VOLTAGE) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Throttle / +BM Voltage. Read the value displayed on the Techstream. RESULT Result Proceed to Less than 4 V A 11 to 14 V B B --> See step 3 A: Go to next step
2. CHECK HARNESS AND CONNECTOR (ECM - BATTERY, BODY GROUND) Disconnect the ECM connectors. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition E26-29 (+BM) - Body ground Always 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E26-58 (ME01) - Body ground Always Below 1 ohms E26-16 (E1) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
3. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-507772-S06236680232012100900000) .
4. REPLACE ECM. Refer to «REMOVAL»(ref-507932-S06201290982012100900000) .

Scheme 154

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. Idle the engine for 20 seconds.
8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
11. Input the DTC: P2119.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, fully depress and release the accelerator pedal 3 times, and then check the DTC judgment result [C].
13. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

When this DTC or other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue running at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2119) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P2119 is output A DTC P2119 and other DTCs are output B HINT: If any DTCs other than P2119 are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
2. READ VALUE USING TECHSTREAM (THROTTLE POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Throttle / Throttle Position No. 1 and Throttle Position Command. Read the values displayed on the Techstream while fully depressing and releasing the accelerator pedal quickly. RESULT Result Proceed to Throttle Position No. 1 does not change A Throttle Position No. 1 changes even a little B HINT: When a DTC is output, the system changes to fail-safe mode. Therefore, only use the data up until the time the DTC is stored for confirmation. B --> See step 4 A: Go to next step
3. INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY (RESISTANCE OF THROTTLE ACTUATOR) Inspect the throttle with motor body assembly. Refer to «INSPECTION»(ref-507932-S06057287362012100900000) . NG --> See step 7 OK: Go to next step
4. INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and housing. If necessary, clean the throttle with motor body assembly. Also, check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. HINT: Perform "Inspection After Repair" after cleaning the throttle with motor body assembly. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> See step 7 OK: Go to next step
5. READ VALUE USING TECHSTREAM (THROTTLE POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Throttle / Throttle Position No. 1, Throttle Position No. 2 and Throttle Position Command. Read the values displayed on the Techstream while wiggling the ECM wire harness. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to Value in Data List changes when wire harness is wiggled, or DTC is output A Other than above B B --> See step 8 A: Go to next step
6. REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - THROTTLE WITH MOTOR BODY ASSEMBLY) As the DTC was stored due to a change in the contact resistance of the connector, repair or replace the wire harness or connector. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-507751-S08160859722012100900000) . NEXT --> END
7. REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Replace the throttle with motor body assembly. Refer to «REMOVAL»(ref-507932-S05487718332012100900000) . HINT: Perform "Inspection After Repair" after replacing the throttle with motor body assembly. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NEXT: Go to next step
8. CHECK WHETHER DTC OUTPUT RECURS (DTC P2119) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P2119 is output B B --> See step 9 A --> END
9. REPLACE ECM. Refer to «REMOVAL»(ref-507932-S06201290982012100900000) .
10. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-507772-S10021867342012100900000) .

P2120

P2122

P2123

P2125

P2127

P2128

P2138

Scheme 155

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Fully depress and release the accelerator pedal [B].
7. Check that 5 seconds or more have elapsed since the ignition switch is turned ON.
8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
11. Input the DTC: P2120, P2122, P2123, P2125, P2127, P2128 or P2138.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
13. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

When DTC P2120, P2121, P2122, P2123, P2125, P2127, P2128 or P2138 is stored, the ECM enters fail-safe mode. If either of the 2 sensor circuits malfunctions, the ECM uses the remaining circuit to calculate the accelerator pedal position to allow the vehicle to continue driving. If both of the circuits malfunction, the ECM regards the accelerator pedal as being released. As a result, the throttle valve is closed and the engine idles.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is turned off.

Scheme 156

ALL (CASE 1 AND CASE 2)

CASE 2

CASE 1

CASE 2

Scheme 157

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Wait for 5 seconds after turning the ignition switch to ON.
7. Operate the accelerator pedal in accordance with the following procedure [B]. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Throttle / Accel Sens. No. 1 Volt %, and Accel Sens. No. 2 Volt %. Slowly depress the accelerator pedal until Accel Sens. No. 1 Volt % is approximately 30% and Accel Sens. No. 2 Volt % is approximately 46%, then slowly release the accelerator pedal.
8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
11. Input the DTC: P2121.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
13. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

The accelerator pedal position sensor has 2 (main and sub) sensor circuits. If a malfunction occurs in either of the sensor circuits, the ECM detects the abnormal signal voltage difference between the 2 sensor circuits and switches to fail-safe mode. In fail-safe mode, the functioning circuit is used to calculate the accelerator pedal opening angle to allow the vehicle to continue driving. If both circuits malfunction, the ECM regards the opening angle of the accelerator pedal as being fully closed. In this case, the throttle valve remains closed as if the engine is idling.

If a pass condition is detected and then the ignition switch is turned off, the fail-safe operation stops and the system returns to normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2121) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P2121 is output A DTC P2121 and other DTCs are output B HINT: If any DTCs other than P2121 are output, troubleshoot those DTCs first. B --> See step 7 A: Go to next step
2. READ VALUE USING TECHSTREAM (ACCELERATOR PEDAL POSITION SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Accel Sensor Out No. 1 and Accel Sensor Out No. 2. Read the values displayed on the Techstream. Standard Voltage Accelerator Pedal Operation Accel Sensor Out No. 1 Accel Sensor Out No. 2 Fully Released 0.5 to 1.1 V 1.2 to 2.0 V Fully Depressed 2.6 to 4.5 V 3.4 to 4.98 V TEXT IN ILLUSTRATION *a Fully Depressed *b Fully Released NG --> See step 3 OK --> See step 6
3. REPLACE ACCELERATOR PEDAL SENSOR ASSEMBLY Replace the accelerator pedal sensor assembly. Refer to «REMOVAL»(ref-507932-S07695192822012100900000) . NEXT: Go to next step
4. CHECK WHETHER DTC OUTPUT RECURS (DTC P2121) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P2121 is output A DTC is not output B B --> END A --> See step 5
5. REPLACE ECM. Refer to «REMOVAL»(ref-507932-S06201290982012100900000) .
6. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-507772-S06236680232012100900000) .
7. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-507772-S10021867342012100900000) .

ALL

P2195 AND P2196: SENSOR VOLTAGE DETECTION MONITOR

P2195 AND P2196: SENSOR CURRENT DETECTION MONITOR

P2195: SENSOR VOLTAGE DETECTION MONITOR (LEAN SIDE MALFUNCTION)

P2196: SENSOR VOLTAGE DETECTION MONITOR (RICH SIDE MALFUNCTION)

P2195: SENSOR CURRENT DETECTION MONITOR (HIGH SIDE MALFUNCTION)

P2196: SENSOR CURRENT DETECTION MONITOR (LOW SIDE MALFUNCTION)

MONITOR RESULT

Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

P2195, P2196: O2 SENSOR / RANGE B1S1

Scheme 158

Scheme 159

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [A].
8. On the Techstream, enter the following menus to check the fuel-cut status: Powertrain / Engine and ECT / Data List / Primary / Idle Fuel Cut.
9. Drive the vehicle at a speed between 60 and 120 km/h (37 and 75 mph) for at least 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
10. With the shift lever in S position [C], accelerate the vehicle to 64 km/h (40 mph) or more by depressing the accelerator pedal for at least 10 seconds [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
11. Soon after performing step [D] above, release the accelerator pedal for at least 4 seconds without depressing the brake pedal in order to execute fuel-cut control [E]. HINT: Fuel-cut is performed when the following conditions are met: Accelerator pedal is fully released. Engine speed is 1400 rpm or higher (fuel injection restart rpm).
12. Allow the vehicle to decelerate until the vehicle speed decreases to less than 10 km/h (6 mph).
13. Repeat steps [C] through [E] above at least 3 times in one driving cycle.
14. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [F].
15. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
16. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
17. Input the DTC: P2195 or P2196.
18. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [F] again.
19. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2195 OR P2196) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P2195 or P2196 is output A DTC P2195 or P2196 and P0136, P0137 or P0138 are output DTC P2195 or P2196 and other DTCs are output B HINT: If any DTCs relating to the air fuel ratio sensor (DTCs for the air fuel ratio sensor heater or air fuel ratio sensor admittance) are output, troubleshoot those DTCs first. B --> See step 17 A: Go to next step
2. CONFIRM IF VEHICLE HAS RUN OUT OF FUEL IN PAST Has the vehicle run out of fuel in the past? NO --> See step 4 YES: Go to next step
3. CHECK WHETHER DTC OUTPUT RECURS (DTC P2195 OR P2196) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2195 or P2196. Check the DTC judgment. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P2195 or P2196 is output) B B --> See step 4 A --> DTC CAUSED BY RUNNING OUT OF FUEL
4. READ VALUE USING TECHSTREAM (TEST VALUE OF AIR FUEL RATIO SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / O2 Sensor / Current. Check that the status of O2 Sensor is Complete. If the status is still Incomplete, drive the vehicle according to the driving pattern again. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / O2 Sensor / Details / RANGE B1S1. Check the test value of the air fuel ratio sensor output current during fuel-cut. RESULT Result Proceed to Within normal range (0.7 mA or higher, and lower than 2.2 mA) A Outside normal range (lower than 0.7 mA, or 2.2 mA or higher) B B --> See step 14 A: Go to next step
5. READ VALUE USING TECHSTREAM (OUTPUT VOLTAGE OF AIR FUEL RATIO SENSOR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the air fuel ratio sensor at an engine speed of 2500 rpm for 90 seconds. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume / Gas AF Control / AFS Voltage B1S1 and O2S B1S2. Perform the Control the Injection Volume operation with the engine idling. Monitor the output voltages of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream. HINT: Change the fuel injection volume within the range of -12% to +12%. The injection volume can be changed in fine gradations. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 (Air fuel ratio) +12% Rich Below 3.1 V AFS Voltage B1S1 (Air fuel ratio) -12% Lean Higher than 3.4 V O2S B1S2 (Heated oxygen) +12% Rich Higher than 0.55 V O2S B1S2 (Heated oxygen) -12% Lean Below 0.4 V RESULT Status of AFS Voltage B1S1 Status of O2S B1S2 Air Fuel Ratio Condition and Air Fuel Ratio Sensor Condition Proceed to Lean Lean Actual air fuel ratio lean A Rich Rich Actual air fuel ratio rich A Lean Lean/Rich Air fuel ratio sensor malfunction B Rich Lean/Rich Air fuel ratio sensor malfunction B Lean/Rich Lean/Rich Normal B Lean: During the Control the Injection Volume Active Test, the air fuel ratio sensor output voltage (AFS Voltage B1S1) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S B1S2) is consistently below 0.4 V. Rich: During the Control the Injection Volume Active Test, the AFS Voltage B1S1 is consistently below 3.1 V, and the O2S B1S2 is consistently higher than 0.55 V. Lean/Rich: During the Control the Injection Volume Active Test, the output voltage of the heated oxygen sensor alternates correctly. HINT: Refer to "Data List / Active Test" [AFS Voltage B1S1 and O2S B1S2]. Refer to «DATA LIST / ACTIVE TEST»(ref-507772-S13031543512012100900000) . B --> See step 14 A: Go to next step
6. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-507934-S31467281272012100900000) . OK No leaks in the intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
7. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. HINT: Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
8. CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-507927-S32506839072012100900000) . NG --> See step 16 OK: Go to next step
9. INSPECT FUEL INJECTOR ASSEMBLY Inspect the fuel injector assembly injection (whether fuel volume is high or low, and whether injection pattern is poor). Refer to «INSPECTION»(ref-507933-S20934952172012100900000) . HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> See step 18 OK: Go to next step
10. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-507932-S09346630982012100900000) . HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NEXT: Go to next step
11. CHECK WHETHER DTC OUTPUT RECURS (DTC P2195 OR P2196) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2195 or P2196. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P2195 or P2196 is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
12. REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-507932-S06201290982012100900000) . NEXT: Go to next step
13. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2195 or P2196. Check the DTC judgment result. RESULT Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit NEXT --> END
14. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-507932-S09346630982012100900000) . HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NEXT: Go to next step
15. CHECK WHETHER DTC OUTPUT RECURS (DTC P2195 OR P2196) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2195 or P2196. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P2195 or P2196 is output) B B --> See step 19 A --> END
16. CHECK FUEL LINE Check the fuel lines for leaks or blockage. HINT: Perform "Inspection After Repair" after replacing the fuel pump. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> REPAIR OR REPLACE FUEL LINE OK --> See step 20
17. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-507772-S10021867342012100900000) .
18. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(ref-507933-S17998760102012100900000) .
19. REPLACE ECM. Refer to «REMOVAL»(ref-507932-S06201290982012100900000) .
20. REPLACE FUEL PUMP. Refer to «REMOVAL»(ref-507933-S03560904862012100900000) .

AIR FUEL RATIO SENSOR MONITORING METHOD

CRANKSHAFT POSITION SENSOR MONITORING METHOD

AIR FUEL RATIO SENSOR MONITORING METHOD

CRANKSHAFT POSITION SENSOR MONITORING METHOD

Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

P219A: FUEL SYSTEM / A/F SENSOR DETERMINATION B1

P219A: FUEL SYSTEM / ENGINE SPEED FLUCTUATION AVERAGE B1

Scheme 160

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [A]. HINT: The A/C switch and all accessory switches should be off and the shift lever should be in P or N.
5. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
6. Drive the vehicle at 60 km/h (37 mph) or higher for 2 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: It is acceptable to turn electrical loads on while driving.
7. Idle the engine for 2 minutes or more [C]. HINT: The A/C switch and all accessory switches should be off and the shift lever should be in P or N.
8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Drive the vehicle at less than 30 km/h (19 mph) for 5 seconds or more [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
11. Accelerate the vehicle from 30 to 60 km/h (19 to 37 mph) over a period of approximately 10 to 20 seconds. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Refer to the values of mass air flow and engine speed in Typical Enabling Conditions before accelerating the vehicle from 30 to 60 km/h (19 to 37 mph).
12. Drive the vehicle at 60 km/h (37 mph) or more for 5 seconds or more [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
13. Drive the vehicle at less than 30 km/h (19 mph) for 5 seconds or more [G]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
14. Accelerate the vehicle from 30 to 60 km/h (19 to 37 mph) over a period of approximately 10 to 20 seconds. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Refer to the values of mass air flow and engine speed in Typical Enabling Conditions before accelerating the vehicle from 30 to 60 km/h (19 to 37 mph).
15. Drive the vehicle at 60 km/h (37 mph) or more for 5 seconds or more [H]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
16. Repeat steps [G] and [H] above at least 2 times [I].
17. Idle the engine for 1 minute or more [J]. HINT: The A/C switch and all accessory switches should be off and the shift lever should be in P or N.
18. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [K].
19. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
20. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
21. Input the DTC: P219A.
22. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure.
23. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P219A) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P219A is output A DTC P219A and other DTCs are output B HINT: If any DTCs other than P219A are output, troubleshoot those DTCs first. B --> See step 14 A: Go to next step
2. READ VALUE USING TECHSTREAM (FREEZE FRAME DATA) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA»(ref-507772-S19657288732012100900000) . Freeze Frame Data Items for DTC P219A Vehicle Speed Engine Speed Calculate Load Accelerator Idle Position Short FT #1 Long FT #1 Cylinder #1 Misfire Count to Cylinder #4 Misfire Count A/F Sensor Determination (worst value) #1 Engine Speed Fluctuation Avg (worst value) #1 to #4 HINT: When the sum of Short FT #1 and Long FT #1 is positive, the engine is running lean, and when the sum is negative, the engine is running rich. DTC stored during idling It is possible to conclude that the problem was detected due to a "lean imbalance" (detected using crankshaft speed variation). DTC stored while vehicle being driven It is possible to conclude that the problem was detected due to a "rich imbalance" (detected using the air fuel ratio sensor). NEXT: Go to next step
3. READ VALUE USING TECHSTREAM (MONITOR RESULT) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. HINT: If any misfire count ("Cylinder #1 Misfire Count" to "Cylinder #4 Misfire Count) increases while idling or driving the vehicle, proceed to step 6 . Perform inspections while focusing on the cylinder whose misfire count has increased. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / Fuel System / Details / A/F SENSOR DETERMINATION B1 and ENGINE SPEED FLUCTUATION AVERAGE B1. Check the Test Result (A/F SENSOR DETERMINATION B1 and ENGINE SPEED FLUCTUATION AVERAGE B1). RESULT Result Proceed to A/F SENSOR DETERMINATION is Fail A A/F SENSOR DETERMINATION and ENGINE SPEED FLUCTUATION AVERAGE are Fail B ENGINE SPEED FLUCTUATION AVERAGE is Fail B* HINT: When the results of A/F SENSOR DETERMINATION and ENGINE SPEED FLUCTUATION AVERAGE are both Pass, drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern again. If both results are still Pass, proceed to step 4 . *: Perform inspections while focusing on the cylinder whose engine speed fluctuation value ("Engine Speed Fluctuation Avg (worst value) #1" to "Engine Speed Fluctuation Avg (worst value) #4") was the largest. B --> See step 6 A: Go to next step
4. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. HINT: The A/C switch and all accessory switches should be off and the shift lever should be in P or N. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume / Gas Misfire / Cylinder #1 to #4 Misfire Count. HINT: When the "Control the Injection Volume" Active Test is selected (injection volume is 0%), if a misfire count increases, proceed to step 6 (Check Intake System). Perform the Control the Injection Volume operation with the engine idling. Check the misfire counts ("Cylinder #1 Misfire Count" to "Cylinder #4 Misfire Count") while decreasing the injection volume in 5% increments. NOTE: Do not decrease the injection volume by higher than 20%. Result The cylinder whose misfire count has not increased can be assumed to be running rich. Therefore, perform inspections while focusing on that cylinder. NEXT: Go to next step
5. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. HINT: Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
6. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-507934-S31467281272012100900000) . OK No leakage in intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
7. INSPECT SPARK PLUG Inspect the spark plug of the cylinder causing the imbalance. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-507916-S32322150512012100900000) . HINT: Perform "Inspection After Repair" after replacing the spark plug. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> See step 15 OK: Go to next step
8. CHECK FOR SPARK (SPARK TEST) Perform a spark test. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-507916-S32322150512012100900000) . HINT: If the result of the spark test is normal, proceed to the next step. Perform "Inspection After Repair" after repairing or replacing the ignition system. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NEXT: Go to next step
9. CHECK CYLINDER COMPRESSION PRESSURE Measure the cylinder compression pressure of the misfiring cylinder. Refer to «ON-VEHICLE INSPECTION - Step 9»(ref-507910-S40397789942012100900000) . HINT: Perform "Inspection After Repair" after repairing or replacing the engine assembly. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> CHECK ENGINE TO DETERMINE CAUSE OF LOW COMPRESSION OK: Go to next step
10. CHECK TERMINAL VOLTAGE (POWER SOURCE OF FUEL INJECTOR ASSEMBLY). Refer to «PROCEDURE - Step 10»(ref-507928-S06384946012012100900000) . NG --> See step 16 OK: Go to next step
11. CHECK FUEL INJECTOR ASSEMBLY OF CYLINDER CAUSING IMBALANCE Check the fuel injector injection [whether fuel volume is high or low, and whether injection pattern is poor]. Refer to «INSPECTION»(ref-507933-S20934952172012100900000) . HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> See step 17 OK: Go to next step
12. CHECK FOR CAUSE OF FAILURE If the cause of the problem has not been found even after performing the troubleshooting procedure, perform the inspection below. Check the intake valve for deposits. HINT: As the DTC may have been stored due to deposits on the intake valve, remove the cylinder head and check the intake valve. NEXT: Go to next step
13. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check for DTCs. Result P219A is not output. NEXT --> END
14. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-507772-S10021867342012100900000) .
15. REPLACE SPARK PLUG. Refer to «REMOVAL»(ref-507932-S10435136292012100900000) .
16. CHECK FUEL INJECTOR CIRCUIT. Refer to «Fuel Injector Circuit»(ref-507926-S23864662642012100900000) .
17. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(ref-507933-S17998760102012100900000) .

P2237 AND P2238

P2239, P2252 AND P2253

P2237: AIR FUEL RATIO SENSOR OPEN CIRCUIT BETWEEN A1A+ AND A1A

P2238: AIR FUEL RATIO SENSOR LOW IMPEDANCE

P2238: AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND GND

P2238: AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND A1A

P2239: AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND +B

P2252: AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A- AND GND

P2253: AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A- AND +B

P2237: (AIR FUEL RATIO SENSOR OPEN CIRCUIT BETWEEN A1A+ AND A1A-)

P2238: (AIR FUEL RATIO SENSOR LOW ADMITTANCE)

P2238: (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND GND)

P2238: (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND A1A-)

P2239: (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND +B)

P2252: (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A- AND GND)

P2253: (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A- AND +B)

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Start the engine and wait 5 minutes.
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P2237, P2238, P2239, P2252 or P2253.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 5 minutes and check the DTC judgment result again.
12. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E19-1 (HA1A) - E26-23 (HA1A) Always Below 1 ohms E19-3 (A1A+) - E26-133 (A1A+) Always Below 1 ohms E19-4 (A1A-) - E26-134 (A1A-) Always Below 1 ohms E19-1 (HA1A) or E26-23 (HA1A) - Body ground Always 10 kohms or higher E19-3 (A1A+) or E26-133 (A1A+) - Body ground Always 10 kohms or higher E19-4 (A1A-) or E26-134 (A1A-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-507932-S09346630982012100900000) . HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NEXT: Go to next step
3. CHECK WHETHER DTC OUTPUT RECURS (DTC P2237, P2238, P2239, P2252 OR P2253) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2237, P2238, P2239, P2252 or P2253. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P2237, P2238, P2239, P2252 or P2253 is output) B B --> See step 4 A --> END
4. REPLACE ECM. Refer to «REMOVAL»(ref-507932-S06201290982012100900000) .

Refer to EVAP system. Refer to MONITOR RESULT .

Note. The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is higher than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
7. After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
8. Input the DTC: P2420.
9. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
10. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

ALL

CASE 1

CASE 2

CASE 3

CASE 1

CASE 2

CASE 3

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Start the engine.
7. Idle the engine for 10 minutes or more.
8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
11. Input the DTC: P2610.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
13. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-507932-S06201290982012100900000) . NEXT: Go to next step
2. CHECK WHETHER DTC OUTPUT RECURS (DTC P2610) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and wait for 10 minutes or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. If no pending DTC is output, the repair has been successfully completed. NEXT --> END

Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

P2A00: O2 SENSOR / RES RATE B1S1

HINT

Performing this confirmation pattern will activate the air fuel ratio sensor response monitor.

Scheme 161

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor.
8. Check that O2 Sensor / Current is Incomplete.
9. Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher [A].
10. Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more in a city area [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
11. Check the monitor result values on the Techstream by entering the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / O2 Sensor / Details / RES RATE B1S1.
12. If the values indicated on the Techstream do not change, perform Readiness Monitor Drive Pattern for the air fuel ratio sensor and heated oxygen sensor. Refer to «READINESS MONITOR DRIVE PATTERN»(ref-507772-S04575335352012100900000) .
13. Note the value of Test Results.
14. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
15. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
16. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
17. Input the DTC: P2A00.
18. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure.
19. Drive the vehicle at a speed between 75 and 100 km/h (47 and 62 mph) for 10 minutes [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
20. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
21. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
22. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
23. Input the DTC: P2A00.
24. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result is INCOMPLETE or N/A, drive the vehicle again under an increased load and then recheck the judgment result.
25. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2A00) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P2A00 is output A DTC P2A00 and other DTCs are output B HINT: If any DTCs other than P2A00 are output, troubleshoot those DTCs first. B --> See step 13 A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine and run the engine at an engine speed of 2500 rpm for approximately 90 seconds. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume / Gas AF Control / AFS Voltage B1S1 and O2S B1S2. Perform the Control the Injection Volume operation with the engine idling. Monitor the output voltages of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream. HINT: Change the fuel injection volume within the range of -12% to +12%. The injection volume can be changed in fine gradations. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 (Air fuel ratio) +12% Rich Below 3.1 V AFS Voltage B1S1 (Air fuel ratio) -12% Lean Higher than 3.4 V O2S B1S2 (Heated oxygen) +12% Rich Higher than 0.55 V O2S B1S2 (Heated oxygen) -12% Lean Below 0.4 V RESULT Status of AFS Voltage B1S1 Status of O2S B1S2 Air Fuel Ratio Condition and Air Fuel Ratio Sensor Condition Proceed to Lean/Rich Lean/Rich Normal A Lean Lean Actual air fuel ratio lean B Rich Rich Actual air fuel ratio rich B Lean Lean/Rich Air fuel ratio sensor malfunction C Rich Lean/Rich Air fuel ratio sensor malfunction C Lean: During the Control the Injection Volume Active Test, the air fuel ratio sensor output voltage (AFS Voltage B1S1) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S B1S2) is consistently below 0.4 V. Rich: During the Control the Injection Volume Active Test, the AFS Voltage B1S1 is consistently below 3.1 V, and the O2S B1S2 is consistently higher than 0.55 V. Lean/Rich: During the Control the Injection Volume Active Test, the output voltage of the heated oxygen sensor alternates correctly. HINT: Refer to "Data List / Active Test" [AFS Voltage B1S1 and O2S B1S2]. Refer to «DATA LIST / ACTIVE TEST»(ref-507772-S13031543512012100900000) . B --> See step 4 C --> See step 8 A: Go to next step
3. CHECK WHETHER DTC OUTPUT RECURS (DTC P2A00) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2A00. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P2A00 is output) B B --> See step 8 A --> See step 14
4. INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE). Refer to «PROCEDURE - Step 1»(ref-507928-S40588965732012100900000) . NG --> See step 15 OK: Go to next step
5. CHECK INTAKE SYSTEM Check the intake system. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-507934-S31467281272012100900000) . HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
6. CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-507927-S32506839072012100900000) . NG --> See step 12 OK: Go to next step
7. INSPECT FUEL INJECTOR ASSEMBLY Inspect the fuel injector assembly. Refer to «INSPECTION»(ref-507933-S20934952172012100900000) . HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> See step 16 OK: Go to next step
8. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-507932-S09346630982012100900000) . HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NEXT: Go to next step
9. CHECK WHETHER DTC OUTPUT RECURS (DTC P2A00) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2A00. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P2A00 is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
10. REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-507932-S06201290982012100900000) . NEXT: Go to next step
11. CHECK WHETHER DTC OUTPUT RECURS (DTC P2A00) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2A00. Check that the DTC judgment result is NORMAL. NEXT --> END
12. CHECK FUEL LINE Check the fuel lines for leaks or blockage. HINT: Perform "Inspection After Repair" after replacing the fuel pump. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> REPAIR OR REPLACE FUEL LINE OK --> See step 17
13. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-507772-S10021867342012100900000) .
14. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-507772-S06236680232012100900000) .
15. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-507932-S09346630982012100900000) .
16. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(ref-507933-S17998760102012100900000) .
17. REPLACE FUEL PUMP. Refer to «REMOVAL»(ref-507933-S03560904862012100900000) .

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 5 seconds or more.
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: U0101.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-507772-S40821088752012100900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC U0101) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC U0101 is output A DTC U0101 and other DTCs are output B HINT: If any DTCs other than U0101 are output, troubleshoot those DTCs first. B --> See step 2 A --> See step 3
2. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-507772-S10021867342012100900000) .
3. REPLACE ECM. Refer to «REMOVAL»(ref-507932-S06201290982012100900000) .

RELATED DTCS

If any EVAP system DTCs are output, the malfunctioning area can be determined using the table below.

Scheme 162

Note. If the reference pressure difference between the first and second checks is more than the specification, all the DTCs relating to the reference pressure (P043E, P043F, P0441, P0455, P0456, P2401, P2420) will all be stored.

Scheme 163

TEXT IN ILLUSTRATION

Scheme 164

TEXT IN ILLUSTRATION

HINT

The canister pressure sensor, the leak detection pump and the vent valve are built into the canister pump module.

Scheme 165

TEXT IN ILLUSTRATION

Note. In the EVAP system of this vehicle, turning on the vent valve does not seal off the EVAP system. To check for leaks in the EVAP system, disconnect the air inlet vent hose and apply pressure from the atmospheric side of the canister.

While the engine is running, if a predetermined condition (closed-loop, etc.) is met, the purge VSV is opened by the ECM and fuel vapors stored in the canister are purged to the intake manifold. The ECM changes the duty cycle ratio of the purge VSV to control purge flow volume.

The purge flow volume is also determined by the intake manifold pressure. Atmospheric pressure is allowed into the canister through the vent valve to ensure that the purge flow is maintained when negative pressure (vacuum) is applied to the canister.

The following two monitors run to confirm appropriate EVAP system operation.

Scheme 166

Scheme 167

Scheme 168

Scheme 169

1. Key-off monitor This monitor checks for EVAP (evaporative emission) system leaks and canister pump module malfunctions. The monitor starts 5 hours* after the ignition switch is turned off. At least 5 hours are required for the fuel to cool down to stabilize the EVAP pressure, thus making the EVAP system monitor more accurate. The leak detection pump creates negative pressure (vacuum) in the EVAP system and the pressure is measured. Finally, the ECM monitors for leaks from the EVAP system, and malfunctions in both the canister pump module and purge VSV based on the EVAP pressure. HINT: *: If the engine coolant temperature is not below 35°C (95°F) 5 hours after the ignition switch is turned off, the monitor check starts 2 hours later. If it is still not below 35°C (95°F) 7 hours after the ignition switch is turned off, the monitor check starts 2.5 hours later.
2. Purge flow monitor The purge flow monitor consists of the 2 monitors. The 1st monitor is conducted every time and the 2nd monitor is activated if necessary. The 1st monitor While the engine is running and the purge VSV (Vacuum Switching Valve) is on (open), the ECM monitors the purge flow by measuring the EVAP pressure change. If negative pressure is not created, the ECM begins the 2nd monitor. The 2nd monitor The vent valve is turned on (closed) and the EVAP pressure is then measured. If the variation in the pressure is less than 0.15 kPa(gauge) [1.125 mmHg(gauge)], the ECM interprets this as the purge VSV being stuck closed, illuminates the MIL and stores DTC P0441 (2 trip detection logic). Atmospheric pressure check: In order to ensure reliable malfunction detection, the variation between the atmospheric pressures, before and after of the purge flow monitor, is measured by the ECM. TEXT IN ILLUSTRATION *1 Canister *2 to Intake Manifold *3 ECM *4 Soak Timer *5 Purge VSV (On) *6 Fuel Cap *7 Canister Filter *8 Fuel Tank *9 Leak Detection Pump (Off) *10 Canister Pressure Sensor *11 Reference Orifice (0.02 inches) *12 Vent Valve (Off) *13 Canister Pump Module - - *a EVAP Purge Flow - - Component Operation Canister Contains activated charcoal to absorb EVAP (Evaporative Emissions) generated in fuel tank. Cut-off valve Located in fuel tank. Valve floats and closes when fuel tank is 100% full. Purge VSV (Vacuum Switching Valve) Opens or closes line between canister and intake manifold. ECM uses purge VSV to control EVAP purge flow. In order to discharge EVAP absorbed by canister to intake manifold, ECM opens purge VSV. EVAP discharge volume to intake manifold controlled by purge VSV duty cycle (current-carrying time). (Open: on, Close: off) Roll-over valve Located in fuel tank. Valve closes by its own weight when vehicle overturns to prevent fuel from spilling out. Soak timer Built into ECM. To ensure accurate EVAP monitor, measures 5 hours (+/-15 min) after ignition switch is turned off. This allows fuel to cool down, stabilizing EVAP pressure. When approximately 5 hours elapsed, ECM activates (Scheme 169) Canister pump module Consists of (a) to (d) below. Canister pump module cannot be disassembled. (a) Vent valve Vents and closes EVAP system. When ECM turns valve on, EVAP system is closed. When ECM turns valve off, EVAP system is vented. Negative pressure (vacuum) is created in EVAP system to check for EVAP leaks by closing purge VSV, turning on vent valve (closing it) and operating leak detection pump (Scheme 167) (b) Canister pressure sensor Indicates pressure as voltages. ECM supplies regulated 5 V to pressure sensor, and uses feedback from sensor to monitor EVAP system pressure (Scheme 168) (c) Leak detection pump Creates negative pressure (vacuum) in EVAP system for leak check. (d) Reference orifice Has opening with 0.02 inch diameter. Vacuum is produced through orifice by closing purge VSV, turning off vent valve and operating leak detection pump, to monitor reference pressure. Reference pressure is used when checking for small EVAP leaks. TEXT IN ILLUSTRATION *1 Canister *2 Reference Orifice (0.02 Inch) *3 Canister Pressure Sensor - - *a Canister Pump Module see scheme 1 *b Airflow *c Condition: Purge Flow *d Condition: Leak Check *e Vent Valve: Off (vent) *f to Canister Filter (Atmosphere) *g Leak Detection Pump: Off *h Vent Valve: On (closed) *i Leak Detection Pump: On

HINT

After a repair, check Monitor Status by performing the Key-Off Monitor Confirmation and Purge Flow Monitor Confirmation described below.

1. KEY-OFF MONITOR CONFIRMATION Preconditions The monitor will not run unless: The vehicle has been driven for 10 minutes or more (in a city area or on a freeway). The fuel tank is less than 90% full. The altitude is less than 2400 m (7875 ft.). The engine coolant temperature is between 4.4°C and 35°C (40°F and 95°F). The intake air temperature is between 4.4°C and 35°C (40°F and 95°F). The vehicle remains stationary (the vehicle speed is 0 km/h [0 mph]). Monitor Conditions Allow the engine to idle for at least 5 minutes. Turn the ignition switch off and wait for 6 hours (8 or 10.5 hours). HINT: Do not start the engine until checking Monitor Status. If the engine is started, the steps described above must be repeated. Monitor Status Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor. Check the Monitor Status displayed on the Techstream. HINT: If Incomplete is displayed, the monitor did not complete. Make sure that the preconditions have been met, and perform the Monitor Conditions again.
2. PURGE FLOW MONITOR CONFIRMATION (P0441) HINT: Perform this monitor confirmation after the Key-Off Monitor Confirmation shows Complete. Preconditions The monitor will not run unless: The vehicle has been driven for 10 minutes or more (in a city area or on a freeway). The engine coolant temperature is 4.4°C (40°F) or higher. The intake air temperature is 4.4°C (40°F) or higher. Monitor Conditions Release the pressure from the fuel tank by removing and reinstalling the fuel cap. Warm the engine up until the engine coolant temperature reaches higher than 75°C (167°F). Increase the engine speed to 3000 rpm once. Allow the engine to idle and turn the A/C switch on for 1 minute. Monitor Status Turn the ignition switch off (if ON or if the engine is running). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor. Check the Monitor Status displayed on the Techstream. HINT: If Incomplete is displayed, the monitor did not complete. Make sure that the preconditions have been met, and perform the Monitor Conditions again.

Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

P0456: EVAPORATIVE SYSTEM / SMALL LEAK

P0455: EVAPORATIVE SYSTEM / GROSS LEAK

P2401: EVAPORATIVE SYSTEM / VACUUM PMP OFF

P2402: EVAPORATIVE SYSTEM / VACUUM PMP ON

P2420: EVAPORATIVE SYSTEM / VENT VALVE OFF

P2419: EVAPORATIVE SYSTEM / VENT VALVE ON

P043E: EVAPORATIVE SYSTEM / ORIFICE CLOGGED

P043F: EVAPORATIVE SYSTEM / ORIFICE HI-FLW

P0441: EVAPORATIVE SYSTEM / PURGE VSV CLOSED

P0441: EVAPORATIVE SYSTEM / PURGE VSV OPENED

P0441: EVAPORATIVE SYSTEM / PURGE FLOW

1. CHECK HARNESS AND CONNECTOR (NO. 1 INTEGRATION RELAY VOLTAGE) Remove the No. 1 integration relay from the engine room relay block and junction block assembly. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition 1C-8 - Body ground Ignition switch ON 11 to 14 V RESULT Result Proceed to OK A NG (w/o smart key system) B NG (w/ smart key system) C B --> See step 7 C --> See step 9 A: Go to next step
2. CHECK HARNESS AND CONNECTOR (BATTERY - NO. 1 INTEGRATION RELAY) Remove the No. 1 integration relay from the engine room relay block and junction block assembly. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition 1D-3 - Body ground Always 11 to 14 V 1B-1 - Body ground Always 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. INSPECT NO. 1 INTEGRATION RELAY Inspect the No. 1 integration relay. Refer to «INSPECTION»(ref-507932-S17637183212012100900000) . NG --> See step 10 OK: Go to next step
4. CHECK HARNESS AND CONNECTOR (NO. 1 INTEGRATION RELAY - BODY GROUND) Remove the No. 1 integration relay from the engine room relay block and junction block assembly. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1E-2 - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (NO. 1 INTEGRATION RELAY - ECM) Remove the No. 1 integration relay from the engine room relay block and junction block assembly. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1C-1- A25-37 (IGSW) Always Below 1 ohms 1C-9 - A25-2 (+B) Always Below 1 ohms 1C-10 - A25-3 (+B2) Always Below 1 ohms 1C-7 - A25-46 (MREL) Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
6. CHECK HARNESS AND CONNECTOR (ECM - BODY GROUND) Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E26-16 (E1) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 12
7. CHECK HARNESS AND CONNECTOR (BATTERY - IGNITION SWITCH ASSEMBLY) Disconnect the ignition switch assembly connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition I36-5 (AM2) - Body ground Always 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
8. INSPECT IGNITION SWITCH ASSEMBLY Inspect the ignition switch assembly. Refer to «INSPECTION»(ref-507930-S02939650732012100900000) . NG --> See step 11 OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (NO. 1 INTEGRATION RELAY - IGNITION SWITCH ASSEMBLY)
9. CHECK HARNESS AND CONNECTOR (CERTIFICATION ECU - NO. 1 INTEGRATION RELAY) Remove the No. 1 integration relay from the engine room relay block and junction block assembly. Disconnect the certification ECU (smart key ECU assembly) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A43-9 (IG2D) - 1C-8 Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 13
10. REPLACE NO. 1 INTEGRATION RELAY. Refer to «REMOVAL»(ref-507932-S19819398262012100900000) .
11. REPLACE IGNITION SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-507930-S04229081492012100900000) .
12. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-507772-S25544096432012100900000) .
13. GO TO SMART KEY SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-507760-S20559569422012100900000) .

1. CHECK MIL Check that the Malfunction Indicator Lamp (MIL) lights up when the ignition switch is turned to ON. OK MIL lights up. NG --> See step 2 OK --> See step 17
2. CHECK COMMUNICATION BETWEEN TECHSTREAM AND ECM Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Check the communication between the Techstream and ECM. RESULT Result Proceed to Communication is not possible A Communication is possible B B --> See step 10 A: Go to next step
3. CHECK MIL (THROTTLE POSITION SENSOR) Disconnect the throttle with motor body assembly connector. Turn the ignition switch to ON. Check the MIL. RESULT Result Proceed to MIL does not illuminate A MIL illuminates B HINT: Perform "Inspection After Repair" after replacing the throttle with motor body assembly. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . B --> See step 11 A: Go to next step
4. CHECK MIL (ACCELERATOR PEDAL POSITION SENSOR) Disconnect the accelerator pedal sensor assembly connector. Turn the ignition switch to ON. Check the MIL. RESULT Result Proceed to MIL does not illuminate A MIL illuminates B B --> See step 12 A: Go to next step
5. CHECK MIL (CANISTER PUMP MODULE) Disconnect the canister pump module connector. Turn the ignition switch to ON. Check the MIL. RESULT Result Proceed to MIL does not illuminate A MIL illuminates B B --> See step 13 A: Go to next step
6. CHECK MIL (INTAKE AIR CONTROL VALVE ACTUATOR (FOR TUMBLE CONTROL VALVE)) Disconnect the intake air control valve actuator (for tumble control valve) connector. Turn the ignition switch to ON. Check the MIL. RESULT Result Proceed to MIL does not illuminate A MIL illuminates B B --> See step 14 A: Go to next step
7. CHECK MIL (CAMSHAFT POSITION SENSOR FOR INTAKE CAMSHAFT) Disconnect the camshaft position sensor (for intake camshaft) connector. Turn the ignition switch to ON. Check the MIL. RESULT Result Proceed to MIL does not illuminate A MIL illuminates B B --> See step 15 A: Go to next step
8. CHECK MIL (CAMSHAFT POSITION SENSOR FOR EXHAUST CAMSHAFT) Disconnect the camshaft position sensor (for exhaust camshaft) connector. Turn the ignition switch to ON. Check the MIL. RESULT Result Proceed to MIL does not illuminate A MIL illuminates B B --> See step 16 A: Go to next step
9. CHECK HARNESS AND CONNECTOR Disconnect the throttle with motor body assembly connector. Disconnect the accelerator pedal sensor assembly connector. Disconnect the canister pump module connector. Disconnect the intake air control valve actuator (for tumble control valve) connector. Disconnect the camshaft position sensor (for intake camshaft) connector. Disconnect the camshaft position sensor (for exhaust camshaft) connector. Disconnect the ECM connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E26-125 (VCTA) - Body ground Always 10 kohms or higher A25-53 (VCPA) - Body ground Always 10 kohms or higher A25-56 (VCP2) - Body ground Always 10 kohms or higher E26-130 (VCIA) - Body ground Always 10 kohms or higher E26-34 (VCPP) - Body ground Always 10 kohms or higher E26-111 (VCE1) - Body ground Always 10 kohms or higher E26-113 (VCV1) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 18
10. GO TO MIL CIRCUIT. Refer to «MIL Circuit»(ref-507926-S25705414762012100900000) .
11. REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY. Refer to «REMOVAL»(ref-507932-S05487718332012100900000) .
12. REPLACE ACCELERATOR PEDAL SENSOR ASSEMBLY. Refer to «REMOVAL»(ref-507932-S07695192822012100900000) .
13. REPLACE CANISTER PUMP MODULE. Refer to «REMOVAL»(ref-507920-S03610229802012100900000) .
14. REPLACE INTAKE AIR CONTROL VALVE ACTUATOR (FOR TUMBLE CONTROL VALVE). Refer to «REMOVAL»(ref-507935-S20777780342012100900000) .
15. REPLACE CAMSHAFT POSITION SENSOR (FOR INTAKE CAMSHAFT). Refer to «REMOVAL»(ref-507932-S27231254392012100900000) .
16. REPLACE CAMSHAFT POSITION SENSOR (FOR EXHAUST CAMSHAFT). Refer to «REMOVAL»(ref-507932-S27231254392012100900000) .
17. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-507772-S25544096432012100900000) .
18. REPLACE ECM. Refer to «REMOVAL»(ref-507932-S06201290982012100900000) .

1. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Fuel Pump / Speed. Check whether the fuel pump operating sound occurs when performing the Active Test on the Techstream. RESULT Result Proceed to Fuel pump operating sound does not occur A Fuel pump operating sound occurs B B --> See step 6 A: Go to next step
2. CHECK HARNESS AND CONNECTOR (NO. 1 INTEGRATION RELAY - ECM) Remove the No. 1 integration relay from the engine room relay block and junction block assembly. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1E-1 - A25-21 (FC) Always Below 1 ohms 1E-1 or A25-21 (FC) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (NO. 1 INTEGRATION RELAY - FUEL PUMP - BODY GROUND) Remove the No. 1 integration relay from the engine room relay block and junction block assembly. Disconnect the fuel pump connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1C-6 - N11-4 (B) Always Below 1 ohms N11-5 (E) - Body ground Always Below 1 ohms 1C-6 or N11-4 (B) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT FUEL PUMP Inspect the fuel pump. Refer to «INSPECTION»(ref-507933-S27318319572012100900000) . HINT: Perform "Inspection After Repair" after replacing the fuel pump. Refer to «INITIALIZATION»(ref-507772-S36366337852012100900000) . NG --> See step 8 OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (BATTERY - NO. 1 INTEGRATION RELAY) Remove the No. 1 integration relay from the engine room relay block and junction block assembly. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition 1D-1 - Body ground Always 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 9
6. READ VALUE USING TECHSTREAM (STARTER SIGNAL) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Starter Signal. Check the result when the ignition switch is ON and the engine starts. OK Ignition Switch Position Starter Signal ON Close (OFF) START Open (ON) NG --> See step 10 OK: Go to next step
7. READ VALUE USING TECHSTREAM (ENGINE SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Engine Speed. Read the values displayed on the Techstream while cranking. OK Values are displayed continuously. NG --> See step 12 OK --> See step 11
8. REPLACE FUEL PUMP. Refer to «REMOVAL»(ref-507933-S03560904862012100900000) .
9. REPLACE NO. 1 INTEGRATION RELAY. Refer to «REMOVAL»(ref-507932-S19819398262012100900000) .
10. CHECK STARTER SIGNAL CIRCUIT. Refer to «Starter Signal Circuit»(ref-507926-S09259899412012100900000) .
11. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-507772-S25544096432012100900000) .
12. CHECK CRANKSHAFT POSITION SENSOR CIRCUIT. Refer to «DTC P0335: Crankshaft Position Sensor "A" Circuit; DTC P0339: Crankshaft Position Sensor "A" Circuit Intermittent»(ref-507928-S25990689732012100900000) .

1. CHECK WHETHER ENGINE CAN BE CRANKED Check if the engine can be cranked. RESULT Result Proceed to Engine cannot be cranked A Engine can be cranked B B --> See step 12 A: Go to next step
2. READ VALUE USING TECHSTREAM (STARTER SIGNAL) Connect the Techstream to DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Starter Signal. Check the value displayed on the Techstream when the ignition switch is turned to the ON and START positions. OK Ignition Switch Position Starter Signal ON Close (OFF) START Open (ON) NG --> See step 13 OK: Go to next step
3. INSPECT RELAY (ST RELAY) Inspect the ST relay. Refer to «ON-VEHICLE INSPECTION»(ref-507930-S41032981932012100900000) . NG --> REPLACE RELAY (ST RELAY) OK: Go to next step
4. INSPECT STARTER ASSEMBLY Inspect the starter assembly. Refer to «INSPECTION»(ref-507930-S24133675462012100900000) . NG --> See step 19 OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (ST RELAY - STARTER ASSEMBLY) Remove the ST relay from the engine room relay block and junction block assembly. Disconnect the starter assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition ST relay terminal 3 - E9-1 (ST) Always Below 1 ohms ST relay terminal 3 or E9-1 (ST) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
6. CHECK HARNESS AND CONNECTOR (BATTERY - STARTER ASSEMBLY) Disconnect the cable from the negative (-) battery terminal. Disconnect the cable from the positive (+) battery terminal. Disconnect the starter assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Positive (+) battery terminal - F2-1 (B) Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
7. CHECK HARNESS AND CONNECTOR (ST RELAY - BODY GROUND) Remove the ST relay from the engine room relay block and junction block assembly. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition ST relay terminal 1 - Body ground Always Below 1 ohms RESULT Result Proceed to OK (w/o smart key system) A OK (w/ smart key system) B NG C B --> See step 11 C --> REPAIR OR REPLACE HARNESS OR CONNECTOR A: Go to next step
8. CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH ASSEMBLY - ST RELAY) Remove the ST relay from the engine room relay block and junction block assembly. Disconnect the park/neutral position switch assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E4-9 (L) - ST relay terminal 2 Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
9. INSPECT IGNITION SWITCH ASSEMBLY Inspect the ignition switch assembly. Refer to «INSPECTION»(ref-507930-S02939650732012100900000) . NG --> See step 20 OK: Go to next step
10. CHECK HARNESS AND CONNECTOR (IGNITION SWITCH ASSEMBLY - ST RELAY) Disconnect the ignition switch assembly connector. Remove the ST relay from the engine room relay block and junction block assembly. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition I36-7 (ST2) - ST relay terminal 5 Always Below 1 ohms I36-7 (ST2) or ST relay terminal 5 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (BATTERY - IGNITION SWITCH ASSEMBLY)
11. CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH ASSEMBLY - ST RELAY) Remove the ST relay from the engine room relay block and junction block assembly. Disconnect the park/neutral position switch assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E4-9 (L) - ST relay terminal 2 Always Below 1 ohms A25-22 (STA) - ST relay terminal 2 Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (BATTERY - ST RELAY)
12. READ VALUE USING TECHSTREAM (STARTER SIGNAL) Connect the Techstream to DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Starter Signal. Check the value displayed on the Techstream when the ignition switch is turned to the ON and START positions. OK Ignition Switch Position Starter Signal ON Close (OFF) START Open (ON) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ST RELAY - ECM) OK --> See step 21
13. INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Inspect the park/neutral position switch assembly. Refer to «INSPECTION»(ref-507931-S42133411712012100900000) . RESULT Result Proceed to OK (w/o smart key system) A OK (w/ smart key system) B NG C B --> See step 17 C --> See step 22 A: Go to next step
14. INSPECT IGNITION SWITCH ASSEMBLY Inspect the ignition switch assembly. Refer to «INSPECTION»(ref-507930-S02939650732012100900000) . NG --> See step 20 OK: Go to next step
15. CHECK HARNESS AND CONNECTOR (IGNITION SWITCH ASSEMBLY - PARK/NEUTRAL POSITION SWITCH ASSEMBLY - ECM) Disconnect the park/neutral position switch assembly connector. Disconnect the ignition switch assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition I36-3 (ST1) - E4-4 (B) Always Below 1 ohms I36-3 (ST1) - E26-63 (NSW) Always Below 1 ohms I36-3 (ST1) or E4-4 (B) or E26-63 (NSW) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
16. CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH ASSEMBLY - ST RELAY - ECM) Remove the ST relay from the engine room relay block and junction block assembly. Disconnect the park/neutral position switch assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition ST relay terminal 2 - E4-9 (L) Always Below 1 ohms ST relay terminal 2 or E4-9 (L) or A25-22 (STA) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (BATTERY - IGNITION SWITCH ASSEMBLY)
17. CHECK HARNESS AND CONNECTOR (CERTIFICATION ECU - PARK/NEUTRAL POSITION SWITCH ASSEMBLY - ECM) Disconnect the park/neutral position switch assembly connector. Disconnect the certification ECU (smart key ECU assembly) connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A43-5 (STAR) - E4-4 (B) Always Below 1 ohms A43-5 (STAR) - E26-63 (NSW) Always Below 1 ohms A43-5 (STAR) or E4-4 (B) or E26-63 (NSW) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
18. CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH ASSEMBLY - ST RELAY - ECM - CERTIFICATION ECU) Remove the ST relay from the engine room relay block and junction block assembly. Disconnect the park/neutral position switch assembly connector. Disconnect the ECM connector. Disconnect the certification ECU (smart key ECU assembly) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition ST relay terminal 2 - E4-9 (L) Always Below 1 ohms ST relay terminal 2 or E4-9 (L) or A25-22 (STA) or A43-7 (STA) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 23
19. REPLACE STARTER ASSEMBLY. Refer to «REMOVAL»(ref-507930-S35395100072012100900000) .
20. REPLACE IGNITION SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-507930-S04229081492012100900000) .
21. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-507772-S25544096432012100900000) .
22. REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-507931-S07177998062012100900000) .
23. GO TO SMART KEY SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-507760-S20559569422012100900000) .

1. CHECK DTC OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: System Select / Health Check. Check the DTCs. RESULT Result Proceed to DTC is not output A DTCs are output B B --> GO TO DTC CHART A: Go to next step
2. READ VALUE USING TECHSTREAM (STOP LIGHT SWITCH AND ST1) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Throttle / Stop Light Switch and ST1. Check the Data List indication when the brake pedal is depressed and released. OK Techstream Display Condition Specified Condition Stop Light Switch Brake pedal released OFF Brake pedal depressed ON ST1 Brake pedal released OFF Brake pedal depressed ON NG --> See step 10 OK: Go to next step
3. INSPECT BRAKE PEDAL Inspect and adjust the brake pedal. Refer to «ADJUSTMENT»(ref-507908-S23110410782012100900000) . HINT: If the stop light switch turns ON too late, the start of brake override system control may be delayed; if it turns ON too soon, brake override system control may begin too early, so conduct inspection of the brake pedal and stop light switch assembly. NG --> See step 9 OK: Go to next step
4. READ VALUE USING TECHSTREAM (ACCELERATOR PEDAL SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Throttle / Accel Sens. No. 1 Volt % and Accel Sens. No. 2 Volt %. Read the value displayed on the Techstream. OK Techstream Display Condition Specified Condition Accel Sens. No. 1 Volt % Accelerator Pedal Released --> Depressed --> Released Values smoothly change following accelerator pedal operation Accel Sens. No. 2 Volt % HINT: For numerical values of Accel Sens. No. 1 Volt % and Accel Sens. No. 2 Volt %, refer to the «DATA LIST / ACTIVE TEST»(ref-507772-S13031543512012100900000) . NG --> See step 8 OK: Go to next step
5. READ VALUE USING TECHSTREAM (VEHICLE SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Start the engine. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Vehicle Speed. Read the value displayed on the Techstream. Standard Techstream Display Condition Specified Condition Vehicle Speed Vehicle stopped, engine running 0 km/h (0 mph) Vehicle running at constant speed between 16.1 to 64.4 km/h (10 to 40 mph) No large fluctuations when driving at a constant speed WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Confirm the data after performing the drive test. NG --> See step 7 OK: Go to next step
6. READ VALUE USING TECHSTREAM (FR, FL, RR, RL WHEEL SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Start the engine. Enter the following menus: Chassis / ABS/VSC/TRAC / Data List / FR Wheel Speed, FL Wheel Speed, RR Wheel Speed and RL Wheel Speed. Read the value displayed on the Techstream. Standard Techstream Display Condition Specified Condition FR Wheel Speed FL Wheel Speed RR Wheel Speed RL Wheel Speed Vehicle stopped, engine running 0 km/h (0 mph) Vehicle running at constant speed between 16.1 to 64.4 km/h (10 to 40 mph) No large fluctuations when driving at a constant speed WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Confirm the data after performing the drive test. NG --> INSPECT FRONT OR REAR SPEED SENSOR OK --> END
7. GO TO METER / GAUGE SYSTEM (SPEED SIGNAL CIRCUIT). Refer to «Speed Signal Circuit»(ref-507936-S39301228192012100900000) .
8. REPLACE ACCELERATOR PEDAL SENSOR ASSEMBLY. Refer to «REMOVAL»(ref-507932-S07695192822012100900000) .
9. REPAIR OR REPLACE BRAKE PEDAL. Refer to «REMOVAL»(ref-507908-S25946476002012100900000) .
10. INSPECT STOP LIGHT SWITCH ASSEMBLY. Refer to «INSPECTION»(ref-507937-S06905367332012100900000) .
