Engine Control System (1GR-FE) (Diagnostic Codes (P0335-P1605): Diagnosis Toyota 4Runner V

INSPECTION PROCEDURE

HINT

1. After performing the inspection procedure for the crankshaft position sensor, if DTC P0335 is output again, check the following items related to the camshaft position sensor. Installation condition of the camshaft position sensor. Installation condition of the camshaft. Connection of the camshaft position sensor connector.
2. If no problem is found through this diagnostic troubleshooting procedure, troubleshoot the engine mechanical system.
3. Check the engine speed. The engine speed can be checked by using the Techstream. To check the engine speed, follow the procedure below: Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Engine Speed. The engine speed may be indicated as zero despite the crankshaft revolving normally. This is caused by a lack of NE signals from the crankshaft position sensor. Alternatively, the engine speed may be indicated as lower than the actual engine speed if the crankshaft position sensor output voltage is insufficient.
4. Read freeze frame data using the Techstream. Freeze frame data records the engine condition when malfunctions are detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 300

1. READ VALUE USING TECHSTREAM (ENGINE SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Engine Speed. Start the engine. Read the values displayed on the Techstream while the engine is running. OK Correct values are displayed. HINT: To check the engine speed change, display the graph on the Techstream. If the engine does not start, check the engine speed while cranking. If the engine speed indicated on the Techstream remains at zero (0), there may be an open or short in the crankshaft position sensor circuit. NG --> See step 2 OK --> See step 8
2. INSPECT CRANKSHAFT POSITION SENSOR (RESISTANCE) Inspect the crankshaft position sensor, refer to «INSPECTION - Step 1»(ref-421954-S17130490952011092600000) . NG -->See step 9 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (CRANKSHAFT POSITION SENSOR - ECM) Disconnect the crankshaft position sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B14-1 - B36-6 (NE+) Always Below 1 ohms B14-2 - B36-5 (NE-) Always Below 1 ohms B14-1 or B36-6 (NE+) - Body ground Always 10 kohms or higher B14-2 or B36-5 (NE-) - Body ground Always 10 kohms or higher Reconnect the ECM connector. Reconnect the crankshaft position sensor connector. NG -->REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. CHECK SENSOR INSTALLATION (CRANKSHAFT POSITION SENSOR) Check the crankshaft position sensor installation. OK Sensor is installed correctly. NG -->See step 10 OK: Go to next step
5. CHECK CRANKSHAFT POSITION SENSOR PLATE (TEETH OF SENSOR PLATE) Check the teeth of the sensor plate. OK Sensor plate teeth do not have any cracks or deformation. NG -->See step 11 OK: Go to next step
6. REPLACE CRANKSHAFT POSITION SENSOR Replace the crankshaft position sensor, refer to «REMOVAL»(ref-421954-S37461955022011092600000) . NEXT: Go to next step
7. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs, refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . Start the engine. Enter the following menus: Powertrain / Engine and ECT / Trouble Code. Read DTCs. RESULT Display (DTC Output) Proceed to No output A P0335 or P0339 B HINT: If the engine does not start, replace the ECM. B -->See step 12 A -->END
8. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-421952-S26737171072011092600000)
9. REPLACE CRANKSHAFT POSITION SENSOR. Refer to «REMOVAL»(ref-421954-S37461955022011092600000)
10. SECURELY REINSTALL SENSOR. Refer to «INSTALLATION»(ref-421954-S31496877172011092600000)
11. REPLACE CRANKSHAFT. Refer to «DISASSEMBLY»(ref-422094-S18119486062011092600000)
12. REPLACE ECM. Refer to «REMOVAL»(ref-421954-S13588411562011092600000)

HINT

Read freeze frame data using the Techstream. Freeze frame data records the engine condition when malfunctions are detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 301

Scheme 302

1. CHECK TERMINAL VOLTAGE (SENSOR POWER SOURCE) Disconnect the VVT sensor connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition B21-3 (VC) - Body ground Ignition switch ON 4.5 to 5.0 V B22-3 (VC) - Body ground Ignition switch ON 4.5 to 5.0 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to VVT Sensor) Reconnect the VVT sensor connector. NG -->REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (VVT SENSOR FOR INTAKE CAMSHAFT - ECM) Disconnect the VVT sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B21-1 (VVR+) - B36-9 (VV1+) Always Below 1 ohms B21-2 (VVR-) - B36-10 (VV1-) Always Below 1 ohms B22-1 (VVL+) - B36-12 (VV2+) Always Below 1 ohms B22-2 (VVL-) - B36-11 (VV2-) Always Below 1 ohms B21-1 (VVR+) or B36-9 (VV1+) - Body ground Always 10 kohms or higher B21-2 (VVR-) or B36-10 (VV1-) - Body ground Always 10 kohms or higher B22-1 (VVL+) or B36-12 (VV2+) - Body ground Always 10 kohms or higher B22-2 (VVL-) or B36-11 (VV2-) - Body ground Always 10 kohms or higher Reconnect the VVT sensor connector. Reconnect the ECM connector. NG -->REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK SENSOR INSTALLATION (VVT SENSOR FOR INTAKE CAMSHAFT) Check the VVT sensor installation. OK Sensor is installed correctly. NG -->See step 7 OK: Go to next step
4. CHECK CAMSHAFT TIMING GEAR ASSEMBLY (TEETH OF PLATE) Check the teeth of the signal plate. OK Sensor plate teeth do not have any cracks or deformation. NG -->See step 8 OK: Go to next step
5. REPLACE VVT SENSOR Replace the VVT sensor, refer to «REMOVAL»(ref-421954-S36760255232011092600000) . NEXT: Go to next step
6. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs, refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . Start the engine. Enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending. Read DTCs. RESULT Display (DTC Output) Proceed to No output A P0340, P0342, P0343, P0345, P0347 or P0348 B HINT: If the engine does not start, replace the ECM. B -->See step 9 A -->END
7. SECURELY REINSTALL SENSOR. Refer to «INSTALLATION»(ref-421954-S29574656632011092600000)
8. REPLACE CAMSHAFT TIMING GEAR ASSEMBLY. Refer to «DISASSEMBLY»(ref-422094-S07769615052011092600000)
9. REPLACE ECM. Refer to «REMOVAL»(ref-421954-S13588411562011092600000)

HINT

Read freeze frame data using the Techstream. Freeze frame data records the engine condition when malfunctions are detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 303

1. INSPECT IGNITION COIL ASSEMBLY (POWER SOURCE) Disconnect the ignition coil assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B7-4 (GND) - Body ground Always Below 1 ohms B8-4 (GND) - Body ground Always Below 1 ohms B9-4 (GND) - Body ground Always Below 1 ohms B10-4 (GND) - Body ground Always Below 1 ohms B11-4 (GND) - Body ground Always Below 1 ohms B12-4 (GND) - Body ground Always Below 1 ohms Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B7-1 (+B) - B7-4 (GND) Ignition switch ON 11 to 14 V B8-1 (+B) - B8-4 (GND) Ignition switch ON 11 to 14 V B9-1 (+B) - B9-4 (GND) Ignition switch ON 11 to 14 V B10-1 (+B) - B10-4 (GND) Ignition switch ON 11 to 14 V B11-1 (+B) - B11-4 (GND) Ignition switch ON 11 to 14 V B12-1 (+B) - B12-4 (GND) Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Ignition Coil with Igniter) Reconnect the ignition coil assembly connector. NG -->REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (IGNITION COIL ASSEMBLY - ECM) Disconnect the ignition coil assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B7-2 (IGF) - B38-6 (IGF1) Always Below 1 ohms B8-2 (IGF) - B38-6 (IGF1) Always Below 1 ohms B9-2 (IGF) - B38-6 (IGF1) Always Below 1 ohms B10-2 (IGF) - B38-6 (IGF1) Always Below 1 ohms B11-2 (IGF) - B38-6 (IGF1) Always Below 1 ohms B12-2 (IGF) - B38-6 (IGF1) Always Below 1 ohms B7-3 (IGT1) - B38-24 (IGT1) Always Below 1 ohms B8-3 (IGT2) - B38-25 (IGT2) Always Below 1 ohms B9-3 (IGT3) - B38-26 (IGT3) Always Below 1 ohms B10-3 (IGT4) - B38-27 (IGT4) Always Below 1 ohms B11-3 (IGT5) - B38-28 (IGT5) Always Below 1 ohms B12-3 (IGT6) - B37-25 (IGT6) Always Below 1 ohms B7-2 (IGF) or B38-6 (IGF1) - Body ground Always 10 kohms or higher B8-2 (IGF) or B38-6 (IGF1) - Body ground Always 10 kohms or higher B9-2 (IGF) or B38-6 (IGF1) - Body ground Always 10 kohms or higher B10-2 (IGF) or B38-6 (IGF1) - Body ground Always 10 kohms or higher B11-2 (IGF) or B38-6 (IGF1) - Body ground Always 10 kohms or higher B12-2 (IGF) or B38-6 (IGF1) - Body ground Always 10 kohms or higher B7-3 (IGT1) or B38-24 (IGT1) - Body ground Always 10 kohms or higher B8-3 (IGT2) or B38-25 (IGT2) - Body ground Always 10 kohms or higher B9-3 (IGT3) or B38-26 (IGT3) - Body ground Always 10 kohms or higher B10-3 (IGT4) or B38-27 (IGT4) - Body ground Always 10 kohms or higher B11-3 (IGT5) or B38-28 (IGT5) - Body ground Always 10 kohms or higher B12-3 (IGT6) or B37-25 (IGT6) - Body ground Always 10 kohms or higher Reconnect the ECM connector. Reconnect the ignition coil assembly connector. NG -->REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK WHETHER DTC OUTPUT RECURS (DTC P0351, P0352, P0353, P0354, P0355 OR P0356) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear DTCs, refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . Shuffle the arrangement of the ignition coil assemblies (among the No. 1 to No. 6 cylinders). NOTE: Do not shuffle the connectors. Perform a simulation test. Check the DTCs output on the Techstream. RESULT Display (DTC Output) Proceed to Same DTC output A Different ignition coil DTC output B B -->See step 4 A -->See step 5
4. REPLACE IGNITION COIL ASSEMBLY. Refer to «REMOVAL»(ref-421954-S28657318342011092600000)
5. REPLACE ECM. Refer to «REMOVAL»(ref-421954-S13588411562011092600000)

Read freeze frame data using the Techstream. Freeze frame data records the engine condition when malfunctions are detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 304

Scheme 305

1. CHECK TERMINAL VOLTAGE (SENSOR POWER SOURCE) Disconnect the VVT sensor connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B23-3 (VC2) - Body ground Ignition switch ON 4.5 to 5.0 V B24-3 (VC2) - Body ground Ignition switch ON 4.5 to 5.0 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to VVT Sensor) Reconnect the VVT sensor connector. NG -->REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (VVT SENSOR - ECM) Disconnect the VVT sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B23-1 (EX+) - B36-13 (EV1+) Always Below 1 ohms B23-2 (EX-) - B36-14 (EV1-) Always Below 1 ohms B24-1 (EX+) - B36-18 (EV2+) Always Below 1 ohms B24-2 (EX-) - B36-17 (EV2-) Always Below 1 ohms B23-1 (EX+) or B36-13 (EV1+) - Body ground Always 10 kohms or higher B23-2 (EX-) or B36-14 (EV1-) - Body ground Always 10 kohms or higher B24-1 (EX+) or B36-18 (EV2+) - Body ground Always 10 kohms or higher B24-2 (EX-) or B36-17 (EV2-) - Body ground Always 10 kohms or higher Reconnect the VVT sensor connector. Reconnect the ECM connector. NG -->REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK SENSOR INSTALLATION (VVT SENSOR FOR EXHAUST CAMSHAFT) Check the VVT sensor installation. OK Sensor is installed correctly. NG -->See step 7 OK: Go to next step
4. CHECK EXHAUST CAMSHAFT Check the teeth of the camshaft. OK Teeth do not have any cracks or deformation. NG -->See step 8 OK: Go to next step
5. REPLACE VVT SENSOR Replace the VVT sensor, refer to «REMOVAL»(ref-421954-S36760255232011092600000) . NEXT: Go to next step
6. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs, refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . Start the engine. Enter the following menus: Powertrain / Engine and ECT / Trouble Code. Read DTCs. RESULT Display (DTC Output) Proceed to No output A P0365, P0367, P0368, P0390, P0392 or P0393 B HINT: If the engine does not start, replace the ECM. B -->See step 9 A -->END
7. SECURELY REINSTALL SENSOR. Refer to «INSTALLATION»(ref-421954-S29574656632011092600000)
8. REPLACE EXHAUST CAMSHAFT. Refer to «REMOVAL»(ref-422094-S36590258942011092600000)
9. REPLACE ECM. Refer to «REMOVAL»(ref-421954-S13588411562011092600000)

CONDITIONING FOR SENSOR TESTING

HINT

Perform the operation with the engine speeds and time durations described below prior to checking the waveforms of the air fuel ratio and heated oxygen sensors. This is in order to activate the sensors sufficiently to obtain the appropriate inspection results.

Scheme 306

1. Connect the Techstream to the DLC3 (a).
2. Start the engine and warm it up with all the accessories switched off until the engine coolant temperature stabilizes (b).
3. Run the engine at an engine speed of between 2500 RPM and 3000 RPM for at least 3 minutes (c).
4. While running the engine at 3000 RPM for 2 seconds, and then 2000 RPM for 2 seconds, check the waveforms of the air fuel ratio and heated oxygen sensors using the Techstream (d).

HINT

1. If either voltage output of the air fuel ratio or heated oxygen sensor does not fluctuate, or there is noise in the waveform of either sensor, the sensor may be malfunctioning.
2. If the voltage outputs of both sensors remain lean or rich, the air-fuel ratio may be extremely lean or rich. In such cases, perform A/F Control using the Techstream.
3. If the three-way catalytic converter has deteriorated, the heated oxygen sensor (located behind the three-way catalytic converter) voltage output fluctuates up and down frequently, even under normal driving conditions (active air-fuel ratio control is not performed).

Scheme 307

HINT

Read freeze frame data using the Techstream. Freeze frame data records the engine condition when malfunctions are detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 308

Scheme 309

Scheme 310

Scheme 311

1. CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0420 OR P0430) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Code. Read DTCs. RESULT Display (DTC Output) Proceed to P0420 or P0430 A P0420 or P0430 and other DTCs B HINT: If any DTCs other than P0420 or P0430 are output, troubleshoot those DTCs first. B -->See step 8 A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (A/F CONTROL) Connect the Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine at an engine speed of 2500 RPM for approximately 90 seconds. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor. Perform the Control the Injection Volume for A/F Sensor operation with the engine idling (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the voltage outputs of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2, or AFS Voltage B2S1 and O2S B2S2) displayed on the Techstream. Standard Air fuel ratio sensor reacts in accordance with increases and decreases in fuel injection volume: +25% = Rich output Below 3.1 V -12.5% = Lean output Higher than 3.4 V NOTE: The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. Case Air Fuel Ratio Sensor (Sensor 1) Output Voltage Heated Oxygen Sensor (Sensor 2) Output Voltage Main Suspected Trouble Area 1 - 2 Air fuel ratio sensor Air fuel ratio sensor heater Air fuel ratio sensor circuit 3 Heated oxygen sensor Heated oxygen sensor heater Heated oxygen sensor circuit 4 Fuel injector Fuel pressure Gas leak from exhaust system (air-fuel ratio extremely rich or lean) Following the Control the Injection Volume for A/F Sensor procedure enables technicians to check and graph the voltage outputs of both the air fuel ratio and heated oxygen sensors. To display the graph, enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor / AFS Voltage B1S1 or AFS Voltage B2S1 and O2S B1S2 or O2S B2S2. Then press the graph button on the Data List display. RESULT Result Proceed to Case 1 A Case 2 B Case 3 C Case 4 D B -->See step 9 C -->See step 7 D -->CHECK CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR-FUEL RATIO, REPLACE FAULTY AREA AND GO TO NEXT STEP A: Go to next step
3. CHECK FOR EXHAUST GAS LEAKAGE OK No gas leakage. NG -->REPAIR OR REPLACE EXHAUST GAS LEAKAGE POINT OK: Go to next step
4. CHECK DTC OUTPUT (DTC P0420 AND/OR P0430) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Code. Read DTCs. RESULT Display (DTC Output) Proceed to P0420 A P0430 B P0420 and P0430 A and B B -->See step 6 A: Go to next step
5. REPLACE EXHAUST MANIFOLD SUB-ASSEMBLY RH (TWC: FRONT CATALYST) Replace the exhaust manifold sub-assembly RH, refer to «REMOVAL»(ref-422104-S23626308532011092600000) . NEXT -->See step 11
6. REPLACE EXHAUST MANIFOLD SUB-ASSEMBLY LH (TWC: FRONT CATALYST) Replace the exhaust manifold sub-assembly LH, refer to «REMOVAL»(ref-422104-S23626308532011092600000) . NEXT -->See step 12
7. CHECK FOR EXHAUST GAS LEAKAGE OK No gas leakage. NG -->REPAIR OR REPLACE EXHAUST GAS LEAKAGE POINT OK -->See step 10
8. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421952-S27905813582011092600000)
9. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-421954-S24359359142011092600000)
10. REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL»(ref-421954-S24008159712011092600000)
11. REPLACE FRONT EXHAUST PIPE (TWC: REAR CATALYST). Refer to «REMOVAL»(ref-422104-S24564558782011092600000)
12. REPLACE FRONT NO. 2 EXHAUST PIPE (TWC: REAR CATALYST). Refer to «REMOVAL»(ref-422104-S24564558782011092600000)

DTC SUMMARY

HINT

The reference orifice is located inside the canister pump module.

Refer to EVAP System, refer to INSPECTION PROCEDURE .

Refer to EVAP System, refer to INSPECTION PROCEDURE .

Note. Inspect the fuses of circuits related to this system before performing the following inspection procedure.

HINT

Read freeze frame data using the Techstream. Freeze frame data records the engine condition when malfunctions are detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 312

1. PERFORM ACTIVE TEST USING TECHSTREAM (ACTIVATE VSV FOR EVAP CONTROL) Connect the Techstream to the DLC3. Disconnect the vacuum hose (charcoal canister side) from the purge VSV. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Activate the VSV for EVAP Control. When the purge VSV is operated using the Techstream, check whether the port of the purge VSV applies suction to your finger. OK Tester Operation Specified Condition VSV ON Purge VSV port applies suction to finger VSV OFF Purge VSV port applies no suction to finger TEXT IN ILLUSTRATION *1 Purge VSV *2 Hose (to Canister) Reconnect the vacuum hose to the purge VSV. NG --> See step 2 OK -->See step 4
2. INSPECT PURGE VSV (RESISTANCE) Inspect the purge VSV, refer to «INSPECTION - Step 1»(ref-422126-S04491379762011092600000) . NG -->See step 5 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (PURGE VSV - ECM, NO. 1 INTEGRATION RELAY (EFI MAIN) Disconnect the purge VSV connector. Disconnect the ECM connector. Remove the No. 1 integration relay from the engine room relay block. Disconnect the No. 1 integration relay connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B15-2 - B38-18 (PRG) Always Below 1 ohms B15-1 - 1D-4 Always Below 1 ohms B15-2 or B38-18 (PRG) - Body ground Always 10 kohms or higher B15-1 or 1D-4 - Body ground Always 10 kohms or higher Reconnect the No. 1 integration relay connector. Reinstall the No. 1 integration relay. Reconnect the ECM connector. Reconnect the purge VSV connector. NG -->REPAIR OR REPLACE HARNESS OR CONNECTOR OK -->See step 6
4. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-421952-S26737171072011092600000)
5. REPLACE PURGE VSV. Refer to «REMOVAL»(ref-422126-S33218404612011092600000)
6. REPLACE ECM. Refer to «REMOVAL»(ref-421954-S13588411562011092600000)

HINT

The canister pressure sensor is built into the canister pump module.

Note. When a vehicle is brought into the workshop, leave it as it is. Do not change the vehicle condition. For example, do not tighten the fuel tank cap assembly. Do not disassemble the canister pump module. The Techstream is required to conduct the following diagnostic troubleshooting procedure.

Scheme 313

1. CONFIRM DTC AND EVAP PRESSURE Connect the Techstream to the DLC3. Turn the ignition switch to ON (do not start the engine). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Code. Read DTCs. Enter the following menus: Powertrain / Engine and ECT / Data List / Vapor Pressure Pump. Read the EVAP (Evaporative Emission) pressure displayed on the Techstream. RESULT Display (DTC Output) Test Result Suspected Trouble Area Proceed to P0451 - Canister pressure sensor C P0452 Below 45 kPa-a (337.3 mmHg-a) Wire harness/connector (ECM - Canister pressure sensor) Canister pressure sensor Short in ECM circuit A P0453 Higher than 120 kPa-a (900 mmHg-a) Wire harness/connector (ECM - Canister pressure sensor) Canister pressure sensor Open in ECM circuit B B -->See step 5 C -->See step 4 A: Go to next step
2. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - ECM) Turn the ignition switch off. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. RESULT Tester Connection Condition Test Result Suspected Trouble Area Proceed to B37-1 (PPMP) - Body ground Always 10 ohms or less Wire harness/connector (ECM - Canister pressure sensor) Short in canister pressure sensor circuit A 10 kohms or higher Wire harness/connector (ECM - Canister pressure sensor) Short in ECM circuit B Reconnect the ECM connector. B --> See step 8 A: Go to next step
3. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - ECM) Disconnect the canister pump module connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. RESULT Tester Connection Condition Test Result Suspected Trouble Area Proceed to B37-1 (PPMP) - Body ground Always 10 kohms or higher Short in canister pressure sensor circuit A 10 ohms or less Short in wire harness/connector (ECM - Canister pressure sensor) B Reconnect the canister pump module connector. Reconnect the ECM connector. A -->See step 6 B -->See step 7
4. GO TO EVAP SYSTEM. Refer to «EVAP System»(ref-422119-S23021756392011092600000)
5. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - ECM) Disconnect the canister pump module connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition O15-8 (SGND) - Body ground Always 100 ohms or less Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition O15-6 (VCC) - Body ground Ignition switch ON 4.5 to 5.5 V O15-7 (VOUT) - Body ground Ignition switch ON 4.5 to 5.5 V RESULT Test Result Suspected Trouble Area Proceed to Voltage and resistance within standard ranges Open in canister pressure sensor circuit A Voltage and resistance outside standard ranges Open in wire harness/connector (ECM - Canister pressure sensor) B Reconnect the canister pump module connector. A -->See step 6 B -->See step 7
6. REPLACE CANISTER ASSEMBLY Replace the canister assembly, refer to «REMOVAL»(ref-422126-S24142266332011092600000) . NOTE: When replacing the canister, check the canister pump module interior and related pipes for water, fuel and other liquids. If liquids are present, check for disconnections and/or cracks in the following: 1) the pipe from the air inlet port to the canister pump module; 2) the canister filter; and 3) the fuel tank vent hose. TEXT IN ILLUSTRATION *1 Fuel Tank Vent Hose *2 Vent Hose *3 Air Inlet Port *4 Fuel Tank *5 Canister Assembly - - *a Inspection Area (check for disconnection and/or cracks) - - NEXT -->See step 9
7. REPAIR OR REPLACE HARNESS OR CONNECTOR HINT: If the exhaust pipe has been removed, go to the next step before reinstalling it. NEXT -->See step 9
8. REPLACE ECM Replace the ECM, refer to «REMOVAL»(ref-421954-S13588411562011092600000) . NEXT: Go to next step
9. CHECK WHETHER DTC OUTPUT RECURS (AFTER REPAIR) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0451, P0452 or P0453. Check the DTC judgment result. HINT: If the DTC judgment result is NORMAL, the repair has been successfully completed. NEXT -->COMPLETED

Refer to EVAP System, refer to INSPECTION PROCEDURE .

HINT

1. Various systems use the vehicle speed signal distributed from the combination meter. Check all the components possibly related to speed signal.
2. Read freeze frame data using the Techstream. Freeze frame data records the engine condition when malfunctions are detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 314

Scheme 315

Scheme 316

1. CHECK OPERATION OF SPEEDOMETER Drive the vehicle and check whether the operation of the speedometer in the combination meter assembly is normal. OK The operation of the speedometer is normal. HINT: The vehicle speed sensor is operating normally if the speedometer reading is normal. If the speedometer does not operate, check it by following the procedure described in Speedometer Malfunction, refer to «Speedometer Malfunction»(ref-422130-S04159321722011092600000) . NG -->See step 8 OK: Go to next step
2. READ VALUE USING TECHSTREAM (VEHICLE SPD) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Vehicle Speed. Drive the vehicle. Read the value displayed on the Techstream. OK Vehicle speeds displayed on Techstream and speedometer display are equal. NG --> See step 3 OK -->See step 9
3. CHECK HARNESS AND CONNECTOR (ECM - COMBINATION METER ASSEMBLY) Disconnect the ECM connector. Disconnect the combination meter assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition F14-28 (+S) - F51-18 (SPD) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition F14-28 (+S) or F51-18 (SPD) - Body ground Always Below 1 ohms HINT: If the wire has a short, check the speed signal circuit in other systems related to the vehicle speed signal (e.g. tire pressure warning system, audio system, etc.). Reconnect the ECM connector. Reconnect the combination meter assembly connector. NG -->REPAIR OR REPLACE HARNESS OR CONNECTOR (OTHER SYSTEMS RELATED TO SPEED SIGNAL) OK: Go to next step
4. CHECK COMBINATION METER ASSEMBLY (VOLTAGE) Disconnect the combination meter assembly connector. HINT: Disconnect the ECU connectors on the other systems related to the speed signal (but the ECM connectors must be connected). Turn the ignition switch to ON. Measure the resistance according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition F14-28 (+S) - Body ground Ignition switch ON 4.5 to 5.5 V Reconnect the combination meter assembly connector. NG -->See step 10 OK: Go to next step
5. CHECK COMBINATION METER ASSEMBLY (SPD SIGNAL OUTPUT WAVEFORM) Remove the combination meter assembly, refer to «REMOVAL»(ref-422131-S19922124762011092600000) . Connect the combination meter assembly connector. Move the shift lever to the neutral position. Jack up the vehicle. Turn the ignition switch to ON. Check the voltage between the terminal of the combination meter assembly and the body ground while the wheel is turned slowly. Standard Voltage Tester Connection Switch Condition Specified Condition F14-28 (+S) - Body ground Ignition switch ON (Turn wheel slowly) Voltage generated intermittently TEXT IN ILLUSTRATION *a Component with harness connected (Combination Meter Assembly) *b Turn Wheel HINT: The output voltage should fluctuate up and down, similarly to the diagram, when the wheel is turned slowly. Reinstall the combination meter assembly, refer to «INSTALLATION»(ref-422131-S25053827972011092600000) . NG -->See step 6 OK -->See step 10
6. CHECK COMBINATION METER ASSEMBLY (SPD SIGNAL INPUT WAVEFORM) Remove the combination meter assembly, refer to «REMOVAL»(ref-422131-S19922124762011092600000) . Connect the combination meter assembly connector. Move the shift lever to the neutral position. Jack up the vehicle. Turn the ignition switch to ON. Check the voltage between the terminal of the combination meter assembly and the body ground while the wheel is turned slowly. Standard Voltage Tester Connection Switch Condition Specified Condition F14-29 (SI) - Body ground Ignition switch ON (Turn wheel slowly) Voltage generated intermittently TEXT IN ILLUSTRATION *a Component with harness connected (Combination Meter Assembly) *b Turn Wheel HINT: The output voltage should fluctuate up and down, similarly to the diagram, when the wheel is turned slowly. Reinstall the combination meter assembly, refer to «INSTALLATION»(ref-422131-S25053827972011092600000) . NG -->See step 7 OK -->See step 11
7. CHECK HARNESS AND CONNECTOR (COMBINATION METER ASSEMBLY - SKID CONTROL ECU) Disconnect the skid control ECU connector. Disconnect the combination meter assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition F14-29 (SI) - A6-12 (SP1) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition F14-29 (SI) or A6-12 (SP1)- Body ground Always Below 1 ohms Reconnect the skid control ECU connector. Reconnect the combination meter assembly connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (COMBINATION METER ASSEMBLY - SKID CONTROL ECU) OK --> See step 12
8. GO TO MALFUNCTION IN SPEEDOMETER. Refer to «Speedometer Malfunction»(ref-422130-S04159321722011092600000)
9. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-421952-S26737171072011092600000)
10. REPLACE ECM. Refer to «REMOVAL»(ref-421954-S13588411562011092600000)
11. REPLACE COMBINATION METER ASSEMBLY. Refer to «REMOVAL»(ref-422131-S19922124762011092600000)
12. REPLACE MASTER CYLINDER SOLENOID. Refer to «DISASSEMBLY»(ref-422132-S27132768212011092600000)

Note. Inspect the fuses of circuits related to this system before performing the following inspection procedure.

HINT

1. Read freeze frame data using the Techstream. Freeze frame data records the engine condition when malfunctions are detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred.
2. STP signal conditions can be checked using the Techstream. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Stop Light Switch and ST1. Check the STP signal when the brake pedal is depressed and released.

Scheme 317

Scheme 318

1. CHECK STOP LIGHT SWITCH ASSEMBLY (TERMINAL B VOLTAGE) Disconnect the stop light switch assembly connector. Measure the resistance according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A4-2 - Body ground Always 11 to 14 V A4-4 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Stop Light Switch Assembly) Reconnect the stop light switch assembly connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. INSPECT STOP LIGHT SWITCH ASSEMBLY Inspect the stop light switch assembly, refer to «INSPECTION - Step 1»(ref-422133-S00354950082011092600000) . NG --> See step 4 OK: Go to next step
3. CHECK ECM (STP AND ST1- VOLTAGE) Disconnect the ECM connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Brake Pedal Operation Specified Condition F51-8 (ST1-) - Body ground Released 11 to 14 V Depressed 0 to 3 V F50-18 (STP) - Body ground Released 0 to 3 V Depressed 11 to 14 V TEXT IN ILLUSTRATION *a Brake Pedal Depressed *b Brake Pedal Released *c Component with harness connected (ECM) Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 5
4. REPLACE STOP LIGHT SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-422133-S22473036062011092600000)
5. REPLACE ECM. Refer to «REMOVAL»(ref-421954-S13588411562011092600000)

HINT

1. The following conditions may also cause DTC P0505 to be stored: The floor carpet overlapping slightly onto the accelerator pedal, causing the accelerator pedal to be slightly depressed and therefore the throttle valve position to be slightly open. The accelerator pedal being not fully released.
2. Read freeze frame data using the Techstream. Freeze frame data records the engine condition when malfunctions are detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred.
3. Refer to "Data List / Active Test" [Engine Speed, ISC Feedback Value and ISC Learning Value], refer to «DATA LIST / ACTIVE TEST»(ref-421952-S15138037352011092600000) .

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Read freeze frame data using the Techstream. Freeze frame data records the engine condition when malfunctions are detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

1. DTC P050B may be stored when the engine shows the symptoms listed below. If necessary, check the trouble areas listed below. Symptoms Factor Trouble Area Low idle speed when engine cold Excessive engine friction Engine oil deterioration Drive belt tension A/C compressor Generator PS pump Rough idle when engine cold Abnormal combustion Fuel quality
2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can be helpful in determining whether the vehicle was moving or stationary, whether the engine was warmed up or not, whether the air-fuel ratio was lean or rich, as well as other data recorded at the time of a malfunction.

HINT

1. If other DTCs relating to different systems that have terminal ETHW as the ground terminal are output simultaneously, terminal ETHW may have an open circuit.
2. Read freeze frame data using the Techstream. Freeze frame data records the engine condition when malfunctions are detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Read freeze frame data using the Techstream. Freeze frame data records the engine condition when malfunctions are detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Read freeze frame data using the Techstream. Freeze frame data records the engine condition when malfunctions are detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred.

HINT

1. The following troubleshooting flowchart is based on the premise that the engine can be cranked normally. If the engine does not crank, proceed to Problem Symptoms Table, refer to «PROBLEM SYMPTOMS TABLE»(ref-421952-S22152412832011092600000) .
2. Read freeze frame data using the Techstream. Freeze frame data records the engine condition when malfunctions are detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred.

HINT

Using the Techstream to read the Data List allows switch, sensor, actuator and other item values to be read without removing any parts. Reading the Data List early in troubleshooting is one way to save time.

Note. In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not.

1. Warm up the engine.
2. Turn the ignition switch off.
3. Connect the Techstream to the DLC3.
4. Turn the ignition switch to ON.
5. Turn the Techstream ON.
6. Enter the following menus: Powertrain / Engine and ECT / Data List.
7. Follow the instructions on the Techstream and read the Data List.

Read freeze frame data using the Techstream. Freeze frame data records the engine condition when malfunctions are detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 319

Scheme 320

1. CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P1500) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Display (DTC Output) Proceed to P1500 A P1500 and other DTCs B If any DTCs other than P1500 are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
2. CHECK TERMINAL VOLTAGE (SPD SIGNAL) Move the shift lever to N. Jack up the vehicle. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition F51-18 (SPD) - B38-12 (E1) Ignition switch ON Wheel is turned slowly Voltage generated intermittently HINT: The output voltage should fluctuate up and down similarly to the diagram on the left when a wheel is turned slowly. TEXT IN ILLUSTRATION *a Component with harness connected (ECM) *b Wheel Turning NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK ECM (ELS2 VOLTAGE) Disconnect the voltage inverter connector. Start the engine. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition N19-9 (EXCD) - Body ground Engine running 1 V or less TEXT IN ILLUSTRATION *a Rear view of wire harness connector (to Voltage Inverter) Reconnect the voltage inverter connector. NG --> See step 4 OK --> See step 7
4. CHECK HARNESS AND CONNECTOR (ECM - VOLTAGE INVERTER) Disconnect the voltage inverter connector. Disconnect the ECM connector. Turn the ignition to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage (Check for Short in Idle-up Signal Circuit) Tester Connection Condition Specified Condition N19-9 (EXCD) or F51-10 (ELS2) - Body ground Ignition switch ON 1 V or less Reconnect the voltage inverter connector and ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 5
5. REPLACE ECM. Refer to «REMOVAL»(ref-421954-S13588411562011092600000)
6. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421952-S27905813582011092600000)
7. REPLACE VOLTAGE INVERTER ASSEMBLY. Refer to «REMOVAL»(ref-422134-S32036135412011092600000)

HINT

1. In contrast to normal malfunction diagnosis for components, circuits and systems, DTCs P1603 and P1605 are used to determine the malfunctioning area from the problem symptoms and freeze frame data when the user mentions problems such as engine stall. As these DTCs can be stored as a result of certain user actions, even if these DTCs are output, if the customer makes no mention of problems, clear these DTCs without performing any troubleshooting and return the vehicle to the customer.
2. If any other DTCs are output, perform troubleshooting for those DTCs first.
3. Use any information from the customer problem analysis about the condition of the vehicle at the time when the problem occurred (how the engine stopped, conditions when the engine was restarted, etc.) as a reference. Symptom Suspected Area Engine vibration occurs and engine stops Air-fuel ratio abnormal Engine stops with no engine vibration Ignition system, injection stoppage, high load from external parts Engine can be started with accelerator pedal depressed Insufficient air volume Rough idling after engine started Air-fuel ratio abnormal, abnormal combustion
4. Read freeze frame data using the Techstream. Freeze frame data records engine conditions when a malfunction occurs. This information can be useful when troubleshooting.
5. When confirming the freeze frame data, be sure to check all 5 sets of freeze frame data, refer to «FREEZE FRAME DATA»(ref-421952-S05337952652011092600000) .
6. When DTC P1603 (Engine Stall History) is stored, DTC P1605 (Rough Idling) is also stored. When confirming freeze frame data, check DTC P1605. The ECM stores DTC P1605 first. Therefore, 5 sets of freeze frame data can be confirmed through DTC P1605, enabling the technician to obtain more information.
7. When confirming freeze frame data, if there are multiple items related to the cause of the malfunction, perform troubleshooting for all related items.
8. Try to operate the vehicle under the conditions recorded in the freeze frame data which were present when the malfunction occurred. Confirm the data at this time and the data when the engine is idling (engine warmed up, no load, and shift lever in D or N) and compare these data with the freeze frame data.
9. Inspections take into account the fact that the malfunction may not have reoccurred and place emphasis on checking the vehicle conditions present at the time when the malfunction occurred.
10. When performing inspections, jiggle the relevant wire harnesses and connectors in an attempt to reproduce malfunctions that do not always occur.

Inspection flow

Using freeze frame data, narrow down the parts to be inspected according to the vehicle conditions at the time when the malfunction occurred.

P1603

Scheme 321

1

1. If the engine stalled when the intake air volume was low (during idling or deceleration), there may be a decrease in torque due to an incorrect air-fuel ratio, etc.
2. If the engine stalled when the intake air volume was high (during driving or acceleration), there may be a major malfunction such as continuous misfire due to ignition stoppage, fuel injection stoppage, etc. and the torque drops to zero.

2

1. If the engine speed decreased slowly, there may have been a decrease in torque due to an air-fuel ratio that was incorrect (by approximately 20 to 30%), etc.
2. If the engine speed decreased rapidly, there may have been a malfunction such as when the engine misfires almost continuously due to ignition stoppage, fuel injection stoppage, etc., or when the external load increases due to an external part malfunctioning.

3

1. If the air-fuel ratio is abnormal, there may have been an intake air leak, sensor malfunction, or fuel supply problem.
2. If the vehicle was normal, the air volume may have been insufficient or the ignition timing may have been incorrect.

P1603 inspection flow: Narrow down the parts to be inspected according to the vehicle conditions at the time when the malfunction occurred (freeze frame data).

P1605

Scheme 322

1

1. If the engine speed decreased slowly, there may have been a decrease in torque due an air-fuel ratio that was incorrect (by approximately 20 to 30%), etc.
2. If the engine speed decreased rapidly, there may have been a malfunction such as when the engine misfires almost continuously due to ignition stoppage, fuel injection stoppage, etc., or when the external load increases due to an external part malfunctioning.

2

1. If the air-fuel ratio is abnormal, there may have been an intake air leak, sensor malfunction, or fuel supply problem.
2. If the vehicle was normal, the air volume may have been insufficient or the ignition timing may have been incorrect.

P1605 inspection flow: Narrow down the parts to be inspected according to the vehicle conditions at the time when the malfunction occurred (freeze frame data).

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Scheme 323

Scheme 324

Scheme 325

Scheme 326

Scheme 327

Scheme 328

Scheme 329

Scheme 330

Scheme 331

Scheme 332

1. CHECK FOR ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Read the DTCs, refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . RESULT Result Proceed to Only DTC P1603 and P1605 are output A DTCs other than P1603 and P1605 are output B B --> See step 58 A: Go to next step
2. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored, refer to «FREEZE FRAME DATA»(ref-421952-S05337952652011092600000) . RESULT Problem Symptom Freeze Frame Data Item for DTC P1605 Suspected Area Proceed to Closed Throttle Position SW Engine Speed Total of Short FT and Long FT When idling or decelerating, engine speed slowly decreases and engine stalls All 5 sets of freeze frame data are ON Decreases slowly*1 All 5 sets of freeze frame data are +15% or more*2 Air suction Sensor malfunction (value from sensor too lean) Fuel supply problem A At least 1 of the 5 sets of freeze frame data is -15% or less*3 Sensor malfunction (value from sensor too rich) B All 5 sets of freeze frame data are from -15% to +15% Intake air volume insufficient Ignition timing incorrect C When idling or decelerating, engine speed rapidly decreases and engine stalls Decreases rapidly*1 - Injection stoppage, ignition stoppage Load from external parts D When accelerating or driving at constant speed, engine stalls*4 At least one is OFF - - Sensor malfunction Injection stoppage, ignition stoppage Fuel supply problem E HINT: *1: A rapid decrease in engine speed may be caused by an electrical fault in the shared wiring of all or a number of cylinders, an increase in load from external parts, etc. The engine speed is considered to have decreased rapidly if either of the following conditions applies. Otherwise, the engine speed is considered to have decreased slowly. In the freeze frame data, the decrease in engine speed from #3 to #5 is 400 RPM or more. In the freeze frame data, the engine speed at #5 is 120 RPM or less. If the vehicle speed is 30 km/h or less and the difference between Engine Speed and SPD (NT) is 100 RPM or less, inspect the automatic transmission. (Depending on the rate of vehicle deceleration, the engine speed may have decreased due to the A/T lock-up release being late.) *2: When a DTC is stored, feedback compensation increases because the air-fuel ratio is determined to be lean. *3: When a DTC is stored, feedback compensation decreases because the air-fuel ratio is determined to be rich. *4: This item should be checked when DTC P1603 is output and is not necessary to check when only P1605 is output. B --> See step 23 C --> See step 33 D --> See step 41 E --> See step 48 A: Go to next step
3. CHECK INTAKE SYSTEM Check for air leakage in the intake system [vacuum hose disconnection, cracks, damaged gaskets, etc.], refer to «ON-VEHICLE INSPECTION - Step 1»(ref-422125-S11358849972011092600000) . HINT: If the accelerator pedal is released after racing the engine, the inspection is easier to perform because the vacuum inside the intake pipes increases and the air suction noise becomes louder. If Short FT and Long FT are largely different from the normal values when idling (the intake air volume is small) and almost the same as the normal values when racing the engine (the intake air volume is high), air leakage may be present. OK There is no air leakage. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
4. CHECK PURGE VSV Disconnect the purge hose (on the canister side) of the purge VSV. Start the engine. Idle the engine. Disconnect the connector of the purge VSV. Check if air flows through the purge VSV. OK Air does not flow. Connect the connector of the purge VSV. Connect the purge hose of the purge VSV. HINT: When this inspection is performed, the MIL may illuminate. After finishing the inspection, check and clear DTCs, refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . NG --> See step 59 OK: Go to next step
5. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored, refer to «FREEZE FRAME DATA»(ref-421952-S05337952652011092600000) . RESULT Freeze Frame Data Item for DTC P1605 Result Suspected Area Proceed to Calculate Load Below 90% of the current value of the vehicle*1 Mass air flow meter A AFS Voltage B1S1 3.3 V or higher*2 Air fuel ratio sensor Wire harness or connector Actual air-fuel ratio abnormal B Both freeze frame data items listed above Values are other than above - C HINT: Try to operate the vehicle under the conditions recorded in the freeze frame data which were present when the malfunction occurred. Confirm the data at this time and the data when the engine is idling (engine warmed up, no load, and shift lever in D or N) and compare these data with the freeze frame data. *1: If the mass air flow meter is malfunctioning and incorrectly measures the pressure to be less than the actual intake manifold pressure, the freeze frame data will show a low engine load value. *2: If the air fuel ratio sensor is malfunctioning and constantly outputs a value indicating the air-fuel ratio is lean, the actual air-fuel ratio will become rich and the engine may stall. B --> See step 7 C --> See step 10 A: Go to next step
6. CHECK MASS AIR FLOW METER Remove the mass air flow meter. Check for foreign matter in the airflow passage of the mass air flow meter. RESULT Result Proceed to Visible foreign matter is present A Visible foreign matter is not present B Install the mass air flow meter. HINT: Even if the results are normal, the mass air flow meter may have been malfunctioning. Continue this inspection procedure until step 22, and if there are no problems with other parts, replace the mass air flow meter (refer to step 55 55 ). B --> See step 10 A --> See step 76
7. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine, turn off all accessory switches and warm up the engine until the engine coolant temperature stabilizes. Idle the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume. Read the output voltage from the air fuel ratio sensor when increasing and decreasing the fuel injection volume. Standard Tester Display Specified Condition Control the Injection Volume (25%) Air fuel ratio sensor output voltage is below 3.1 V Control the Injection Volume (-12.5%) Air fuel ratio sensor output voltage is higher than 3.4 V RESULT Result Proceed to Abnormal A Normal B HINT: The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. Even if the results are normal, the air fuel ratio sensor may have been malfunctioning. Continue this inspection procedure until step 22, and if there are no problems with other parts, replace the air fuel ratio sensor (refer to step 55 55 ). B --> See step 10 A: Go to next step
8. CHECK TERMINAL VOLTAGE (AIR FUEL RATIO SENSOR POWER SOURCE) Disconnect the air fuel ratio sensor connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B26-2 (+B) - Body ground Ignition switch ON 11 to 14 V B27-2 (+B) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *A Bank 1 *B Bank 2 *a Front view of wire harness connector (to Air Fuel Ratio Sensor) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> See step 60 OK: Go to next step
9. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B26-1 (HA1A) - B39-17 (HA1A) Always Below 1 ohms B26-3 (A1A+) - B38-1 (A1A+) Always Below 1 ohms B26-4 (A1A-) - B38-2 (A1A-) Always Below 1 ohms B27-1 (HA2A) - B39-19 (HA2A) Always Below 1 ohms B27-3 (A2A+) - B38-7 (A2A+) Always Below 1 ohms B27-4 (A2A-) - B38-8 (A2A-) Always Below 1 ohms B26-1 (HA1A) or B39-17 (HA1A) - Body ground Always 10 kohms or higher B26-3 (A1A+) or B38-1 (A1A+) - Body ground Always 10 kohms or higher B26-4 (A1A-) or B38-2 (A1A-) - Body ground Always 10 kohms or higher B27-1 (HA2A) or B39-19 (HA2A) - Body ground Always 10 kohms or higher B27-3 (A2A+) or B38-7 (A2A+) - Body ground Always 10 kohms or higher B27-4 (A2A-) or B38-8 (A2A-) - Body ground Always 10 kohms or higher RESULT Result Proceed to Abnormal A Normal B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. B --> See step 61 A --> REPAIR OR REPLACE HARNESS OR CONNECTOR
10. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored, refer to «FREEZE FRAME DATA»(ref-421952-S05337952652011092600000) . RESULT Freeze Frame Data Item for DTC P1605 Result Proceed to Initial Engine Coolant Temp, Ambient Temperature, Initial Intake Air Temp Difference in temperature between each item is less than 10°C*1 A Difference in temperature between each item is 10°C or more*2 B HINT: *1: A long time had elapsed after stopping the engine. *2: A long time had not elapsed after stopping the engine. B --> See step 13 A: Go to next step
11. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored, refer to «FREEZE FRAME DATA»(ref-421952-S05337952652011092600000) . RESULT Freeze Frame Data Item for DTC P1605 Result Suspected Area Proceed to Initial Engine Coolant Temp, Coolant Temp, Engine Run Time Range A Engine coolant temperature sensor Thermostat A Range B Engine coolant temperature sensor B Range C - C HINT: This step is not directly related to engine stall. B --> See step 14 C --> See step 15 A: Go to next step
12. INSPECT THERMOSTAT HINT: For the thermostat inspection, refer to the following procedures, refer to «INSPECTION - Step 1»(ref-422100-S18691408332011092600000) . RESULT Result Proceed to Abnormal A Normal B HINT: This step is not directly related to engine stall. B --> See step 14 A --> See step 77
13. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored, refer to «FREEZE FRAME DATA»(ref-421952-S05337952652011092600000) . RESULT Freeze Frame Data Item for DTC P1605 Result Suspected Area Proceed to Coolant Temp 120°C or higher Engine coolant temperature sensor A Coolant Temp, Ambient Temperature Engine coolant temperature is lower than outside temperature by 15°C or more Engine coolant temperature sensor Both freeze frame data items listed above Values are other than above - B B --> See step 15 A: Go to next step
14. INSPECT ENGINE COOLANT TEMPERATURE SENSOR HINT: For the engine coolant temperature sensor inspection, refer to the following procedures, refer to «INSPECTION»(ref-421954-S34192139062011092600000) . RESULT Result Proceed to Abnormal A Normal B HINT: Even if the results are normal, the engine coolant temperature sensor may have been malfunctioning. Continue this inspection procedure until step 22, and if there are no problems with other parts, replace the engine coolant temperature sensor (refer to step 55 55 ). B --> See step 15 A --> See step 78
15. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored, refer to «FREEZE FRAME DATA»(ref-421952-S05337952652011092600000) . RESULT Freeze Frame Data Item for DTC P1605 Result Suspected Area Proceed to EVAP (Purge) VSV At least 1 of the 5 sets of freeze frame data is not 0% Purge VSV A All 5 sets of freeze frame data are 0% - B HINT: If the purge VSV is stuck closed, air-fuel ratio compensation by the purge VSV is incorrectly adjusted, and then the air-fuel ratio becomes lean and the engine may stall. B --> See step 20 A: Go to next step
16. PERFORM ACTIVE TEST USING TECHSTREAM (ACTIVATE THE VSV FOR EVAP CONTROL) Disconnect the purge hose (on the canister side) of the purge VSV. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Activate the VSV for Evap Control. Operate the purge VSV and check the airflow. OK Activate the VSV for Evap Control Specified Condition ON Air flows OFF Air does not flow RESULT Result Proceed to NG A OK B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Even if the results are normal, the purge VSV may have been malfunctioning. Continue this inspection procedure until step 22, and if there are no problems with other parts, replace the purge VSV (refer to step 55 55 ). B --> See step 20 A: Go to next step
17. INSPECT PURGE VSV Inspect the purge VSV, refer to «INSPECTION - Step 1»(ref-422126-S04491379762011092600000) . NG --> See step 62 OK: Go to next step
18. CHECK TERMINAL VOLTAGE (PURGE VSV POWER SOURCE) Disconnect the purge VSV connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B15-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Purge VSV) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> See step 63 OK: Go to next step
19. CHECK HARNESS AND CONNECTOR (PURGE VSV - ECM) Disconnect the purge VSV connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B15-2 - B38-18 (PRG) Always Below 1 ohms B15-2 or B38-18 (PRG) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 79
20. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Fuel Pump / Speed. When performing the Active Test, check for an operating sound from the fuel pump. OK Control the Fuel Pump / Speed Specified Condition ON Operating sound heard OFF Operating sound not heard RESULT Result Proceed to NG A OK B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. While performing the Active Test, make sure that there is no fuel leakage from the pipes, no signs that fuel has leaked, and no fuel smell. If the fuel pump operating noise is abnormal, proceed to step 21 below. B --> See step 22 A: Go to next step
21. INSPECT FUEL PUMP Inspect the fuel pump, refer to «INSPECTION - Step 1»(ref-422124-S20481679232011092600000) . NG --> See step 64 OK --> See step 80
22. CHECK FUEL SYSTEM Check for foreign matter such as iron particles around the fuel pump (fuel pump, fuel pump filter and inside the fuel tank), and for signs that the fuel pump was stuck. RESULT Result Proceed to There is foreign matter or signs that fuel pump was stuck A There is no foreign matter and no signs that fuel pump was stuck B HINT: If there is foreign matter such as iron particles on the fuel pump, fuel filter or fuel tank, remove the foreign matter. B --> See step 55 A --> REPAIR OR REPLACE FUEL SYSTEM
23. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored, refer to «FREEZE FRAME DATA»(ref-421952-S05337952652011092600000) . RESULT Freeze Frame Data Item for DTC P1605 Result Suspected Area Proceed to Calculate Load 110% or more of the current value of the vehicle*1 Mass air flow meter A AFS Voltage B1S1 Below 3.3 V*2 Air fuel ratio sensor Harness and connector Actual air-fuel ratio abnormal B Both freeze frame data items listed above Values are other than above - C HINT: Try to operate the vehicle under the conditions recorded in the freeze frame data which were present when the malfunction occurred. Confirm the data at this time and the data when the engine is idling (engine warmed up, no load, and shift lever in D or N) and compare these data with the freeze frame data. *1: If the mass air flow meter is malfunctioning and incorrectly measures the intake air volume to be higher than the actual volume of air flowing through the intake manifold, the freeze frame data will show a high engine load value. *2: As the air fuel ratio sensor output is low before the sensor warms up, the value at that time cannot be used for diagnosis. If the air fuel ratio sensor is malfunctioning and constantly outputs a value indicating the air-fuel ratio is rich, the actual air-fuel ratio will become lean and the engine may stall. B --> See step 25 C --> See step 28 A: Go to next step
24. CHECK MASS AIR FLOW METER Remove the mass air flow meter. Check for foreign matter in the airflow passage of the mass air flow meter. RESULT Result Proceed to Visible foreign matter is present A Visible foreign matter is not present B HINT: Even if the results are normal, the mass air flow meter may have been malfunctioning. Continue this inspection procedure until step 32, and if there are no problems with other parts, replace the mass air flow meter (refer to 55 step 55). B --> See step 28 A --> See step 81
25. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine, turn off all accessory switches and warm up the engine until the engine coolant temperature stabilizes. Idle the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume. Read the output voltage from the air fuel ratio sensor when increasing and decreasing the fuel injection volume. Standard Tester Display Specified Condition Control the Injection Volume (25%) Air fuel ratio sensor output voltage is below 3.1 V Control the Injection Volume (-12.5%) Air fuel ratio sensor output voltage is higher than 3.4 V RESULT Result Proceed to Abnormal A Normal B HINT: The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. Even if the results are normal, the air fuel ratio sensor may have been malfunctioning. Continue this inspection procedure until step 32, and if there are no problems with other parts, replace the air fuel ratio sensor (refer to 55 step 55). B --> See step 28 A: Go to next step
26. CHECK TERMINAL VOLTAGE (AIR FUEL RATIO SENSOR POWER SOURCE) Disconnect the air fuel ratio sensor connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B26-2 (+B) - Body ground Ignition switch ON 11 to 14 V B27-2 (+B) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *A Bank 1 *B Bank 2 *a Front view of wire harness connector (to Air Fuel Ratio Sensor) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> See step 65 OK: Go to next step
27. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B26-1 (HA1A) - B39-17 (HA1A) Always Below 1 ohms B26-3 (A1A+) - B38-1 (A1A+) Always Below 1 ohms B26-4 (A1A-) - B38-2 (A1A-) Always Below 1 ohms B27-1 (HA2A) - B39-19 (HA2A) Always Below 1 ohms B27-3 (A2A+) - B38-7 (A2A+) Always Below 1 ohms B27-4 (A2A-) - B38-8 (A2A-) Always Below 1 ohms B26-1 (HA1A) or B39-17 (HA1A) - Body ground Always 10 kohms or higher B26-3 (A1A+) or B38-1 (A1A+) - Body ground Always 10 kohms or higher B26-4 (A1A-) or B38-2 (A1A-) - Body ground Always 10 kohms or higher B27-1 (HA2A) or B39-19 (HA2A) - Body ground Always 10 kohms or higher B27-3 (A2A+) or B38-7 (A2A+) - Body ground Always 10 kohms or higher B27-4 (A2A-) or B38-8 (A2A-) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS AND CONNECTOR OK --> See step 82
28. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored, refer to «FREEZE FRAME DATA»(ref-421952-S05337952652011092600000) . RESULT Freeze Frame Data Item for DTC P1605 Result Proceed to Initial Engine Coolant Temp, Ambient Temperature, Initial Intake Air Temp Difference in temperature between each item is less than 10°C*1 A Difference in temperature between each item is 10°C or more*2 B HINT: *1: A long time had elapsed after stopping the engine. *2: A long time had not elapsed after stopping the engine. B --> See step 31 A: Go to next step
29. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions present when the DTC was stored which are recorded in the freeze frame data. RESULT Freeze Frame Data Item for DTC P1605 Result Suspected Area Proceed to Initial Engine Coolant Temp, Coolant Temp, Engine Run Time Range A Engine coolant temperature sensor Thermostat A Range B Engine coolant temperature B Range C - C HINT: This step is not directly related to engine stall. B --> See step 32 C --> See step 56 A: Go to next step
30. INSPECT THERMOSTAT HINT: For the thermostat inspection, refer to the following procedures, refer to «INSPECTION - Step 1»(ref-422100-S18691408332011092600000) . RESULT Result Proceed to Abnormal A Normal B HINT: This step is not directly related to engine stall. B --> See step 32 A --> See step 83
31. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored, refer to «FREEZE FRAME DATA»(ref-421952-S05337952652011092600000) . RESULT Freeze Frame Data Item for DTC P1605 Result Suspected Area Proceed to Coolant Temp 120°C or higher Engine coolant temperature sensor A Coolant Temp, Ambient Temperature Engine coolant temperature is lower than outside temperature by 15°C or more Engine coolant temperature sensor Both freeze frame data items listed above Values are other than above - B B --> See step 56 A: Go to next step
32. INSPECT ENGINE COOLANT TEMPERATURE SENSOR HINT: For the engine coolant temperature sensor inspection, refer to the following procedures, refer to «INSPECTION - Step 1»(ref-421954-S31158558512011092600000) . RESULT Result Proceed to Abnormal A Normal B HINT: Even if the results are normal, the engine coolant temperature sensor may have been malfunctioning. If there are no problems with other parts, replace the engine coolant temperature sensor (refer to step 55 55 ). B --> See step 55 A --> See step 84
33. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored, refer to «FREEZE FRAME DATA»(ref-421952-S05337952652011092600000) . RESULT Freeze Frame Data Item for DTC P1605 Result Suspected Area Proceed to Total of ISC Learning Value and ISC Feedback Value Below 80% of the current value of the vehicle*1 Throttle body with motor assembly A 120% or more of the current value of the vehicle*2 B From 80 to 120% of the current value of the vehicle - C HINT: Try to operate the vehicle under the conditions recorded in the freeze frame data which were present when the malfunction occurred. Confirm the data at this time and the data when the engine is idling (engine warmed up, no load, and shift lever in D or N) and compare these data with the freeze frame data. *1: If the throttle body with motor assembly has a temporary problem in which it cannot fully close, the intake air volume and engine speed increase. As a result, the ISC compensation amount becomes less than the standard. At this time, if the throttle body with motor assembly returns to normal and fully closes, the intake air volume will be insufficient and the engine may stall. *2: If carbon accumulates on the throttle body with motor assembly and the intake air volume decreases, the ISC compensation amount is increased to maintain the idling speed. If this situation continues, the ISC compensation amount reaches the upper limit, the idling speed cannot be maintained causing idling to become unstable, and the engine may stall. B --> See step 35 C --> See step 36 A: Go to next step
34. CHECK THROTTLE BODY WITH MOTOR ASSEMBLY Check for foreign matter and signs that the throttle body with motor assembly was stuck, and also check that the valve and shaft move smoothly during operation. RESULT Result Proceed to Abnormal A Normal B HINT: Even if the results are normal, the throttle body with motor assembly may have been malfunctioning. Continue this inspection procedure until step 40, and if there are no problems with other parts, replace the throttle body with motor assembly (refer to 55 step 55). B --> See step 36 A --> See step 85
35. CHECK THROTTLE BODY WITH MOTOR ASSEMBLY Check if carbon is in the airflow passage of the throttle body. RESULT Result Proceed to Carbon in passage A No carbon in passage B HINT: Even if the results are normal, the throttle body with motor assembly may have been malfunctioning. Continue this inspection procedure until step 40, and if there are no problems with other parts, replace the throttle body with motor assembly (refer to step 55 55 ). B --> See step 36 A --> See step 86
36. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT SYSTEM) Connect the Techstream to the DLC3. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT System (Bank 1) or Control the VVT System (Bank 2). HINT: When performing the Active Test, make sure the A/C is on and the shift lever is in P or N. Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Tester Operation Specified Condition OFF Normal engine speed ON Soon after camshaft timing oil control valve switched from OFF to ON, engine idles roughly or stalls HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. When the results of the inspection using the Active Test are normal but the valve operating noise is abnormal, check the valve for any signs of problems. If the camshaft timing oil control valve is stuck ON, the valve overlap increases and combustion worsens due to the internal EGR which may cause rough idle or cause the engine to stall. NG --> See step 66 OK: Go to next step
37. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR) Connect the Techstream to the DLC3. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Exhaust Linear (Bank1) or Control the VVT Exhaust Linear (Bank2). HINT: When performing the Active Test, make sure the A/C is on and the shift lever is in P or N. Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Tester Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. When the results of the inspection using the Active Test are normal but the valve operating noise is abnormal, check the valve for any signs of problems. If the camshaft timing oil control valve is stuck ON, the valve overlap increases and combustion worsens due to the internal EGR which may cause rough idle or cause the engine to stall. NG --> See step 67 OK: Go to next step
38. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored, refer to «FREEZE FRAME DATA»(ref-421952-S05337952652011092600000) . RESULT Freeze Frame Data Item for DTC P1605 Suspected Area Proceed to IGN Advance Knock Correct Learn Value Differs from the current value of the vehicle by 10° or more Less than 3° Engine coolant temperature sensor Mass air flow meter Knock sensor A 3° or more - B Differs from the current value of the vehicle by less than 10° - - HINT: Try to operate the vehicle under the conditions recorded in the freeze frame data which were present when the malfunction occurred. Confirm the data at this time and the data when the engine is idling (engine warmed up, no load, and shift lever in D or N) and compare these data with the freeze frame data. Even if the results are normal, the knock sensors may have been malfunctioning. If there are no problems with other parts, replace the knock sensors (refer to step 55 55 ). B --> See step 55 A: Go to next step
39. INSPECT ENGINE COOLANT TEMPERATURE SENSOR HINT: For the engine coolant temperature sensor inspection, refer to the following procedures, refer to «INSPECTION - Step 1»(ref-421954-S31158558512011092600000) . NG --> See step 68 OK: Go to next step
40. INSPECT MASS AIR FLOW METER Remove the mass air flow meter. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (THA) - 2 (E2) 20°C 2.21 to 2.69 kohms TEXT IN ILLUSTRATION *a Component without harness connected (Mass Air Flow Meter) HINT: If the intake air temperature sent to the ECM is higher than the standard due to the mass air flow meter (intake air temperature sensor) malfunctioning, the ignition timing may become delayed. NG --> See step 69 OK --> See step 87
41. CHECK TERMINAL VOLTAGE (FUEL INJECTOR POWER SOURCE) Disconnect the fuel injector assembly connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Cylinder Tester Connection Switch Condition Specified Condition No. 1 B1-1 - Body ground Ignition switch ON 11 to 14 V No. 2 B2-1 - Body ground Ignition switch ON 11 to 14 V No. 3 B3-1 - Body ground Ignition switch ON 11 to 14 V No. 4 B4-1 - Body ground Ignition switch ON 11 to 14 V No. 5 B5-1 - Body ground Ignition switch ON 11 to 14 V No. 6 B6-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Fuel Injector Assembly) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. A rapid decrease in engine speed may have been caused by a malfunction in all or multiple cylinders. (There may be an electrical malfunction in the wiring shared by all the cylinders.) NG --> See step 70 OK: Go to next step
42. CHECK TERMINAL VOLTAGE (IGNITION COIL POWER SOURCE) Disconnect the ignition coil assembly connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B7-1 (+B) - B7-4 (GND) Ignition switch ON 11 to 14 V B8-1 (+B) - B8-4 (GND) Ignition switch ON 11 to 14 V B9-1 (+B) - B9-4 (GND) Ignition switch ON 11 to 14 V B10-1 (+B) - B10-4 (GND) Ignition switch ON 11 to 14 V B11-1 (+B) - B11-4 (GND) Ignition switch ON 11 to 14 V B12-1 (+B) - B12-4 (GND) Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Ignition Coil Assembly) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. A rapid decrease in engine speed may have been caused by a malfunction in all or multiple cylinders. (There may be an electrical malfunction in the wiring shared by all the cylinders.) NG --> See step 71 OK: Go to next step
43. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored, refer to «FREEZE FRAME DATA»(ref-421952-S05337952652011092600000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Idle Spark Advn Ctrl (#1 to #6) At least one cylinder shows a value of 4° or more Fuel injector system Ignition coil system A All cylinders show a value of less than 4° - B B --> See step 45 A: Go to next step
44. CHECK FREEZE FRAME DATA Change the location of the ignition coil for the cylinder whose Idle Spark Advn Ctrl (#1 to #6) was 4° or more in step 43. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine and ECT / Data List / Idle Spark Advn Ctrl (#1 to #6). RESULT Result Proceed to Same as result in step 43 A Different from result in step 43 B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. B --> See step 72 A: Go to next step
45. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored, refer to «FREEZE FRAME DATA»(ref-421952-S05337952652011092600000) . RESULT Freeze Frame Data Item for DTC P1605 Suspected Area Proceed to A/C Signal Air Conditioner FB Val Power Steering Signal A/C Signal display changes from OFF to ON*1 Value displayed for Air Conditioner FB Val increases Does not change from OFF A/C system A Changes from OFF to ON Power steering system B A/C Signal display does not change from OFF Value displayed for Air Conditioner FB Val does not increase Changes from OFF to ON Does not change from OFF - HINT: Try to operate the vehicle under the conditions recorded in the freeze frame data which were present when the malfunction occurred. Confirm the data at this time and the data when the engine is idling (engine warmed up, no load, and shift lever in D or N) and compare these data with the freeze frame data. *1: Check not only the on/off state of the air conditioner, but also the change in air conditioner load. The normal value for the ISC learned value is engine displacement (liters) x 0.9. Even if the results are normal, the power steering system may have been malfunctioning. Continue this inspection procedure until step 47, and if there are no problems with other parts, inspect the power steering system (refer to step 55 55 ). A --> CHECK AIR CONDITIONING SYSTEM B: Go to next step
46. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored, refer to «FREEZE FRAME DATA»(ref-421952-S05337952652011092600000) . RESULT Freeze Frame Data Item for DTC P1605 Suspected Area Proceed to Electrical Load Signal or Electric Load Feedback Val Electric Load Feedback Val Difference between Engine Speed and Turbine Speed Vehicle Speed Electrical Load Signal display changes from OFF to ON*1, or value displayed for Electric Load Feedback Val increases*1 Value displayed for Electric Load Val changes - - Electrical load signal circuit A Value displayed for Electric Load Val does not change At least 1 of the 5 sets of freeze frame data is less than 100 RPM Less than 30 km/h A/T system B 30 km/h or more - C All 5 sets of freeze frame data are 100 RPM or more - - C Electrical Load Signal display does not change from OFF, or value displayed for Electric Load Feedback Val does not increase - At least 1 of the 5 sets of freeze frame data is less than 100 RPM Less than 30 km/h A/T system B 30 km/h or more - C All 5 sets of freeze frame data are 100 RPM or more - - C HINT: *1: If the Electrical Load Signal display changes from OFF to ON, or the "Electric Load Feedback Val" increases, it probably is a malfunction due to a change in electrical load. Check the generator and the continuity and connections between the generator and ECM. The normal value for the ISC learned value is engine displacement (liters) x 0.9. Even if the results are normal, the electrical load signal system and/or A/T system may have been malfunctioning. Continue this inspection procedure until step 47, and if there are no problems with other parts, inspect the electrical load system and/or A/T system (refer to step 55 55 ). B --> CHECK AUTOMATIC TRANSMISSION SYSTEM C --> See step 47 A --> See step 88
47. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored, refer to «FREEZE FRAME DATA»(ref-421952-S05337952652011092600000) . RESULT Freeze Frame Data Item for DTC P1605 Suspected Area Proceed to P Position or N Position Park/Neutral Position Switch P and N position are both OFF in at least one data set In D or R, NSW is ON Park/neutral position switch assembly A In D or R, NSW is OFF A/T system B All 5 sets of freeze frame data are ON - - C HINT: Even if the results are normal, the park/neutral position switch assembly and/or A/T system may have been malfunctioning. If there are no problems with other parts, inspect the park/neutral position switch assembly and/or A/T system (refer to step 55 55 ). B --> CHECK AUTOMATIC TRANSMISSION SYSTEM C --> See step 55 A --> CHECK PARK/NEUTRAL POSITION SWITCH
48. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored, refer to «FREEZE FRAME DATA»(ref-421952-S05337952652011092600000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Throttle Sensor Position, Calculate Load Calculate Load decreases while Throttle Sensor Position increases Mass air flow meter A Calculate Load does not decrease while Throttle Sensor Position increases - B B --> See step 50 A: Go to next step
49. CHECK MASS AIR FLOW METER Remove the mass air flow meter. Check for foreign matter in the airflow passage of the mass air flow meter. RESULT Result Proceed to Visible foreign matter is present A Visible foreign matter is not present B Install the mass air flow meter. HINT: Even if the results are normal, the mass air flow meter may have been malfunctioning. Continue this inspection procedure until step 54, and if there are no problems with other parts, replace the mass air flow meter (refer to step 55 55 ). B --> See step 50 A --> See step 89
50. CHECK TERMINAL VOLTAGE (FUEL INJECTOR POWER SOURCE) Disconnect the fuel injector assembly connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Cylinder Tester Connection Switch Condition Specified Condition No. 1 B1-1 - Body ground Ignition switch ON 11 to 14 V No. 2 B2-1 - Body ground Ignition switch ON 11 to 14 V No. 3 B3-1 - Body ground Ignition switch ON 11 to 14 V No. 4 B4-1 - Body ground Ignition switch ON 11 to 14 V No. 5 B5-1 - Body ground Ignition switch ON 11 to 14 V No. 6 B6-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Fuel Injector Assembly) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. A rapid decrease in engine speed may have been caused by a malfunction in all or multiple cylinders. (There may be an electrical malfunction in the wiring shared by all the cylinders.) NG --> See step 73 OK: Go to next step
51. CHECK TERMINAL VOLTAGE (IGNITION COIL POWER SOURCE) Disconnect the ignition coil assembly connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B7-1 (+B) - B7-4 (GND) Ignition switch ON 11 to 14 V B8-1 (+B) - B8-4 (GND) Ignition switch ON 11 to 14 V B9-1 (+B) - B9-4 (GND) Ignition switch ON 11 to 14 V B10-1 (+B) - B10-4 (GND) Ignition switch ON 11 to 14 V B11-1 (+B) - B11-4 (GND) Ignition switch ON 11 to 14 V B12-1 (+B) - B12-4 (GND) Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Ignition Coil Assembly) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. A rapid decrease in engine speed may have been caused by a malfunction in all or multiple cylinders. (There may be an electrical malfunction in the wiring shared by all the cylinders.) NG --> See step 74 OK: Go to next step
52. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Fuel Pump / Speed. When performing the Active Test, check for an operating sound from the fuel pump. OK Control the Fuel Pump / Speed Specified Condition ON Operating sound heard OFF Operating sound not heard RESULT Result Proceed to NG A OK B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. While performing the Active Test, make sure that there is no fuel leakage from the pipes, no signs that fuel has leaked, and no fuel smell. If the fuel pump operating noise is abnormal, proceed to step 53 below. B --> See step 54 A: Go to next step
53. INSPECT FUEL PUMP Inspect the fuel pump, refer to «INSPECTION - Step 1»(ref-422124-S20481679232011092600000) . NG --> See step 75 OK --> See step 90
54. CHECK FUEL SYSTEM Check for foreign matter such as iron particles around the fuel pump (fuel pump, fuel pump filter and inside the fuel tank), and for signs that the fuel pump was stuck. RESULT Result Proceed to There is foreign matter or signs that fuel pump was stuck A There is no foreign matter and no signs that fuel pump was stuck B B --> See step 55 A --> REPAIR OR REPLACE FUEL SYSTEM
55. REPLACE MALFUNCTIONING PARTS If the malfunction could not be identified in steps 3 to 22, replace the part which is suspected to be malfunctioning according to the step where an inspection was performed. Performed Step Part to Replace Step 6 Mass air flow meter Step 7 Air fuel ratio sensor Step 14 Engine coolant temperature sensor Step 16 Purge VSV Step 22 Fuel pump If the malfunction could not be identified in steps 23 to 32, replace the part which is suspected to be malfunctioning according to the step where an inspection was performed. Performed Step Part to Replace Step 24 Mass air flow meter Step 25 Air fuel ratio sensor Step 32 Engine coolant temperature sensor If the malfunction could not be identified in steps 33 to 40, replace the part which is suspected to be malfunctioning according to the step where an inspection was performed. Performed Step Part to Replace Step 34, 35 Throttle body with motor assembly Step 38 Knock sensor If the malfunction could not be identified in steps 41 to 47, inspect and repair the part which is suspected to be malfunctioning according to the step where an inspection was performed. Performed Step Inspection Step 45 A/C system inspection and repair Power steering system inspection and repair Step 46 A/T system inspection and repair Electrical load system inspection and repair Step 47 Park/neutral position switch assembly inspection and repair A/T system inspection and repair If the malfunction could not be identified in steps 48 to 54, replace the part which is suspected to be malfunctioning according to the step where an inspection was performed. Performed Step Part to Replace Step 49 Mass air flow meter HINT: Referring to the chart, inspect and repair or replace the part from the step where an inspection was performed. NEXT: Go to next step
56. CLEAR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . NEXT: Go to next step
57. PERFORM CONFIRMATION DRIVING PATTERN Check if engine stall symptoms are present. HINT: If any engine stall symptoms are present, recheck for DTCs and freeze frame data and perform an inspection. NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS OK --> END
58. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421952-S27905813582011092600000)
59. INSPECT PURGE VSV. Refer to «INSPECTION - Step 1»(ref-422126-S04491379762011092600000)
60. REPAIR POWER SOURCE CIRCUIT. Refer to «PROCEDURE - Step 2»(ref-422121-S16179541262011092600000)
61. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-421954-S24359359142011092600000)
62. REPLACE PURGE VSV. Refer to «REMOVAL»(ref-422126-S33218404612011092600000)
63. REPAIR POWER SOURCE CIRCUIT See step 3
64. REPLACE FUEL PUMP. Refer to «REMOVAL - Step 1»(ref-422124-S28924260772011092600000)
65. REPAIR POWER SOURCE CIRCUIT. Refer to «PROCEDURE - Step 2»(ref-422121-S16179541262011092600000)
66. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-421954-S26745234372011092600000)
67. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-421954-S26745234372011092600000)
68. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-421954-S30792072392011092600000)
69. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-421954-S12208818912011092600000)
70. REPAIR FUEL INJECTOR CIRCUIT. Refer to «PROCEDURE - Step 1»(ref-422119-S19927614072011092600000)
71. REPAIR POWER SOURCE CIRCUIT See step 1
72. REPLACE IGNITION COIL. Refer to «REMOVAL»(ref-421954-S28657318342011092600000)
73. REPAIR POWER SOURCE CIRCUIT. Refer to «PROCEDURE - Step 1»(ref-422119-S19927614072011092600000)
74. REPAIR POWER SOURCE CIRCUIT See step 1
75. REPLACE FUEL PUMP. Refer to «REMOVAL»(ref-422124-S40983736172011092600000)
76. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-421954-S12208818912011092600000)
77. REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-422100-S08683431582011092600000)
78. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-421954-S30792072392011092600000)
79. REPLACE ECM. Refer to «REMOVAL»(ref-421954-S13588411562011092600000)
80. CHECK FUEL PUMP CONTROL SYSTEM. Refer to «Fuel Pump Control Circuit»(ref-422119-S10206888832011092600000)
81. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-421954-S12208818912011092600000)
82. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-421954-S24359359142011092600000)
83. REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-422100-S08683431582011092600000)
84. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-421954-S30792072392011092600000)
85. REPLACE THROTTLE BODY WITH MOTOR ASSEMBLY. Refer to «REMOVAL»(ref-421954-S26809158672011092600000)
86. REPLACE THROTTLE BODY WITH MOTOR ASSEMBLY. Refer to «REMOVAL»(ref-421954-S26809158672011092600000)
87. REPLACE KNOCK SENSOR. Refer to «REMOVAL»(ref-421954-S03023696052011092600000)
88. CHECK GENERATOR CIRCUIT. Refer to «ON-VEHICLE INSPECTION - Step 4»(ref-422122-S26333496652011092600000)
89. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-421954-S12208818912011092600000)
90. CHECK FUEL PUMP CONTROL SYSTEM. Refer to «Fuel Pump Control Circuit»(ref-422119-S10206888832011092600000)
