Engine Control System (2TR-FE) (Diagnostics - Introduction): Diagnosis Toyota 4Runner V

HOW TO PROCEED WITH TROUBLESHOOTING

HINT

*: Use the Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS NEXT: Go to next step
3. CONNECT TECHSTREAM TO DLC3* HINT: If the display indicates a communication fault in the Techstream, inspect the DLC3. NEXT: Go to next step
4. CHECK DTC AND FREEZE FRAME DATA* Check DTC, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000). Check freeze frame data, refer to «FREEZE FRAME DATA»(ref-421953-S01312698402011092600000). NEXT: Go to next step
5. CLEAR DTC AND FREEZE FRAME DATA* Clear DTC, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000). Clear Freeze Frame Data, refer to «FREEZE FRAME DATA»(ref-421953-S01312698402011092600000). NEXT: Go to next step
6. CONDUCT VISUAL INSPECTION NEXT: Go to next step
7. SET CHECK MODE DIAGNOSIS* HINT: Refer to Check Mode Procedure, refer to «CHECK MODE PROCEDURE»(ref-421953-S37177155462011092600000). NEXT: Go to next step
8. CONFIRM PROBLEM SYMPTOMS Confirm problem symptoms. HINT: If the engine does not start, first perform the "CHECK DTC" procedures and "CONDUCT BASIC INSPECTION" procedures below. RESULT Result Proceed to Malfunction does not occur A Malfunction occurs B B --> GO TO STEP 10 A: Go to next step
9. SIMULATE SYMPTOMS NEXT: Go to next step
10. CHECK FOR DTC* Refer to DTC Check / Clear, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000). RESULT Result Proceed to Trouble code output A No trouble code output B B --> GO TO 12 STEP 12 A: Go to next step
11. REFER TO DTC CHART Refer to Diagnostic Trouble Code Chart, refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421953-S08108164442011092600000). NEXT --> GO TO 14 STEP 14
12. CONDUCT BASIC INSPECTION HINT: Refer to Basic Inspection, refer to «BASIC INSPECTION»(ref-421953-S20226449612011092600000). RESULT Result Proceed to Malfunctioning parts not confirmed A Malfunctioning parts confirmed B B --> GO TO 17 STEP 17 A: Go to next step
13. REFER TO PROBLEM SYMPTOMS TABLE Refer to Problem Symptoms Table, refer to «PROBLEM SYMPTOMS TABLE»(ref-421953-S21099219972011092600000). RESULT Result Proceed to Malfunctioning circuit confirmed A Malfunctioning parts confirmed B B --> GO TO 17 STEP 17 A: Go to next step
14. CHECK ECM POWER SOURCE CIRCUIT Refer to ECM Power Source Circuit, refer to «ECM Power Source Circuit»(ref-422140-S00333349102011092600000). NEXT: Go to next step
15. CONDUCT CIRCUIT INSPECTION RESULT Result Proceed to Malfunction not confirmed A Malfunction confirmed B B --> GO TO 18 STEP 18 A: Go to next step
16. CHECK FOR INTERMITTENT PROBLEMS Refer to Check for Intermittent Problems, refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-421953-S36764272642011092600000). NEXT --> GO TO 18 STEP 18
17. CONDUCT PARTS INSPECTION NEXT: Go to next step
18. IDENTIFY PROBLEM NEXT: Go to next step
19. ADJUST AND/OR REPAIR NEXT: Go to next step
20. CONDUCT CONFIRMATION TEST NEXT --> END

BASIC INSPECTION

When the malfunction cannot be confirmed by the DTC check, troubleshooting should be carried out for all circuits considered to be possible causes of the problem. In many cases, by carrying out the basic engine check shown in the following flowchart, the location of the problem can be found quickly and efficiently. Therefore, using this check is essential when troubleshooting the engine.

1. CHECK BATTERY VOLTAGE NOTE: Conduct this check with the engine stopped and the ignition switch off. Result Result Proceed to 11 V or higher OK Below 11 V NG NG --> CHARGE OR REPLACE BATTERY OK: Go to next step
2. CHECK WHETHER ENGINE CRANKS NG --> PROCEED TO PROBLEM SYMPTOMS TABLE, refer to «PROBLEM SYMPTOMS TABLE»(ref-421953-S21099219972011092600000) OK: Go to next step
3. CHECK WHETHER ENGINE STARTS NG --> GO TO 6 STEP 6 OK: Go to next step
4. CHECK AIR FILTER Visually check that the air filter is not excessively contaminated with dirt or oil. NG --> REPLACE AIR FILTER OK: Go to next step
5. CHECK IDLE SPEED NG --> TROUBLESHOOT IDLE SPEED AND PROCEED TO NEXT STEP OK: Go to next step
6. CHECK FUEL PRESSURE NG --> TROUBLESHOOT FUEL PRESSURE AND PROCEED TO NEXT STEP OK: Go to next step
7. CHECK FOR SPARK NG --> TROUBLESHOOT IGNITION SYSTEM AND PROCEED TO NEXT STEP OK --> PROCEED TO PROBLEM SYMPTOMS TABLE, refer to «PROBLEM SYMPTOMS TABLE»(ref-421953-S21099219972011092600000)

PROBLEM SYMPTOMS TABLE

HINT

1. Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
2. Inspect the fuses and relays related to this system before inspecting the suspected areas below.

SFI SYSTEM

Scheme 35

HINT

The standard voltage between each pair of ECM terminals is shown in the table below. The appropriate conditions for checking each pair of terminals are also indicated. The result of checks should be compared with the standard voltage for that pair of terminals displayed in the "Specified Condition" column. The illustration above can be used as a reference to identify the ECM terminal locations.

*1: The ECM terminal voltage is constant regardless of the output voltage from the sensor.

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

1. WAVEFORM 1 Fuel injector ECM Terminal Name Between #10 (to 40) and E01 Tester Range 20 V/DIV., 20 msec./DIV. Condition Idling HINT: The wavelength becomes shorter as the engine speed increases.
2. WAVEFORM 2 Igniter IGT signal (from ECM to igniter) Igniter IGF signal (from igniter to ECM) ECM Terminal Name (a) Between IGT (1 to 4) and E1 (b) Between IGF1 and E1 Tester Range 2 V/DIV., 20 msec./DIV. Condition Idling HINT: The wavelength becomes shorter as the engine speed increases.
3. WAVEFORM 3 Camshaft position sensor Crankshaft position sensor ECM Terminal Name (a) Between G2 and NE- (b) Between NE+ and NE- Tester Range 5 V/DIV., 20 msec./DIV. Condition Idling HINT: The wavelength becomes shorter as the engine speed increases.
4. WAVEFORM 4 Throttle actuator positive terminal ECM Terminal Name Between M+ and ME01 Tester Range 5 V/DIV., 1 msec./DIV. Condition Idling with warm engine HINT: The duty ratio varies depending on the throttle actuator operation.
5. WAVEFORM 5 Throttle actuator negative terminal ECM Terminal Name Between M- and ME01 Tester Range 5 V/DIV., 1 msec./DIV. Condition Idling with warm engine HINT: The duty ratio varies depending on the throttle actuator operation.
6. WAVEFORM 6 Heated oxygen sensor ECM Terminal Name Between OX1B and E2 Tester Range 0.2 V/DIV., 200 msec./DIV. Condition Engine speed maintained at 2500 RPM for 2 minutes after warming up engine HINT: In the Data List, item O2S B1S2 shows the ECM input values from the heated oxygen sensor.
7. WAVEFORM 7 Air fuel ratio sensor heater ECM Terminal Name Between HA1A and E04 Tester Range 5 V/DIV., 10 msec./DIV. Condition Idling with warm engine HINT: The wavelength varies in accordance with the engine operating condition.
8. WAVEFORM 8 Knock sensor ECM Terminal Name Between KNK1 and EKNK Tester Range 1 V/DIV., 1 msec./DIV. Condition Engine speed maintained at 4000 RPM after warming up engine HINT: The wavelength becomes shorter as the engine speed increases. The waveforms and amplitudes displayed differ slightly depending on the vehicle.
9. WAVEFORM 9 Camshaft timing oil control valve ECM Terminal Name Between OC1+ and OC1- Tester Range 5 V/DIV., 1 msec./DIV. Condition Idling HINT: The wavelength becomes shorter as the engine speed increases.
10. WAVEFORM 10 Purge VSV ECM Terminal Name Between PRG and E01 Tester Range 5 V/DIV., 50 msec./DIV. Condition Idling HINT: If the waveform is not similar to the illustration, check the waveform again after idling for 10 minutes or more.
11. WAVEFORM 11 Engine speed signal ECM Terminal Name Between TACH and E1 Tester Range 5 V/DIV., 10 msec./DIV. Condition Idling HINT: The wavelength becomes shorter as the engine speed increases.
12. WAVEFORM 12 Vehicle speed signal ECM Terminal Name Between SPD and E1 Tester Range 5 V/DIV., 20 msec./DIV. Condition Driving at 20 km/h (12 mph) HINT: The wavelength becomes shorter as the vehicle speed increases.
13. WAVEFORM 13 CAN communication signal (reference) ECM Terminal Name Between CANH and E1 Tester Range 1 V/DIV., 10 μs/DIV. Condition Ignition switch ON
14. WAVEFORM 14 CAN communication signal (reference) ECM Terminal Name Between CANL and E1 Tester Range 1 V/DIV., 10 μs/DIV. Condition Ignition switch ON
15. WAVEFORM 15 Terminal DI of air injection control driver ECM Terminal Name Between AIDI and E1 Tester Range 5 V/DIV., 20 msec./DIV. Condition Performing Active Test using Techstream (air injection system) HINT: The wavelength changes when the air injection control driver detects malfunctions in the air injection system.

Scheme 51

1. DESCRIPTION When troubleshooting OBD II (On-Board Diagnostics) vehicles, the Techstream (complying with SAE J1987) must be connected to the DLC3 (Data Link Connector 3) of the vehicle. Various data in the vehicle's ECM (Engine Control Module) can then be read. OBD II regulations require that the vehicle's on-board computer illuminate the MIL (Malfunction Indicator Lamp) on the instrument panel when the computer detects a malfunction in: (a) The emission control systems and components (b) The powertrain control components which affect vehicle emissions (c) The computer itself In addition, the applicable DTCs (Diagnostic Trouble Codes) prescribed by SAE J2012 are stored in the ECM memory. If the malfunction does not recur in 3 consecutive trips, the MIL turns off automatically but the DTCs remain stored in the ECM memory. To check DTCs, connect the Techstream to the DLC3. The Techstream displays DTCs, freeze frame data and a variety of engine data. The DTCs and freeze frame data can be cleared with the Techstream, refer to «FREEZE FRAME DATA»(ref-421953-S01312698402011092600000). In order to enhance OBD function on vehicles and develop the Off-Board diagnosis system, Controller Area Network (CAN) communication is used in this system. CAN is a network which uses a pair of data transmission lines spanning multiple computers and sensors. It allows for high speed communication between systems and simplification of the wire harness connections. Since this system is equipped with CAN communication, connecting the Techstream is necessary to display any information from the ECM. Also, the communication between the Techstream and ECM uses CAN communication signals. When confirming DTCs and ECM data, connect the Techstream to the DLC3.
2. NORMAL MODE AND CHECK MODE The diagnosis system operates in normal mode during normal vehicle use. In normal mode, 2 trip detection logic is used to ensure accurate detection of malfunctions. Check mode is also available as an option for technicians. In check mode, 1 trip detection logic is used increase the system's ability to detect malfunctions, including intermittent problems, when simulating malfunction symptoms (Techstream only) Refer to «CHECK MODE PROCEDURE»(ref-421953-S37177155462011092600000).
3. 2 TRIP DETECTION LOGIC When a malfunction is first detected, the DTC is temporarily stored in the ECM memory (1st trip). If the same malfunction is detected during the next subsequent driving cycle, the MIL is illuminated (2nd trip).
4. FREEZE FRAME DATA Freeze frame data records the engine conditions (fuel system, calculated load, engine coolant temperature, fuel trim, engine speed, vehicle speed, etc.) when a malfunction is detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred.
5. DLC3 (Data Link Connector 3) The vehicle's ECM uses the ISO 15765-4 for communication protocol. The terminal arrangement of the DLC3 complies with SAE J1962 and matches the ISO 15765-4 format. Symbol (Terminal No.) Terminal Description Condition Specified Condition SIL (7) - SG (5) Bus "+" line During transmission Pulse generation CG (4) - Body ground Chassis ground Always Below 1 ohms SG (5) - Body ground Signal ground Always Below 1 ohms BAT (16) - Body ground Battery positive Always 9 to 14 V CANH (6) - CANL (14) CAN bus line Ignition switch off* 54 to 69 ohms CANH (6) - Battery positive HIGH-level CAN bus line Ignition switch off* 6 kohms or higher CANH (6) - CG (4) HIGH-level CAN bus line Ignition switch off* 200 ohms or higher CANL (14) - Battery positive LOW-level CAN bus line Ignition switch off* 6 kohms or higher CANL (14) - CG (4) LOW-level CAN bus line Ignition switch off* 200 ohms or higher HINT: *: Before measuring the resistance, leave the vehicle as is for at least 1 minute and do not operate the ignition switch, any other switches or the doors. HINT: The DLC3 is the interface prepared for reading various data from the vehicle's ECM. After connecting the cable of the Techstream, turn the ignition switch on and turn the Techstream ON. If a communication failure message is displayed on the Techstream screen (on the Techstream: Unable to Connect to VIM), a problem exists in either the vehicle or Techstream. In order to identify the location of the problem, connect the Techstream to another vehicle. If communication is normal: Inspect the DLC3 on the original vehicle. If communication is impossible: The problem is probably with the Techstream itself. Consult the Service Department listed in the instruction manual.
6. BATTERY VOLTAGE Standard voltage 11 to 14 V If the voltage is below 11 V, recharge the battery before proceeding.
7. MIL (Malfunction Indicator Lamp) The MIL is illuminated when the ignition switch is first turned to ON (the engine is not running). The MIL should turn off when the engine is started. If the MIL remains illuminated, the diagnosis system has detected a malfunction or abnormality in the system. HINT: If the MIL is not illuminated when the ignition switch is first turned to ON, check the MIL circuit, refer to «MIL Circuit»(ref-422140-S00206108072011092600000).
8. ALL READINESS HINT: With "ALL READINESS" you can check whether or not the DTC judgment has been completed by using the Techstream. You should check "ALL READINESS" after simulating malfunction symptoms or for validation after finishing repairs. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream ON. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000). Turn the ignition switch off and wait for at least 30 seconds. Perform the DTC judgment driving pattern to run the DTC judgment. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTCs to be confirmed. Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit

DTC CHECK / CLEAR

Note. When the diagnosis system is changed from normal mode to check mode or vice versa, all DTCs and freeze frame data recorded in normal mode are cleared. Before changing modes, always check and make a note of DTCs and freeze frame data.

HINT

1. DTCs which are stored in the ECM can be displayed on the Techstream. The Techstream can display the current, pending and permanent DTCs.
2. If a malfunction is detected during the current driving cycle, current and permanent DTCs are stored.
3. Some DTCs are not stored if the ECM does not detect the same malfunction again during a second consecutive driving cycle. However, such malfunctions, detected on only one occasion, are stored as pending DTCs.
4. Current and pending DTCs can be cleared by using the Techstream or by disconnecting the cable from the negative battery terminal. However, permanent DTCs cannot be cleared using either of these two methods.
5. After clearing current DTCs using the Techstream (or by disconnecting the cable from the negative battery terminal), permanent DTCs can be cleared when the system is determined to be normal for the relevant DTCs and then the universal trip is performed. The driving pattern to obtain a normal judgment is described under the "Confirmation Driving Pattern" for the respective DTC.

2 TRIP DETECTION EXAMPLES

Scheme 52

Scheme 53

HINT

1. Obtaining a normal judgment and performing a universal trip driving pattern can be done in the same driving cycle or in different driving cycles.
2. It is unnecessary to obtain a normal judgment if the DTCs are misfire or fuel system DTCs.

Scheme 54

1. CHECK DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check the DTCs and freeze frame data, and then write them down. Check the details of the DTCs, refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421953-S08108164442011092600000).
2. CLEAR DTC (Pending and Current DTC using Techstream) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Clear the DTCs.
3. CLEAR DTC (Pending and Current DTC without using Techstream) Perform either of the following operations: Disconnect the cable from the negative (-) battery terminal for more than 1 minute. Remove the EFI and ETCS fuses from the engine room relay block located inside the engine compartment for more than 1 minute.
4. CLEAR PERMANENT DTC HINT: Even if the following procedure is not performed, permanent DTCs are cleared by obtaining a normal judgment during 3 consecutive driving cycles. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check if permanent DTCs are stored. HINT: If permanent DTCs are not output, it is not necessary to continue this procedure. Clear DTCs. Perform the respective confirmation driving patterns in order to obtain a normal judgment for the output DTCs. HINT: Confirmation driving patterns do not need to be performed for misfire and fuel system DTCs. For the confirmation driving pattern, refer to the procedures for the relevant DTC, refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421953-S08108164442011092600000). Perform the universal trip. HINT: The driving pattern to obtain a normal judgment and the universal trip driving pattern can be performed consecutively in the same driving cycle. Idle the engine for 30 seconds or more. Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more. HINT: It is possible to complete the drive pattern even if the vehicle decelerates to less than 40 km/h (25 mph) during the driving cycle provided that the vehicle is driven at 40 km/h (25 mph) or more for a total of 5 minutes. Allow 10 minutes or more to elapse from the time the engine is started. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check that the permanent DTCs have been cleared. HINT: The permanent DTCs are cleared when the universal trip is completed.

Scheme 55

1. DESCRIPTION Freeze frame data records the engine conditions (fuel system information, calculated load, engine coolant temperature, fuel trim, engine speed, vehicle speed, etc.) when a malfunction is detected. When troubleshooting, it can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was Lean or Rich, and other data from the time the malfunction occurred. HINT: If it is impossible to duplicate the problem even though a DTC is output, confirm the freeze frame data. The ECM records engine conditions in the form of freeze frame data every 0.5 seconds. Using the Techstream, 5 separate sets of freeze frame data can be checked. 3 data sets from before the DTC was stored 1 data set from when the DTC was stored 1 data set from after the DTC was stored These data sets can be used to simulate the condition of the vehicle from around the time of the occurrence of the malfunction. The data may assist in identifying the cause of the malfunction, and in judging whether it was temporary or not.
2. LIST OF FREEZE FRAME DATA Label (Tester Display) Measurement Item/Range Diagnostic Note Vehicle Speed Vehicle speed Speed indicated on the speedometer. Engine Speed Engine speed - Calculate Load Calculated load Load calculated by the ECM. Vehicle Load Vehicle load - MAF Mass air flow volume If the value is approximately 0.0 g/sec: Mass air flow meter power source circuit is open or shorted. VG circuit is open or shorted. If the value is 160.0 g/sec or more: E2G circuit is open. Atmosphere Pressure Atmospheric pressure - Coolant Temp Engine coolant temperature If the value is -40°C, the sensor circuit is open. If the value is 140°C, the sensor circuit is shorted. Intake Air Intake air temperature If the value is -40°C, the sensor circuit is open. If the value is 140°C, the sensor circuit is shorted. Engine Run Time Accumulated engine running time - Initial Engine Coolant Temp Initial engine coolant temperature - Initial Intake Air Temp Initial intake air temperature - Battery Voltage Battery voltage - Accel Sens. No. 1 Volt % Absolute No. 1 accelerator pedal position - Accel Sens. No. 2 Volt % Absolute No. 2 accelerator pedal position - Throttle Sensor Volt % Throttle sensor position Read the value with the ignition switch ON (do not start engine). Throttle Sensor #2 Volt % Throttle sensor position #2 - Throttle Sensor Position Throttle position Read the value with the ignition switch ON (do not start engine). Throttle Motor DUTY Throttle actuator - Throttle Position Throttle position For use when engine stall, starting problems or rough idle is present. ISC Flow Flow rate calculated using information from each sensor For use when engine stall, starting problems or rough idle is present. ISC Position Requested opening amount calculated using ISC control For use when engine stall, starting problems or rough idle is present. ISC Feedback Value ISC feedback compensation amount For use when engine stall, starting problems or rough idle is present. ISC Learning Value ISC learned compensation amount For use when engine stall, starting problems or rough idle is present. Electric Load Feedback Val Compensation flow rate according to electrical load For use when engine stall, starting problems or rough idle is present. Air Conditioner FB Val Compensation flow rate according to air conditioner load For use when engine stall, starting problems or rough idle is present. PS Feedback Val Compensation flow rate according to power steering load For use when engine stall, starting problems or rough idle is present. Low Revolution Control Low engine speed control operation state For use when engine stall, starting problems or rough idle is present. Neutral Control Neutral control operation state For use when engine stall, starting problems or rough idle is present. N Range Status Shift lever N status For use when engine stall, starting problems or rough idle is present. Injector (Port) Injection period of No. 1 cylinder - Injection Volum (Cylinder 1) Injection volume - Fuel Pump/Speed Status Fuel pump status - Vacuum Pump Key-off EVAP system leak detection pump status Refer to EVAP System (. Refer to «EVAP System»(ref-422140-S39023177172011092600000) ). EVAP (Purge) VSV EVAP purge VSV duty ratio - Evap Purge Flow Ratio of evaporative purge flow to intake air volume - Purge Density Learn Value Purge density learned value - EVAP System Vent Valve Key-off EVAP system vent valve status - EVAP Purge VSV EVAP purge VSV - Purge Cut VSV Duty Purge cut VSV duty - Target Air-Fuel Ratio Air-fuel ratio - AF Lambda B1S1 Fuel trim at air fuel ratio sensor - AFS Voltage B1S1 Air fuel ratio sensor output Performing the Control the Injection Volume or Control the Injection Volume for A/F Sensor function of the Active Test enables the technician to check the output voltage of the air fuel ratio sensor. AFS Current B1S1 Air fuel ratio sensor current - A/F Heater Duty #1 Air fuel ratio sensor heater duty ratio - O2S B1S2 Heated oxygen sensor output Performing the Control the Injection Volume or Control the Injection Volume for A/F Sensor function of the Active Test enables the technician to check the output voltage of the heated oxygen sensor. O2S Impedance B1S2 Sub heated oxygen sensor impedance - O2 Heater B1S2 Heated oxygen sensor heater - O2 Heater Curr Val B1S2 Heated oxygen sensor current - Short FT #1 Short-term fuel trim Short-term fuel compensation is used to maintain the air-fuel ratio at the stoichiometric air-fuel ratio. Long FT #1 Long-term fuel trim Overall fuel compensation is carried out in the long term to compensate for a continual deviation of the short-term fuel trim from the central value. Total FT #1 Total fuel trim - Fuel System Status #1 Fuel system status (Bank 1) OL (Open Loop): Has not yet satisfied the conditions to go closed loop. CL (Closed Loop): Using the heated oxygen sensor as feedback for fuel control. OLDrive: Open loop due to driving conditions (fuel enrichment). OLFault: Open loop due to a detected system fault. CLFault: Closed loop but the heated oxygen sensor, which is used for fuel control, is malfunctioning. Fuel System Status #2 Fuel system status (Bank 2) - Air pump pressure (Absolute) Air pump pressure - Air Pump Pulsation Pressure Air pump pulsation pressure - Secondary Air Control VSV Secondary air injection system status - 2nd Air System Status Secondary air system status - AI Test Secondary air injection system operation prohibition - IGN Advance Ignition timing advance for No. 1 cylinder - Knock Feedback Value Knocking feedback value - Knock Correct Learn Value Knocking correction learned value - Idle Spark Advn Ctrl #1 Individual cylinder timing advance compensation amount (No. 1) For use when engine stall, starting problems or rough idle is present. Idle Spark Advn Ctrl #2 Individual cylinder timing advance compensation amount (No. 2) For use when engine stall, starting problems or rough idle is present. Idle Spark Advn Ctrl #3 Individual cylinder timing advance compensation amount (No. 3) For use when engine stall, starting problems or rough idle is present. Idle Spark Advn Ctrl #4 Individual cylinder timing advance compensation amount (No. 4) For use when engine stall, starting problems or rough idle is present. Actual VVT Angle #1 VVT angle status - VVT Control Status #1 VVT control status - VVT Advance Fail VVT control failure status - Catalyst Temp B1S1 Catalyst temperature - Catalyst Temp B1S2 Catalyst temperature - Starter Signal Starter signal - Power Steering Signal Power steering signal - Neutral Position SW Signal Park/neutral position switch signal - Stop Light Switch Stop light switch - A/C Signal A/C signal - Closed Throttle Position SW Closed throttle position switch - Fuel Cut Condition Fuel cut condition - Immobilizer Communication Immobilizer communication - TC Terminal TC terminal status - Time after DTC Cleared Cumulative time after DTCs cleared - Distance from DTC Cleared Accumulated distance driven after DTCs cleared - Warm-up Cycle Cleared DTC Warm-up cycles after DTCs cleared - Dist Batt Cable Disconnect Total distance vehicle driven after battery cable disconnected - IG OFF Elapsed Time Cumulative time after ignition switch off - TC and TE1 TC and CG (TE1) terminals of DLC3 - Ignition Trig. Count Ignition counter - Cylinder #1 Misfire Count Cylinder #1 misfire count - Cylinder #2 Misfire Count Cylinder #2 misfire count - Cylinder #3 Misfire Count Cylinder #3 misfire count - Cylinder #4 Misfire Count Cylinder #4 misfire count - All Cylinders Misfire Rate Misfire count of all cylinders - Misfire RPM Misfire RPM - Misfire Load Misfire load - Misfire Margin Misfire monitoring - Catalyst OT MF F/C Fuel cut to prevent misfire causing catalyst overheating - Cat OT MF F/C History History of fuel cut to prevent misfire causing catalyst overheating - Cat OT MF F/C Cylinder#1 Display of fuel cut operation in No. 1 cylinder (if certain level of misfire malfunction is detected) - Cat OT MF F/C Cylinder#2 Display of fuel cut operation in No. 2 cylinder (if certain level of misfire malfunction is detected) - Cat OT MF F/C Cylinder#3 Display of fuel cut operation in No. 3 cylinder (if certain level of misfire malfunction is detected) - Cat OT MF F/C Cylinder#4 Display of fuel cut operation in No. 4 cylinder (if certain level of misfire malfunction is detected) - Engine Speed (Starter Off) Engine speed when starter off For use when engine stall, starting problems or rough idle is present. Starter Count Number of times starter turned on after ignition switch turned to ON For use when engine stall, starting problems or rough idle is present. Run Dist of Previous Trip Distance driven during previous trip For use when engine stall, starting problems or rough idle is present. Engine Starting Time Time elapsed after engine started (interval between ignition switch ON and off) For use when engine stall, starting problems or rough idle is present. Previous Trip Coolant Temp Engine coolant temperature during previous trip For use when engine stall, starting problems or rough idle is present. Previous Trip Intake Temp Intake air temperature during previous trip For use when engine stall, starting problems or rough idle is present. Engine Oil Temperature Engine oil temperature (estimated temperature) For use when engine stall, starting problems or rough idle is present. Previous Trip Eng Oil Temp Engine oil temperature during previous trip For use when engine stall, starting problems or rough idle is present. Ambient Temp for A/C Ambient temperature for A/C For use when engine stall, starting problems or rough idle is present. Previous Trip Ambient Temp Ambient temperature during previous trip For use when engine stall, starting problems or rough idle is present. Engine Start Hesitation History of hesitation during engine start For use when engine stall, starting problems or rough idle is present. Low Rev for Eng Start History of low engine speed after engine start For use when engine stall, starting problems or rough idle is present. Minimum Engine Speed Minimum engine speed For use when engine stall, starting problems or rough idle is present. ACT VSV A/C cut status for Active Test - Idle Fuel Cut Fuel cut at idle ON: The throttle valve is fully closed and the engine speed is more than 3500 RPM. FC TAU Fuel cut during very light load Fuel cut is being performed under a very light load to prevent the engine combustion from becoming incomplete. Immobilizer Fuel Cut Status of the immobilizer fuel cut - Electrical Load Signal 1 Electrical load signal - Electrical Load Signal 2 Electrical load signal

DATA LIST / ACTIVE TEST

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List. According to the display on the Techstream, read the Data List. Tester Display Measurement Item/Range Normal Condition Diagnostic Note Vehicle Speed Vehicle speed/ Min.: 0 km/h, Max.: 255 km/h Actual vehicle speed The speed indicated on the speedometer. Engine Speed Engine speed/ Min.: 0 RPM, Max.: 16383 RPM 600 to 700 RPM: Idling - Calculated Load Lode calculated by ECM/ Min.: 0%, Max.: 100% 11 to 26%: Idling 12 to 27%: Running without load (2500 RPM) - Vehicle Load Vehicle load/ Min.: 0%, Max.: 25700% Actual vehicle load - MAF Air flow rate from MAF meter/ Min.: 0 g/sec, Max.: 655.35 g/sec 2.0 to 4.5 g/sec: Idling If the value is approximately 0.0 g/sec: The mass air flow meter power source circuit is open. The VG circuit is open or shorted. If the value is 160 g/sec or more: The E2G circuit is open. Atmosphere Pressure Atmospheric pressure/ Min.: 0 kPa, Max.: 255 kPa Equivalent to atmospheric pressure (absolute pressure) - Coolant Temp Engine coolant temperature/ Min.: -40°C, Max.: 215°C 80 to 100°C (176 to 212°F): After warming up If the value is -40°C (-40°F): the sensor circuit is open. If the value is 140°C (284°F): the sensor circuit is shorted. Intake Air Intake air temperature/ Min.: -40°C, Max.: 140°C Equivalent to ambient air temperature If the value is -40°C (-40°F): the sensor circuit is open. If the value is 140°C (284°F): the sensor circuit is shorted. Engine Run Time Engine run time/ Min.: 0 s, Max.: 65535 s Time after engine start Service data. Initial Engine Coolant Temp Initial engine coolant temperature/ Min.: -40°C, Max.: 119.3°C Engine coolant temperature when engine started Service data. Initial Intake Air Temp Initial intake air temperature/ Min.: -40°C, Max.: 119.3°C Intake air temperature when engine started Service data. Battery Voltage Battery voltage/ Min.: 0 V, Max.: 65.535 V 11 to 14 V: Idling - Accelerator Position Accelerator pedal position/ Min.: 0%, Max.: 399.9% Actual accelerator pedal position - Accel Sens. No. 1 Volt % Absolute No. 1 accelerator pedal position/ Min.: 0%, Max.: 100% 10 to 22%: Accelerator pedal released 54 to 86%: Accelerator pedal fully depressed - Accel Sens. No. 2 Volt % Absolute No. 2 accelerator pedal position/ Min.: 0%, Max.: 100% 12 to 42%: Accelerator pedal released 66 to 98%: Accelerator pedal fully depressed - Accel Sensor Out No. 1 No. 1 accelerator pedal position sensor voltage/ Min.: 0 V, Max.: 4.98 V 0.5 to 1.1 V: Accelerator pedal released 2.6 to 4.5 V: Accelerator pedal fully depressed - Accel Sensor Out No. 2 No. 2 accelerator pedal position sensor voltage/ Min.: 0 V, Max.: 4.98 V 1.2 to 2.0 V: Accelerator pedal released 3.4 to 5.0 V: Accelerator pedal fully depressed - Accelerator Idle Position Whether or not accelerator pedal position sensor detecting idle/ ON or OFF ON: Idling - Accel Fully Close Learn #1 Accelerator fully closed learned value No. 1/ Min.: 0 deg, Max.: 124.5 deg - ETCS service data. Accel Fully Close Learn #2 Accelerator fully closed learned value No. 2/ Min.: 0 deg, Max.: 124.5 deg - ETCS service data. Throttle Sensor Volt % Throttle sensor positioning/ Min.: 0% Max.: 100% 10 to 22%: Accelerator pedal released 64 to 96%: Accelerator pedal fully depressed A calculated value based on VTA1. Throttle Sensor #2 Volt % Throttle sensor positioning #2/ Min.: 0%, Max.: 100% 42 to 62%: Accelerator pedal released 92 to 100%: Accelerator pedal fully depressed A calculated value based on VTA2. ST1 Brake pedal signal/ ON or OFF ON: Brake pedal depressed - System Guard System guard/ ON or OFF - ETCS service data. Open Side Malfunction Open side malfunction/ ON or OFF - ETCS service data. Throttle Idle Position Whether or not throttle position sensor detecting idle/ ON or OFF ON: Accelerator pedal released OFF: Accelerator pedal depressed - Throttle Require Position Required throttle position/ Min.: 0 V, Max.: 4.98 V 0.5 to 1.1 V: Idling - Throttle Sensor Position* Throttle sensor position/ Min.: 0%, Max.: 100% 0%: Accelerator pedal released 50 to 80%: Accelerator pedal fully depressed Value for the recognition of the throttle opening angle for the ECM. Throttle Position No. 1 No. 1 throttle position/ Min.: 0 V, Max.: 4.98 V 0.5 to 1.1 V: Accelerator pedal released 3.2 to 4.8 V: Accelerator pedal fully depressed 0.6 to 1.4 V: Fail-safe operating - Throttle Position No. 2 No. 2 throttle position/ Min.: 0 V, Max.: 4.98 V 2.1 to 3.1 V: Accelerator pedal released 4.6 to 5.0 V: Accelerator pedal fully depressed 2.1 to 3.1 V: Fail-safe operating - Throttle Position Command Throttle position command value/ Min.: 0 V, Max.: 4.980 V 0.5 to 4.8 V - Throttle Sens Open Pos#1 Throttle position sensor No. 1/ Min.: 0 V, Max.: 4.980 V 0.6 to 1.4 V ETCS service data. Throttle Sens Open Pos#2 Throttle position sensor No. 2/ Min.: 0 V, Max.: 4.980 V 1.7 to 2.5 V ETCS service data. Throttle Motor Current Throttle actuator current/ Min.: 0 A, Max.: 19.9 A 0 to 3.0 A: Idling ETCS service data. Throttle Motor DUTY Throttle actuator/ Min.: 0% Max.: 100% 10 to 22%: Idling after engine warmed up ETCS service data. Throttle Motor Duty (Open) Throttle motor duty ratio (open)/ Min.: 0%, Max.: 255% 0 to 40%: Idling ETCS service data. Throttle Motor Duty (Close) Throttle motor duty ratio (close)/ Min.: 0%, Max.: 255% 0 to 40%: Idling ETCS service data. Throttle Fully Close Learn Throttle valve fully closed learned value/ Min.: 0 V, Max.: 4.98 V 0.4 to 1.0 V: Accelerator pedal released - +BM Voltage +BM voltage/ Min.: 0, Max.: 79.998 V 11 to 14 V: Ignition switch ON and system normal ETCS service data. Actuator Power Supply Actuator power supply/ ON or OFF ON: Ignition switch ON and system normal OFF: ETCS has failed ETCS service data. Throttle Position Throttle valve opening angle/ Min.: 0 deg, Max.: 499.99 deg - For use when engine stall, starting problems or rough idle is present. ISC Flow Flow rate calculated using information from each sensor/ Min.: 0 L/s, Max.: 79.99 L/s - For use when engine stall, starting problems or rough idle is present. ISC Position Requested opening amount calculated using ISC control/ Min.: 0 deg, Max.: 499.99 deg - For use when engine stall, starting problems or rough idle is present. ISC Feedback Value ISC feedback compensation amount/ Min.: -40 L/s, Max.: 39.99 L/s - For use when engine stall, starting problems or rough idle is present. ISC Learning Value ISC learned compensation amount/ Min.: -40 L/s, Max.: 39.99 L/s - For use when engine stall, starting problems or rough idle is present. Electric Load Feedback Val Compensation flow rate according to electrical load/ Min.: -40 L/s, Max.: 39.99 L/s - For use when engine stall, starting problems or rough idle is present. Air Conditioner FB Val Compensation flow rate according to air conditioner load/ Min.: -40 L/s, Max.: 39.99 L/s - For use when engine stall, starting problems or rough idle is present. PS Feedback Val Compensation flow rate according to power steering load/ Min.: -40 L/s, Max.: 39.99 L/s - For use when engine stall, starting problems or rough idle is present. Low Revolution Control Low engine speed control operation state/ ON or OFF - For use when engine stall, starting problems or rough idle is present. Neutral Control Neutral control operation state/ ON or OFF - For use when engine stall, starting problems or rough idle is present. N Range Status Shift lever N status/ ON or OFF - For use when engine stall, starting problems or rough idle is present. Injector (Port) Injection period of No. 1 cylinder/ Min.: 0 μs, Max.: 65535 μs 1800 to 3800 μs: Idling - Injection Volume (Cylinder 1) Injection volume (cylinder 1)/ Min.: 0 ml, Max.: 2.047 ml 0 to 0.5 ml: Idling The fuel injection volume for 10 injections. Fuel Pump/Speed Status Fuel pump status/ ON or OFF - Active Test support data. Vacuum Pump Key-off EVAP system leak detection pump status: ON or OFF - - EVAP (Purge) VSV EVAP (Purge) VSV control duty/ Min.: 0%, Max.: 100% 0 to 100%: During idling A command signal from the ECM. EVAP Purge Flow Purge flow/ Min.: 0%, Max.: 399.9% 0 to 100%: Idling - Purge Density Learn Value Purge density learned value/ Min.: -200, Max.: 199.993 -40 to 1: Idling Service data. Vapor Pressure Pump Vapor pressure/ Min.: 0 kPa (0 mmHg), Max.: 1441.77 kPa (10814.17 mmHg) Approximately 100 kPa (750 mmHg): Ignition switch ON EVAP system pressure is monitored by the canister pressure sensor. Vapor Pressure (calculated) Calculated EVAP system pressure/ Min.: -720.896 kPa (-5407.167 mmHg), Max.: 720.874 kPa (5407.002 mmHg) Approximately 100 kPa (750 mmHg): Ignition switch ON - EVAP System Vent Valve Key-off EVAP system vent valve status/ ON or OFF - Active Test support data. EVAP Purge VSV VSV status for EVAP control/ ON or OFF - Active Test support data. Purge Cut VSV Duty Purge cut VSV duty/ Min.: 0%, Max.: 399.9% - - Target Air-Fuel Ratio Target air fuel ratio/ Min.: 0, Max.: 1.999 0.8 to 1.2: Idling - AF Lambda B1S1 Short-term fuel trim/ Min.: 0, Max.: 1.999 Value less than 1 (0.000 to 0.999) = Rich Stoichiometric air-fuel ratio=1 Value more than 1 (1.001 to 1.999) = Lean - AFS Voltage B1S1 Air fuel ratio sensor output voltage/ Min.: 0 V, Max.: 7.999 V 2.8 to 3.8 V: Idling Performing the Control the Injection Volume or Control the Injection Volume for A/F Sensor function of the Active Test enables the technician to check the output current of the sensor. AFS Current B1S1 Air fuel ratio sensor current/ Min.: -128 mA, Max.: 127.99 mA -0.5 to 0.5 mA: Idling Performing the Control the Injection Volume or Control the Injection Volume for A/F Sensor function of the Active Test enables the technician to check the output current of the sensor. A/F Heater Duty #1 Air fuel ratio sensor heater duty ratio/ Min.: 0%, Max.: 399.9% 0 to 100% - O2S B1S2 Heated oxygen sensor output voltage/ Min.: 0 V, Max.: 1.275 V 0 to 1.0 V: Driving at 70 km/h (44 mph) Performing the Control the Injection Volume or Control the Injection Volume for A/F Sensor function of the Active Test enables the technician to check the output current of the sensor. O2S Impedance B1S2 Sub heated oxygen sensor impedance/ Min.: 0 ohms, Max.: 21247.67 ohms 5 to 15000 ohms After driving approx. 10 min. in an urban area. O2 Heater B1S2 Heated oxygen sensor heater/ ON or OFF - - O2 Heater Curr Val B1S2 Heated oxygen sensor current/ Min.: 0 A, Max.: 4.9 A - - Short FT #1 Short-term fuel trim of bank 1/ Min.: -100%, Max.: 99.2% -20 to +20% Short-term fuel compensation used to maintain the air-fuel ratio at the stoichiometric air-fuel ratio. Long FT #1 Long-term fuel trim of bank 1/ Min.: -100%, Max.: 99.2% -20 to +20% Overall fuel compensation carried out in the long term to compensate for a continual deviation of the short-term fuel trim from the central value. Total FT #1 Total fuel trim of bank 1/ Min.: -0.5, Max.: 0.496 -0.2 to 0.2: Idling - Fuel System Status #1 Fuel system status (Bank 1)/ OL or CL or OLDrive or OLFault or CLFault CL: Idling after warming up OL (Open Loop): Has not yet satisfied the conditions to go to closed loop. CL (Closed Loop): Using the heated oxygen sensor as feedback for fuel control. OLDrive: Open loop due to driving conditions (fuel enrichment). OLFault: Open loop due to a detected system fault. CLFault: Closed loop but the heated oxygen sensor, which is used for fuel control, is malfunctioning. Fuel System Status #2 Fuel system status (Bank 2)/ OL or CL or OLDrive or OLFault or CLFault - - Air Pump Pressure (Absolute) Air pump pressure (absolute)/ Min.: 0 kPa, Max.: 65535 kPa Atmospheric pressure +1 kPa or more: Air pump on, air switching valve open Close to atmospheric pressure: Air pump off, air switching valve closed Refer to DTC P2431 (. Refer to «DTC P2431: Secondary Air Injection System Air Flow / Pressure Sensor Circuit Range / Performance Bank1; DTC P2432: Secondary Air Injection System Air Flow / Pressure Sensor Circuit Low Bank1; DTC P2433: Secondary Air Injection System Air Flow / Pressure Sensor Circuit High Bank1»(ref-422140-S05659727882011092600000) ). Air Pump Pulsation Pressure Air pump pulsation pressure/ Min.: 0 kPa, Max.: 655.35 kPa - Cumulative pulsation pressure calculated by ECM Secondary Air Control VSV Secondary air injection system status/ ON or OFF ON: Secondary air injection system operating - 2nd Air System Status Secondary air injection system status/ ON or OFF ON: Secondary air system operating - AI Test Secondary air injection system operation prohibition/ ON or OFF - - IGN Advance Ignition timing advance for No. 1 cylinder/ Min.: -64 deg., Max.: 63.5 deg. BTDC 3 to 13°: Idling - Knock Feedback Value Knocking feedback value/ Min.: -1024°CA, Max.: 1023.9°CA -19 to 0°CA Driving, 70 km/h (44 mph) Service data. Knock Correct Learn Value Knocking correction learned value/ Min.: -1024°CA, Max.: 1023.9°CA 0 to 18.5°CA: Driving, 70 km/h (44 mph) Service data. Idle Spark Advn Ctrl #1 Individual cylinder timing advance compensation amount (No. 1)/ Min.: 0° CA, Max.: 15.93° CA - For use when engine stall, starting problems or rough idle is present. Idle Spark Advn Ctrl #2 Individual cylinder timing advance compensation amount (No. 2)/ Min.: 0° CA, Max.: 15.93° CA - For use when engine stall, starting problems or rough idle is present. Idle Spark Advn Ctrl #3 Individual cylinder timing advance compensation amount (No. 3)/ Min.: 0° CA, Max.: 15.93° CA - For use when engine stall, starting problems or rough idle is present. Idle Spark Advn Ctrl #4 Individual cylinder timing advance compensation amount (No. 4)/ Min.: 0° CA, Max.: 15.93° CA - For use when engine stall, starting problems or rough idle is present. VVT Control Status #1 VVT control status/ ON or OFF - Active Test support data. VVT Advance Fail VVT control failure status/ ON or OFF ON: VVT control failure - VVT Aim Angle #1 VVT target angle/ Min.: 0%, Max.: 399.9% 0%: Idling The VVT duty signal value during the forced operation. VVT Change Angle #1 VVT displacement angle/ Min.: 0 DegFR, Max.: 639.9 DegFR 0 to 5 DegFR: Idling The displacement angle during the forced operation. VVT OCV Duty #1 VVT OCV operation duty/ Min.: 0%, Max.: 399.9% 26.5 to 75.0%: Idling The requested duty value for the forced operation. VN Turbo Type VN turbo type/ Not Avl, Commo, Vacuum or CAN Com - - Catalyst Temp B1S1 Catalyst temperature (Bank 1, Sensor 1)/ Min.: -40°C, Max.: 6513.5°C - - Catalyst Temp B1S2 Catalyst temperature (Bank 1, Sensor 2)/ Min.: -40°C, Max.: 6513.5°C - - Starter Signal Starter signal/ ON or OFF ON: Cranking - Power Steering Signal Power steering switch signal/ ON or OFF ON: Power steering operating - Neutral Position SW Signal PNP switch status/ ON or OFF ON: P or N position - Stop Light Switch Stop light switch/ ON or OFF ON: Brake pedal depressed - A/C Signal A/C switch status/ ON or OFF ON: A/C on - Closed Throttle Position SW Closed throttle position switch/ ON or OFF ON: Throttle fully closed OFF: Throttle open - Fuel Cut Condition Fuel cut condition/ ON or OFF ON: Fuel cut operating - Immobilizer Communication Immobilizer communication/ ON or OFF ON: Normal - Check Mode Check mode/ ON or OFF ON: Check mode on Refer to Check Mode Procedure, refer to «CHECK MODE PROCEDURE»(ref-421953-S37177155462011092600000). SPD Test Result Check mode result for vehicle speed sensor/ Compl or Incmpl - - AS Test Result Check mode result for secondary air injection system/ Compl or Incmpl - - Misfire Test Result Check mode result for misfire monitor/ Compl or Incmpl - - OXS1 Test Result Check mode result for heated oxygen sensor (Bank 1)/ Compl or Incmpl - - A/F Test Results #1 Check mode result for air fuel ratio sensor (Bank 1)/ Compl or Incmpl - - Complete Parts Monitor Comprehensive component monitor/ Not Avl or Avail - - Fuel System Monitor Fuel system monitor/ Not Avl or Avail - - Misfire Monitor Misfire monitor/ Not Avl or Avail - - EGR/VVT Monitor EGR/VVT monitor/ Not Avl or Avail - - EGR/VVT Monitor EGR/VVT monitor/ Compl or Incmpl - - O2S(A/FS) Heater Monitor O2S (A/FS) heater monitor/ Not Avl or Avail - - O2S(A/FS) Heater Monitor O2S (A/FS) heater monitor/ Compl or Incmpl - - O2S(A/FS) Monitor O2S (A/FS) heater monitor/ Not Avl or Avail - - O2S(A/FS) Monitor O2S (A/FS) heater monitor/ Compl or Incmpl - - A/C Monitor A/C monitor/ Not Avl or Avail - - A/C Monitor A/C monitor/ Compl or Incmpl - - 2nd Air Monitor 2nd air monitor/ Not Avl or Avail - - 2nd Air Monitor 2nd air monitor/ Compl or Incmpl - - EVAP Monitor EVAP monitor/ Not Avl or Avail - - EVAP Monitor EVAP monitor/ Compl or Incmpl - - Heated Catalyst Monitor Heated catalyst monitor/ Not Avl or Avail - - Heated Catalyst Monitor Heated catalyst monitor/ Compl or Incmpl - - Catalyst Monitor Catalyst monitor/ Not Avl or Avail - - Catalyst Monitor Catalyst monitor/ Compl or Incmpl - - Component Monitor ENA Comprehensive component monitor/ Unable or Enable - - Component Monitor CMPL Comprehensive component monitor/ Compl or Incmpl - - Fuel System Monitor ENA Fuel system monitor/ Unable or Enable - - Fuel System Monitor CMPL Fuel system monitor/ Compl or Incmpl - - Misfire Monitor ENA Misfire monitor/ Unable or Enable - - Misfire Monitor CMPL Misfire monitor/ Compl or Incmpl - - EGR/VVT Monitor ENA EGR/VVT monitor/ Unable or Enable - - EGR/VVT Monitor CMPL EGR/VVT monitor/ Compl or Incmpl - - Heater Monitor ENA O2S (A/FS) heater monitor/ Unable or Enable - - Heater Monitor CMPL O2S (A/FS) heater monitor/ Compl or Incmpl - - O2S(A/FS) Monitor ENA O2S (A/FS) monitor/ Unable or Enable - - O2S(A/FS) Monitor CMPL O2S (A/FS) monitor/ Compl or Incmpl - - A/C Monitor ENA A/C monitor/ Unable or Enable - - A/C Monitor CMPL A/C monitor/ Compl or Incmpl - - 2nd Air Monitor ENA 2nd air monitor/ Unable or Enable - - 2nd Air Monitor CMPL 2nd air monitor/ Compl or Incmpl - - EVAP Monitor ENA EVAP monitor/ Unable or Enable - - EVAP Monitor CMPL EVAP monitor/ Compl or Incmpl - - Heated Cat Monitor ENA Heated catalyst monitor/ Unable or Enable - - Heated Cat Monitor CMPL Heated catalyst monitor/ Compl or Incmpl - - Catalyst Monitor ENA Catalyst monitor/ Unable or Enable - - Catalyst Monitor CMPL Catalyst monitor/ Compl or Incmpl - - TC Terminal TC terminal status/ ON or OFF - - # Codes (Include History) Number of codes/ Min.: 0, Max.: 255 - Number of stored DTCs. MIL MIL status/ ON or OFF ON: MIL on - MIL ON Run Distance Distance driven after MIL turns on/ Min.: 0 second, Min.: 0 km, Max.: 65535 km Distance driven after DTC stored - Running Time from MIL ON Running time after MIL turned on/ Min.: 0 min, Max.: 65535 min Running time after MIL turned on - Time after DTC Cleared Time after DTC cleared/ Min.: 0 min, Max.: 65535 min Time after DTCs cleared - Distance from DTC Cleared Distance driven after DTC cleared/ Min.: 0 km, Max.: 65535 km Driving distance after DTCs cleared - Warm-up Cycle Cleared DTC Warm-up cycles after DTC cleared/ Min.: 0, Max.: 255 - The number of warm-up cycles after the DTCs were cleared. Dist Batt Cable Disconnect Distance driven after battery cable disconnected/ Min.: 0 km, Max.: 65535 km Total distance vehicle driven after battery cable disconnected - IG OFF Elapsed Time Time after ignition switch off/ Min.: 0 minutes, Max.: 655350 minutes Cumulative time after ignition switch off - OBD Requirements OBD requirement OBD2 - Number of Emission DTC Emissions-related DTCs - The number of emissions-related DTCs. TC and TE1 TC and CG (TE1) terminals of DLC3/ ON or OFF - - Ignition Trig. Count Ignition counter/ Min.: 0, Max.: 65535 0 to 400 - Cylinder #1 Misfire Count to Cylinder #4 Misfire Count Misfire count of cylinder 1 to 4/ Min.: 0, Max.: 255 0 - All Cylinders Misfire Count Misfire count of all cylinder/ Min.: 0, Max.: 255 0 - Misfire RPM Engine speed for first misfire range/ Min.: 0 RPM, Max.: 6375 RPM 0 RPM: 0 misfires - Misfire Load Engine load for first misfire range/ Min.: 0 g/rev, Max.: 3.98 g/rev 0 g/rev: 0 misfires - Misfire Margin Misfire monitoring/ Min.: -100%, Max.: 127% -100 to 99.2% Misfire detecting margin. Catalyst OT MF F/C Fuel cut to prevent misfire causing catalyst overheating/ Not Avl or Avail Avail: Fuel cut to prevent misfire causing catalyst overheating available Not Avl: Fuel cut to prevent misfire causing catalyst overheating not available - Cat OT MF F/C History History of fuel cut to prevent misfire causing catalyst overheating/ ON or OFF ON: Fuel cut operation history exists - Cat OT MF F/C Cylinder #1 Display of fuel cut operation in No. 1 cylinder (if certain level of misfire malfunction is detected)/ ON or OFF ON: Fuel cut operating - Cat OT MF F/C Cylinder #2 Display of fuel cut operation in No. 2 cylinder (if certain level of misfire malfunction is detected)/ ON or OFF ON: Fuel cut operating - Cat OT MF F/C Cylinder #3 Display of fuel cut operation in No. 3 cylinder (if certain level of misfire malfunction is detected)/ ON or OFF ON: Fuel cut operating - Cat OT MF F/C Cylinder #4 Display of fuel cut operation in No. 4 cylinder (if certain level of misfire malfunction is detected)/ ON or OFF ON: Fuel cut operating - Engine Speed (Starter Off) Engine speed when starter off/ Min.: 0 RPM, Max.: 51199 RPM - For use when engine stall, starting problems or rough idle is present. Starter Count Number of times starter turned on after ignition switch turned to ON/ Min.: 0, Max.: 255 - For use when engine stall, starting problems or rough idle is present. Run Dist of Previous Trip Distance driven during previous trip/ Min.: 0 km, Max.: 655.35 km - For use when engine stall, starting problems or rough idle is present. Engine Starting Time Time elapsed after engine started (interval between ignition switch ON and off)/ Min.: 0 ms, Max.: 655350 ms - For use when engine stall, starting problems or rough idle is present. Previous Trip Coolant Temp Engine coolant temperature during previous trip/ Min.: -40°C, Max.: 215°C - For use when engine stall, starting problems or rough idle is present. Previous Trip Intake Temp Intake air temperature during previous trip/ Min.: -40°C, Max.: 215°C - For use when engine stall, starting problems or rough idle is present. Engine Oil Temperature Engine oil temperature (estimated temperature)/ Min.: -40°C, Max.: 215°C - For use when engine stall, starting problems or rough idle is present. Previous Trip Eng Oil Temp Engine oil temperature during previous trip/ Min.: -40°C, Max.: 215°C - For use when engine stall, starting problems or rough idle is present. Ambient Temp for A/C Ambient temperature for A/C/ Min.: -40°C, Max.: 215°C - For use when engine stall, starting problems or rough idle is present. Previous Trip Ambient Temp Ambient temperature during previous trip/ Min.: -40°C, Max.: 215°C - For use when engine stall, starting problems or rough idle is present. Engine Start Hesitation History of hesitation during engine start/ ON or OFF - - Low Rev for Eng Start History of low engine speed after engine start/ ON or OFF - - Minimum Engine Speed Minimum engine speed/ Min.: 0 RPM, Max.: 51199 RPM - For use when engine stall, starting problems or rough idle is present. ACT VSV A/C cut status for Active Test/ ON or OFF - Active Test support data. Idle Fuel Cut Fuel cut at idle/ ON or OFF ON: Fuel cut operating Idle Fuel Cut is "ON" when the throttle valve fully is closed and the engine speed is over 2800 RPM. FC TAU Fuel cut TAU (Fuel cut during very light load)/ ON or OFF ON: Fuel cut operating Fuel cut is being performed under a very light load to prevent the engine combustion from becoming incomplete. Immobilizer Fuel Cut Status of the immobilizer fuel cut/ ON or OFF - - Electrical Load Signal 1 Electrical load signal/ ON or OFF - - Electrical Load Signal 2 Electrical load signal/ ON or OFF - - Model Code Model code - Used for identifying model code: TRN28# Engine Type Engine type - Used for identifying engine type: 2TRFE Cylinder Number Number of cylinders/ Min.: 0, Max.: 255 - Used for identifying number of cylinders: 4 Transmission Type Transmission type - Used for identifying the transmission type: ECT(4AT) Destination Destination - Used for identifying the destination: A Model Year Model year/ Min.: 1900, Max.: 2155 - Used for identifying the model year: 20## System Identification System identification - Used for identifying the engine system: Gasoline (gasoline engine) Engine Speed of Cyl #1 Engine speed for cylinder 1/ Min.: 0 RPM, Max.: 51199 RPM - Output only when Check the Cylinder Compression is performed using the Active Test. Engine Speed of Cyl #2 Engine speed for cylinder 2/ Min.: 0 RPM, Max.: 51199 RPM - Output only when Check the Cylinder Compression is performed using the Active Test. Engine Speed of Cyl #3 Engine speed for cylinder 3/ Min.: 0 RPM, Max.: 51199 RPM - Output only when Check the Cylinder Compression is performed using the Active Test. Engine Speed of Cyl #4 Engine speed for cylinder 4/ Min.: 0 RPM, Max.: 51199 RPM - Output only when Check the Cylinder Compression is performed using the Active Test. Av Engine Speed of All Cyl Engine speed for all cylinders/ Min.: 0 RPM, Max.: 51199 RPM - Output only when Check the Cylinder Compression is performed using the Active Test. HINT: *: This excludes the throttle valve opening percentage due to Idle Speed Control (ISC).
2. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. According to the display on Techstream, perform the "Active Test". Tester Display Test Part Control Range Diagnostic Notes Control the Injection Volume Change injection volume Between -12% and 24.8% All the injectors are tested at the same time. Perform the test at less than 3000 RPM. The injection volume can be changed in 1% gradations within the control range. Control the Injection Volume for A/F Sensor Change injection volume Lower by 12.5% or increase by 25% Perform the test at less than 3000 RPM. Control the Injection Volume for the A/F Sensor enables checking and graphing of A/F (Air Fuel Ratio) sensor and Heated Oxygen (HO2) sensor voltage outputs. To conduct the test, enter the following menus: Active Test / Control the Injection Volume for A/F Sensor / Data List / A/ F Control System / AFS B1 S1 and O2S B1S2. Activate the VSV for Secondary Air Control Activate secondary air system ON/OFF Do not the perform test for 5 seconds or more. After the test, do not perform the test again for 30 seconds. Activate the VSV for Evap Control Activate EVAP VSV control ON/OFF - Control the A/C Cut Signal Control A/C cut signal ON/OFF - Control the Fuel Pump / Speed Activate fuel pump (C/OPN relay) ON/OFF - Connect the TC and TE1 Turn on and off TC and TE1 connection ON/OFF ON: TC and TE1 are connected. OFF: TC and TE1 are disconnected. Control the Idle Fuel Cut Prohibit Prohibit idling fuel cut control ON/OFF - Prohibit the Catalyst OT Misfire prevent F/C Prohibit catalyst overheat malfunction prevention fuel cut operation during misfire ON: Fuel cut prohibited Confirm that the vehicle is stopped and the engine speed is 3000 RPM or less. Control the ETCS Open/Close Slow Speed Throttle actuator Close/Open Open: Throttle valve opens slowly This test is possible when the following conditions are met: The ignition switch is ON. The engine is stopped. The accelerator pedal is fully depressed (accelerator pedal sensor: 58 degrees or more). The shift lever is in P. Control the ETCS Open/Close Fast Speed Throttle actuator Close/Open Open: Throttle valve opens quickly Same as above. Control the VVT Linear (Bank 1) Control Variable Valve Timing (VVT) -128 to 127% OCV control duty ratio can be set to any value within this range 100%: Maximum advance -100%: Maximum retard The engine stalls or idles roughly when the VVT actuator is operated by 100%. The test is possible during idle. Control the VVT System (Bank 1) Turn Oil Control Valve (OCV) on and off ON/OFF The engine stalls or idles roughly when the OCV is turned on. The engine runs and idles normally when the OCV is off. Activate the Vacuum Pump Activate vacuum pump (built into canister pump module) ON/OFF - Activate the VSV for Vent Valve Activate vent valve (built into canister pump module) ON/OFF - Control the Cylinder #1 Fuel Cut Cylinder #1 injector fuel cut ON/OFF The test is possible while the vehicle is stopped and the engine is idling.*1 Control the Cylinder #2 Fuel Cut Cylinder #2 injector fuel cut ON/OFF The test is possible while the vehicle is stopped and the engine is idling.*1 Control the Cylinder #3 Fuel Cut Cylinder #3 injector fuel cut ON/OFF The test is possible while the vehicle is stopped and the engine is idling.*1 Control the Cylinder #4 Fuel Cut Cylinder #4 injector fuel cut ON/OFF The test is possible while the vehicle is stopped and the engine is idling.*1 Control the All Cylinders Fuel Cut All cylinder fuel cut ON/OFF The test is possible while the vehicle is stopped and the engine is idling.*1 Check the Cylinder Compression*2 Check the cylinder compression pressure ON/OFF The fuel injection and ignition stops in all cylinders.*1 NOTE: *1 If the display of the Data List item Catalyst OT MF F/C item is Not Avl, perform this Active Test with the vehicle stopped and the engine idling. If the display of the Data List item Catalyst OT MF F/C item is Avail, perform this Active Test as described below. Stop the engine, turn the ignition switch to ON and turn Control the Cylinder #1 Fuel Cut (to Control the Cylinder #4 Fuel Cut) ON. Start the engine. HINT: *2: When cranking the engine, each cylinder measures the engine speed. In this Active Test, the fuel and ignition of all cylinders is cut. The engine must then be cranked for approximately 10 seconds. At this time, the speed of each cylinder is measured. If the speed of one cylinder is more than the other cylinders, it can be determined that compression pressure of that cylinder is lower than the other cylinders. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Check the Cylinder Compression. HINT: To display the entire Data List, press the pull down menu button next to Primary. Then select Compression. Push the snapshot button to turn the snapshot function on. HINT: Using the snapshot function, data can be recorded during the Active Test. While the engine is not running, press the RIGHT or LEFT button to change Check the Cylinder Compression to ON. HINT: After performing the above procedure, Check the Cylinder Compression will start. Fuel injection for all cylinders is prohibited and each cylinder engine speed measurement enters standby mode. Crank the engine for about 10 seconds. HINT: Continue to crank the engine until the values change from the default value (51199 RPM). Monitor the engine speed (Engine Speed of Cyl #1 to #4) displayed on the Techstream. HINT: At first, the Techstream displays extremely high cylinder engine speed values. After approximately 10 seconds of engine cranking, each cylinder engine speed measurement will change to the actual engine speed. NOTE: Do not crank the engine continuously for 20 seconds or more. If it is necessary to crank the engine again after Check the Cylinder Compression to ON has been changed to ON and the engine has been cranked once, press Exit to return to the Active Test menu screen. Then change Check the Cylinder Compression to ON and crank the engine. Use a fully-charged battery. Stop cranking the engine, and then change "Check the Cylinder Compression" to OFF after the engine stops. NOTE: If the Active Test is changed to OFF while the engine is being cranked, the engine will start. Push the snapshot button to turn the snapshot function off. Select "Stored Data" on the Techstream screen, select the recorded data and display the data as a graph. HINT: If the data is not displayed as a graph, the change of the values cannot be observed. Check the change in engine speed values. HINT: As the data values of the Active Test return to their default values when cranking is stopped, the engine speed value of each cylinder cannot be observed. Therefore, it is necessary to use the data recorded with the snapshot function to check the engine speed values recorded during cranking.
3. SYSTEM CHECK HINT: Performing a system check enables the system, which consists of multiple actuators, to be operated without removing any parts. In addition, it can show whether or not any DTCs (Pending Codes) are stored, and can detect potential malfunctions in the system. The system check can be performed with the Techstream. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility. Perform the system check by referring to the table below. Turn the ignition switch off. Tester Display Test Part Control Range Diagnostic Notes Air Injection Check (Automatic Mode) Perform secondary air injection system operation automatically - With a warm engine, make sure to turn the ignition switch off once. If there are no pending DTCs after performing this test, the system is functioning normally. Refer to the inspection procedure for secondary air injection system DTCs. When performing the Air Injection Check operation after the battery cable is reconnected, wait for 7 minutes with the ignition switch ON or the engine running. Turn the ignition switch off when the system check is finished. Air Injection Check (Manual Mode) Perform secondary air injection system operation manually Select monitor item 1, 2 or 3 AIR PUMP: OFF ASV: CLOSE AIR PUMP: ON ASV: OPEN AIR PUMP: ON ASV: CLOSE - With a warm engine, make sure to turn the ignition switch off once. Used to detect malfunctioning parts. Refer to the inspection procedure for secondary air injection system DTCs. When performing the Air Injection Check operation after the battery cable is reconnected, wait for 7 minutes with the ignition switch ON or the engine running. Turn the ignition switch off when the system check is finished.

DIAGNOSTIC TROUBLE CODE CHART

SFI SYSTEM
