MONITOR STRATEGY
| Related DTCs | P0010: VVT OCV range check |
| Required Sensors/Components (Main) | VVT OCV |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
TYPICAL ENABLING CONDITIONS
| Monitor runs whenever following DTCs not stored | None |
| All of following conditions met | |
| Starter | OFF |
| Ignition switch | ON |
| Time after ignition switch off to ON | 0.5 seconds or more |
| Either of following conditions are met | Condition A or B |
| A. All of following conditions met | |
| Battery voltage | 11 to 13 V |
| Target duty ratio | Less than 70% |
| Current cut status | Not cut |
| B. All of following conditions met | |
| Battery voltage | 13 V or higher |
| Target duty ratio | Less than 80% |
| Current cut status | Not cut |
TYPICAL MALFUNCTION THRESHOLDS
| VVT oil control valve condition | No operation record |
COMPONENT OPERATING RANGE
| VVT oil control valve condition | Operation record |
Scheme 576
Scheme 576: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 5 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Code.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0010.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 577
Scheme 577: WIRING DIAGRAM
| Related DTCs | P0011: Advance camshaft timing P0012: Retard camshaft timing |
| Required Sensors/Components (Main) | VVT OCV and VVT actuator |
| Required Sensors/Components (Related) | Crankshaft position sensor, Camshaft position sensor and Engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 10 seconds |
| MIL Operation | Advanced camshaft timing: Immediate Retarded camshaft timing: 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (VVT Oil Control Valve) P0016 (VVT system - Misalignment) P0102, P0103 (Mass Air Flow Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) |
| Battery voltage | 11 V or higher |
| Engine speed | 550 to 4000 RPM |
| Engine coolant temperature | 70 to 100°C (158 to 212°F) |
| Both of following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (crankshaft angle) |
| Valve timing | No change at advanced (retarded) valve timing |
If the difference between the target and actual camshaft timing is more than the specified value, the ECM operates the VVT (Variable Valve Timing) actuator. Then, the ECM monitors the camshaft timing change for 5 seconds.
MONITOR RESULT
Refer to Checking Monitor Status, refer to CHECKING MONITOR STATUS .
Scheme 578
Scheme 578: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 3 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0011 or P0012.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
- Repeat the pattern of accelerating the vehicle from rest to approximately 60 km/h (37 mph) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
- Idle the engine for 3 minutes or more [G].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [H].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform the following procedure.
- Perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
PROCEDURE
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0011 OR P0012) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0011 or P0012 is output A DTC P0011 or P0012 and other DTCs are output B HINT: If any DTCs other than P0011 or P0012 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Turn the A/C switch on. Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. OK Tester Operation Specified Condition 0% (OFF) Normal engine speed 127% (ON) Engine idles roughly or stalls (soon after camshaft timing oil control valve switched from OFF to ON) HINT: Refer to "Data List / Active Test" [VVT OCV Duty #1, VVT Change Angle #1], refer to «DATA LIST / ACTIVE TEST»(ref-421953-S34024941762011092600000) . NG --> See step 4 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0011 OR P0012) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . Start the engine and warm it up. Switch the ECM from normal mode to check mode using the Techstream, refer to «CHECK MODE PROCEDURE»(ref-421953-S37177155462011092600000) . Allow the engine to idle for more than 1 minute. Drive the vehicle for more than 10 minutes. Enter the following menus: Powertrain / Engine and ECT / DTC. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P0011 or P0012 is output B HINT: DTC P0011 or P0012 is stored when foreign objects in the engine oil are caught in some parts of the system. These codes remain stored for a short time even after the system returns to normal. These foreign objects may then be captured by the oil control valve filter, thus eliminating the source of the problem. B --> See step 7 A --> See step 10
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Inspect the camshaft timing oil control valve assembly, refer to «INSPECTION»(ref-421955-S27104242852011092600000) . Connect the positive (+) battery terminal to terminal 1 and the negative (-) battery terminal to terminal 2. Check the valve operation. OK Valve moves quickly. Reinstall the camshaft timing oil control valve assembly. NG --> See step 11 OK: Go to next step
- INSPECT CAMSHAFT TIMING GEAR ASSEMBLY Inspect the camshaft timing gear assembly, refer to «REMOVAL - Step 20»(ref-422095-S29140587252011092600000) . NG --> See step 12 OK: Go to next step
- INSPECT OIL CONTROL VALVE FILTER Remove the oil control valve filter. Check that the filter is not clogged. OK Filter is not clogged. Reinstall the oil control valve filter. NG --> REPLACE OIL CONTROL VALVE FILTER OK: Go to next step
- ADJUST VALVE TIMING HINT: There are no marks on the cylinder head to align for the purpose of checking valve timing. Valve timing can only be inspected by aligning the colored plates on the timing chain with the marks on the pulleys. It may be necessary to remove and reinstall the chain to align the timing marks, refer to «INSTALLATION - Step 5»(ref-422095-S31729269002011092600000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0011 OR P0012) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . Start the engine and warm it up. Switch the ECM from normal mode to check mode using the Techstream, refer to «CHECK MODE PROCEDURE»(ref-421953-S37177155462011092600000) . Allow the engine to idle for more than 1 minute. Drive the vehicle for more than 10 minutes. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P0011 or P0012 is output B HINT: DTC P0011 or P0012 is stored when foreign objects in the engine oil are caught in some parts of the system. These codes remain stored for a short time even after the system returns to normal. These foreign objects may then be captured by the oil control valve filter, thus eliminating the source of the problem. B --> See step 13 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421953-S08108164442011092600000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-421953-S36764272642011092600000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-421955-S34519218492011092600000)
- REPLACE CAMSHAFT TIMING GEAR ASSEMBLY. Refer to «REMOVAL»(ref-422095-S05888635252011092600000)
- REPLACE ECM. Refer to «REMOVAL»(ref-421955-S17323454082011092600000)
| Related DTCs | P0016: Camshaft timing (bank 1) misalignment |
| Required Sensors/Components (Main) | VVT actuator |
| Required Sensors/Components (Related) | Camshaft position sensor, Crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 60 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (VVT Oil Control Valve) P0102, P0103 (Mass Air Flow Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) |
| Engine speed | 550 to 1000 RPM |
| One of the following conditions is met | Condition 1 or 2 |
| 1. VVT learned value at maximum retarded valve timing | Less than 33° crankshaft angle |
| 2. VVT learned value at maximum retarded valve timing | More than 51° crankshaft angle |
Scheme 579
Scheme 579: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the ECT reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0016.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [G].
- Drive the vehicle for 2 to 3 minutes [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 5 minutes or more [F].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [G].
- Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0016) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0016 is output A DTC P0016 and other DTCs are output B HINT: If any DTCs other than P0016 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Turn the A/C switch on. Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. OK Tester Operation Specified Condition 0% (OFF) Normal engine speed 127% (ON) Engine idles roughly or stalls (soon after camshaft timing oil control valve switched from OFF to ON) NG --> See step 4 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0016) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . Start the engine and warm it up. Switch the ECM from normal mode to check mode using the Techstream, refer to «CHECK MODE PROCEDURE»(ref-421953-S37177155462011092600000) . Allow the engine to idle for more than 1 minute. Drive the vehicle for more than 10 minutes. Enter the following menus: Powertrain / Engine and ECT / DTC. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P0016 is output B HINT: DTC P0016 is stored when foreign objects in the engine oil are caught in some parts of the system. This code remains stored for a short time even after the system returns to normal. These foreign objects may then be captured by the oil control valve filter, thus eliminating the source of the problem. B --> See step 7 A --> See step 13
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Inspect the camshaft timing oil control valve assembly, refer to «INSPECTION»(ref-421955-S27104242852011092600000) . Connect the positive (+) battery terminal to terminal 1 and the negative (-) battery terminal to terminal 2. Check the valve operation. OK Valve moves quickly. Reinstall the camshaft timing oil control valve assembly. NG --> See step 10 OK: Go to next step
- INSPECT CAMSHAFT TIMING GEAR ASSEMBLY Inspect the camshaft timing gear assembly, refer to «REMOVAL - Step 20»(ref-422095-S29140587252011092600000) . NG --> See step 11 OK: Go to next step
- INSPECT OIL CONTROL VALVE FILTER Remove the oil control valve filter. Check that the filter is not clogged. OK Filter is not clogged. Reinstall the oil control valve filter. NG --> REPLACE OIL CONTROL VALVE FILTER OK: Go to next step
- ADJUST VALVE TIMING HINT: There are no marks on the cylinder head to align for the purpose of checking valve timing. Valve timing can only be inspected by aligning the colored plates on the timing chain with the marks on the pulleys. It may be necessary to remove and reinstall the chain to align the timing marks, refer to «INSTALLATION - Step 5»(ref-422095-S31729269002011092600000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0016) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . Start the engine and warm it up. Switch the ECM from normal mode to check mode using the Techstream, refer to «CHECK MODE PROCEDURE»(ref-421953-S37177155462011092600000) . Allow the engine to idle for more than 1 minute. Drive the vehicle for more than 10 minutes. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P0016 is output B B --> See step 12 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421953-S08108164442011092600000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-421955-S34519218492011092600000)
- REPLACE CAMSHAFT TIMING GEAR ASSEMBLY. Refer to «REMOVAL»(ref-422095-S05888635252011092600000)
- REPLACE ECM. Refer to «REMOVAL»(ref-421955-S17323454082011092600000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-421953-S36764272642011092600000)
| Related DTCs | P0031: Air fuel ratio sensor heater range check (Low current) P0032: Air fuel ratio sensor heater range check (High current) P101D: Air fuel ratio sensor heater (for Bank 1) performance |
| Required Sensors/Components (Main) | Air fuel ratio sensor heater |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 11 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P101D (Air fuel ratio sensor heater) |
| Battery voltage | 10.5 V or higher |
| Time after heater ON | 5 seconds or more |
| Active heater OFF control | Not operating |
| Active heater ON control | Not operating |
| Air fuel ratio sensor heater duty cycle | 10% or more |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Time after heater ON | 5 seconds or more |
| Active heater OFF control | Not operating |
| Active heater ON control | Not operating |
| Air fuel ratio sensor heater duty cycle | More than 0% |
| Monitor runs whenever following DTCs not stored | P0031 (Air fuel ratio sensor heater) |
| Battery voltage | 10.5 V or higher |
| Time after heater ON | 5 seconds or more |
| Active heater OFF control | Not operating |
| Active heater ON control | Not operating |
| Air fuel ratio sensor heater duty cycle | 10 to 60% |
| Air fuel ratio sensor heater ON current | 0.8 A or higher |
| Air fuel ratio sensor heater current | Below 0.8 A |
| Hybrid IC high current limiter monitor | Fail |
| Hybrid IC high current limiter port | Fail |
| Air fuel ratio sensor heater current | 0.8 A or higher |
Scheme 580
Scheme 580: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0031, P0032 or P101D.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0037: Heated oxygen sensor heater range check (Low current) P0038: Heated oxygen sensor heater range check (High current) P0141: Heated oxygen sensor heater performance P102D: Heated oxygen sensor heater stuck ON |
| Required Sensors/Components (Main) | Heated oxygen sensor heater |
| Required Sensors/Components (Related) | Vehicle speed sensor |
| Frequency of Operation | Continuous: P0037, P0038 and P102D Once per driving cycle: P0141 |
| Duration | Within 1 second: P0037 and P0038 10 seconds: P0141 0.5 seconds: P102D |
| MIL Operation | Immediate: P0037, P0038 and P102D 2 driving cycles: P0141 |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0031, P0032 (Air fuel ratio sensor heater) P0037, P0038 (Rear oxygen sensor heater) |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active A/F control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation | Complete |
| Heater OFF current learned value | Acquired |
| Monitor runs whenever following DTCs not stored | P0031, P0032 (Air fuel ratio sensor heater) P0037, P0038 (Rear oxygen sensor heater) |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active A/F control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation | Complete |
| Heated oxygen sensor heater OFF current | Higher than 3.5 A |
| Hybrid IC high current limiter port | Fail |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active A/F control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation | Complete |
| Monitor runs whenever following DTCs not stored | P0031, P0032 (Air fuel ratio sensor heater) P0037, P0038, P102D (Rear oxygen sensor heater) |
| Battery voltage | 10.5 V or higher |
| Fuel cut | OFF |
| Time after fuel cut ON to OFF | 30 seconds or more |
| Accumulated heater ON time | 100 seconds or more |
| Learned heater OFF current operation | Complete |
| Monitor runs whenever following DTCs not stored | None |
| Duration that rear heated oxygen sensor impedance is less than 15 kohms | 2 seconds or more |
| Monitor runs whenever following DTCs not stored | P0031, P0032 (Air fuel ratio sensor heater) P0037, P0038 (Rear oxygen sensor heater) |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active A/F control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation | Complete |
| Heated oxygen sensor heater OFF current | Higher than 3.5 A |
| Hybrid IC high current limiter port | Fail |
When the values for the Data List items O2 Heater Curr Val B1S2 is not 0 A, the heater is on.
| Heated oxygen sensor heater current | 0.3 A or less |
| Heated oxygen sensor heater current | 1 A or less |
| Hybrid IC high current limiter port | Fail |
| Heated oxygen sensor heater output | ON |
| Accumulated heater resistance | Varies with sensor element temperature (example: Higher than 23 ohms) |
| Heated oxygen sensor heater ON current | Higher than 1 A |
| Heated oxygen sensor heater current | 0.4 to 1 A (when engine idling, heated oxygen sensor warmed up and battery voltage 11 to 14 V) |
Refer to Checking Monitor Status, refer to CHECKING MONITOR STATUS .
Scheme 581
Scheme 581: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0037, P0038, P0141 or P102D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0101: Mass air flow meter rationality |
| Required Sensors/Components (Main) | Mass air flow meter |
| Required Sensors/Components (Related) | Crankshaft position sensor, engine coolant temperature sensor, throttle position sensor |
| Frequency of Operation | Continuous |
| Duration | 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0102, P0103 (Mass Air Flow Sensor) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0335 (Crankshaft Position Sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0452, P0453 (EVAP System) P2401, P2402 (Leak detection pump) P2419, P2420 (EVAP system vent valve) |
| Throttle position sensor voltage | 0.2 to 2 V |
| Time after engine start | 5 seconds or more |
| Battery voltage | 10.5 V or higher |
| Engine coolant temperature | 70°C (158°F) or higher |
| Estimated load | 30 to 70% |
| Both conditions 1 and 2 met | |
| 1. Average engine load value ratio | Less than 0.85, or more than 1.16 (varies with estimated engine load) |
| 2. Average air-fuel ratio | Less than -20%, or more than 20% |
Scheme 582
Scheme 582: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or higher [A].
- Drive the vehicle at approximately 80 km/h (50 mph) to 112 km/h (70 mph) for 5 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive while keeping the engine load as stable as possible.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0101.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
CONFIRMATION DRIVING PATTERN
Performing this confirmation pattern will activate the mass air flow performance monitor.
Scheme 583
Scheme 583: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) .
- Start the engine, and warm it up until the engine coolant temperature reaches 70°C (158°F) or higher.
- Drive the vehicle at approximately 100 km/h (62 mph) for 20 seconds or more.
- On the Techstream, enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending; then check if any DTCs (any pending DTCs) are output.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0101 is output A DTC P0101 and other DTCs are output B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leakage. OK No leakage from air induction system. NG --> REPAIR OR REPLACE AIR INDUCTION SYSTEM OK: Go to next step
- CHECK PCV HOSE Check the PCV hose. OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK --> See step 5
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421953-S08108164442011092600000)
- REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-421955-S10732600322011092600000)
| Related DTCs | P0102: Mass air flow meter range check (Low voltage) P0103: Mass air flow meter range check (High voltage) |
| Required Sensors/Components (Main) | Mass air flow meter |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediate: Engine speed less than 4000 RPM 2 driving cycles: Engine speed 4000 RPM or more |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Mass air flow meter voltage | Below 0.2 V |
| Mass air flow meter voltage | Higher than 4.9 V |
| Mass air flow meter voltage | 0.2 V to 4.9 V |
Scheme 584
Scheme 584: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 5 seconds [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Run the engine at an engine speed of 4000 RPM or more for 5 seconds [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0102 or P0103.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [E] again.
- If the no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 585
Scheme 585: WIRING DIAGRAM
| Related DTCs | P0111: Intake air temperature sensor rationality (After engine stop) P0111: Intake air temperature sensor rationality (After cold engine start) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required Sensors/Components (Sub) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 5 hours or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0102, P0103 (Mass Air Flow Sensor) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) |
| Time after engine start | 10 seconds or more |
| Battery voltage | 10.5 V or higher |
| Engine coolant temperature when ECM started by soak timer | 40°C (-40°F) or higher |
| Time that MAF is low before engine stop | 70 minutes |
| Accumulated mass air flow amount before engine stop | 2504 g or more |
| Key-off duration | 30 minutes |
| Key-off duration | 5 hours |
| Time after engine start | 10 seconds or more |
| Engine coolant temperature | 70°C (158°F) or more |
| Accumulated mass air flow amount | 2504 g or more |
| Either of the following conditions is met | |
| 1. Duration while engine load is low | 10 seconds or more |
| 2. Duration while engine load is high | 10 seconds or more |
| IAT change | Less than 1°C (2°F) |
| IAT change | Less than 1°C (2°F) |
Scheme 586
Scheme 586: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the ECT reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C]. HINT: During steps [A] through [C], if the change in the intake air temperature is less than 1°C (1.8°F), the intake air temperature sensor (MAF meter) is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0111.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F].
- Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Check the DTC judgment result again [F]. HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0111 and other DTCs are output A DTC P0111 is output B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. B --> See step 3 A --> See step 2
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421953-S08108164442011092600000)
- REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-421955-S10732600322011092600000)
| Related DTCs | P0112: Intake air temperature sensor range check (Low voltage) P0113: Intake air temperature sensor range check (High voltage) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Intake air temperature sensor voltage | Below 0.18 V [Higher than 140°C (284°F)] |
| Intake air temperature sensor voltage | Higher than 4.91 V [Below -40°C (-40°F)] |
| Intake air temperature sensor voltage | 0.18 to 4.91 V [-40°C to 140°C (-40°F to 284°F)] |
Scheme 587
Scheme 587: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 0.5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0112 or P0113.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 588
Scheme 588: WIRING DIAGRAM
| Related DTCs | P0115: ECT sensor range check (Fluctuating) P0117: ECT sensor range check (Low voltage) P0118: ECT sensor range check (High voltage) |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Engine coolant temperature sensor voltage | Below 0.14 V, or higher than 4.91 V |
| Engine coolant temperature sensor voltage | Below 0.14 V [higher than 140°C (284°F)] |
| Engine coolant temperature sensor voltage | Higher than 4.91 V [Below -40°C (-40°F)] |
| Engine coolant temperature sensor voltage | 0.14 to 4.91 V [-40°C to 140°C (-40°F to 284°F)] |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 0.5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0115, P0117 or P0118.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 589
Scheme 589: WIRING DIAGRAM
| Related DTCs | P0116: Engine coolant temperature sensor output stuck at low engine coolant temperature P0116: Engine coolant temperature sensor output stuck at high engine coolant temperature |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Related) | Crankshaft position sensor, intake air temperature sensor, mass air flow meter |
| Frequency of Operation | Once per driving cycle |
| Duration | 5 hours or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0128 (Thermostat) |
| Battery voltage | 10.5 V or higher |
| Time after engine start | 1 second or more |
| Engine coolant temperature at engine start | Below 60°C (140°F) |
| Soak time | 0 seconds or more |
| Accumulated mass air flow | 1081 g or more |
| Fuel cut | OFF |
| Difference between engine coolant temperature at engine start and intake air temperature | Less than 40°C (72°F) |
ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR
| Monitor runs whenever following DTCs not stored | P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0128 (Thermostat) P2610 (Soak Timer Circuit) |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Soak time | 5 hours or more |
| Engine coolant temperature at engine start | 60°C (140°F) or higher |
| Accumulated mass air flow | 2139 g or more |
ENGINE COOLANT TEMPERATURE SENSOR SOAK MONITOR
| Engine coolant temperature sensor value change | Less than 5°C (9°F) |
ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR
| Difference between current engine coolant temperature sensor value and previous engine coolant temperature sensor value when engine stopped | Less than 5°C (9°F) |
| Engine coolant temperature | Engine coolant temperature sensor value changes in accordance with actual engine coolant temperature |
Scheme 590
Scheme 590: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp.
- Check that the coolant temperature is 60°C (140°F) or less.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B]. HINT: If the engine coolant temperature does not change by 5°C (9°F) or higher, the ECT sensor is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0116.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E] again.
- Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: In the event of the drive pattern being interrupted (possibly due to factors such as traffic conditions), the drive pattern can be resumed.
- Check the DTC judgment result again [E]. HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0116) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0116 is output A DTC P0116 and other DTCs are output B HINT: If any DTCs other than P0116 are output, troubleshoot those DTCs first. B --> See step 3 A: Go to next step
- INSPECT THERMOSTAT Inspect the thermostat, refer to «INSPECTION»(ref-422101-S29114552122011092600000) . NG --> See step 4 OK --> See step 5
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421953-S08108164442011092600000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-422101-S16434980572011092600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-421955-S03198855172011092600000)
| Related DTCs | P011B: Engine coolant temperature/Intake air temperature sensor correlation |
| Required Sensors / Components (Main) | Engine coolant temperature/Intake air temperature sensor |
| Required Sensors / Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 7 hours or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P2610 (Soak timer circuit) |
| Both conditions met | Conditions 1 and 2 |
| 1. All of following conditions met | Conditions (a), (b), (c) and (d) |
| (a) After ignition switch ON and engine not running time | Less than 20 seconds |
| (b) Soak time | 7 hours or more |
| (c) Battery voltage | 10.5 V or higher |
| (d) Time after engine start | 15 seconds or more |
| 2. Either of the following conditions is met | Condition (a) and (b) |
| (a) Minimum intake air temperature after engine start | 10°C (14°F) or higher |
| (b) Engine coolant temperature before engine start | 10°C (14°F) or higher |
| Difference between engine coolant temperature and intake air temperature | Less than -20°C (-36°F) or more than 36°C (96°F) |
Scheme 591
Scheme 591: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Turn the ignition switch off.
- With the engine stopped, leave the vehicle as is for 7.5 hours or more [B].
- Start the engine and wait 60 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P011B.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO P011B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P011B is output A DTC P011B and other DTCs are output B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- READ VALUE USING TECHSTREAM (INTAKE AIR TEMPERATURE) Leave the vehicle for 7 hours or more. HINT: It is necessary to leave the vehicle for 7 hours or more to simulate conditions similar to the DTC detection conditions. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / All Data / Intake Air. Read the value displayed on the Techstream. OK Difference between the intake air temperature and actual outside air temperature is 10°C (18°F) or less. HINT: Temperature readings on the vehicle's outside temperature gauge (if equipped) are not suitable for comparing to the intake air temperature reading. The outside temperature gauge has a significant delay built-in to prevent temperature swings from being displayed on its display. Use an accurate thermometer to determine the outside air temperature. NG --> See step 5 OK: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMPERATURE) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / All Data / Coolant Temp. Read the value displayed on the Techstream. OK The difference between the coolant temperature and actual outside air temperature is 10°C (18°F) or less. HINT: If the result is not as specified, check if there are heat sources such as a block heater in the engine compartment. NG --> See step 7 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421953-S08108164442011092600000)
- REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-421955-S10732600322011092600000)
- REPLACE ECM. Refer to «REMOVAL»(ref-421955-S17323454082011092600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-421955-S03198855172011092600000)
| Related DTCs | P0120: Throttle position sensor 1 range check (fluctuating) P0121: Throttle position sensor rationality P0122: Throttle position sensor 1 range check (low voltage) P0123: Throttle position sensor 1 range check (high voltage) P0220: Throttle position sensor 2 range check (fluctuating) P0222: Throttle position sensor 2 range check (low voltage) P0223: Throttle position sensor 2 range check (high voltage) P2135: Throttle position sensor range check (correlation) |
| Required sensors/components (Main) | Throttle position sensor |
| Required sensors/components (Related) | |
| Frequency of operation | Continuous |
| Duration | 2 seconds: P0120, P0122, P0123, P0220, P0222 and P0223 Within 2 seconds: P0121 0.5 seconds: P2135 Case 1 0.4 seconds: P2135 Case 2 |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Either of following conditions A or B met | |
| A. Ignition switch ON | 0.012 seconds or more |
| B. Electronic throttle actuator power | ON |
P0120, P0122, P0123, P0220, P0222, P0223 AND P2135
| Monitor runs whenever following DTCs not stored | P0120, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) |
| Either of following conditions A or B met | |
| A. Ignition switch | ON |
| B. Electronic throttle motor power | ON |
| VTA1 voltage | 0.2 V or less, or 4.54 V or higher |
| Difference in voltage between VTA1 and VTA2 TP sensor 1 - [TP sensor 2 x 0.8 (corrected by learning value)] | Less than 0.8 V, or more than 1.6 V |
| VTA1 voltage | 0.2 V or less |
| VTA1 voltage | 4.54 V or higher |
| Either of the following conditions A or B is met | |
| A. VTA2 voltage | 1.75 V or less |
| B. Both of the following conditions are met | |
| VTA2 voltage | 4.8 V or higher |
| VTA1 voltage | 0.2 to 2.02 V |
| VTA2 voltage | 1.75 V or less |
| VTA2 voltage when the VTA1 is 0.2 to 2.02 V | 4.8 V or higher |
| Difference between VTA1 and VTA2 voltage | 0.02 V or less |
| VTA1 voltage | 0.2 V or less |
| VTA2 voltage | 1.75 V or less |
| VTA1 voltage | 0.2 to 4.54 V |
| VTA2 voltage | 1.75 to 4.8 V |
Scheme 592
Scheme 592: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- With the vehicle stationary, fully depress and release the accelerator pedal [B].
- Idle the engine for 2 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0120, P0121, P0122, P0123, P0220, P0222, P0223 or P2135.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
FAIL-SAFE
When any of these DTCs as well as other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator and the throttle valve is returned to a 6.5° opening angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing in accordance with the accelerator pedal position to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
The ECM continues operating in fail-safe mode until a pass condition is detected and the ignition switch is turned off.
Scheme 593
Scheme 593: WIRING DIAGRAM
| Related DTCs | P0125: Insufficient engine coolant temperature for closed-loop fuel control |
| Required Sensors/Components (Main) | Thermostat, cooling system |
| Required Sensors/Components (Related) | Engine coolant temperature sensor and mass air flow meter |
| Frequency of Operation | Continuous |
| Duration | 62 seconds: Engine coolant temperature at engine start -8.33°C (17°F) or higher 106 seconds: Engine coolant temperature at engine start between -8.33°C (17°F) and -19.44°C (-3°F) 1200 seconds: Engine coolant temperature at engine start less than -19.44°C (-3°F) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0101, P0102, P0103 (Mass Air Flow Sensor) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0128 (Thermostat) |
| Engine coolant temperature sensor output | 62 seconds: Engine coolant temperature at engine start -8.33°C (17°F) or higher 106 seconds: Engine coolant temperature at engine start between -8.33°C (17°F) and -19.44°C (-3°F) 1200 seconds: Engine coolant temperature at engine start less than -19.44°C (-3°F) |
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0125 is output A DTC P0125 and other DTCs are output B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- INSPECT THERMOSTAT Check the valve opening temperature of the thermostat, refer to «INSPECTION»(ref-422101-S29114552122011092600000) . Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. NG --> See step 5 OK: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK --> REPLACE ENGINE COOLANT TEMPERATURE SENSOR
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421953-S08108164442011092600000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-422101-S16434980572011092600000)
CAUTION / NOTICE / HINT
This DTC relates to the thermostat.
| Related DTCs | P0128: Coolant Thermostat |
| Required Sensors / Components (Main) | Thermostat |
| Required Sensor / Components (Related) | Engine coolant temperature sensor, intake air temperature sensor, vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 900 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010, (VVT Oil Control Valve) P0011 (VVT System - Advance) P0012 (VVT System - Retard) P0016 (VVT system - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater) P0102, P0103 (Mass Air Flow Sensor) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0171, P0172 (Fuel System) P0301 - P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0351 - P0354 (Igniter) P0500 (Vehicle Speed Sensor) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor) |
| Battery voltage | 11 V or higher |
| Either of following conditions 1 or 2 met | |
| 1. All of following conditions (a), (b) and (c) met | |
| (a) Engine coolant temperature at engine start - intake air temperature at engine start | 15 to 7°C (-27 to 12.6°F) |
| (b) Engine coolant temperature at engine start | 10 to 51°C (14 to 133°F) |
| (c) Intake air temperature at engine start | 10 to 51°C (14 to 133°F) |
| 2. All of following conditions (d), (e) and (f) met | |
| (d) Engine coolant temperature at engine start - intake air temperature at engine start | More than 7°C (12.6°F) |
| (e) Engine coolant temperature at engine start | 51°C (133°F) or less |
| (f) Intake air temperature at engine start | 10°C (14°F) or higher |
| Accumulated time at vehicle speed of 128 km/h (80 mph) or more | Less than 20 seconds |
| Duration that following conditions A and B met | 5 seconds or more |
| A. Estimated engine coolant temperature | 70°C (158°F) or higher |
| B. Engine coolant temperature sensor output | Below 70°C (158°F) |
Scheme 594
Scheme 594: CONFIRMATION DRIVING PATTERN
- Stop the engine and allow it to soak.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp and Intake Air.
- Check that "Coolant Temp" is 56°C (133°F) or less and "Intake Air" is between 0 and 35°C (0 and 95°F).
- Set the heater to MAX HOT with fresh air mode selected and turn the A/C off.
- Start the engine and drive the vehicle at 80 km/h (50 mph) for 15 minutes [B]. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Enter the following menus: Data List / Function / Snap-shot configuration / Record time / 5 min. Data capture can be started by using the target point. For example, setting the target point to an engine speed of 4000 RPM and then racing the engine, etc. to raise the engine speed to a speed of 4000 RPM or more will cause data capture to start.
- After driving the vehicle at 80 km/h (50 mph) and "Coolant Temp" stabilizes, check that "Coolant Temp" is 70°C (158°F) or higher [C]. HINT: IF "Coolant Temp" is below 70°C (158°F) while driving the vehicle at 80 km/h (50 mph), inspect the cooling system and thermostat.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0128) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0128 is output A DTC P0128 and other DTCs are output B HINT: If any DTCs other than P0128 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK: Go to next step
- INSPECT THERMOSTAT Check the valve opening temperature of the thermostat, refer to «INSPECTION»(ref-422101-S29114552122011092600000) . Standard 80° to 84°C (176° to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. NG --> See step 6 OK --> See step 4
- REPLACE ECM. Refer to «REMOVAL»(ref-421955-S17323454082011092600000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421953-S08108164442011092600000)
- REPLACE THERMOSTAT. Refer to «INSPECTION»(ref-422101-S29114552122011092600000)
| Related DTCs | P0136: Heated oxygen sensor (bank 1) output voltage (Abnormal voltage output) P0136: Heated oxygen sensor (bank 1) impedance (Low) P0137: Heated oxygen sensor (bank 1) output voltage (Low voltage) P0137: Heated oxygen sensor (bank 1) impedance (High) P0138: Heated oxygen sensor (bank 1) output voltage (High voltage) P0138: Heated oxygen sensor (bank 1) output voltage (Extremely high) P0139: Heated oxygen sensor (bank 1) output voltage during fuel cut |
| Required Sensors/Components (Main) | Heated oxygen sensor |
| Required Sensors/Components (Related) | Crankshaft position sensor, engine coolant temperature sensor, mass air flow meter and throttle position sensor |
| Frequency of Operation | Once per driving cycle: Active air-fuel ratio control detection / Heated oxygen sensor output voltage during fuel cut Continuous: Other |
| Duration | 20 seconds: Active air-fuel ratio control detection 90 seconds: Heated oxygen sensor impedance (High) 30 seconds: Heated oxygen sensor impedance (Low) 10 seconds: Output voltage (Stuck high) 7 seconds: Heated oxygen sensor voltage during fuel cut |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0016 (VVT System - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater) P0037, P0038, P102D (Rear Oxygen Sensor Heater) P0102, P0103 (Mass Air Flow Sensor) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0128 (Thermostat) P0171, P0172 (Fuel System) P0301 - P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0412, P0418, P1613 (Secondary Air Injection System Control) P0451, P0452, P0453 (EVAP System) P0500, P0722 (Vehicle Speed Sensor) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor) P2440, P2441, P2444, P2445 (Secondary Air Injection System) |
| Active air-fuel ratio control | Executing |
| Active air-fuel ratio control begins when all of following conditions met | |
| Battery voltage | 11 V or higher |
| Engine coolant temperature | 70°C (158°F) or higher |
| Idling | OFF |
| Engine speed | Less than 4000 RPM |
| Air fuel ratio sensor status | Activated |
| Fuel system status | Closed loop |
| Fuel cut | OFF |
| Engine load | 10 to 80% |
| Shift position | 4th or higher |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (ABNORMAL VOLTAGE OUTPUT, HIGH VOLTAGE AND LOW VOLTAGE)
| DTC P0607 | Not set |
| Battery voltage | 11 V or higher |
| Estimated rear heated oxygen sensor temperature | Below 700°C (1292°F) |
| ECM monitor | Completed |
HEATED OXYGEN SENSOR IMPEDANCE (LOW)
| DTC P0607 | Not set |
| Battery voltage | 11 V or higher |
| Estimated rear heated oxygen sensor temperature | 450 to 750°C (842 to 1382°F) or higher |
| ECM monitor | Completed |
HEATED OXYGEN SENSOR IMPEDANCE (HIGH)
| Battery voltage | 11 V or higher |
| Time after engine start | 2 seconds or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)
| Engine coolant temperature | 70°C (158°F) or higher |
| Estimated catalyst temperature | 400°C (752°F) or higher |
| Fuel cut | ON |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE DURING FUEL CUT
| Either of following conditions met | 1 or 2 |
| 1. Conditions (a), (b) and (c) met | |
| (a) Commanded air-fuel ratio | 14.3 or less |
| (b) Rear heated oxygen sensor voltage | 0.21 to 0.59 V |
| (c) OSC (Oxygen Storage Capacity of Catalyst) | 2 g or more |
| 2. Conditions (d), (e) and (f) met | |
| (d) Commanded air-fuel ratio | 14.9 or more |
| (e) Rear heated oxygen sensor voltage | 0.21 to 0.59 V |
| (f) OSC | 2 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (ABNORMAL VOLTAGE OUTPUT)
| Conditions (a), (b) and (c) met | |
| (a) Commanded air-fuel ratio | 14.3 or less |
| (b) Rear heated oxygen sensor voltage | Below 0.21 V |
| (c) OSC | 2 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (LOW)
| Conditions (a), (b) and (c) met | |
| (a) Commanded air-fuel ratio | 14.9 or more |
| (b) Rear heated oxygen sensor voltage | Higher than 0.59 V |
| (c) OSC | 2 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (HIGH)
| Duration following condition met | 30 seconds or more |
| Heated oxygen sensor impedance | Below 5 ohms |
HEATED OXYGEN SENSOR IMPEDANCE (LOW)
| Duration following condition met | 90 seconds or more |
| Heated oxygen sensor impedance | 15 kohms or higher |
HEATED OXYGEN SENSOR IMPEDANCE (HIGH)
| Duration following condition met | 10 seconds or more |
| Heated oxygen sensor voltage | 1.2 V or higher |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)
| Either condition is met | |
| Time for rear heated oxygen sensor voltage to drop to 0.2 V during fuel cut | 7 seconds or more |
| Time for rear heated oxygen sensor voltage to drop from 0.35 V to 0.2 V during fuel cut | 1 second or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE DURING FUEL CUT
| Duration following condition met | 30 seconds or more |
| Heated oxygen sensor voltage | Varies between 0.1 and 0.9 V |
Scheme 595
Scheme 595: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- With the transmission in 4th gear or higher, drive the vehicle at 60 to 120 km/h (40 to 75 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0136, P0137 and P0138.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [C] through [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 596
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at 60 km/h (40 mph), and then decelerate the vehicle by releasing the accelerator pedal for 5 seconds or more to perform the fuel-cut [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the DTCs. HINT: If a pending DTC or current DTC is output, the system is malfunctioning. If a pending DTC or current DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0139.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, move the shift lever to 2, and then perform steps [C] and [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Refer to Checking Monitor Status, refer to CHECKING MONITOR STATUS .
| Related DTCs | P0171: Fuel trim lean P0172: Fuel trim rich |
| Required Sensors/Components (Main) | Fuel system |
| Required Sensors/Components (Related) | Air fuel ratio sensor Mass air flow meter Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | Within 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010 (Camshaft Timing Oil Control Valve) P0011 (VVT System 1 - Advance) P0012 (VVT System 1 - Retard) P0016 (VVT System - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater) P0102, P0103 (Mass Air Flow Meter) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0351 - P0354 (Igniter) P0412, P0418, P1613 (Secondary air Injection System Control) P0500 (Vehicle Speed Sensor) P2440, P2441, P2444, P2445 (Secondary Air Injection System) |
| Fuel system status | Closed-loop |
| Battery voltage | 11 V or more |
| Catalyst Monitor | Not executed |
| Either of following conditions A or B set | |
| A. Engine RPM | Below 1100 RPM |
| B. Intake air amount per revolution | 0.22 g/rev. or more |
| EVAP purge-cut | Executing |
| Either of following conditions met | |
| Average between short-term fuel trim and long-term fuel trim | 35% or more (varies with ECT) |
| Average between short-term fuel trim and long-term fuel trim | 35% or less (varies with ECT) |
Scheme 597
Scheme 597: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with all the accessories switched off [B].
- With the engine warmed up, idle the engine for 2 minutes or more [C].
- Drive the vehicle at a speed between 60 and 135 km/h (38 and 85 mph) for 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0171 OR P0172) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0171 or P0172 is output A DTC P0171 or P0172 and other DTCs are output B HINT: If any DTCs other than P0171 or P0172 are output, troubleshoot those DTCs first. B --> See step 23 A: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections, refer to «ON-VEHICLE INSPECTION - Step 3»(ref-422107-S17564895802011092600000) . OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leakage, refer to «ON-VEHICLE INSPECTION»(ref-422148-S19823457642011092600000) . OK No leaks from intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Start the engine and turn the Techstream ON. Warm up the engine at an engine speed of 2500 RPM for approximately 90 seconds. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume. Perform the Control the Injection Volume operation with the engine idling (press the Right or Left button to change the fuel injection volume). Monitor the voltage outputs of air fuel ratio sensor and heated oxygen sensor (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream. HINT: Change the fuel injection volume within the range of -12.0% to +12.0%. The injection volume can be changed in fine gradations. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. Standard Voltage Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 (Air fuel ratio) +25% Rich Below 3.1 V -12.5% Lean More than 3.4 V O2S B1S2 (Heated oxygen) +25% Rich More than 0.55 -12.5% Lean Less than 0.4 RESULT Status AFS Voltage B1S1 Status O2S B1S2 Air Fuel Ratio Condition and Air Fuel Ratio Sensor Condition Misfires Suspected Trouble Areas Proceed to Lean/Rich Lean/Rich Normal - - A Lean Lean Actual air fuel ratio lean May occur PCV valve and hose PCV hose connections Injector blockage Gas leakage from exhaust system Intake system Fuel pressure Mass air flow meter Engine coolant temperature sensor A Rich Rich Actual air fuel ratio rich - Injector leakage or blockage Gas leakage from exhaust system Ignition system Fuel pressure Mass air flow meter Engine coolant temperature sensor A Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Lean: During Control the Injection Volume, the air fuel ratio sensor output voltage (AFS Voltage B1S1) is consistently more than 3.4 V, and the heated oxygen sensor output voltage (O2S B1S1) is consistently less than 0.4 V. Rich: During Control the Injection Volume, the AFS Voltage B1S1 is consistently less than 3.1 V, and the O2S is consistently more than 0.55 V. Lean/Rich: During Control the Injection Volume of the Active Test, the output voltage of the heated oxygen sensor alternates correctly. B --> See step 11 A: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp. Read the Coolant Temp twice, when the engine is both cold and warmed up. Standard With cold engine Same as ambient air temperature. With warm engine Between 75°C and 100°C (167°F and 212°F). NG --> See step 24 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / MAF, Coolant Temp and Engine Speed. Allow the engine to idle until the Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 RPM. Standard Between 10.7 g/sec. and 13.1 g/sec. (shift lever: N; A/C: Off NG --> See step 16 OK: Go to next step
- CHECK FUEL PRESSURE Check the fuel pressure, refer to «ON-VEHICLE INSPECTION - Step 2»(ref-422149-S00000012412011092600000) . NG --> REPAIR OR REPLACE FUEL SYSTEM OK: Go to next step
- CHECK FOR EXHAUST GAS LEAKS Check for exhaust gas leaks. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
- CHECK FOR SPARK AND IGNITION HINT: Refer to the ignition system inspection procedure, refer to «ON-VEHICLE INSPECTION»(ref-422103-S00634735632011092600000) . If the spark plugs or ignition system malfunctions, engine misfire may occur. The misfire count can be read using the Techstream. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Cylinder #1 Misfire Count (to Cylinder #4 Misfire Count). NG --> REPAIR OR REPLACE IGNITION SYSTEM OK: Go to next step
- INSPECT FUEL INJECTOR ASSEMBLY (INJECTION AND VOLUME) HINT: Refer to the fuel injector assembly inspection procedure, refer to «INSPECTION»(ref-422143-S37633170572011092600000) . If the injectors malfunction, engine misfire may occur. The misfire count can be read using the Techstream. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Cylinder #1 Misfire Count (to Cylinder #4 Misfire Count). OK --> See step 15 NG --> See step 25
- INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) Inspect the air fuel ratio sensor, refer to «INSPECTION»(ref-421955-S39257944352011092600000) . NG --> See step 26 OK: Go to next step
- CHECK TERMINAL VOLTAGE (POWER SOURCE OF AIR FUEL RATIO SENSOR) See step 2 NG --> See step 21 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM). Refer to «PROCEDURE - Step 11»(ref-422140-S21449223702011092600000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor, refer to «REMOVAL»(ref-421955-S25491508152011092600000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0171 OR P0172) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0171 or P0172 is output A DTC is not output B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER CONNECTOR) Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM, refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-421949-S41663372572011092600000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0171 OR P0172) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0171 or P0172 is output A DTC is not output B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) See step 4 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE MASS AIR FLOW METER Replace the mass air flow meter, refer to «REMOVAL»(ref-421955-S10732600322011092600000) . HINT: If the result of the inspection performed in step 6 indicated no problem, proceed to the next step without replacing the mass air flow meter. NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC is not output A DTC P0171 or P0172 is output B B --> See step 27 A --> END
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - INTEGRATION RELAY [A/F]) See step 6 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- INSPECT A/F HEATER RELAY Inspect the A/F relay, refer to «ON-VEHICLE INSPECTION - Step 4»(ref-421955-S22638332972011092600000) . NG --> REPLACE A/F HEATER RELAY OK --> See step 28
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421953-S08108164442011092600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-421955-S03198855172011092600000)
- REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(ref-422143-S42633620052011092600000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-421955-S25491508152011092600000)
- REPLACE ECM. Refer to «REMOVAL»(ref-421955-S17323454082011092600000)
- CHECK ECM POWER SOURCE CIRCUIT. Refer to «ECM Power Source Circuit»(ref-422140-S00333349102011092600000)
| Related DTCs | P0300: Multiple cylinder misfire P0301: Cylinder 1 misfire P0302: Cylinder 2 misfire P0303: Cylinder 3 misfire P0304: Cylinder 4 misfire |
| Required Sensors/Components (Main) | Fuel injector, Ignition coil and spark plug |
| Required Sensors/Components (Related) | Crankshaft, Camshaft, Engine coolant temperature and intake air temperature sensors and Mass air flow meter |
| Frequency of Operation | Continuous |
| Duration | 1000 to 4000 crankshaft revolutions: Emissions-related misfire 200 to 600 crankshaft revolutions: Catalyst-damaging misfire |
| MIL Operation | 2 driving cycles: (MIL illuminates when misfire detected) MIL flashes immediately: When catalyst-damaging misfire occurs |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0016 (VVT system - Misalignment) P0102, P0103 (Mass Air Flow Meter) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop) P0327, P0328 (Knock Sensor) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0351 - P0354 (Igniter) P0500 (Vehicle Speed Sensor) P0705 (Shift Lever Position Switch) |
| Battery voltage | 8 V or higher |
| VVT system | Not operated by scan tool |
| Engine speed | 400 to 5800 RPM |
| Either of following conditions (a) or (b) met | |
| (a) Engine coolant temperature at engine start | Higher than -7°C (19°F) |
| (b) Engine coolant temperature | Higher than 20°C (68°F) |
| Fuel cut | OFF |
| First 1000 revolutions after engine start, or Check Mode | Crankshaft 1000 revolutions |
| Except above | Crankshaft 1000 revolutions x 4 |
MONITOR PERIOD OF EMISSIONS-RELATED MISFIRE
| Conditions 1, 2 and 3 met | Crankshaft 200 revolutions |
| 1. Driving cycle | 1st |
| 2. Check mode | OFF |
| 3. Engine speed | Less than 2200 RPM |
| Except above | Crankshaft 200 revolutions x 3 |
MONITOR PERIOD OF CATALYST-DAMAGING MISFIRE (MIL BLINKS)
| Misfire rate | 1.538% or more |
EMISSIONS-RELATED MISFIRE
| Number of misfire per 200 revolutions | 113 or more (varies with intake air amount and engine speed) |
CATALYST-DAMAGING MISFIRE (MIL BLINKS)
Refer to Checking Monitor Status, refer to CHECKING MONITOR STATUS .
Scheme 598
Scheme 598: WIRING DIAGRAM
Refer to DTC P0102, refer to WIRING DIAGRAM .
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Record the DTC(s) and freeze frame data.
- Using the Techstream, switch the ECM from normal mode to check mode, refer to «CHECK MODE PROCEDURE»(ref-421953-S37177155462011092600000) .
- Read the misfire count of each cylinder (Cylinder #1 to #4) with the engine idling. If any misfire count is displayed, skip the following confirmation driving pattern.
- If no misfire counts are displayed, drive the vehicle several times at the engine speed and engine load recorded in the freeze frame data. HINT: In order to detect misfire DTCs, drive the vehicle at the engine speed and engine load recorded in the freeze frame data for the time specified in the table below. Engine Speed Duration Idling 7 minutes or more 1000 4 minutes or more 2000 2 minutes or more 3000 1.5 minutes or more
- Check whether misfires have occurred by checking DTCs and freeze frame data. HINT: Do not turn the ignition switch off until the stored DTCs and freeze frame data have been recorded. When the ECM returns to normal mode (default), the stored DTCs, freeze frame data and other data are cleared.
- Record the DTCs, freeze frame data and misfire count.
- Turn the ignition switch off and wait for at least 5 seconds.
| Related DTCs | P0327: Knock sensor range check (Low voltage) P0328: Knock sensor range check (High voltage) |
| Required Sensors/Components (Main) | Knock sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Time after engine start | 5 seconds or more |
| Knock sensor voltage | Below 0.5 V |
KNOCK SENSOR RANGE CHECK (LOW VOLTAGE) P0327
| Knock sensor voltage | Higher than 4.5 V |
KNOCK SENSOR RANGE CHECK (HIGH VOLTAGE) P0328
Scheme 599
Scheme 599: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and wait 10 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0327 or P0328.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 5 minutes and check the DTC judgment result again [C].
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 600
Scheme 600: WIRING DIAGRAM
| Related DTCs | P0335: Crankshaft position sensor range check during cranking P0335: Crankshaft position sensor range check during engine running |
| Required Sensors/Components (Main) | Crankshaft position sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | Case 1: 4.7 seconds Case 2: 15 seconds Case 3: 0.016 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Starter | ON |
| Minimum battery voltage while starter ON | Below 11 V |
| Monitor runs whenever following DTCs not stored | None |
| Engine speed | 600 RPM or less |
| Starter | OFF |
| Time after starter ON to OFF | 3 seconds or more |
| Monitor runs whenever following DTCs not stored | P0340 (Camshaft Position Sensor) |
| All of the following conditions are met | |
| Time after starter OFF to ON | 3 seconds or more |
| Number of crankshaft position sensor signal pulses | 6 times |
| Battery voltage | 7 V or higher |
| Minimum battery voltage while starter ON | Below 11 V |
| Engine speed signal | No signal |
| Number of crankshaft position sensor signal pulses | 132 or less, or 174 or more |
| CKP sensor | CKP sensor output voltage fluctuates while crankshaft revolving 34 CKP sensor signals per crankshaft revolution |
Scheme 601
Scheme 601: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 20 seconds or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0335 or P0339.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 602
Scheme 602: WIRING DIAGRAM
| Related DTCs | P0340: Camshaft position sensor range check P0340: Camshaft position/crankshaft position misalignment |
| Required Sensors/Components (Main) | Camshaft position sensor |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 4 seconds: P0340 (range check) 5 seconds: P0340 (misalignment) |
| MIL Operation | 2 driving cycles: Camshaft position sensor range check Immediate: Camshaft position/crankshaft position misalignment |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Starter | ON |
| Minimal battery voltage while starter ON | Below 11 V |
| CPU initial | Not initial |
CAMSHAFT POSITION SENSOR RANGE CHECK P0340
| Engine speed | 600 RPM or more |
| Starter | OFF |
| VVT system misalignment | Not detected |
CAMSHAFT POSITION/CRANKSHAFT POSITION MISALIGNMENT P0340
| Camshaft position sensor signal | No signal |
CAMSHAFT POSITION SENSOR RANGE CHECK P0340
| Camshaft position and crankshaft position phase | Misaligned |
| Camshaft position sensor signal | No signal |
CAMSHAFT POSITION/CRANKSHAFT POSITION MISALIGNMENT P0340
| Camshaft position sensor signal | Camshaft position sensor output voltage fluctuates while camshaft revolving 3 camshaft position sensor signals per 2 crankshaft revolutions |
Scheme 603
Scheme 603: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 10 seconds or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0340.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0351: Igniter (cylinder 1) malfunction P0352: Igniter (cylinder 2) malfunction P0353: Igniter (cylinder 3) malfunction P0354: Igniter (cylinder 4) malfunction |
| Required Sensors/Components (Main) | Igniter |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 0.256 seconds and 4 sparks |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Either of following conditions met | |
| A. Engine speed | 1500 RPM or less |
| B. Starter | OFF |
| Spark cut | Not operating |
| Either of following conditions C or D met | |
| C. Both of following conditions (a) and (b) met | |
| (a) Engine speed | 500 RPM or less |
| (b) Battery voltage | 6 V or higher |
| D. All of following conditions (a), (b) and (c) met | |
| (a) Engine speed | More than 500 RPM |
| (b) Battery voltage | 10 V or higher |
| (c) Number of sparks after CPU reset | 5 sparks or more |
| IGF signal | ECM does not receive any IGF signal despite ECM sending IGT signal to igniter |
| IGF signal | Igniter transmits IGF signal when it receives IGT signal from ECM |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 10 seconds or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0351, P0352, P0353 or P0354.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 604
Scheme 604: WIRING DIAGRAM
Scheme 605
| Related DTCs | P0412: Secondary air injection system air switching valve circuit range check |
| Required Sensors/Components (Main) | Air injection control driver |
| Required Sensors/Components (Related) | Air switching valve |
| Frequency of Operation | Once per driving cycle |
| Duration | 3 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Secondary air injection system | Operating |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Time after ignition switch off to ON | 0.5 seconds or more |
| Starter | OFF |
| Time after starter turned from ON to OFF | 0.5 seconds or more |
| Monitor runs whenever following DTCs not stored | None |
| Secondary air injection system | Not operating |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Time after ignition switch off to ON | 0.5 seconds or more |
| Starter | OFF |
| Time after starter turned from ON to OFF | 0.5 seconds or more |
| Diagnostic signal duty ratio from air injection control driver | 31% or more, and 48% or less |
| Diagnostic signal duty ratio from air injection control driver | 70% or more, and 90% or less when secondary air injection system operating. 0% when secondary air injection system not operating. |
Scheme 606
Scheme 606: CONFIRMATION DRIVING PATTERN
Note. This Air Injection Check only allows technicians to operate the AIR system for a maximum of 5 seconds. Furthermore, the check can only be performed up to 4 times per trip. If the test is repeated, intervals of at least 30 seconds are required between checks. While AIR system operation using the Techstream is prohibited, the Techstream display indicates the prohibition (WAIT or ERROR). If ERROR is displayed on the Techstream during the test, stop the engine for 10 minutes, and then try again. Performing the Air Injection Check repeatedly may cause damage to the AIR system. If necessary, leave an interval of several minutes between System Check operations to prevent the system from overheating. When performing the Air Injection Check operation after the battery cable has been reconnected, wait for 7 minutes with the ignition switch turned to ON or the engine running. Turn the ignition switch off when the Air Injection Check operation finishes.
- Start the engine and warm it up.
- Turn the ignition switch off.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear DTCs (if output), refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine and ECT / Utility / Secondary Air Injection Check / Automatic Mode.
- Start the engine after the Techstream initialization is finished.
- Perform the System Check operation by pressing ENTER (Next).
- Perform the following to confirm the AIR system pending codes: Press the ENTER (Exit).
- Check for pending DTCs [B]. OK No pending DTC is output.
- After the "Air injection check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0412.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If no permanent DTC is output, the system is normal. If a permanent DTC is output, the system is malfunctioning.
- Turn the ignition switch off.
Scheme 607
Scheme 607: WIRING DIAGRAM
| Related DTCs | P0418: Secondary air injection system air pump circuit range check |
| Required Sensors/Components (Main) | Air injection control driver |
| Required Sensors/Components (Related) | Air pump |
| Frequency of Operation | Once per driving cycle |
| Duration | 3 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | |
| Secondary air injection system | Operating |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Time after ignition switch off to ON | More than 0.5 seconds |
| Starter | OFF |
| Time after starter turned from ON to OFF | More than 0.5 seconds |
| Monitor runs whenever following DTCs not stored | |
| Secondary air injection system | Not operating |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Time after ignition switch off to ON | More than 0.5 seconds |
| Starter | OFF |
| Time after starter turned from ON to OFF | More than 0.5 seconds |
| Diagnostic signal duty ratio from air injection control driver | 11% or more, and 29% or less |
| Diagnostic signal duty ratio from air injection control driver | 70% or more, and 90% or less when secondary air injection system operating. 0% when secondary air injection system not operating. |
Note. This Air Injection Check only allows technicians to operate the AIR system for a maximum of 5 seconds. Furthermore, the check can only be performed up to 4 times per trip. If the test is repeated, intervals of at least 30 seconds are required between checks. While AIR system operation using the Techstream is prohibited, the Techstream display indicates the prohibition (WAIT or ERROR). If ERROR is displayed on the Techstream during the test, stop the engine for 10 minutes, and then try again. Performing the Air Injection Check repeatedly may cause damage to the AIR system. If necessary, leave an interval of several minutes between System Check operations to prevent the system from overheating. When performing the Air Injection Check operation after the battery cable has been reconnected, wait for 7 minutes with the ignition switch turned to ON or the engine running. Turn the ignition switch off when the Air Injection Check operation finishes.
- Start the engine and warm it up.
- Turn the ignition switch off.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear DTCs (if output), refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine and ECT / Utility / Secondary Air Injection Check / Automatic Mode.
- Start the engine after the Techstream initialization is finished.
- Perform the System Check operation by pressing ENTER (Next).
- Perform the following to confirm the AIR system pending codes: Press the ENTER (Exit).
- Check for pending DTCs [B]. OK No pending DTC is output.
- After the "Air injection check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0418.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . HINT: If no permanent DTC is output, the system is normal. If a permanent DTC is output, the system is malfunctioning.
- Turn the ignition switch off.
- CHECK HARNESS AND CONNECTOR (AIR PUMP ASSEMBLY - AIR INJECTION CONTROL DRIVER, AIR INJECTION CONTROL DRIVER - BATTERY) Disconnect the cable from the negative (-) battery terminal. Disconnect the cable from the positive (+) battery terminal. Disconnect the air pump connector. Disconnect the air injection control driver connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition A33-2 - A9-2 (VP) Always Below 1 ohms A9-1 - Positive battery terminal Always Below 1 ohms A33-4 - Body ground Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition A33-2 or A9-2 (VP) - Body ground Always 10 kohms or higher A9-1 or Positive battery terminal - Body ground Always 10 kohms or higher Reconnect the air injection control driver connector. Reconnect the air pump connector. Reconnect the cable to the positive (+) battery terminal. Reconnect the cable to the negative (-) battery terminal. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- INSPECT AIR PUMP ASSEMBLY Inspect the air pump assembly, refer to «ON-VEHICLE INSPECTION»(ref-422150-S25143702582011092600000) . NG --> See step 4 OK --> See step 3
- REPLACE AIR INJECTION CONTROL DRIVER. Refer to «REMOVAL»(ref-422150-S18310450202011092600000)
- REPLACE AIR PUMP ASSEMBLY Replace the air pump assembly, refer to «REMOVAL»(ref-422150-S21810488222011092600000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Start the engine and warm it up. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear DTCs (if stored), refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . Enter the following menus: Powertrain / Engine and ECT / Utility / Secondary Air Injection Check / Automatic Mode. Start the engine after the Techstream initialization is finished. Perform the system check operation by pressing Next. After operating the AIR system, perform the following to confirm the AIR system pending codes: Press the Exit button. Check pending DTCs. OK No pending DTC is output. Turn the ignition switch off. NOTE: When performing the Air Injection Check operation after the battery cable has been reconnected, wait for 7 minutes with the ignition switch turned to ON or the engine running. Turn the ignition switch off when the Air Injection Check operation finishes. NG --> See step 6 OK --> END
- REPLACE AIR INJECTION CONTROL DRIVER. Refer to «REMOVAL»(ref-422150-S18310450202011092600000)
| Related DTCs | P0420: Catalyst Deterioration |
| Required Sensors/Components (Main) | Air fuel ratio sensor and heated oxygen sensor |
| Required Sensors/Components (Related) | Intake air temperature sensor, mass air flow meter, crankshaft position sensor and engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | Approximately 30 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (VVT Oil Control Valve) P0011 (VVT System - Advance) P0012 (VVT System - Retard) P0016 (VVT system - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater) P0037, P0038, P0141, P102D (Rear Oxygen Sensor Heater) P0102, P0103 (Mass Air Flow Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0136, P0137, P0138, P0139, P0607 (Rear Oxygen Sensor) P0171, P0172 (Fuel System) P0301 - P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0351 - P0354 (Igniter) P0412, P0418, P1613 (Secondary Air Injection System Control) P0500 (Vehicle Speed Sensor) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor) P2440, P2441, P2444, P2445 (Secondary Air Injection System) |
| Battery voltage | 11 V or higher |
| Intake air temperature | 10°C (14°F) or higher |
| Engine coolant temperature sensor | 70°C (158°F) or higher |
| Atmospheric pressure | 75 kPa (562 mmHg) or higher |
| Idling | OFF |
| Engine speed | Less than 4000 RPM |
| Air fuel ratio sensor status | Activated |
| Fuel system status | Closed loop |
| Engine load | 10 to 80% |
| All of following conditions (a), (b) and (c) met | |
| (a) Mass air flow rate | 2.5 to 50 g/sec |
| (b) Estimated front catalyst temperature | 660 to 840°C (1220 to 1544°F) |
| (c) Estimated rear catalyst temperature | 475 to 800°C (887 to 1472°F) |
| Shift position | 4th or higher |
| Oxygen Storage Capacity (OSC) of three-way catalytic converter | Less than 0.084 g |
Refer to Checking Monitor Status, refer to CHECKING MONITOR STATUS .
Performing this confirmation driving pattern will activate the catalyst efficiency monitor. This is very useful for verifying the completion of a repair.
Scheme 608
Scheme 608: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor.
- Check that Catalyst Efficiency / Current is Incomplete.
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher [A].
- Drive the vehicle at approximately 60 km/h (38 mph) for 10 minutes or more [B]. NOTE: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item will change to Complete as the catalyst efficiency monitor operates [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Check if any DTCs (pending DTCs) are stored. HINT: If the monitor does not change to Complete, and no pending DTCs are stored, perform the following procedure.
- Drive the vehicle at a speed between 75 and 100 km/h (47 and 63 mph) for 10 minutes or more [D]. NOTE: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item will change to Complete as the catalyst efficiency monitor operates [E].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Check if any DTCs (pending DTCs) are stored.
If Catalyst does not change to Complete, and no pending DTCs are stored, extend the driving time.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0420) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0420 is output A DTC P0420 and other DTCs are output B HINT: If any DTCs other than P0420 are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (INJECTION VOLUME CONTROL) Connect the Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine at an engine speed of 2500 RPM for approximately 90 seconds. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume for A/F sensor. Perform the Control the Injection Volume for A/F sensor operation with the engine idling (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the voltage outputs of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream. HINT: The Control the Injection Volume for A/F sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 25%. Each sensor reacts in accordance with increases and decreases in the fuel injection volume. Standard Tester Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 (Air fuel ratio sensor) +25% Rich Below 3.1 V AFS Voltage B1S1 (Air fuel ratio sensor) -12.5% Lean Higher than 3.4 V O2S B1S2 (Heated oxygen sensor) +25% Rich Higher than 0.55 V O2S B1S2 (Heated oxygen sensor) -12.5% Lean Below 0.4 V RESULT Status of AFS Voltage B1S1 Status of O2S B1S2 A/F Condition and A/F and HO2 Sensor Condition Misfire Main Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - Three Way Catalytic Converter (TWC) Gas leak from exhaust system A Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor Lean/Rich Lean Heated oxygen sensor malfunction - Heated oxygen sensor Gas leak from exhaust system C Lean/Rich Rich Heated oxygen sensor malfunction - Heated oxygen sensor Gas leak from exhaust system Lean Lean Actual air fuel ratio lean May occur Extremely rich or lean actual air fuel ratio Gas leak from exhaust system D Rich Rich Actual air fuel ratio rich - Extremely rich or lean actual air fuel ratio Gas leak from exhaust system Lean: During Control the Injection Volume for A/F sensor, the air fuel ratio sensor output voltage (AFS) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S) is consistently below 0.4 V. Rich: During Control the Injection Volume for A/F sensor, the AFS voltage is consistently below 3.1 V, and the O2S voltage is consistently higher than 0.55 V. Lean/Rich: During Control the Injection Volume for A/F sensor of the Active Test, the output voltages of the air fuel ratio sensor and heated oxygen sensor alternate correctly. B --> See step 7 C --> See step 9 D --> See step 8 A: Go to next step
- INSPECT FOR EXHAUST GAS LEAK Inspect for exhaust gas leakage. OK No gas leakage. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK: Go to next step
- REPLACE FRONT EXHAUST PIPE ASSEMBLY (TWC: FRONT CATALYST AND REAR CATALYST) Replace the front exhaust pipe assembly, refer to «REMOVAL»(ref-422105-S03173197242011092600000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-421953-S17634125332011092600000) . Drive the vehicle at a speed between 64 km/h and 113 km/h (40 mph and 70 mph) for at least 10 minutes. Enter the following menus: Powertrain / Engine / DTC. Read the DTCs (Pending DTCs). Result Pending DTC is not output NEXT --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421953-S08108164442011092600000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-421955-S25491508152011092600000)
- CHECK EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO, REPAIR CAUSE AND GO TO STEP 3. Refer to «DTC P0171: System Too Lean (Bank 1); DTC P0172: System Too Rich (Bank 1)»(ref-422141-S29714303582011092600000)
- INSPECT FOR EXHAUST GAS LEAK Inspect for exhaust gas leakage. OK No gas leakage. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK --> See step 10
- REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL»(ref-421955-S02330336742011092600000)
