MONITOR STRATEGY
| Related DTCs | P0010: Camshaft timing oil control valve range check (bank 1) P0020: Camshaft timing oil control valve range check (bank 2) |
| Required Sensors/Components (Main) | Camshaft timing oil control valve |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
TYPICAL ENABLING CONDITIONS
| Monitor runs whenever following DTCs not present | None |
| All of following conditions met | |
| Starter | OFF |
| Ignition switch | ON |
| Time after ignition switch off to ON | 0.5 seconds or more |
TYPICAL MALFUNCTION THRESHOLDS
| One of following conditions met | |
| A. All of following conditions met | |
| Battery voltage | 11 to 13 V |
| Target duty ratio | Less than 70% |
| Output signal duty ratio | 100% |
| B. All of following conditions met | |
| Battery voltage | 13 V or higher |
| Target duty ratio | Less than 80% |
| Output signal duty ratio | 100% |
| C. Both of following conditions met | |
| Current cut status | Not cut |
| Output signal duty ratio | 3% or less |
COMPONENT OPERATING RANGE
| Camshaft timing oil control valve duty ratio | 3 to 100% |
Scheme 396
Scheme 396: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 5 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Code.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0010 or P0020.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 397
Scheme 397: WIRING DIAGRAM
PROCEDURE
- CHECK DTC Clear the DTCs after recording the freeze frame data and DTCs. Turn the ignition switch off. Allow the engine to idle and check for DTCs. Check that P0010 or P0020 is output. OK P0010 or P0020 is output. NG --> CHECK FOR INTERMITTENT PROBLEMS OK: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Inspect the camshaft timing oil control valve assembly (for Intake Side of Bank 1, 2). Refer to «INSPECTION - Step 1»(ref-421954-S15004613002011092600000) . NG --> REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY OK: Go to next step
- CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY - ECM) Disconnect the camshaft timing oil control valve assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B16-1 - B37-19 (OC1+) Always Below 1 ohms B19-1 - B36-19 (OC2+) Always Below 1 ohms B16-2 - B37-20 (OC1-) Always Below 1 ohms B19-2 - B36-20 (OC2-) Always Below 1 ohms B16-1 or B37-19 (OC1+) - Body ground Always 10 kohms or higher B19-1 or B36-19 (OC2+) - Body ground Always 10 kohms or higher B16-2 or B37-20 (OC1-) - Body ground Always 10 kohms or higher B19-2 or B36-20 (OC2-) - Body ground Always 10 kohms or higher Reconnect the camshaft timing oil control valve assembly connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE ECM
| Related DTCs | P0011: Advanced camshaft timing (bank 1) P0012: Retarded camshaft timing (bank 1) P0021: Advanced camshaft timing (bank 2) P0022: Retarded camshaft timing (bank 2) |
| Required Sensors/Components (Main) | Camshaft timing oil control valve and VVT Actuator |
| Required Sensors/Components (Related) | Crankshaft position sensor, VVT sensor and Engine coolant temperature sensor |
| Frequency of Operation | Continuous |
| Duration | Within 10 seconds |
| MIL Operation | Advanced camshaft timing: Immediate Retarded camshaft timing: 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010, P0020 (VVT Oil Control Valve) P0016, P0018 (VVT System - Misalignment) P0102, P0103 (Mass Air Flow Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) |
| Battery voltage | 11 V or higher |
| Engine speed | 400 to 4000 RPM |
| Engine coolant temperature sensor | 75°C (167°F) to 100°C (212°F) |
| Both of following conditions are met | |
| Deviation of actual valve timing and target valve timing | 5°CA (Crankshaft Angle) |
| Valve timing | No change at advanced valve timing |
| Both of following conditions are met | |
| Deviation of actual valve timing and target valve timing | 5°CA (Crankshaft Angle) |
| Valve timing | No change at retarded valve timing |
If the difference between the target and actual camshaft timing is more than the specified value, the ECM operates the VVT actuator. Then, the ECM monitors the camshaft timing change for 5 seconds.
Scheme 398
Scheme 398: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 3 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0011, P0012, P0021 or P0022.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
- Repeat the pattern of accelerating the vehicle from rest to approximately 60 km/h (37 mph) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
- Idle the engine for 3 minutes or more [G].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [H].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform the following procedure.
- Perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0013: Exhaust camshaft timing oil control valve (bank 1) P0023: Exhaust camshaft timing oil control valve (bank 2) |
| Required sensors/components (Main) | Exhaust camshaft timing oil control valve |
| Required sensors/components (Related) | |
| Frequency of operation | Continuous |
| Duration | 1 second |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not present | None |
| All of following conditions met | |
| Starter | OFF |
| Ignition switch | ON |
| Time after ignition switch off to ON | 0.5 seconds or more |
| One of following conditions met | |
| A. All of following conditions met | |
| Battery voltage | 11 to 13 V |
| Target duty ratio | Less than 70% |
| Output signal duty ratio | 100% |
| B. All of following conditions met | |
| Battery voltage | 13 V or higher |
| Target duty ratio | Less than 80% |
| Output signal duty ratio | 100% |
| C. Both of following conditions met | |
| Current cut status | Not cut |
| Output signal duty ratio | 3% or less |
| Camshaft timing oil control valve duty-cycle | 3 to 100% when engine running |
CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 5 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Code [B].
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0013 or P0023.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 399
Scheme 399: WIRING DIAGRAM
- CHECK DTC (DTC P0013 OR P0023) Connect the Techstream to the DLC3. Clear the DTCs after recording the freeze frame data and DTCs. Turn the ignition switch off. Allow the engine to idle and check DTCs. Check that P0013 or P0023 is output. OK P0013 or P0023 is output. NG --> See step 4 OK: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Inspect the camshaft timing oil control valve assembly (for Exhaust Side of Bank 1, 2). Refer to «INSPECTION - Step 1»(ref-421954-S15004613002011092600000) . NG --> See step 5 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY - ECM) Disconnect the camshaft timing oil control valve assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B17-1 - B37-21 (OE1+) Always Below 1 ohms B17-2 - B37-22 (OE1-) Always Below 1 ohms B20-1 - B36-21 (OE2+) Always Below 1 ohms E20-2 - B36-22 (OE2-) Always Below 1 ohms B17-1 or B37-21 (OE1+) - Body ground Always 10 kohms or higher B17-2 or B37-22 (OE1-) - Body ground Always 10 kohms or higher B20-1 or B36-21 (OE2+) - Body ground Always 10 kohms or higher E20-2 or B36-22 (OE2-) - Body ground Always 10 kohms or higher Reconnect the camshaft timing oil control valve assembly connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-421952-S26737171072011092600000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-421954-S26745234372011092600000)
- REPLACE ECM. Refer to «REMOVAL»(ref-421954-S13588411562011092600000)
| Related DTCs | P0014: Advanced camshaft timing (bank 1) P0015: Retarded camshaft timing (bank 1) P0024: Advanced camshaft timing (bank 2) P0025: Retarded camshaft timing (bank 2) |
| Required sensors/components (Main) | Camshaft timing oil control valve and VVT Actuator |
| Required sensors/components (Related) | Crankshaft position sensor, VVT sensor and Engine coolant temperature sensor |
| Frequency of operation | Continuous |
| Duration | Within 10 seconds |
| MIL operation | Advanced camshaft timing (bank 1): 2 driving cycles Advanced camshaft timing (bank 2): 2 driving cycles Retarded camshaft timing (bank 1): Immediate Retarded camshaft timing (bank 2): Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | P0013, P0023 (Exhaust VVT Oil Control Valve) P0017, P0019 (Exhaust VVT System - Misalignment) P0102, P0103 (Mass Air Flow Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) |
| Battery voltage | 11 V or higher |
| Engine speed | 500 to 4000 RPM |
| Engine coolant temperature | 75 to 100°C (167 to 212°F) |
| Both conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at advanced valve timing |
| Both conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at retarded valve timing |
Scheme 400
Scheme 400: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 3 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0014, P0015, P0024 or P0025.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
- Repeat the pattern of accelerating the vehicle from rest to approximately 60 km/h (37 mph) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
- Idle the engine for 3 minutes or more [G].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [H].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform the following procedure.
- Perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0014, P0015, P0024 OR P0025) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Display (DTC Output) Proceed to P0014, P0015, P0024 or P0025 A P0014, P0015, P0024 or P0025 and other DTCs B HINT: If any DTCs other than P0014, P0015, P0024 or P0025 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE) Connect the Techstream to the DLC3. Start the engine. Warm up the engine. Turn the Techstream on. Turn the A/C switch on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1) or Control the VVT Linear (Bank 2). Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Techstream Operation Specified Condition 0% (OFF) Normal engine speed 127% (ON) Engine idles roughly or stalls (soon after camshaft timing oil control valve switched from OFF to ON) HINT: Refer to "Data List / Active Test" [VVT OCV Duty #1, VVT Change Angle #1, VVT OCV Duty #2 and VVT Change Angle #2]. Refer to «DATA LIST / ACTIVE TEST»(ref-421952-S15138037352011092600000) . NG --> See step 5 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0014, P0015, P0024 OR P0025) Connect the Techstream to the DLC3. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . Warm up the engine. Switch the ECM from normal mode to check mode using the Techstream. Refer to «CHECK MODE PROCEDURE»(ref-421952-S25071577192011092600000) . Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Read DTCs using the Techstream. OK No DTC output. NG --> See step 5 OK --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421952-S27905813582011092600000)
- CHECK VALVE TIMING (CHECK FOR LOOSE TEETH AND WHETHER TIMING CHAIN HAS JUMPED TOOTH) Remove the cylinder head cover RH and LH. TEXT IN ILLUSTRATION *1 Timing Mark Turn the crankshaft pulley and align its groove with the "0" timing mark on the timing chain cover. Check that the timing marks on the camshaft timing gears are aligned with the timing marks of the bearing cap as shown in the illustration. If not, turn the crankshaft 1 revolution (360°), and then align the marks as above. OK Timing marks on camshaft timing gears are aligned as shown in the illustration. Reinstall the cylinder head cover RH and LH. NG --> See step 10 OK: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (CAMSHAFT TIMING OIL CONTROL VALVE FOR EXHAUST CAMSHAFT) Inspect the camshaft timing oil control valve assembly. Refer to «INSPECTION - Step 1»(ref-421954-S15004613002011092600000) . NG --> See step 11 OK: Go to next step
- INSPECT OIL CONTROL VALVE FILTER AND PIPE Remove the oil pipe No. 1 or No. 2. TEXT IN ILLUSTRATION *1 No. 1 Oil Pipe *2 No. 2 Oil Pipe Remove the oil control valve filter. Check that the filter and pipe are not clogged. OK The filter and pipe are not clogged. Reinstall the oil control valve filter. Reinstall the oil pipe No. 1 or No. 2. NG --> CLEAN OIL CONTROL VALVE FILTER AND PIPE OK: Go to next step
- REPLACE CAMSHAFT TIMING EXHAUST GEAR ASSEMBLY Replace the camshaft timing exhaust gear assembly. Refer to «REMOVAL»(ref-422094-S36590258942011092600000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the Techstream on. Clear DTCs. Warm up the engine. Switch the ECM from normal mode to check mode using the Techstream. Refer to «CHECK MODE PROCEDURE»(ref-421952-S25071577192011092600000) . Drive the vehicle for more than 10 minutes or more. Read output DTCs using the Techstream. OK No DTC output. HINT: DTC P0014, P0015, P0024 or P0025 is stored when foreign objects in the engine oil are caught in some parts of the system. These codes will remain stored even if the system returns to normal after a short time. These foreign objects are then captured by the oil filter, thus eliminating the source of the problem. NG --> See step 12 OK --> SYSTEM IS OK
- ADJUST VALVE TIMING. Refer to «REASSEMBLY»(ref-422094-S42016673532011092600000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-421954-S26745234372011092600000)
- REPLACE ECM. Refer to «REMOVAL»(ref-421954-S13588411562011092600000)
| Related DTCs | Deviation in crankshaft position sensor signal and VVT sensor signal (Bank 1) |
| Required Sensors/Components (Main) | VVT actuator |
| Required Sensors/Components (Related) | VVT sensor, Crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | Less than 60 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | P0010, P0020 (VVT Oil Control Valve) P0016, P0018 (VVT System - Misalignment) P0102, P0103 (Mass Air Flow Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) |
| Engine speed | 500 to 1000 RPM |
| One of following conditions is met | |
| VVT learning value at maximum retarded valve timing (Bank 1) | Less than 25.1°CA (crankshaft angle) |
| VVT learning value at maximum retarded valve timing (Bank 2) | Less than 25.1°CA (crankshaft angle) |
| VVT learning value at maximum retarded valve timing (Bank 1) | More than 49.9°CA (crankshaft angle) |
| VVT learning value at maximum retarded valve timing (Bank 2) | More than 49.9°CA (crankshaft angle) |
Scheme 401
Scheme 401: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the ECT reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0016 or P0018.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [G].
- Drive the vehicle for 2 to 3 minutes [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 5 minutes or more [F].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [G].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0016 OR P0018) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Display (DTC Output) Proceed to P0016 or P0018 A P0016 or P0018 and other DTCs B HINT: If any DTCs other than P0016 or P0018 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE FOR INTAKE CAMSHAFT) Connect the Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine. Turn the A/C switch on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1) or Control the VVT Linear (Bank 2). Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Tester Operation Specified Condition 0% (OFF) Normal engine idle speed 127% (ON) Engine idles roughly or stalls (soon after camshaft timing oil control valve switched from OFF to ON) HINT: Refer to "Data List / Active Test" [VVT OCV Duty #1, VVT Change Angle #1, VVT OCV Duty #2 and VVT Change Angle #2]. Refer to «DATA LIST / ACTIVE TEST»(ref-421952-S15138037352011092600000) . NG --> See step 4 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0016 OR P0018) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . Start the engine and warm it up. Switch the ECM from normal mode to check mode using the Techstream. Refer to «CHECK MODE PROCEDURE»(ref-421952-S25071577192011092600000) . Drive the vehicle in accordance with the driving pattern described in the CONFIRMATION DRIVING PATTERN. Read the DTCs using the Techstream. OK No DTC output. NG --> See step 4 OK --> END
- CHECK VALVE TIMING (CHECK FOR LOOSE TEETH AND WHETHER TIMING CHAIN HAS JUMPED TOOTH) Remove the cylinder head cover RH and LH. TEXT IN ILLUSTRATION *1 Timing Mark Turn the crankshaft pulley and align its groove with the "0" timing mark on the timing chain cover. Check that the timing marks on the camshaft timing gears are aligned with the timing marks of the bearing cap as shown in the illustration. If not, turn the crankshaft 1 revolution (360°), and then align the marks as above. OK Timing marks on camshaft timing gears are aligned as shown in the illustration. Reinstall the cylinder head cover RH and LH. NG --> See step 10 OK: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) Inspect the camshaft timing oil control valve. Refer to «INSPECTION - Step 1»(ref-421954-S15004613002011092600000) . NG --> See step 11 OK: Go to next step
- CHECK OIL PIPE AND OIL CONTROL VALVE FILTER Remove the oil pipe No. 1 or No. 2. TEXT IN ILLUSTRATION *1 No. 1 Oil Pipe *2 No. 2 Oil Pipe Remove the oil control valve filter. Check that the filter and pipe are not clogged. OK The filter and pipe are not clogged. Reinstall the oil control valve filter. Reinstall the oil pipe No. 1 or No. 2. NG --> See step 12 OK: Go to next step
- REPLACE CAMSHAFT TIMING GEAR ASSEMBLY Replace the camshaft timing gear assembly. Refer to «REMOVAL»(ref-422094-S36590258942011092600000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . Start the engine and warm it up. Switch the ECM from normal mode to check mode using the Techstream. Refer to «CHECK MODE PROCEDURE»(ref-421952-S25071577192011092600000) . Drive the vehicle for more than 10 minutes. Confirm that no DTC is output using the Techstream. OK No DTC output. HINT: DTC P0016 or P0018 is stored when foreign objects in the engine oil are caught in some parts of the system. These codes will stay stored even if the system returns to normal after a short time. These foreign objects are then captured by the oil filter, thus eliminating the source of the problem. NG --> See step 13 OK --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421952-S27905813582011092600000)
- ADJUST VALVE TIMING. Refer to «REASSEMBLY»(ref-422094-S42016673532011092600000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-421954-S26745234372011092600000)
- REPLACE OIL PIPE AND OIL CONTROL VALVE FILTER. Refer to «DISASSEMBLY»(ref-422094-S07769615052011092600000)
- REPLACE ECM. Refer to «REMOVAL»(ref-421954-S13588411562011092600000)
| Related DTCs | Deviation in crankshaft position sensor signal and camshaft position sensor signal (Bank 2 Sensor 2) |
| Required Sensors/Components (Main) | Timing chain/belt |
| Required Sensors/Components (Related) | None |
| Frequency of Operation | Once per driving cycle |
| Duration | Less than 60 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | P0013, P0023 (Exhaust VVT Oil Control Valve) P0017, P0019 (Exhaust VVT System - Misalignment) P0102, P0103 (Mass Air Flow Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) |
| Engine speed | 500 to 1000 RPM |
| One of following conditions is met | |
| VVT learning value at maximum advanced valve timing (Bank 1) | Less than 81.1°CA (crankshaft angle) |
| VVT learning value at maximum advanced valve timing (Bank 2) | Less than 81.1°CA (crankshaft angle) |
| VVT learning value at maximum advanced valve timing (Bank 1) | More than 105.9°CA (crankshaft angle) |
| VVT learning value at maximum advanced valve timing (Bank 2) | More than 105.9°CA (crankshaft angle) |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the ECT reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0017 or P0019.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [G].
- Drive the vehicle for 2 to 3 minutes [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 5 minutes or more [F].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [G].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0017 AND P0019) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Code. Read the DTCs. RESULT Display (DTC Output) Proceed to P0017 or P0019 A P0017 or P0019 and other DTCs B HINT: If any DTCs other than P0017 or P0019 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY FOR EXHAUST CAMSHAFT) Connect the Techstream to the DLC3. Start the engine and turn the Techstream on. Turn the A/C switch on. Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Exhaust Linear (Bank 1) or Control the VVT Exhaust Linear (Bank 2). Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Tester Operation Specified Condition 0% (OFF) Normal engine idle speed 127% (ON) Engine idles roughly or stalls (soon after camshaft timing oil control valve switched from OFF to ON) HINT: Refer to "Data List / Active Test" [VVT OCV Duty #1, VVT Change Angle #1]. Refer to «DATA LIST / ACTIVE TEST»(ref-421952-S15138037352011092600000) . NG --> See step 4 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0017 OR P0019) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . Start the engine and warm it up. Switch the ECM from normal mode to check mode using the Techstream. Refer to «CHECK MODE PROCEDURE»(ref-421952-S25071577192011092600000) . Drive the vehicle for more than 10 minutes. Read the DTCs using the Techstream. OK No DTC output. NG --> See step 4 OK --> END
- CHECK VALVE TIMING (CHECK FOR LOOSE TEETH AND WHETHER TIMING CHAIN HAS JUMPED TOOTH) Remove the cylinder head cover RH and LH. TEXT IN ILLUSTRATION *1 Timing Mark Turn the crankshaft pulley and align its groove with the "0" timing mark on the timing chain cover. Check that the timing marks on the camshaft timing gears are aligned with the timing marks of the bearing cap as shown in the illustration. If not, turn the crankshaft 1 revolution (360°), and then align the marks as above. OK Timing marks on camshaft timing gears are aligned as shown in the illustration. Reinstall the cylinder head cover RH and LH. NG --> See step 10 OK: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Inspect the camshaft timing oil control valve. Refer to «REMOVAL»(ref-421954-S26745234372011092600000) . NG --> See step 11 OK: Go to next step
- CHECK OIL CONTROL VALVE FILTER AND PIPE Remove the oil pipe No. 1 or No. 2. TEXT IN ILLUSTRATION *1 No. 1 Oil Pipe *2 No. 2 Oil Pipe Remove the oil control valve filter. Check that the filter and pipe are not clogged. OK The filter and pipe are not clogged. Reinstall the oil control valve filter. Reinstall the oil pipe No. 1 or No. 2. NG --> REPLACE OIL CONTROL VALVE FILTER OR PIPE OK: Go to next step
- REPLACE CAMSHAFT TIMING EXHAUST GEAR ASSEMBLY Replace the camshaft timing exhaust gear assembly. Refer to «REMOVAL»(ref-422094-S36590258942011092600000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . Start the engine and warm it up. Switch the ECM from normal mode to check mode using the Techstream. Refer to «CHECK MODE PROCEDURE»(ref-421952-S25071577192011092600000) . Drive the vehicle for more than 10 minutes. Confirm that no DTC is output using the Techstream. OK No DTC output. HINT: DTC P0017 or P0019 is stored when foreign objects in the engine oil are caught in some parts of the system. These codes will remain stored even if the system returns to normal after a short time. These foreign objects are then captured by the oil filter, thus eliminating the source of the problem. NG --> See step 12 OK --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421952-S27905813582011092600000)
- ADJUST VALVE TIMING. Refer to «REASSEMBLY»(ref-422094-S42016673532011092600000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-421954-S26745234372011092600000)
- REPLACE ECM. Refer to «REMOVAL»(ref-421954-S13588411562011092600000)
| Related DTCs | P0031: Air fuel ratio sensor heater (bank 1) open/short (Low electrical current) P0032: Air fuel ratio sensor heater (bank 1) open/short (High electrical current) P0051: Air fuel ratio sensor heater (bank 2) open/short (Low electrical current) P0052: Air fuel ratio sensor heater (bank 2) open/short (High electrical current) P101D: Air fuel ratio sensor heater (for Bank 1) performance P103D: Air fuel ratio sensor heater (for Bank 2) performance |
| Required Sensors/Components (Main) | Air fuel ratio sensor heater |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 11 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P101D, P103D (Air fuel ratio sensor heater) |
| Battery voltage | 10.5 V or higher |
| Time after engine start | 10 seconds or more |
| Active heater OFF control | Not operating |
| Active heater ON control | Not operating |
| Air fuel ratio sensor heater duty-cycle | 50% or more |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Time after engine start | 10 seconds or more |
| Active heater OFF control | Not operating |
| Active heater ON control | Not operating |
| Air fuel ratio sensor heater duty-cycle | More than 0% |
| Monitor runs whenever following DTCs not stored | P0031, P0051 (Air fuel ratio sensor heater) |
| Battery voltage | 10.5 V or higher |
| Time after engine start | 10 seconds or more |
| Active heater OFF control | Not operating |
| Active heater ON control | Not operating |
| Air fuel ratio sensor heater duty-cycle | 10 to 60% |
| Air fuel ratio sensor heater ON current | 0.8 A or higher |
| Air fuel ratio sensor heater current | Below 0.8 A |
| Hybrid IC high current limiter monitor | Fail |
| Hybrid IC high current limiter port | Fail |
| Air fuel ratio sensor heater current | 0.8 A or higher |
Scheme 402
Scheme 402: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream ON.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0031, P0032, P0051, P0052, P101D or P103D.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0037: Heated oxygen sensor heater (bank 1) range check (Low electrical current) P0038: Heated oxygen sensor heater (bank 1) range check (High electrical current) P0057: Heated oxygen sensor heater (bank 2) range check (Low electrical current) P0058: Heated oxygen sensor heater (bank 2) range check (High electrical current) P0141: Heated oxygen sensor heater performance (bank 1) P0161: Heated oxygen sensor heater performance (bank 2) P102D: Heated oxygen sensor heater stuck ON (for Bank 1 Sensor 2) P105D: Heated oxygen sensor heater stuck ON (for Bank 2 Sensor 2) |
| Required Sensors/Components (Main) | Heated oxygen sensor heater |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous: P0037, P0038, P0057, P0058 P102D and P105D Once per driving cycle: P0141 and P0161 |
| Duration | 0.5 seconds: P0037 and P0057 Within 3 seconds: P0038 and P0058 10 seconds: P0141 and P0161 0.5 seconds: P102D and P105D |
| MIL Operation | Immediate: P0037, P0038, P0057, P0058, P102D and P105D 2 driving cycles: P0141 and P0161 |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0032, P0052 (Air fuel ratio sensor heater) P0038, P0058 (Rear oxygen sensor heater) |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active A/F control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation | Complete |
| Heater OFF current learned value | Acquired |
| Monitor runs whenever following DTCs not stored | P0031, P0032, P0051, P0052 (Air fuel ratio sensor heater) P0038, P0058 (Rear oxygen sensor heater) |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active A/F control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation | Complete |
| Heated oxygen sensor heater OFF current | Higher than 3.5 A |
| Hybrid IC high current limiter port | Fail |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active A/F control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation | Complete |
| Monitor runs whenever following DTCs not stored | P0031, P0032, P0051, P0052 (Air fuel ratio sensor heater) P0037, P0038, P0057, P0058 (Rear oxygen sensor heater) |
| Battery voltage | 10.5 V or higher |
| Fuel cut | OFF |
| Time after fuel cut ON to OFF | 30 seconds or more |
| Accumulated heater ON time | 100 seconds or more |
| Learned heater OFF current operation | Complete |
| Monitor runs whenever following DTCs not stored | None |
| Duration that rear heated oxygen sensor impedance is less than 15 kohms | 2 seconds or more |
| Monitor runs whenever following DTCs not stored | P0031, P0032, P0051, P0052 (Air fuel ratio sensor heater) P0037, P0038, P0057, P0058 (Rear oxygen sensor heater) |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active A/F control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation | Complete |
| Hybrid IC high current limiter port | Fail |
When the values for the Data List items O2 Heater Curr Val B1S2 and O2 Heater Curr Val B2S2 are not 0 A, the heater is on.
| Heater current - Learned heater OFF current | 0.3 A or less |
| Heated oxygen sensor heater ON current | 1 A or less |
| Hybrid IC high current limiter port | Fail |
| Heated oxygen sensor heater output | ON |
| Accumulated heater resistance | Varies with sensor element temperature (Example: Higher than 23 ohms) |
| Heated oxygen sensor heater ON current | Higher than 1 A |
| Heated oxygen sensor heater current | 0.4 to 1 A (when engine idling, heated oxygen sensor warmed up and battery voltage 11 to 14 V) |
Scheme 403
Scheme 403: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream ON.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0037, P0038, P0057, P0058, P0141, P0161, P102D or P105D.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0101: Mass air flow meter rationality |
| Required Sensors/Components (Main) | Mass air flow meter |
| Required Sensors/Components (Related) | Crankshaft position sensor, engine coolant temperature sensor and throttle position sensor |
| Frequency of Operation | Continuous |
| Duration | 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0102, P0103 (Mass Air Flow Sensor) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0335 (Crankshaft Position Sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0452, P0453 (EVAP System) P2401, P2402 (Leak detection pump) P2419, P2420 (EVAP system vent valve) |
| Throttle position (TP sensor voltage) | 0.2 to 2 V |
| Time after engine start | 5 seconds or more |
| Battery voltage | 10.5 V or higher |
| Engine coolant temperature | 70°C (158°F) or higher |
| Estimated load | 30 to 70% |
| Both conditions 1 and 2 met | |
| 1. Average engine load value ratio | Less than 0.85, or more than 1.19 (varies with estimated engine load) |
| 2. Average air-fuel ratio | Less than -20%, or more than 20% |
Scheme 404
Scheme 404: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or higher [A].
- Drive the vehicle at approximately 80 km/h (50 mph) to 112 km/h (70 mph) for 5 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive while keeping the engine load as stable as possible.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0101.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Code. Read DTCs. RESULT Display (DTC Output) Proceed to P0101 A P0101 and other DTCs B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leakage. OK No leakage from air induction system. NG --> See step 5 OK: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. OK PCV hose is connected correctly and is not damaged. NG --> See step 6 OK --> See step 7
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421952-S27905813582011092600000)
- REPAIR OR REPLACE AIR INDUCTION SYSTEM. Refer to «REMOVAL»(ref-422104-S40592439742011092600000)
- REPAIR OR REPLACE PCV HOSE. Refer to «REMOVAL»(ref-422126-S29243352132011092600000)
- REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-421954-S12208818912011092600000)
| Related DTCs | P0102: Mass air flow meter range check (Low voltage) P0103: Mass air flow meter range check (High voltage) |
| Required Sensors/Components (Main) | Mass air flow meter |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediate: Engine speed less than 4000 RPM 2 driving cycles: Engine speed 4000 RPM or more |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Mass air flow meter voltage | Below 0.2 V |
| Mass air flow meter voltage | Higher than 4.9 V |
| Mass air flow meter voltage | 0.4 V to 2.2 V |
Scheme 405
Scheme 405: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 5 seconds [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Run the engine at an engine speed of 4000 RPM or more for 5 seconds [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0102 or P0103.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 406
Scheme 406: WIRING DIAGRAM
| Related DTCs | P0111: Intake air temperature sensor rationality (After engine stop) P0111: Intake air temperature sensor rationality (After cold engine start) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 5 hours or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0102, P0103 (Mass Air Flow Sensor) |
| Time after engine start | 10 seconds or more |
| Battery voltage | 10.5 V or higher |
| Engine coolant temperature when ECM started by soak timer | 40°C (-40°F) or higher |
| Accumulated mass air flow amount before engine stop | 6791 g or more |
| Key-off duration | 30 minutes |
| Key-off duration | 5 hours |
| Time after engine start | 10 seconds or more |
| Engine coolant temperature | 70°C (158°F) or higher |
| Accumulated mass air flow amount | 6791 g or more |
| Either of the following conditions is met | |
| 1. Duration while engine load is low | 120 seconds or more |
| 2. Duration while engine load is high | 10 seconds or more |
| Intake air temperature change | Less than 1°C (2°F) |
| Intake air temperature change | Less than 1°C (2°F) |
Scheme 407
Scheme 407: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the ECT reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C]. HINT: During steps [A] through [C], if the change in the intake air temperature is less than 1°C (1.8°F), the intake air temperature sensor (mass air flow meter) is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0111.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F] again.
- Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Check the DTC judgment result again [F]. HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Code. Read DTCs. RESULT Display (DTC Output) Proceed to P0111 and other DTCs A P0111 B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. B --> See step 3 A --> See step 2
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421952-S27905813582011092600000)
- REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-421954-S12208818912011092600000)
Scheme 408
- The intake air temperature sensor, mounted on the mass air flow meter, monitors the intake air temperature. The intake air temperature sensor has a built-in thermistor with a resistance that varies according to the temperature of the intake air. When the intake air temperature is low, the resistance of the thermistor increases. When the temperature is high, the resistance drops. These variations in resistance are transmitted to the ECM as voltage changes see scheme 1
- The intake air temperature sensor is powered by a 5 V supply from the THA terminal of the ECM, via resistor R.
- Resistor R and the intake air temperature sensor are connected in series. When the resistance value of the intake air temperature sensor changes according to changes in the intake air temperature, the voltage at terminal THA also varies. Based on this signal, the ECM increases the fuel injection volume when the engine is cold to improve driveability. HINT: When either DTC P0112 or P0113 is stored, the ECM enters fail-safe mode. During fail-safe mode, the intake air temperature is estimated to be 20°C (68°F) by the ECM. The ECM continues operating in fail-safe mode until a pass condition is detected.
| DTC No. | DTC Detection Condition | Trouble Area |
| P0112 | Short in the intake air temperature sensor circuit for 0.5 seconds (1 trip detection logic). | Short in intake air temperature sensor circuit Intake air temperature sensor (built into mass air flow meter) ECM |
| P0113 | Open in the intake air temperature sensor circuit for 0.5 seconds (1 trip detection logic). | Open in intake air temperature sensor circuit Intake air temperature sensor (built into mass air flow meter) ECM |
When any of these DTCs are stored, check the intake air temperature by entering the following menus: Powertrain / Engine and ECT / Data List / All Data / Intake Air.
| Temperature Displayed | Malfunction |
| 40°C (-40°F) | Open circuit |
| 140°C (284°F) or higher | Short circuit |
| Related DTCs | P0112: Intake air temperature sensor range check (Low voltage) P0113: Intake air temperature sensor range check (High voltage) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Intake air temperature sensor voltage | Below 0.18 V [Higher than 140°C (284°F)] |
| Intake air temperature sensor voltage | Higher than 4.91 V [Below -40°C (-40°F)] |
| Intake air temperature sensor voltage | 0.18 to 4.91 V [-40°C to 140°C (-40°F to 284°F)] |
Scheme 409
Scheme 409: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 0.5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0112 or P0113.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 410
Scheme 410: WIRING DIAGRAM
| Related DTCs | P0115: Engine coolant temperature sensor range check (Fluctuating) P0117: Engine coolant temperature sensor range check (Low voltage) P0118: Engine coolant temperature sensor range check (High voltage) |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Engine coolant temperature sensor voltage | Below 0.14 V, or higher than 4.91 V |
| Engine coolant temperature sensor voltage | Below 0.14 V [higher than 140°C (284°F)] |
| Engine coolant temperature sensor voltage | Higher than 4.91 V [Below -40°C (-40°F)] |
| Engine coolant temperature sensor voltage | 0.14 to 4.91 V [-40°C to 140°C (-40°F to 284°F)] |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 0.5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0115, P0117 or P0118.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 411
Scheme 411: WIRING DIAGRAM
| Related DTCs | P0116: Engine coolant temperature sensor cold start monitor P0116: Engine coolant temperature sensor soak monitor |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Related) | None |
| Frequency of Operation | Once per driving cycle |
| Duration | 5 hours or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0128 (Thermostat) |
| Battery voltage | 10.5 V or higher |
| Time after engine start | 1 second or more |
| Engine coolant temperature at engine start | Below 60°C (140°F) |
| Soak time | 0 seconds or more |
| Accumulated mass air flow | 2320 g or more |
| Fuel cut | OFF |
| Difference between engine coolant temperature at engine start and intake air temperature | Less than 40°C (72°F) |
ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR
| Monitor runs whenever following DTCs not present | P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0128 (Thermostat) P2610 (Soak Timer Circuit) |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Soak time | 5 hours or more |
| Either condition (a) or (b) met | |
| (a) Engine coolant temperature | 60°C (140°F) or higher |
| (b) Accumulated mass air flow | 4936 g or more |
ENGINE COOLANT TEMPERATURE SENSOR SOAK MONITOR
| Engine coolant temperature sensor value change | Less than 5°C (9°F) |
ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR
| Difference between current engine coolant temperature sensor value and previous engine coolant temperature sensor value when engine stopped | Less than 5°C (9°F) |
ENGINE COOLANT TEMPERATURE SENSOR SOAK MONITOR
| Engine coolant temperature | Engine coolant temperature sensor value changes in accordance with actual engine coolant temperature |
Scheme 412
Scheme 412: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp.
- Check that the coolant temperature is 60°C (140°F) or less.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B]. HINT: If the engine coolant temperature does not change by 5°C (9°F) or more, the engine coolant temperature sensor is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0116.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E] again.
- Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: In the event of the drive pattern being interrupted (possibly due to factors such as traffic conditions), the drive pattern can be resumed.
- Check the DTC judgment result again [E]. HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0116) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Code. Read the DTCs. RESULT Display (DTC Output) Proceed to P0116 A P0116 and other DTCs B B --> See step 3 A: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-422100-S08683431582011092600000) . Measure the valve opening temperature of the thermostat. Standard value 80°C to 84°C (176°F to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-422100-S06517685842011092600000) . NG --> See step 4 OK --> See step 5
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421952-S27905813582011092600000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-422100-S08683431582011092600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-421954-S30792072392011092600000)
| Related DTCs | P011B: Engine coolant temperature/Intake air temperature sensor correlation |
| Required Sensors/Components (Main) | Engine coolant temperature/Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 7 hours or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P2610 (Soak timer circuit) |
| Both conditions met | Conditions 1 and 2 |
| 1. All of following conditions met | Conditions (a), (b), (c) and (d) |
| (a) After ignition switch ON and engine not running time | Less than 20 seconds |
| (b) Soak time | 7 hours or more |
| (c) Battery voltage | 10.5 V or higher |
| (d) Time after engine start | 494 seconds or more |
| 2. Either of the following conditions is met | Condition (a) and (b) |
| (a) Minimum intake air temperature after engine start | 10°C (14°F) or higher |
| (b) Engine coolant temperature before engine start | 10°C (14°F) or higher |
| Difference between engine coolant temperature and intake air temperature | Less than -20°C (-36°F) or more than 20°C (36°F) |
Scheme 413
Scheme 413: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Turn the ignition switch off.
- With the engine stopped, leave the vehicle as is for 7.5 hours or more [B].
- Start the engine and wait 60 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P011B.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] and [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO P011B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to P011B A P011B and other DTCs B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- READ VALUE USING TECHSTREAM (INTAKE AIR TEMPERATURE) Leave the vehicle for 7 hours or more. HINT: It is necessary leave the vehicle for 7 hours or more to simulate conditions similar to the DTC detection conditions. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / All Data / Intake Air. Read the value displayed on the Techstream. OK Difference between the intake air temperature and actual outside air temperature is within 10°C (18°F). HINT: Temperature readings on the vehicle's outside temperature gauge (if equipped) are not suitable for comparing to the intake air temperature reading. The outside temperature gauge has a significant delay built in to prevent temperature swings from being displayed on its display. Use an accurate thermometer to determine the outside air temperature. NG --> See step 5 OK: Go to next step
- READ VALUE USING TECHSTREAM (ENGINE COOLANT TEMPERATURE) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / All Data / Coolant Temp. Read the value displayed on the Techstream. OK The difference between the coolant temperature and actual outside air temperature is within 10°C (18°F). HINT: If the result is not as specified, check if there are heat sources such as a block heater in the engine compartment. NG --> See step 7 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421952-S27905813582011092600000)
- REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-421954-S12208818912011092600000)
- REPLACE ECM. Refer to «REMOVAL»(ref-421954-S13588411562011092600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-421954-S30792072392011092600000)
| Related DTCs | P0120: Throttle position sensor 1 range check (Fluctuating) P0121: Throttle position sensor rationality P0122: Throttle position sensor 1 range check (Low voltage) P0123: Throttle position sensor 1 range check (High voltage) P0220: Throttle position sensor 2 range check (Fluctuating) P0222: Throttle position sensor 2 range check (Low voltage) P0223: Throttle position sensor 2 range check (High voltage) P2135: Throttle position sensor range check (Correlation) |
| Required Sensors/Components (Main) | Throttle position sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 2 seconds: P0120, P0121, P0122, P0123, P0220, P0222 and P0223 0.5 seconds: P2135 Case 1 0.4 seconds: P2135 Case 2 |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Either of following conditions A or B met | |
| A. Ignition switch ON | 0.012 seconds or more |
| B. Electronic throttle actuator power | ON |
P0120, P0122, P0123, P0220, P0222, P0223 AND P2135
| Monitor runs whenever following DTCs not present | P0120, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) |
| Either of following conditions A or B met | |
| A. Ignition switch | ON |
| B. Electronic throttle motor power | ON |
| VTA1 voltage | 0.2 V or less, or 4.54 V or higher |
| Difference in voltage between VTA1 and VTA2 TP sensor 1 - [TP sensor 2 x 0.8 (corrected by learning value)] | Less than 0.8 V, or more than 1.6 V |
| VTA1 voltage | 0.2 V or less |
| VTA1 voltage | 4.54 V or higher |
| Either of following conditions A or B met | |
| A. VTA2 voltage | 1.75 V or less |
| B. All of the following conditions are met | |
| VTA2 voltage | 4.8 V or higher |
| VTA1 voltage | 0.2 to 2.02 V |
| VTA2 voltage | 1.75 V or less |
| VTA2 voltage when VTA1 is 0.2 V or higher and 2.02 V or less | 4.8 V or higher |
| Difference between VTA1 and VTA2 voltages | 0.02 V or less |
| VTA1 voltage | 0.2 V or less |
| VTA2 voltage | 1.75 V or less |
| VTA1 voltage | 0.2 to 4.535 V |
| VTA2 voltage | 1.75 to 4.8 V |
Scheme 414
Scheme 414: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- With the vehicle stationary, fully depress and release the accelerator pedal [B].
- Idle the engine for 2 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0120, P0121, P0122, P0123, P0220, P0222, P0223 or P2135.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
FAIL-SAFE
When any of these DTCs as well as other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions are set, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 7° opening angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing in accordance with the accelerator pedal position to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
The ECM continues operating in fail-safe mode until a pass condition is detected and the ignition switch is turned off.
Scheme 415
Scheme 415: WIRING DIAGRAM
| Related DTCs | P0125: Insufficient engine coolant temperature for closed-loop fuel control |
| Required Sensors/Components (Main) | Thermostat, cooling system |
| Required Sensors/Components (Related) | Engine coolant temperature sensor and mass air flow meter |
| Frequency of Operation | Once per driving cycle |
| Duration | 56 seconds: Engine coolant temperature at engine start -8.33°C (17°F) or higher 101 seconds: Engine coolant temperature at engine start between -8.33°C (17°F) and -19.44°C (-3°F) 1200 seconds: Engine coolant temperature at engine start less than -19.44°C (-3°F) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0101, P0102, P0103 (Mass Air Flow Sensor) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0128 (Thermostat) |
| Engine coolant temperature (closed-loop fuel control enabling temperature) | 56 seconds: Engine coolant temperature at engine start -8.33°C (17°F) or higher 101 seconds: Engine coolant temperature at engine start between -8.33°C (17°F) and -19.44°C (-3°F) 1200 seconds: Engine coolant temperature at engine start less than -19.44°C (-3°F) |
Scheme 416
Scheme 416: CONFIRMATION DRIVING PATTERN
- Leave the vehicle outside overnight.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp.
- Check that the engine coolant temperature is 10°C (50°F) or less.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Wait 21 minutes or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0125.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Code. Read DTCs. RESULT Display (DTC Output) Proceed to P0125 A P0125 and other DTCs B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-422100-S08683431582011092600000) . Check the valve opening temperature of the thermostat. Standard value 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-422100-S06517685842011092600000) . NG --> See step 5 OK: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421952-S27905813582011092600000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-422100-S08683431582011092600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-421954-S30792072392011092600000)
| Related DTCs | P0128: Coolant Thermostat |
| Required Sensors/Components (Main) | Thermostat |
| Required Sensors/Components (Related) | Engine coolant temperature sensor, intake air temperature sensor, vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 900 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010, P0020 (VVT Oil Control Valve) P0011, P0021 (VVT System - Advance) P0012, P0022 (VVT System - Retard) P0016, P0018 (VVT System - Misalignment) P0013, P0023 (Exhaust VVT Oil Control Valve) P0014, P0024 (Exhaust VVT System - Advance) P0015, P0025 (Exhaust VVT System - Retard) P0017, P0019 (Exhaust VVT System - Misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air Fuel Ratio Sensor Heater) P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256 (Air Fuel Ratio Sensor) P0102, P0103 (Mass Air Flow Sensor) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0171, P0172, P0174, P0175 (Fuel System) P0301 - P0306 (Misfire) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT Sensor) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT Sensor) P0351 - P0356 (Igniter) P0500 (Vehicle Speed Sensor) |
| Battery voltage | 11 V or higher |
| Either of following conditions 1 or 2 met | |
| 1. All of following conditions met | |
| Engine coolant temperature at engine start - intake air temperature at engine start | 15 to 7°C (-27 to 12.6°F) |
| Engine coolant temperature at engine start | 10 to 56°C (14 to 133°F) |
| Intake air temperature at engine start | 10 to 56°C (14 to 133°F) |
| 2. All of following conditions met | |
| Engine coolant temperature at engine start - intake air temperature at engine start | More than 7°C (12.6°F) |
| Engine coolant temperature at engine start | 56°C (133°F) or less |
| Intake air temperature at engine start | 10°C (14°F) or higher |
| Accumulated time at vehicle speed of 128 km/h (80 mph) or more | Less than 20 seconds |
| Duration that both of following conditions (a) and (b) met | 5 seconds or more |
| (a) Estimated engine coolant temperature | 75°C (167°F) or higher |
| (b) Engine coolant temperature sensor output | Below 75°C (167°F) |
Scheme 417
Scheme 417: CONFIRMATION DRIVING PATTERN
- Stop the engine and allow it to soak.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp and Intake Air.
- Check if "Coolant Temp" is 56°C (133°F) or less and "Intake Air" is between 0 and 35°C (32 and 95°F).
- Set the heater to MAX HOT with fresh air mode selected and turn the A/C off.
- Start the engine and drive the vehicle at 80 km/h (50 mph) for 15 minutes [B]. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Enter the following menus: Data List / Function / Snap-shot configuration / Record time / 5 min. Data capture can be started by using the target point. For example, setting the target point to an engine speed of 4000 RPM and then racing the engine, etc. to raise the engine speed to a speed of 4000 RPM or more will cause data capture to start.
- After driving the vehicle at 80 km/h (50 mph) and "Coolant Temp" stabilizes, check that "Coolant Temp" is 75°C (167°F) or higher [C]. HINT: IF "Coolant Temp" is below 75°C (167°F) while driving the vehicle at 80 km/h (50 mph), inspect the cooling system and thermostat.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0128) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Code. Read DTCs. RESULT Display (DTC Output) Proceed to P0128 A P0128 and other DTCs B HINT: If any DTCs other than P0128 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-422100-S08683431582011092600000) . Measure the valve opening temperature of the thermostat. Standard value 75 to 84°C (167 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-422100-S06517685842011092600000) . NG --> See step 5 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421952-S27905813582011092600000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-422100-S08683431582011092600000)
- REPLACE ECM. Refer to «REMOVAL»(ref-421954-S13588411562011092600000)
| Related DTCs | P0136: Heated oxygen sensor (bank 1) output voltage (Abnormal voltage output) P0136: Heated oxygen sensor (bank 1) impedance (Low) P0137: Heated oxygen sensor (bank 1) output voltage (Low voltage) P0137: Heated oxygen sensor (bank 1) impedance (High) P0138: Heated oxygen sensor (bank 1) output voltage (High voltage) P0138: Heated oxygen sensor (bank 1) output voltage (Extremely high) P0139: Heated oxygen sensor (bank 1) output voltage during fuel cut P0156: Heated oxygen sensor (bank 2) output voltage (Abnormal voltage output) P0156: Heated oxygen sensor (bank 2) impedance (Low) P0157: Heated oxygen sensor (bank 2) output voltage (Low voltage) P0157: Heated oxygen sensor (bank 2) impedance (High) P0158: Heated oxygen sensor (bank 2) output voltage (High voltage) P0158: Heated oxygen sensor (bank 2) output voltage (Extremely high) P0159: Heated oxygen sensor (bank 2) output voltage during fuel cut |
| Required Sensors/Components (Main) | Heated oxygen sensor |
| Required Sensors/Components (Related) | Crankshaft position sensor, engine coolant temperature sensor, mass air flow meter and throttle position sensor |
| Frequency of Operation | Once per driving cycle: Active air-fuel ratio control detection / Heated oxygen sensor output voltage during fuel cut Continuous: Other |
| Duration | 20 seconds: Active air-fuel ratio control detection 90 seconds: Heated oxygen sensor impedance (High) 30 seconds: Heated oxygen sensor impedance (Low) 10 seconds: Output voltage (Stuck high) 7 seconds: Heated oxygen sensor voltage during fuel cut |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0016, P0018 (VVT System - Misalignment) P0017, P0019 (Exhaust VVT System - Misalignment) P0031, P0032, P0051, P0052 (Air Fuel Ratio Sensor Heater) P0037, P0038, P0057, P0058, P101D, P103D (Rear Oxygen Sensor Heater) P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256 (Air Fuel Ratio Sensor) P0102, P0103 (Mass Air Flow Sensor) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0128 (Thermostat) P0171, P0172, P0174, P0175 (Fuel System) P0301 - P0306 (Misfire) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0451, P0452, P0453 (EVAP System) P0500, P0722 (Vehicle Speed Sensor) |
| Active air-fuel ratio control | Executing |
| Active air-fuel ratio control begins when all of following conditions met | |
| Battery voltage | 11 V or higher |
| Engine coolant temperature | 75°C (167°F) or higher |
| Idling | OFF |
| Engine speed | Less than 3200 RPM |
| Air fuel ratio sensor status | Activated |
| Fuel system status | Closed loop |
| Fuel cut | OFF |
| Engine load | 10 to 70% |
| Shift position | 4th or higher |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (ABNORMAL VOLTAGE OUTPUT, HIGH VOLTAGE AND LOW VOLTAGE)
| DTC P0607 | Not set |
| Battery voltage | 11 V or higher |
| Estimated rear heated oxygen sensor temperature | Below 700°C (1292°F) |
| ECM monitor | Completed |
HEATED OXYGEN SENSOR IMPEDANCE (LOW)
| DTC P0607 | Not set |
| Battery voltage | 11 V or higher |
| Estimated rear heated oxygen sensor temperature | 520 to 750°C (968 to 1382°F) or higher |
| ECM monitor | Completed |
HEATED OXYGEN SENSOR IMPEDANCE (HIGH)
| Battery voltage | 11 V or higher |
| Time after engine start | 2 seconds or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)
| Engine coolant temperature | 75°C (167°F) or higher |
| Estimated catalyst temperature | 400°C (752°F) or higher |
| Fuel cut | ON |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE DURING FUEL CUT
| Either of following conditions met | 1 or 2 |
| 1. Conditions (a), (b) and (c) met | |
| (a) Commanded air-fuel ratio | 14.3 or less |
| (b) Rear heated oxygen sensor voltage | 0.21 to 0.59 V |
| (c) OSC (Oxygen Storage Capacity of Catalyst) | 1.8 g or more |
| 2. Conditions (d), (e) and (f) met | |
| (d) Commanded air-fuel ratio | 14.9 or more |
| (e) Rear heated oxygen sensor voltage | 0.21 to 0.59 V |
| (f) OSC | 1.8 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (ABNORMAL VOLTAGE OUTPUT)
| Conditions (a), (b) and (c) met | |
| (a) Commanded air-fuel ratio | 14.3 or less |
| (b) Rear heated oxygen sensor voltage | Below 0.21 V |
| (c) OSC | 1.8 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (LOW)
| Conditions (a), (b) and (c) met | |
| (a) Commanded air-fuel ratio | 14.9 or more |
| (b) Rear heated oxygen sensor voltage | Higher than 0.59 V |
| (c) OSC | 1.8 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (HIGH)
| Duration following condition met | 30 seconds or more |
| Heated oxygen sensor impedance | Below 5 ohms |
HEATED OXYGEN SENSOR IMPEDANCE (LOW)
| Duration following condition met | 90 seconds or more |
| Heated oxygen sensor impedance | 15 kohms or higher |
HEATED OXYGEN SENSOR IMPEDANCE (HIGH)
| Duration following condition met | 10 seconds or more |
| Heated oxygen sensor voltage | 1.2 V or higher |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)
| Either condition is met | |
| Time for rear heated oxygen sensor voltage to drop to 0.2 V during fuel cut | 7 seconds or more |
| Time for rear heated oxygen sensor voltage to drop from 0.35 V to 0.2 V during fuel cut | 1 second or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE DURING FUEL CUT
| Duration following condition met | 30 seconds or more |
| Heated oxygen sensor voltage | Varies between 0.1 and 0.9 V |
P0136, P0137, P0138, P0156, P0157 and P0158
Scheme 418
Scheme 418: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- With the transmission in 4th gear or higher, drive the vehicle at 60 to 120 km/h (40 to 75 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0136, P0137, P0138, P0156, P0157 and P0158.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [C] and [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 419
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at 60 km/h (40 mph), and then decelerate the vehicle by releasing the accelerator pedal for 5 seconds or more to perform the fuel-cut [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the DTCs. HINT: If a pending DTC or current DTC is output, the system is malfunctioning. If a pending DTC or current DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0139 and P0159.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, move the shift lever to 2, and then perform steps [C] and [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
MONITOR RESULT
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 420
Scheme 420: WIRING DIAGRAM
| Related DTCs | P014C: Air fuel ratio sensor (bank 1) slow response (rich to lean) P014D: Air fuel ratio sensor (bank 1) slow response (lean to rich) P014E: Air fuel ratio sensor (bank 2) slow response (rich to lean) P014F: Air fuel ratio sensor (bank 2) slow response (lean to rich) P015A: Air fuel ratio sensor (bank 1) delayed response (rich to lean) P015B: Air fuel ratio sensor (bank 1) delayed response (lean to rich) P015C: Air fuel ratio sensor (bank 2) delayed response (rich to lean) P015D: Air fuel ratio sensor (bank 2) delayed response (lean to rich) |
| Required Sensors/Components (Main) | Air fuel ratio sensor |
| Required Sensors/Components (Related) | Vehicle speed sensor, crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 to 15 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Active air fuel ratio control | Performing |
| Active air fuel ratio control is performed when the following conditions met | |
| Battery voltage | 11 V or higher |
| Engine coolant temperature | 75°C (167°F) or higher |
| Idle | OFF |
| Engine speed | 1000 to 4000 RPM |
| Air fuel ratio sensor status | Activated |
| Fuel-cut | OFF |
| Engine load | 10 to 70% |
| Shift position | 2nd or higher |
| Catalyst monitor | Not executed |
| Mass air flow | 6 to 15 g/sec. |
| Rich to Lean response rate deterioration level | 0.04 V or less |
AIR FUEL RATIO SENSOR SLOW RESPONSE (RICH TO LEAN)
| Lean to Rich response rate deterioration level | 0.044 V or higher |
AIR FUEL RATIO SENSOR SLOW RESPONSE (LEAN TO RICH)
| Rich to Lean delay level | 229.376 ms or more |
AIR FUEL RATIO SENSOR DELAYED RESPONSE (RICH TO LEAN)
| Lean to Rich delay level | 229.376 ms or more |
AIR FUEL RATIO SENSOR DELAYED RESPONSE (LEAN TO RICH)
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Performing this confirmation driving pattern will activate the air fuel ratio sensor response monitor.
Scheme 421
Scheme 421: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream ON.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Monitor / O2 Sensor.
- Check that the monitor item O2 Sensor is Incomplete. HINT: The test values for the test items RL RES RATE B1S1, LR RES RATE B1S1, RL DELAY B1S1, LR DELAY B1S1, RL RES RATE B2S1, LR RES RATE B2S1, RL DELAY B2S1 and LR DELAY B2S1 do not exist in the Detail of O2 Sensor monitor at this item (the initial value of "0.000" is indicated for each test item).
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher [A].
- Drive the vehicle at a constant speed of between 75 and 100 km/h (47 and 62 mph) for 10 minutes [B].
- Check that the monitor item O2 Sensor becomes Complete. HINT: Check the test values on the Techstream by entering the following menus: Powertrain / Engine and ECT / Monitor / O2 Sensor /Details / RL RES RATE B1S1, LR RES RATE B1S1, RL DELAY B1S1, LR DELAY B1S1, RL RES RATE B2S1, LR RES RATE B2S1, RL DELAY B2S1 and LR DELAY B2S1.
- If the monitor item O2 Sensor does not become Complete (if the test values indicated on the Techstream do not change), perform Readiness Monitor Drive Pattern for the air fuel ratio sensor and heated oxygen sensor. Refer to «READINESS MONITOR DRIVE PATTERN»(ref-421952-S03184105072011092600000) .
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D and other DTCs are output B HINT: If any DTCs other than P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
- INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) Inspect the air fuel ratio sensor. Refer to «INSPECTION - Step 1»(ref-421954-S11432199172011092600000) . NG --> See step 11 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) BANK 1 Tester Connection Condition Specified Condition B26-1 (HA1A) - B39-17 (HA1A) Always Below 1 ohms B26-3 (A1A+) - B38-1 (A1A+) Always Below 1 ohms B26-4 (A1A-) - B38-2 (A1A-) Always Below 1 ohms Standard Resistance (Check for Open) BANK 2 Tester Connection Condition Specified Condition B27-1 (HA2A) - B39-19 (HA2A) Always Below 1 ohms B27-3 (A2A+) - B38-7 (A2A+) Always Below 1 ohms B27-4 (A2A-) - B38-8 (A2A-) Always Below 1 ohms Standard Resistance (Check for Short) BANK 1 Tester Connection Condition Specified Condition B26-1 (HA1A) or B39-17 (HA1A) - Body ground Always 10 kohms or higher B26-3 (A1A+) or B38-1 (A1A+) - Body ground Always 10 kohms or higher B26-4 (A1A-) or B38-2 (A1A-) - Body ground Always 10 kohms or higher Standard Resistance (Check for Short) BANK 2 Tester Connection Condition Specified Condition B27-1 (HA2A) or B39-19 (HA2A) - Body ground Always 10 kohms or higher B27-3 (A2A+) or B38-7 (A2A+) - Body ground Always 10 kohms or higher B27-4 (A2A-) or B38-8 (A2A-) - Body ground Always 10 kohms or higher Reconnect the ECM connector. Reconnect the air fuel ratio sensor connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK AIR FUEL RATIO SENSOR Check that the proper air fuel ratio sensor is installed to the vehicle. NG --> REPLACE AIR FUEL RATIO SENSOR OK: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the DTCs. RESULT Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output A DTC is not output B B --> See step 12 A: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-421954-S24359359142011092600000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output B B --> See step 13 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421952-S27905813582011092600000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-421954-S24359359142011092600000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-421952-S26737171072011092600000)
- CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «DTC P0171: System Too Lean (Bank 1); DTC P0172: System Too Rich (Bank 1); DTC P0174: System Too Lean (Bank 2); DTC P0175: System Too Rich (Bank 2)»(ref-422121-S06954811612011092600000)
| Related DTCs | P0171: Fuel trim lean (bank 1) P0172: Fuel trim rich (bank 1) P0174: Fuel trim lean (bank 2) P0175: Fuel trim rich (bank 2) |
| Required Sensors/Components (Main) | Fuel system |
| Required Sensors/Components (Related) | Air fuel ratio sensor, Mass air flow meter, Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | Within 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010, P0020 (VVT Oil Control Valve) P0011, P0021 (VVT System - Advance) P0012, P0022 (VVT System - Retard) P0016, P0018 (VVT System - Misalignment) P0013, P0023 (Exhaust VVT Oil Control Valve) P0014, P0024 (Exhaust VVT System - Advance) P0015, P0025 (Exhaust VVT System - Retard) P0017, P0019 (Exhaust VVT System - Misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air Fuel Ratio Sensor Heater) P0102, P0103 (Mass Air Flow Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT Sensor) P0340 (Camshaft Position Sensor) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT Sensor) P0351 - P0356 (Igniter) P0500 (Vehicle Speed Sensor) |
| Fuel system status | Closed loop |
| Battery voltage | 11 V or higher |
| Either of conditions 1 or 2 met | |
| 1. Engine speed | Less than 1100 RPM |
| 2. Engine load | 10% or more |
| Catalyst monitor | Not executed |
| EVAP purge-cut | Executing |
| Either of conditions 1 or 2 met | |
| 1. Average of short-term fuel trim and long-term fuel trim | 35% or more (varies with ECT) |
| 2. Average of short-term fuel trim and long-term fuel trim | 35% or less (varies with ECT) |
Scheme 422
Scheme 422: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with all the accessories switched off [B].
- With the engine warmed up, idle the engine for 2 minutes or more [C].
- Drive the vehicle at a speed between 60 and 135 km/h (38 and 85 mph) for 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0171, P0172, P0174 OR P0175) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Code. Read DTCs. RESULT Display (DTC Output) Proceed to P0171, P0172, P0174 or P0175 A P0171, P0172, P0174 or P0175 and other DTCs B HINT: If any DTCs other than P0171, P0172, P0174 or P0175 are output, troubleshoot those DTCs first. B --> See step 25 A: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. OK PCV hose is connected correctly and is not damaged. NG --> See step 26 OK: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leakage. OK No leakage from air induction system. NG --> See step 27 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (A/F CONTROL) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine at an engine speed of 2500 RPM for approximately 90 seconds. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor. Perform the Control the Injection Volume for A/F Sensor operation with the engine idling (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the output voltages of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2) displayed on the Techstream. HINT: The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 25%. Each sensor reacts in accordance with increases and decreases in the fuel injection volume. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 or AFS Voltage B2S1 (Air fuel ratio) +25% Rich Below 3.1 V AFS Voltage B1S1 or AFS Voltage B2S1 (Air fuel ratio) -12.5% Lean Higher than 3.4 V O2S B1S2 or O2S B2S2 (Heated oxygen) +25% Rich Higher than 0.55 V O2S B1S2 or O2S B2S2 (Heated oxygen) -12.5% Lean Below 0.4 V RESULT Status of AFS Voltage B1S1 or AFS Voltage B2S1 Status of O2S B1S2 or O2S B2S2 Air Fuel Ratio Condition and Air Fuel Ratio Sensor Condition Misfire Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - - A Lean Lean Actual air fuel ratio lean May occur PCV valve and hose PCV hose connections Fuel injector assembly blockage Gas leaks from exhaust system Intake system Fuel pressure Mass air flow meter sub-assembly Engine coolant temperature sensor A Rich Rich Actual air fuel ratio rich - Fuel injector assembly leakage or blockage Gas leaks from exhaust system Ignition system Fuel pressure Mass air flow meter sub-assembly Engine coolant temperature sensor A Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Lean: During the Control the Injection Volume for A/F Sensor Active Test, the air fuel ratio sensor output voltage (AFS Voltage) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S) is consistently below 0.4 V. Rich: During the Control the Injection Volume for A/F Sensor Active Test, the AFS Voltage is consistently below 3.1 V, and the O2S is consistently higher than 0.55 V. Lean/Rich: During the Control the Injection Volume for A/F Sensor Active Test, the output voltage of the heated oxygen sensor alternates correctly. B --> See step 11 A: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Read Coolant Temp twice, when the engine is cold and when it is warmed up. Standard With cold engine: Same as ambient air temperature. With warm engine: Between 75°C and 100°C (167°F and 212°F). NG --> See step 28 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / MAF, Coolant Temp and Engine speed. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 RPM. Standard Between 13.8 g/sec. and 17.3 g/sec. (shift lever: N; A/C: Off). NG --> See step 17 OK: Go to next step
- CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-422129-S37906946402011092600000) . NG --> REPAIR OR REPLACE FUEL SYSTEM OK: Go to next step
- CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leakage. OK No gas leakage. NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
- CHECK FOR SPARKS AND IGNITION Check for sparks and ignition. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-422102-S16611351722011092600000) . HINT: If the spark plugs or ignition system malfunctions, engine misfire may occur. The misfire count can be read using the Techstream. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Cylinder #1 Misfire Count (to Cylinder #6 Misfire Count). NG --> REPAIR OR REPLACE IGNITION SYSTEM OK: Go to next step
- INSPECT FUEL INJECTOR ASSEMBLY (INJECTION AND VOLUME) Check the fuel injector assembly. Refer to «INSPECTION»(ref-422124-S01545067432011092600000) . HINT: If the injectors malfunction, engine misfire may occur. The misfire count can be read using the Techstream. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Cylinder #1 Misfire Count (to Cylinder #6 Misfire Count). OK --> See step 15 NG --> See step 29
- INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) See step 1 NG --> See step 30 OK: Go to next step
- CHECK TERMINAL VOLTAGE (+B OF AIR FUEL RATIO SENSOR) See step 2 NG --> See step 24 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM). Refer to «PROCEDURE - Step 11»(ref-422119-S28439618892011092600000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-421954-S24359359142011092600000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0171, P0172, P0174 or P0175. Check the DTC judgment result. RESULT Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0171, P0172, P0174 OR P0175) Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0171, P0172, P0174 or P0175. Check that DTC MONITOR is NORMAL. Enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending. Read Pending DTCs. RESULT Display (DTC Output) Proceed to P0171, P0172, P0174 or P0175 A No output B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-421949-S41663372572011092600000) . HINT: Repair any problems. NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0171, P0172, P0174 or P0175. Check the DTC judgment result. RESULT Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0171, P0172, P0174 or P0175. Check that DTC MONITOR is NORMAL. Enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending. Read Pending DTCs. RESULT Display (DTC Output) Proceed to P0171, P0172, P0174 or P0175 A No output B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B35-5 (VG) - B37-14 (VG) Always Below 1 ohms B35-4 (E2G) - B37-13 (E2G) Always Below 1 ohms B35-5 (VG) or B37-14 (VG) - Body ground Always 10 kohms or higher Reconnect the mass air flow meter connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE MASS AIR FLOW METER Replace the mass air flow meter assembly. Refer to «REMOVAL»(ref-421954-S12208818912011092600000) . HINT: If the result of the inspection performed in step 6 indicated no problem, proceed to the next step without replacing the mass air flow meter assembly. NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0171, P0172, P0174 or P0175. Check the DTC judgment result. RESULT Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0171, P0172, P0174 or P0175. Check that DTC MONITOR is NORMAL. Enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending. Read Pending DTCs. RESULT Display (DTC Output) Proceed to No output A P0171, P0172, P0174 or P0175 B B --> See step 31 A --> END
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - NO. 1 INTEGRATION RELAY) See step 6 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 32
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-421952-S27905813582011092600000)
- REPAIR OR REPLACE PCV HOSE. Refer to «REMOVAL»(ref-422126-S29243352132011092600000)
- REPAIR OR REPLACE AIR INDUCTION SYSTEM. Refer to «REMOVAL»(ref-422104-S40592439742011092600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-421954-S30792072392011092600000)
- REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(ref-422124-S16126348042011092600000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-421954-S24359359142011092600000)
- REPLACE ECM. Refer to «REMOVAL»(ref-421954-S13588411562011092600000)
- REPLACE NO. 1 INTEGRATION RELAY. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-422128-S15085534132011092600000)
| Related DTCs | P0300: Multiple cylinder misfire P0301: Cylinder 1 misfire P0302: Cylinder 2 misfire P0303: Cylinder 3 misfire P0304: Cylinder 4 misfire P0305: Cylinder 5 misfire P0306: Cylinder 6 misfire |
| Required Sensors/Components (Main) | Fuel injector, Ignition coil and spark plug |
| Required Sensors/Components (Related) | Crankshaft position, VVT position Engine coolant temperature and intake air temperature sensors and mass air flow meter |
| Frequency of Operation | Continuous |
| Duration | 1000 to 4000 crankshaft revolutions: Emissions-related misfire 200 to 600 crankshaft revolutions: Catalyst-damaging misfire |
| MIL Operation | 2 driving cycles: (MIL illuminates when misfire detected) MIL flashes immediately: When catalyst-damaging misfire occurs |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0016, P0018 (VVT System - Misalignment) P0017, P0019 (Exhaust VVT System - Misalignment) P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient engine coolant temperature for Closed Loop) P0327, P0328, P0332, P0333 (Knock sensor) P0335 (Crankshaft position sensor) P0340 (Camshaft position sensor) P0351 - P0356 (Igniter) P0500 (VSS) P0705 (Shift lever position switch) |
| Battery voltage | 8 V or higher |
| VVT system | Not operated by scan tool |
| Engine speed | 400 to 5900 RPM |
| Either of condition (a) or (b) met | |
| (a) Engine coolant temperature at engine start | Higher than -7°C (19°F) |
| (b) Engine coolant temperature | Higher than 20°C (68°F) |
| Fuel cut | OFF |
| First 1000 revolutions after engine start, or Check Mode | Crankshaft 1000 revolutions |
| Except above | Crankshaft 1000 revolutions x 4 |
MONITOR PERIOD OF EMISSIONS-RELATED MISFIRE
| Conditions 1, 2 and 3 met | Crankshaft 200 revolutions |
| 1. Driving cycles | 1st |
| 2. Check mode | OFF |
| 3. Engine speed | Less than 1900 RPM |
| Except above | Crankshaft 200 revolutions x 3 |
MONITOR PERIOD OF CATALYST-DAMAGING MISFIRE (MIL BLINKS)
| Monitor runs whenever following DTCs not present | P0016, P0018 (VVT System - Misalignment) P0017, P0019 (Exhaust VVT System - Misalignment) P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient engine coolant temperature for Closed Loop) P0327, P0328, P0332, P0333 (Knock sensor) P0335 (Crankshaft position sensor) P0340 (Camshaft position sensor) P0351 - P0356 (Igniter) P0500 (VSS) P0705 (Shift lever position switch) |
| Battery voltage | 8 V or higher |
| Throttle position learning | Completed |
| VVT system | Not operated by scan tool |
| Engine speed | 400 to 5900 RPM |
| Engine coolant temperature | Higher than 65°C (149°F) |
| Fuel cut | OFF |
| First 1000 revolutions after engine start, or Check Mode | Crankshaft 1000 revolutions |
| Except above | Crankshaft 1000 revolutions x 4 |
MONITOR PERIOD OF EMISSIONS-RELATED MISFIRE
| Conditions 1 and 2 are met | Crankshaft 200 revolutions |
| 1. Driving cycles | 1st |
| 2. Check mode | OFF |
| Except above | Crankshaft 200 revolutions x 3 |
MONITOR PERIOD OF CATALYST-DAMAGING MISFIRE (MIL BLINKS)
MONITOR PERIOD OF EMISSIONS-RELATED MISFIRE
| Number of misfires per 200 revolutions | 77 or more (varies with intake air amount and engine speed) |
| Paired cylinder misfire (MIL blinks immediately) | Detected |
MONITOR PERIOD OF CATALYST-DAMAGING MISFIRE (MIL BLINKS)
| Misfire rate | 32.2% or more: for 1st 1000 revolutions 16.6% or more: after 1st 1000 revolutions |
MONITOR PERIOD OF EMISSIONS-RELATED MISFIRE
| Number of misfires per 200 revolutions | 77 or more (varies with intake air amount and engine speed) |
| Paired cylinder misfire | Detected |
MONITOR PERIOD OF CATALYST-DAMAGING MISFIRE (MIL BLINKS)
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Record the DTCs and freeze frame data.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Using the Techstream, switch the ECM from normal mode to check mode. Refer to «CHECK MODE PROCEDURE»(ref-421952-S25071577192011092600000) .
- Read the misfire counts of each cylinder (cylinder No. 1 to No. 6) with the engine idling. If any misfire count is displayed, skip the following confirmation driving pattern.
- Drive the vehicle several times with the conditions, such as engine speed and engine load, as shown in Misfire RPM and Misfire Load in the Data List. HINT: In order to store misfire DTCs, it is necessary to operate the vehicle for the period of time shown in the table below, using the Misfire RPM and Misfire Load in the Data List. Engine Speed Duration Idling 7.0 minutes or more 1000 4.0 minutes or more 2000 2.0 minutes or more 3000 1.5 minutes or more
- Check whether misfires have occurred by checking DTCs and freeze frame data. HINT: Do not turn the ignition switch off until the stored DTCs and freeze frame data have been recorded. When the ECM returns to normal mode (default), the stored DTCs, freeze frame data and other data will be cleared.
- Record the DTCs, freeze frame data and misfire counts.
- Turn the ignition switch off and wait for at least 5 seconds.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 423
Scheme 423: WIRING DIAGRAM
Scheme 424
Scheme 425
Refer to DTC P0102. Refer to WIRING DIAGRAM .
| Related DTCs | P0327: Knock sensor (bank 1) range check (Low voltage) P0328: Knock sensor (bank 1) range check (High voltage) P0332: Knock sensor (bank 2) range check (Low voltage) P0333: Knock sensor (bank 2) range check (High voltage) |
| Required Sensors/Components (Main) | Knock sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Battery voltage | 10.5 V or higher |
| Time after engine start | 5 seconds or more |
| Knock sensor voltage | Below 0.5 V |
KNOCK SENSOR RANGE CHECK (LOW VOLTAGE) P0327 AND P0332
| Knock sensor voltage | Higher than 4.5 V |
KNOCK SENSOR RANGE CHECK (HIGH VOLTAGE) P0328 AND P0333
Scheme 426
Scheme 426: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and wait 10 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0327, P0328, P0332 or P0333.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 5 minutes and check the DTC judgment result again [C].
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-421952-S20670569172011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 427
Scheme 427: WIRING DIAGRAM
