Engine Controls - System/component Tests: Specifications Suzuki X-90 I

Torque Converter Clutch (TCC) Relay

1. Relay is located in relay box near right shock tower in engine compartment. Turn ignition on. Check for battery voltage between ground and TCC relay Black/White wire terminal, then Blue/Black wire terminal. DO NOT depress brake pedal.
2. If no voltage is present, check electrical circuit of each terminal (including brake pedal switch). If voltage is present, connect jumper wire between relay White/Yellow wire terminal and ground. TCC relay should operate and battery voltage should be present at relay White wire terminal. Replace TCC relay if test results are not as specified.

Scheme 22

Scheme 23

Scheme 24

Scheme 25
