Engine Controls - Basic Testing: NVH Suzuki X-90 I

Testing & Diagnostics 1 illustration

NOISE SUPPRESSOR

Disconnect harness connector from noise suppressor located near ignitor/coil assembly. Using an ohmmeter, ensure continuity does not exist between terminals "A" and "B". (Scheme 4) Ensure resistance between terminals "B" and "C" is about 2200 ohms. If either test result is not within specification, replace noise suppressor.

Scheme 4

Scheme 4: NOISE SUPPRESSOR

Scheme 4: NOISE SUPPRESSOR
