Specifications
| Item | Specifications | |||
|---|---|---|---|---|
| Torque converter | Type | 3-element, 1-step, 2-phase type (with TCC (lock-up) mechanism) | ||
| Stall torque ratio | 1.92 - 2.12 | |||
| Oil pump | Type | Vane type oil pump (non crescent type) | ||
| Drive system | Engine drive | |||
| Gear change device | Type | Forward continuously variable, reverse 1-step planetary gear type | ||
| Shift position | "P" range | Gear in neutral, output shaft fixed, engine start | ||
| "R" range | Reverse | |||
| "N" range | Gear in neutral, engine start | |||
| "D" range | Forward continuously variable gear ratio | |||
| Manual mode | UP (+) | 1 --> 2 --> 3 --> 4 --> 5 --> 6 | ||
| DOWN (-) | 6 --> 5 --> 4 --> 3 --> 2 --> 1 | |||
| Gear ratio | Forward (continuously variable) | 2.349 - 0.394 | ||
| Reverse (reverse gear) | 1.750 | |||
| Control elements | Steel belt and pulleys... 1 sets | |||
| Wet type multiple-disc clutch... 1 sets | ||||
| Wet type multiple-disc brake... 1 sets | ||||
| Final gear reduction ratio | 5.798 | |||
| Lubrication | Lubrication system | Force feed system by oil pump | ||
| Cooling | Cooling system | CVT fluid cooler (air-cooled) Radiator assisted cooling (water-cooled) | ||
| Fluid used | SUZUKI CVT FLUID GREEN 1 or Shell GREEN-1 V | |||
ITEM SPECIFICATIONS
Scheme 1
Torque converter Slip (RPM)
This parameter indicates the slip speed of the torque converter according to the difference between engine speed and the secondary pulley speed.
Torque Converter Clutch (Release/Slip/Connect)
This parameter indicates the state of the torque converter clutch according to the difference between engine speed and the secondary pulley speed.
Open: The difference between engine speed and secondly pulley speed is more than specified speed.
Conclude: The speed of engine and secondly pulley is completely corresponding.
Slip: TCC is opening or it is concluding.
Tightening Torque Specifications
| CAUTION | For fastener with * (asterisk) below, be sure to tighten it according to specified procedure in "Repair Instructions". |
| Fastening part | Tightening torque | ||
|---|---|---|---|
| N.m | Kgf-m | Lbf-ft | |
| Fluid pressure check hole bolt | 7.5 | 0.76 | 5.5 |
| CVT fluid drain plug | 34 | 3.5 | 25.0 |
| Transmission range sensor bolt | 5.9 | 0.60 | 4.5 |
| Manual select lever nut | 17 | 1.7 | 12.5 |
| Transmission range sensor bolt | 5.9 | 0.60 | 4.51 |
| Primary pulley speed sensor bolt | 5.9 | 0.60 | 4.5 |
| Secondary pulley speed sensor bolt | 5.9 | 0.60 | 4.5 |
| CVT oil pan bolt* | 7.9 | 0.81 | 6.0 |
| CVT fluid cooler bracket bolt* | 25 | 2.5 | 18.5 |
| CVT fluid cooler bolt | 13 | 1.3 | 9.5 |
| Torque converter No. 1 and No. 2 bolt | 23 | 2.3 | 17.0 |
TIGHTENING TORQUE SPECIFICATIONS
Note. The specified tightening torque is described in the following. SELECT LEVER ASSEMBLY COMPONENTS SELECT CABLE COMPONENTS CVT ASSEMBLY COMPONENTS
Reference
For the tightening torque of fastener not specified in this section, refer to FASTENERS INFORMATION.
