Entertainment System (Except Wrx): Overview Subaru XV GP

CHECK NAVIGATION OPERATION

Start the engine and check that the opening screen is displayed.

Standard: Opening screen is displayed.

OK: Normal.

NG: If the screen is not displayed, check the following items.

1. The map disk (SD CARD) is set in the navigation system unit.
2. Check the connection of the power supply connector at the backside of the navigation unit. If wire connection is correct or has got repaired, check again that the opening screen is displayed. If it is not displayed at this time, it indicates the navigation unit trouble.

Scheme 4

Scheme 5

1. With the main power OFF, press and hold the button (c) for 3 seconds or more while pressing the buttons (a) and (b). NOTE: Diagnostic mode can be cancelled by pressing the button (a) for 3 seconds or more, or turning the ignition switch from ACC OFF to ON position.
2. Line Diag screen is displayed.
3. Check the connection status by monitoring each item in "Connectivity Check" displayed on the left of the screen. OK: Each connection device is connected correctly. NG: No connection or faulty connection has been detected.
4. Check the connection status of the connector. If there are no problems, the connection device or unit body could be faulty.
