Entertainment System (Except Wrx): Other Subaru XV GP

CAUTION

1. Before disassembling or reassembling parts, always disconnect the battery ground cable from battery. When replacing the audio, control module and other parts provided with memory functions, record the memory contents before disconnecting the battery ground cable. Otherwise, the memory is cleared.
2. Reassemble the parts in the reverse order of disassembly procedure unless otherwise indicated.
3. Adjust parts to the given specifications.
4. Connect the connectors securely during reassembly.
5. After reassembly, make sure that the each component operates smoothly.
6. Yellow connectors and harnesses with yellow tapes around them are the connectors and harnesses for the airbag system. Using a tester above such circuits may cause malfunction of airbag system. Follow the cautions of "AIRBAG SYSTEM" in this case. < Refer. to «CAUTION»(ref-560375-S15420108262013061300000) , General Description. >
7. Be careful not to damage the airbag system wiring harness when servicing electrical parts and switches.
8. If the steering wheel and steering angle sensor (steering roll connector) are removed, perform "VDC sensor midpoint setting mode" of the VDC. < Refer. to «VDC SENSOR MIDPOINT SETTING MODE»(ref-560389-S40582429032013061300000) , ADJUSTMENT, VDC Control Module and Hydraulic Control Unit (VDCCM&H/U). >

GENERAL TOOL

AUDIO

Refer to "Audio System" in appropriate SYSTEM WIRING DIAGRAMS. < Refer. to WI-42, WIRING DIAGRAM, Audio System. >

NOTE

For procedure of each component in the audio system, refer to the respective service information.

1. Audio unit: < Refer. to «AUDIO»(ref-560398-S07280255222013061300000) . >
2. Front side speaker: < Refer. to «TWEETER»(ref-560398-S05432295562013061300000) , REMOVAL, Front Speaker. >
3. Front door speaker: < Refer. to «DOOR SPEAKER»(ref-560398-S38961337172013061300000) , REMOVAL, Front Speaker. >
4. Rear door speaker: < Refer. to «REAR SPEAKER»(ref-560398-S34296075022013061300000) . >
5. Antenna: < Refer. to «ANTENNA»(ref-560398-S08211189112013061300000) . >
6. Steering satellite switch: < Refer. to «STEERING SATELLITE SWITCH»(ref-560398-S16558829182013061300000) . >
7. AUX input terminal: < Refer. to «AUX INPUT TERMINAL»(ref-560398-S22892290802013061300000) . >

CHECK EACH VEHICLE SIGNAL

1. With the main power OFF, press and hold the button (c) for 3 seconds or more while pressing the buttons (a) and (b). NOTE: Diagnostic mode can be cancelled by pressing the button (a) for 3 seconds or more, or turning the ignition switch from ACC OFF to ON position.
2. Line Diag screen is displayed.
3. Check the connection status by monitoring each item in "Vehicle Signal Check" displayed on the right of the screen.

1. Check illumination

Note. Before starting inspections, turn the ignition switch to ON.

1. Turn the lighting switch to level 1. Make sure that the bright switch is not turned ON at this time.
2. Make sure that "ON" lights in ILL+ and then the screen becomes dim. ON: Normal. OFF: Abnormal. Check the signal line connector. If there are no problems, the unit could be faulty.

1. Check speed sensor

Note. Before starting inspections, check the safety around the vehicle. Lift up the vehicle as necessary. When the diagnostic trouble code is input in the VDCCM, perform the Clear Memory operation.

1. Drive the vehicle at 9 km/h (6 mph) or more.
2. Check that "ON" is displayed in SPD. ON: Normal. OFF: Vehicle speed is less than 7 km/h (4 mph), or abnormality is found in the signal line. Check the signal line connector. If there are no problems, the unit could be faulty.

1. Check parking brake signal

1. Pull parking brake lever.
2. Check that "ON" is displayed in PKB. ON: Normal. OFF: Abnormal. Check the signal line connector. If there are no problems, the unit could be faulty.

1. Check back sensor

Note. Before starting inspections, check the safety around the rear end of the vehicle and then turn the ignition switch to ON.

1. Pull the parking brake and depress the brake, then put the gear in reverse.
2. Make sure that "ON" is displayed in REV. ON: Normal. OFF: Abnormal. Check the signal line connector. If there are no problems, the unit could be faulty.

For procedure of each component in the navigation system, refer to the respective service information.

1. Navigation unit: < Refer. to «NAVIGATION BODY»(ref-560398-S40303648852013061300000) . >
2. GPS antenna: < Refer. to «GPS ANTENNA»(ref-560398-S06289268662013061300000) . >
3. Rearview camera: < Refer. to «GPS ANTENNA»(ref-560398-S06289268662013061300000) . >

Scheme 67

Scheme 68

Scheme 69

1. Disconnect the ground cable from battery.
2. On manual A/C models, disconnect the control cables from both sides of the heater and cooling unit assembly. NOTE: Remove the glove box pocket assembly on the passenger's side.
3. Remove the panel center assembly. CAUTION: Do not put your finger on the fin of the air vent grille. Doing so may damage the fin. Pull the panel center assembly slowly. Pulling with excessive force may damage the connector. Insert a plastic remover to the three areas shown by the arrows, and lift up the panel center assembly slightly. With the panel center assembly lifted up slightly, release the claw by using a clip remover wrapped with protective tape. Release the rest of the claws, and pull out the panel center assembly. Disconnect the connectors, and remove the panel center assembly.
4. Remove the audio assembly. Remove the left and right screws, and partially pull out the audio assembly. Disconnect the connectors, and remove the audio assembly.

ANTENNA FEEDER CORD

1. Disconnect the ground cable from battery and wait for at least 60 seconds before starting work.
2. Lower the trim panel - roof assembly in the same manner as the removal procedure of antenna. < Refer. to «ANTENNA»(ref-560398-S08211189112013061300000) , REMOVAL, Antenna. > Disconnect the connector of the cord assembly - antenna feeder. Remove the clips and the Velcro tape behind the room light. Detach the connector of the cord assembly - antenna feeder from the trim panel - roof assembly.
