Entertainment System (Except Wrx): Adjustments Subaru XV GP

Entertainment Systems 3 illustrations ~323 words

MARKER ADJUSTMENT MODE

CAUTIONWhen replacing the navigation unit, be sure to replace with specified navigation unit. The marker adjustment can not be performed correctly if replacing with unspecified navigation unit.

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. Prepare the target point. < Refer. to «INSPECTION»(ref-560398-S04826554742013061300000) , Rearview Camera System. >
  2. With the main power OFF, press and hold the button (c) for 3 seconds or more while pressing the buttons (a) and (b) simultaneously. NOTE: Pressing the button (a) for 3 seconds or more, or turning the ignition switch from ACC OFF to ON position can exit the diagnostic mode.
  3. Line Diag screen is displayed.
  4. Touch {Camera Setting} key to display «Camera Setting» screen.
  5. Touch {G-4D} key. CAUTION: Do not use {G-5D} key or {G-XUV} key.
  6. Shift the shift lever or the select lever to the following position to display the image of the rearview camera: MT model: Shift lever shifted to "Reverse" position. CVT model: Select lever shifted to "R" position.
  7. Touch the adjustment keys (d), (e), (f) and (g) on the display screen to adjust the marker line. Confirm that the target point position in the display screen is identified. Adjust by touching the adjustment keys so that the cross line and target point join together.
  8. Turn the ignition switch to OFF and wait for 60 seconds or more before turning the ignition switch to ON again. CAUTION: If the ignition switch is turned to OFF, be sure to wait for 60 seconds or more before turning the ignition switch to ON again. If turning the ignition switch to ON again or disconnecting the ground cable from battery within 60 seconds after turning the ignition switch to OFF, the navigation unit data updating can not be performed correctly.
  9. Shift the shift lever or the select lever to the following position to display the image of the rearview camera: MT model: Shift lever shifted to "Reverse" position. CVT model: Select lever shifted to "R" position.
  10. Confirm that the marker line position is correctly adjusted before turning the ignition switch to OFF, then finish the procedures.
