Exhaust System (Except Wrx): Overview Subaru XV GP

Exhaust 4 illustrations ~101 words

Scheme 2

Scheme 2: FRONT EXHAUST PIPE AND CENTER EXHAUST PIPE
Scheme 2: FRONT EXHAUST PIPE AND CENTER EXHAUST PIPE

Tightening torque: N.m (kgf-m, ft-lb)

T1: 13 (1.3, 9.6)

T2: 18 (1.8, 13.3)

T3: 23 (2.3, 17.0)

T4: 30 (3.1, 22.1)

T5: 35 (3.6, 25.8)

T6: < Refer to INSTALLATION , Front Oxygen (A/F) Sensor. >

T7: < Refer to INSTALLATION , Rear Oxygen Sensor. >

Scheme 3

Scheme 3: REAR EXHAUST PIPE AND MUFFLER
Scheme 3: REAR EXHAUST PIPE AND MUFFLER

Scheme 4

Scheme 4
Scheme 4
  1. 4 door model Tightening torque: N.m (kgf-m, ft-lb) T1: 7.5 (0.8, 5.5) T2: 48 (4.9, 35.4)
  2. 5 door model/XV model Tightening torque: N.m (kgf-m, ft-lb) T: 48 (4.9, 35.4)

Scheme 5

Scheme 5: HEAT SHIELD COVER
Scheme 5: HEAT SHIELD COVER

Tightening torque: N.m (kgf-m, ft-lb)

T1: 10 (1.0, 7.4)

T2: 18 (1.8, 13.3)
