Automatic Transaxle (Cvt) (Except Wrx): Wiring Subaru XV GP

Automatic Trans 2 illustrations ~364 words

COOLING AND HARNESS

Cooling systemCVTF cooler (with warmer feature)
Inhibitor switch harness16 poles
Transmission harness12 poles

INHIBITOR HARNESS

Install in the reverse order of removal.

Note. Install the transmission ground terminal in the direction within the range of approx. 30° (A).

Tightening torque

T1: 7 N.m (0.7 kgf-m, 3.7 ft-lb)

T2: 14 N.m (1.4 kgf-m, 10.3 ft-lb)

Scheme 364

Scheme 364: INHIBITOR HARNESS
Scheme 364: INHIBITOR HARNESS

Scheme 365

Scheme 365
Scheme 365
  1. Clean the mating surface of valve cover and transmission side. CAUTION: When cleaning the mating surface of the transmission side, be careful not to allow any dust, foreign matter and used liquid gasket to enter the transmission.
  2. Check the control valve body for dust and other foreign matter.
  3. Install the O-ring to the transmission harness. NOTE: Use new O-rings. Apply CVTF to the O-ring.
  4. Install the transmission harness to the valve cover. Tightening torque: 7 N.m (0.7 kgf-m, 5.2 ft-lb)
  5. Install the gasket to the transmission. NOTE: Use a new gasket.
  6. Apply liquid gasket to the oval hole of gasket. Liquid gasket: THREE BOND 1215 (Part No. 004403007) or equivalent
  7. Connect the transmission harness connector to the control valve body, and install the valve cover. CAUTION: Be careful not to catch the sheet of the ST. Tightening torque: 8 N.m (0.8 kgf-m, 5.9 ft-lb)
  8. Remove the ST (SHEET SPECIAL TOOL).
  9. Install the transmission harness connector to the harness stay.
  10. Install the transmission harness stay and transmission ground terminal. NOTE: Install the transmission ground terminal in the direction within the range of approx. 30° (A). Tightening torque: T1: 7 N.m (0.7 kgf-m, 5.2 ft-lb) T2: 14 N.m (1.4 kgf-m, 10.3 ft-lb)
  11. Install the transmission case cover. Tightening torque: 8 N.m (0.8 kgf-m, 5.9 ft-lb)
  12. Install the pitching stopper bracket and transmission radio ground cord. Tightening torque: 41 N.m (4.2 kgf-m, 30.2 ft-lb)
  13. Install the air breather hose to the pitching stopper bracket.
  14. Install the pitching stopper. Tightening torque: T1: 50 N.m (5.1 kgf-m, 36.9 ft-lb) T2: 58 N.m (5.9 kgf-m, 42.8 ft-lb)
  15. Connect the following harness connectors. Transmission harness connectors Inhibitor harness connector Transmission radio ground terminal Tightening torque: 13 N.m (1.3 kgf-m, 9.6 ft-lb)
  16. Install the air intake boot assembly. < Refer to «INSTALLATION»(ref-560358-S35284385082013061300000) , Air Intake Boot. >
  17. Adjust the CVTF level. < Refer to «ADJUSTMENT»(ref-560362-S33944955892013061300000) , CVTF. >
