Automatic Transaxle (Cvt) (Except Wrx): Overhaul Subaru XV GP

Automatic Trans 1 illustration

DISASSEMBLY

  1. Remove the dust cover from extension case.
  2. Remove the extension case oil seal from the extension case. < Refer to «REPLACEMENT»(ref-560362-S42651844472013061300000) , Differential Side Retainer Oil Seal. >
  3. Remove all plugs.

Scheme 363

Scheme 363: ASSEMBLY
Scheme 363: ASSEMBLY
  1. Press-fit the dust cover into extension case.
  2. Install the extension case oil seal to extension case. < Refer to «REPLACEMENT»(ref-560362-S42651844472013061300000) , Differential Side Retainer Oil Seal. >
  3. Install all plugs. NOTE: Use a new O-ring or a gasket. Apply CVTF to the O-ring. Tightening torque: T1: 25 N.m (2.5 kgf-m, 18.4 ft-lb) T2: 35 N.m (3.6 kgf-m, 25.8 ft-lb)
