INSTALLATION
Install in the reverse order of removal.
| CAUTION | Be sure to use SUBARU genuine air cleaner element depending on the engine type when replacing the air cleaner elements. Using other air cleaner element may affect the engine performance. |
Note. Check that there are no foreign objects in the air cleaner case. When installing the air cleaner case (rear), align the protrusion of the air cleaner case (rear) to the hole on the air cleaner case (front) to install.
Tightening torque
3 N.m (0.3 kgf-m, 2.2 ft-lb)
Scheme 696
- Install the bolt (A) and nut (B) which secure the air cleaner case (front) to the body. Tightening torque: Bolt (A) 6 N.m (0.6 kgf-m, 4.4 ft-lb) Nut (B) 7.5 N.m (0.8 kgf-m, 5.5 ft-lb)
- Install the air cleaner case (rear) and the air cleaner element. NOTE: When installing the air cleaner case (rear), align the protrusion of the air cleaner case (rear) to the hole on the air cleaner case (front) to install.
- Install the air intake duct. Refer to «INSTALLATION»(ref-565165-S37221606252013071000000) .
- Attach the clip (B) to the air cleaner case (front), and tighten the clamp (A) connecting the air cleaner case (rear) and air intake boot assembly. Tightening torque: Clamp (A) 3 N.m (0.3 kgf-m, 2.2 ft-lb)
- Connect the connector (A) to the mass air flow and intake air temperature sensor, and fasten the harness to clip (B).
- Connect the power steering oil pressure hose (suction hose) to the clip on the side of air cleaner case (rear).
- Connect the ground cable to battery.
- Install the air intake boot assembly and connect the blow-by hose.
- Tighten the clamp (A) which connects the air intake boot assembly and throttle body.
- Tighten the bolt (B) which secures the air intake boot assembly and collector cover bracket. Tightening torque: Clamp (A) 3 N.m (0.3 kgf-m, 2.2 ft-lb) Bolt (B) 6.5 N.m (0.7 kgf-m, 4.8 ft-lb)
- Tighten the clamp which connects the air intake boot assembly and air cleaner case (rear). Tightening torque: 3 N.m (0.3 kgf-m, 2.2 ft-lb)
- Install the collector cover.
Install in the reverse order of removal.
REMOVAL
The resonator chamber and air cleaner case are integrated into one unit; therefore, refer to REMOVAL .
The resonator chamber and air cleaner case are integrated into one unit; therefore, refer to INSTALLATION .
