INSTALLATION
Install in the reverse order of removal.
| CAUTION | Be sure to use SUBARU genuine air cleaner element depending on the engine type when replacing the air cleaner elements. Using other air cleaner element may affect the engine performance. |
Note. Check that there are no foreign objects in the air cleaner case. When installing the air cleaner case (rear), align the protrusion of the air cleaner case (rear) to the hole on the air cleaner case (front) to install.
Scheme 684
Tightening torque
3 N.m (0.3 kgf-m, 2.2 ft-lb)
- Install the bolt (A) and nut (B) which secure the air cleaner case (front) to the body. Tightening torque: Bolt (A) 6 N.m (0.6 kgf-m, 4.4 ft-lb) Nut (B) 7.5 N.m (0.8 kgf-m, 5.5 ft-lb)
- Install the air cleaner case (rear) and air cleaner element. NOTE: When installing the air cleaner case (rear), align the protrusion of the air cleaner case (rear) to the hole on the air cleaner case (front) to install.
- Install the clips (B) to the air cleaner case (front), then tighten the clamp (A) that connects the air cleaner case (rear) to the air intake boot. Tightening torque: Clamp (A) 3 N.m (0.3 kgf-m, 2.2 ft-lb)
- Connect the connector (A) to the mass air flow and intake air temperature sensor and secure the harness with clip (B).
- Connect the power steering oil pressure hose (suction hose) to the clip on the side of air cleaner case (rear).
- Install the air intake duct. Refer to «INSTALLATION»(ref-565164-S36764007252013071000000) .
- Connect the battery ground terminal.
Install in the reverse order of removal.
Tightening torque
3 N.m (0.3 kgf-m, 2.2 ft-lb)
Install in the reverse order of removal.
REMOVAL
The resonator chamber and air cleaner case are integrated into one unit; therefore, refer to REMOVAL .
The resonator chamber and air cleaner case are integrated into one unit; therefore, refer to INSTALLATION .
