CAUTION
- Prior to starting work, pay special attention to the following: Always wear work clothes, a safety cap, protective shoes. Additionally, wear a helmet, protective goggles, etc. if necessary. Protect the vehicle using a seat cover, fender cover, etc. Prepare the service tools, clean cloth, containers to catch grease and oil, etc.
- Vehicle components are extremely hot immediately after driving. Be wary of receiving burns from heated parts.
- When performing a repair, identify the cause of trouble and avoid unnecessary removal, disassembly and replacement.
- Before disconnecting connectors of sensors or units, be sure to disconnect the ground cable from battery.
- Always use the jack-up point when the shop jacks or rigid racks are used to support the vehicle.
- Remove contamination including dirt and corrosion before removal, installation, disassembly or assembly.
- Keep the removed parts in order and protect them from dust and dirt.
- All removed parts, if to be reused, should be reinstalled in the original positions with attention to the correct directions, etc.
- Bolts, nuts and washers should be replaced with new parts as required.
- Be sure to tighten the fasteners including bolts and nuts to the specified torque.
Scheme 697
Scheme 698
Scheme 699
Scheme 700
- Disconnect the ground cable from battery.
- Disconnect the power steering oil pressure hose (suction hose) from the clip on the side of air cleaner case (rear).
- Disconnect the connector (A) from the mass air flow and intake air temperature sensor, and remove the clip (B).
- Loosen the clamp (A) which connects the air cleaner case (rear) and air intake boot assembly.
- Remove the clip (B) securing the upper side of air cleaner case.
- Pull the air cleaner case (rear) backward of the vehicle, and remove the air cleaner element.
