Engine Intake System (Induction) (H6DO): Diagnosis Subaru Outback BR рестайлинг

Mechanical 5 illustrations ~348 words

INSPECTION

  1. Check that the air cleaner element has no deformation, cracks or other damages.
  2. Check if the air cleaner element is extremely dirty.

Scheme 691

Scheme 691
Scheme 691
  1. Disconnect the ground cable from battery.
  2. Disconnect the power steering oil pressure hose (suction hose) from the clip on the side of air cleaner case (rear).
  3. Disconnect the connector (A) from the mass air flow and intake air temperature sensor, and remove the clip (B).
  4. Loosen the clamp (A) which connects the air cleaner case (rear) and air intake boot.
  5. Remove the clip (B) securing the upper side of air cleaner case (rear).
  6. Remove the air intake duct. Refer to «REMOVAL»(ref-565165-S00196848762013071000000) , Air Intake Duct.
  7. Remove the air cleaner case (rear) and air cleaner element.
  8. Remove the bolts (A) and nuts (B) which secure the air cleaner case (front) to the body.
  9. Remove the air cleaner case (front).
  1. Check that the air cleaner case has no deformation, cracks or other damages.
  2. Check the air intake boot assembly for cracks, damage or looseness.

Scheme 692

Scheme 692: REMOVAL
Scheme 692: REMOVAL

Scheme 693

Scheme 693
Scheme 693

Scheme 694

Scheme 694
Scheme 694
  1. Remove the collector cover. NOTE: Follow the steps below when removing the collector cover. Pull up the two points at the rear (A). Pull up the two points at the front (B) while moving them forward.
  2. Loosen the clamp which connects the air intake boot assembly and air cleaner case (rear).
  3. Loosen the clamp (A) which connects the air intake boot assembly and throttle body.
  4. Loosen the bolt (B) which secures the air intake boot assembly and collector cover bracket.
  5. Disconnect the blow-by hose and remove the air intake boot assembly.
  1. Check that the air intake boot assembly does not have deformation, cracks or other damages.
  2. Check there is no foreign matter in the air intake boot assembly.

Scheme 695

Scheme 695: REMOVAL
Scheme 695: REMOVAL
  1. Remove the clip securing the air intake duct.
  2. Remove the air intake duct.
  1. Check that the air intake duct has no deformation, cracks or other damages.
  2. Check that no foreign matter is mixed in air intake duct.

Check that the resonator chamber has no deformation, cracks or other damages.
