ELECTRICAL SPECIFICATION
| CAUTION | Never remove the occupant detection control module, occupant detection sensor or seat frame, because they are integrated into one unit. |
Scheme 200
| Terminal name | Terminal No. | Input/output value | Remarks | |
|---|---|---|---|---|
| IG - power supply | 5 | 9 - 16 V | When ignition switch is ON | |
| Airbag control module communication | (COM) | 3 | Open collector terminal | Communication line |
| Airbag control module communication | (GND) | 4 | 0 V | Ground |
| Buckle switch | 9 | 0 - IG voltage | Ignition voltage when switch is ON | |
| Buckle switch | (GND) | 8 | 0 V | Switch ground |
