INSPECTION
Measure the battery voltage and check electrolyte.
Standard voltage
12 V
Specific gravity
1.260 or more
Fluid level
Between the upper level and lower level
TROUBLE SYMPTOM
Communication is impossible between the airbag control module and the Subaru Select Monitor.
| CAUTION | Before performing diagnosis, refer to CAUTION . |
Communication is impossible between the airbag control module and the occupant detection control module. Perform the diagnosis from step 2 in "DTC B1650 OCCUPANT CLASSIFICATION SYSTEM MALFUNCTION". Refer to DTC B1650 OCCUPANT CLASSIFICATION SYSTEM MALFUNCTION .
Turn the ignition switch to ON, and confirm that the airbag warning light remains on for approx. 6 seconds and then goes off afterwards.
Scheme 202
Scheme 203
DTC DETECTING CONDITION
- Occupant detection sensor is faulty.
- Occupant detection control module is faulty.
- Occupant detection harness is faulty.
- Rear airbag harness is faulty.
- Communication to occupant detection control module and airbag control module is faulty.
- Airbag control module is faulty.
| CAUTION | Before performing diagnosis, refer to CAUTION . |
- Passenger's buckle switch circuit is open, shorted or shorted to ground.
- Seat harness circuit is open, shorted or shorted to ground.
- Occupant detection control module is faulty.
- Calibration of occupant detection control module is initial setting or faulty.
- Occupant detection control module is faulty.
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK DTC. Read the DTC of the airbag system using the Subaru Select Monitor. | Is another DTC detected? | Perform the diagnosis according to the displayed DTC. | Go to step 2 . |
| 2 PERFORM RE-ZEROING. Perform system calibration using the Subaru Select Monitor. Refer to SYSTEM CALIBRATION (REZEROING) . | Did the system calibration complete properly? | Go to step 3 . | Replace the occupant detection system. Refer to PASSENGER'S SEAT . |
| 3 CHECK DTC. Turn the ignition switch to OFF and wait for 60 seconds or more. Turn the ignition switch to ON, and then read the DTC of the airbag system. | Is a DTC other than DTC B16EE displayed? | Perform the diagnosis according to the displayed DTC. | When the DTC is B16EE, replace the occupant detection system. Refer to PASSENGER'S SEAT . When DTC is not displayed, end the diagnosis. |
DIAGNOSTIC PROCEDURE
| CAUTION | When a DTC other than DTC B16EE is present, system calibration (re-zeroing) cannot be completed normally. When occupant detection system DTC other than DTC B16EE is present, perform the diagnosis of the DTCs other than DTC B16EE. |
- Wrong occupant detection control module is installed.
- Occupant detection control module is faulty.
When this DTC is displayed, the occupant detection control module is faulty.
Replace the occupant detection control module with a genuine occupant detection control module.
