Air Bag System (Diagnostics): Overview Subaru Outback BR рестайлинг

OPERATION

For operation procedures, refer to the "PC application help for Subaru Select Monitor".

For operation procedures, refer to the "PC application help for Subaru Select Monitor".

Note. For details concerning DTCs, refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) .

For operation procedures, refer to the "PC application help for Subaru Select Monitor".

Note. Clear the DTC stored in the airbag control module after repairing the airbag system.

Check the operating condition of each sensor in the event of malfunction in the seat belt buckle switch, or when the seat belt buckle switch has been replaced.

1. On »Main Menu« display, select {Each System Check}.
2. On »System Selection Menu« display, select {Airbag System}.
3. On »Airbag System« display, select {Current Data Display & Save}. The following table is for support data. Item Display Note Trip Count - - Count - - Time Count - - Belt Buckle Switch RH Unbelted/Belted "Belted" when passenger's seat belt is fastened "Unbelted" when passenger's seat belt is not fastened Passenger Occupant Status Adult/Child/Empty or CRS "Adult" when the occupant is present "Child" or "Empty or CRS" when the seat is unoccupied or when child restraint seat is installed Passenger Airbag Status ON/OFF "ON" when the passenger occupant status is "Occupied" "OFF" when the status is "Empty or CRS" NOTE: For detailed operation procedures, refer to "PC application help for Subaru Select Monitor".

Scheme 212

1. On »Main Menu« display, select {Each System Check}.
2. On »System Selection Menu« display, select {Airbag System}.
3. On »Airbag System« display, select {Event Record Data}. After it is selected, {IMPORTANT NOTICE} screen is displayed.
4. Once you have read the contents of the »IMPORTANT NOTICE«, click the Yes checkbox.
5. If doing so will not violate any laws, click the {Yes} button to retrieve the EDR data.
6. Select the items to be checked from each event record data.
7. Select the record data to be checked from each record data.
8. The selected record data is displayed. If there is no data recorded, »No Event Record Data Recorded« is displayed.
9. Select [Exit] to return to each event record data screen.
