WIRING HARNESS
The airbag harnesses are integrated into the body harness as follows
- Front sub sensor harness: integrated into the front harness.
- Airbag main harness: integrated into the bulkhead harness.
- Pretensioner and side airbag harnesses: integrated into the rear harness.
AIRBAG HARNESS-TO-BODY HARNESS, OCCUPANT DETECTION CONTROL MODULE-TO-BODY HARNESS, AND SEAT BELT BUCKLE SWITCH CONNECTORS
Disconnection
Hold slide lock (A) moved in the direction of the arrow, then pull the female connector in the direction of the arrow.
Scheme 1
Connection
Push the connector (A) into the male connector carefully until a "click" is heard.
