Contents Section: Airbag All sections

Air Bag System (Diagnostics): Other Subaru Outback BR рестайлинг

Airbag 17 illustrations ~1065 words

PROCEDURE

StepCheckYesNo
1 CHECK WARNING LIGHT. Check whether the airbag warning light in the combination meter is lit.Does the airbag warning light illuminate?Go to step 2 .Perform the diagnosis according to phenomenon of the problem.
2 READ DTC. Turn the ignition switch to OFF. Connect the Subaru Select Monitor to data link connector. Turn the ignition switch to ON and run the Subaru Select Monitor. Read the DTC. (Current malfunction) Refer to OPERATION . NOTE: If the communication function of the Subaru Select Monitor cannot be executed properly, check the communication circuit. Refer to COMMUNICATION FOR INITIALIZING IMPOSSIBLE . Record all DTCs and freeze frame data.Is DTC displayed?Go to step 3 .Go to "Airbag Warning Light Failure" Refer to AIRBAG WARNING LIGHT FAILURE .
3 PERFORM DIAGNOSIS. Determine the possible cause from "List of Diagnostic Trouble Code (DTC)" Refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) . Inspect the DTC using "List of Diagnostic Trouble Code (DTC)". Repair the trouble cause. Perform the Clear Memory Mode. Refer to CLEAR MEMORY MODE . Perform the Inspection Mode. Refer to INSPECTION MODE . Read any other DTCs displayed.Is DTC displayed?Perform the procedure 1 ) to 5 ) in step 3.Finish the diagnosis.
NOTE
If the communication function of the Subaru Select Monitor cannot be executed properly, check the communication circuit. Refer to COMMUNICATION FOR INITIALIZING IMPOSSIBLE .

Scheme 233

Scheme 233: CHECK
Scheme 233: CHECK

CAUTION

Refer to CAUTION .

PREPARATION TOOL

CAUTIONTo measure the voltage and resistance of airbag system component, be sure to use the specified test harness.

Scheme 234

Scheme 234: SPECIAL TOOL
Scheme 234: SPECIAL TOOL

Scheme 235

Scheme 235
Scheme 235

Scheme 236

Scheme 236
Scheme 236

Scheme 237

Scheme 237
Scheme 237

Scheme 238

Scheme 238
Scheme 238

Scheme 239

Scheme 239
Scheme 239

Scheme 240

Scheme 240
Scheme 240

Scheme 241

Scheme 241
Scheme 241

Scheme 242

Scheme 242
Scheme 242

Scheme 243

Scheme 243
Scheme 243

Scheme 244

Scheme 244
Scheme 244

Scheme 245

Scheme 245
Scheme 245
  1. Subaru Select Monitor ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 1B022XU0 SUBARU SELECT MONITOR III KIT Used for troubleshooting the electrical system.
  2. TEST HARNESS H ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FA030 TEST HARNESS H Used when measuring voltage and resistance of front sub sensor and front door impact sensor.
  3. TEST HARNESS N ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA000 TEST HARNESS N Used when measuring voltage and resistance of driver's airbag module, seat belt pretensioner and curtain airbag module.
  4. TEST HARNESS P ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA020 TEST HARNESS P Used when measuring voltage and resistance of passenger's airbag module harness.
  5. TEST HARNESS Q ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA040 TEST HARNESS Q Used when measuring voltage and resistance of driver's airbag module and lap seat belt pretensioner.
  6. TEST HARNESS AG ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG070 TEST HARNESS AG Used when measuring voltage and resistance of airbag control module.
  7. TEST HARNESS AH ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG080 TEST HARNESS AH Used together with test harness AG when measuring voltage and resistance of the airbag control module.
  8. TEST HARNESS V ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG010 TEST HARNESS V Used when measuring voltage and resistance of side airbag sensor and curtain airbag sensor.
  9. AIRBAG RESISTOR ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299PA040 AIRBAG RESISTOR Used in replacement of airbag module for which resistance value is same as airbag module. Two STs are required for diagnosis of two-stage inflator type airbag module.
  10. TEST HARNESS AJ ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FG000 TEST HARNESS AJ Used when measuring power supply and resistance of side airbag harness.
  11. TEST HARNESS AI ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG090 TEST HARNESS AI Used for diagnoses of side airbag sensor and curtain airbag sensor. Used together with test harness V.

GENERAL TOOL

TOOL NAMEREMARKS
Circuit testerUsed for measuring resistance, voltage and current.
OscilloscopeUsed for measuring the sensor.

Scheme 246

Scheme 246: LOCATION
Scheme 246: LOCATION

Scheme 247

Scheme 247
Scheme 247
  1. OUTBACK model
  2. Sedan model
Connector No.(AB2)(AB6)(AB7)(AB9)(AB13)(AB16)(AB17)(AB18)(AB19)(AB21)(AB23)(AB24)
Pin430442215 or 2415 or 244244
ColorYellowYellowYellowYellowYellowYellowYellowYellowYellowBlackYellowYellow
Male/FemaleFemaleFemaleMaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemale
Connector No.(AB26)(AB28)(AB29)(AB30)(AB31)(AB32)(AB33)(AB34)(AB35)(AB37)(AB38)(AB53)
Pin242224242223
ColorBlackYellowOrangeOrangeBlackYellowBlackYellow*OrangeBlackBrown
Male/FemaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemale
Connector No.(AB58)(AB59)(AB60)(AB61)(AB62)(AB63)(AB64)
Pin23210222
ColorYellowBrownYellowBlackYellowYellowYellow
Male/FemaleFemaleMaleMaleFemaleFemaleFemaleFemale
*: White or natural color

For operation procedures, refer to AIRBAG CONNECTOR .

Scheme 248

Scheme 248: ELECTRICAL SPECIFICATION
Scheme 248: ELECTRICAL SPECIFICATION

Scheme 249

Scheme 249
Scheme 249
  1. OUTBACK model
  2. Terminal numbers in airbag control module connector are shown in the figure.
  3. The airbag warning light illuminates when the connector is removed from the airbag control module. Item Control module terminal No. Data link connector (1) - 16 Ignition power supply Dedicated fuse (1) - 21 Passenger's airbag module level one + (1) - 4 - (1) - 3 Passenger's airbag module level two + (1) - 1 - (1) - 2 Driver's airbag module level one + (1) - 5 - (1) - 6 Driver's airbag module level two + (1) - 8 - (1) - 7 CAN-H (1) - 13 CAN-L (1) - 22 Front sub sensor LH + (1) - 30 - (1) - 28 Front sub sensor RH + (1) - 29 - (1) - 27 Ground line (GND) (1) - 25 (1) - 26 Passenger's airbag ON indicator (1) - 23 Passenger's airbag OFF indicator (1) - 17 Passenger's seat belt warning (1) - 15 Side airbag sensor RH Curtain airbag sensor RH Front door impact sensor RH + (2) - 24 - (2) - 23 Seat belt pretensioner RH + (2) - 5 - (2) - 6 Lap seat belt pretensioner RH + (2) - 8 - (2) - 7 Side airbag module RH + (2) - 1 - (2) - 2 Curtain airbag module RH + (2) - 4 - (2) - 3 Occupant detection control module + (2) - 9 - (2) - 17 Side airbag sensor LH Curtain airbag sensor LH Front door impact sensor LH + (3) - 17 - (3) - 18 Side airbag module LH + (3) - 8 - (3) - 7 Curtain airbag module LH + (3) - 5 - (3) - 6 Seat belt pretensioner LH + (3) - 4 - (3) - 3 Lap seat belt pretensioner LH + (3) - 1 - (3) - 2
  4. Sedan model
  5. Terminal numbers in airbag control module connector are shown in the figure.
  6. The airbag warning light illuminates when the connector is removed from the airbag control module. Item Control module terminal No. Data link connector (1) - 16 Ignition power supply Dedicated fuse (1) - 21 Passenger's airbag module level one + (1) - 4 - (1) - 3 Passenger's airbag module level two + (1) - 1 - (1) - 2 Driver's airbag module level one + (1) - 5 - (1) - 6 Driver's airbag module level two + (1) - 8 - (1) - 7 CAN-H (1) - 13 CAN-L (1) - 22 Front sub sensor LH + (1) - 30 - (1) - 28 Front sub sensor RH + (1) - 29 - (1) - 27 Ground line (GND) (1) - 25 (1) - 26 Passenger's airbag ON indicator (1) - 23 Passenger's airbag OFF indicator (1) - 17 Passenger's seat belt warning (1) - 15 Seat belt pretensioner RH + (2) - 2 - (2) - 1 Lap seat belt pretensioner RH + (2) - 4 - (2) - 5 Ground line (GND) (2) - 3 Side airbag sensor RH Curtain airbag sensor RH Front door impact sensor RH + (2) - 8 - (2) - 15 Side airbag module RH + (2) - 9 - (2) - 10 Curtain airbag module RH + (2) - 7 - (2) - 6 Occupant detection control module + (2) - 14 - (2) - 13 Seat belt pretensioner LH + (3) - 4 - (3) - 5 Lap seat belt pretensioner LH + (3) - 2 - (3) - 1 Ground line (GND) (3) - 3 Side airbag sensor LH Curtain airbag sensor LH Front door impact sensor LH + (3) - 8 - (3) - 11 Side airbag module LH + (3) - 7 - (3) - 6 Curtain airbag module LH + (3) - 9 - (3) - 10

Recreate the circumstance by referring to the conditions described in the checklist.

DETECTING CONDITION

  1. Airbag warning light is faulty.
  2. Airbag control module to combination meter circuit is shorted or open.
  3. Grounding circuit is faulty.
  4. Airbag control module is faulty.
  5. Connector connection is improper.
  6. Connections of (AB6, AB17, AB18) to airbag control module are improper.
CAUTIONBefore performing diagnosis, refer to CAUTION .
StepCheckYesNo
1 CHECK CAN COMMUNICATION. Inspect LAN system. Refer to PROCEDURE .Is there any fault?Repair it according to diagnosis of LAN system.Go to step 2 .
2 CHECK DTC. Turn the ignition switch to OFF, disconnect the battery ground cable, and wait for 60 seconds or more. Check the connection status of airbag CM connector.Is there poor contact of connector?Reconnect the connector. Or repair the connector.Go to step 3 .
3 CHECK FOR POOR CONTACT. Check the combination meter. Refer to SELF-DIAGNOSIS DISPLAY MODE .Is there any fault?Replace the combination meter. Refer to REMOVAL .Replace the airbag CM. Refer to REMOVAL .

AIRBAG WARNING LIGHT REMAINS OFF

Note. For the diagnostic procedure, refer to AIRBAG WARNING LIGHT REMAINS ON .

LIST

DTCItemContent of diagnosisReference
U0073Control Module Communication Bus "A" OffCAN communication error occurred.Refer to DTC U0073 CONTROL MODULE COMMUNICATION BUS "A" OFF .
B1000Airbag ECU MalfunctionAirbag control module is faulty.Refer to DTC B1000 AIRBAG ECU MALFUNCTION .
B1003Airbag ECU MalfunctionAirbag control module is faulty.Refer to DTC B1003 AIRBAG ECU MALFUNCTION .
B1105Airbag ECU MalfunctionAirbag control module is faulty.Refer to DTC B1105 AIRBAG ECU MALFUNCTION .
B1106Airbag ECU MalfunctionAirbag control module is faulty.Refer to DTC B1106 AIRBAG ECU MALFUNCTION .
B1115Airbag ECU MalfunctionAirbag control module is faulty.Refer to DTC B1115 AIRBAG ECU MALFUNCTION .
B1116Airbag ECU MalfunctionAirbag control module is faulty.Refer to DTC B1116 AIRBAG ECU MALFUNCTION .
B1120Airbag ECU MalfunctionAirbag control module is faulty.Refer to DTC B1120 AIRBAG ECU MALFUNCTION .
B1121Airbag ECU MalfunctionAirbag control module is faulty.Refer to DTC B1121 AIRBAG ECU MALFUNCTION .
B1125Airbag ECU MalfunctionAirbag control module is faulty.Refer to DTC B1125 AIRBAG ECU MALFUNCTION .
B1126Airbag ECU MalfunctionAirbag control module is faulty.Refer to DTC B1126 AIRBAG ECU MALFUNCTION .
B1145Airbag ECU MalfunctionAirbag control module is faulty.Refer to DTC B1145 AIRBAG ECU MALFUNCTION .
B1146Airbag ECU MalfunctionAirbag control module is faulty.Refer to DTC B1146 AIRBAG ECU MALFUNCTION .
B1170Airbag ECU MalfunctionAirbag control module is faulty.Refer to DTC B1170 AIRBAG ECU MALFUNCTION .
B1185Airbag ECU MalfunctionAirbag control module is faulty.Refer to DTC B1185 AIRBAG ECU MALFUNCTION .
B1195Airbag ECU MalfunctionAirbag control module is faulty.Refer to DTC B1195 AIRBAG ECU MALFUNCTION .
B1196Airbag ECU MalfunctionAirbag control module is faulty.Refer to DTC B1196 AIRBAG ECU MALFUNCTION .
B1199Airbag ECU MalfunctionAirbag control module is faulty.Refer to DTC B1199 AIRBAG ECU MALFUNCTION .
B11E0Rollover IgnitionCurtain airbag module (LH/RH) and seat belt pretensioner (LH/RH) are deployed.Refer to DTC B11E0 ROLLOVER IGNITION .
B11F2Front Impact IgnitionFront airbag module and seat belt pretensioner (LH/RH) are inflated.Refer to DTC B11F2 FRONT IMPACT IGNITION .
B11F3Front Impact IgnitionFront airbag module and seat belt pretensioner (LH/RH) are inflated.Refer to DTC B11F3 FRONT IMPACT IGNITION .
B11F4Front Impact IgnitionFront airbag module and seat belt pretensioner (LH/RH) are inflated.Refer to DTC B11F4 FRONT IMPACT IGNITION .
B11F5Front Impact IgnitionFront airbag module and seat belt pretensioner (LH/RH) are inflated.Refer to DTC B11F5 FRONT IMPACT IGNITION .
B11F7Side Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.Refer to DTC B11F7 SIDE IMPACT IGNITION .
B11F8Side Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.Refer to DTC B11F8 SIDE IMPACT IGNITION .
B11F9Side Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.Refer to DTC B11F9 SIDE IMPACT IGNITION .
B11FASide Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.Refer to DTC B11FA SIDE IMPACT IGNITION .
B11FBSide Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.Refer to DTC B11FB SIDE IMPACT IGNITION .
B11FCSide Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.Refer to DTC B11FC SIDE IMPACT IGNITION .
B1610Front Sub Sensor RH FailureFront sub sensor (RH) is faultyRefer to DTC B1610 FRONT SUB SENSOR RH FAILURE .
B1612Front Sub Sensor RH Lost CommunicationOpen or short circuit in harness (RH) between airbag control module and front sub sensor. Front sub sensor (RH) is faulty. Airbag control module is faulty.Refer to DTC B1612 FRONT SUB SENSOR RH LOST COMMUNICATION .
B1613Front Sub Sensor RH Initialization ErrorRefer to DTC B1613 FRONT SUB SENSOR RH INITIALIZATION ERROR .
B1615Front Sub Sensor LH FailureFront sub sensor (LH) is faulty.Refer to DTC B1615 FRONT SUB SENSOR LH FAILURE .
B1617Front Sub Sensor LH Lost CommunicationOpen or short circuit in harness (LH) between airbag control module and front sub sensor. Front sub sensor (LH) is faulty. Airbag control module is faulty.Refer to DTC B1617 FRONT SUB SENSOR LH LOST COMMUNICATION .
B1618Front Sub Sensor LH Initialization ErrorRefer to DTC B1618 FRONT SUB SENSOR LH INITIALIZATION ERROR .
B16F2Front Sub Sensor RH Recognition ErrorFront sensor (RH) is misinstalled. Airbag control module is faulty.Refer to DTC B16F2 FRONT SUB SENSOR RH RECOGNITION ERROR .
B16F3Front Sub Sensor LH Recognition ErrorFront sensor (LH) is misinstalled. Airbag control module is faulty.Refer to DTC B16F3 FRONT SUB SENSOR LH RECOGNITION ERROR .
B1620Side Airbag Sensor RH FailureSide airbag sensor (RH) is faulty.Refer to DTC B1620 SIDE AIRBAG SENSOR RH FAILURE .
B1622Side Airbag Sensor RH Lost CommunicationOpen or short circuit in harness (RH) between airbag control module and side airbag sensor. Side airbag sensor (RH) is faulty. Airbag control module is faulty.Refer to DTC B1622 SIDE AIRBAG SENSOR RH LOST COMMUNICATION .
B1623Side Airbag Sensor RH Initialization ErrorRefer to DTC B1623 SIDE AIRBAG SENSOR RH INITIALIZATION ERROR .
B1625Side Airbag Sensor LH FailureSide airbag sensor (LH) is faulty.Refer to DTC B1625 SIDE AIRBAG SENSOR LH FAILURE .
B1627Side Airbag Sensor LH Lost CommunicationOpen or short circuit in harness (LH) between airbag control module and side airbag sensor. Side airbag sensor (LH) is faulty. Airbag control module is faulty.Refer to DTC B1627 SIDE AIRBAG SENSOR LH LOST COMMUNICATION .
B1628Side Airbag Sensor LH Initialization ErrorRefer to DTC B1628 SIDE AIRBAG SENSOR LH INITIALIZATION ERROR .
B1630Curtain Airbag Sensor RH FailureCurtain airbag sensor (RH) is faulty.Refer to DTC B1630 CURTAIN AIRBAG SENSOR RH FAILURE .
B1632Curtain Airbag Sensor RH Lost CommunicationOpen or short circuit in harness (RH) between airbag control module and curtain airbag sensor. Side airbag sensor (RH) is faulty. Curtain airbag sensor (RH) is faulty. Airbag control module is faulty.Refer to DTC B1632 CURTAIN AIRBAG SENSOR RH LOST COMMUNICATION .
B1633Curtain Airbag Sensor RH Initialization ErrorRefer to DTC B1633 CURTAIN AIRBAG SENSOR RH INITIALIZATION ERROR .
B1635Curtain Airbag Sensor LH FailureCurtain airbag sensor (LH) is faulty.Refer to DTC B1635 CURTAIN AIRBAG SENSOR LH FAILURE .
B1637Curtain Airbag Sensor LH Lost CommunicationOpen or short circuit in harness (LH) between airbag control module and curtain airbag sensor. Side airbag sensor (LH) is faulty. Curtain airbag sensor (LH) is faulty. Airbag control module is faulty.Refer to DTC B1637 CURTAIN AIRBAG SENSOR LH LOST COMMUNICATION .
B1638Curtain Airbag Sensor LH Initialization ErrorRefer to DTC B1638 CURTAIN AIRBAG SENSOR LH INITIALIZATION ERROR .
B16F4Side Airbag Sensor RH Recognition ErrorSide airbag sensor (RH) is misinstalled. Airbag control module is faulty.Refer to DTC B16F4 SIDE AIRBAG SENSOR RH RECOGNITION ERROR .
B16F5Side Airbag Sensor LH Recognition ErrorSide airbag sensor (LH) is misinstalled. Airbag control module is faulty.Refer to DTC B16F5 SIDE AIRBAG SENSOR LH RECOGNITION ERROR .
B16F6Curtain Airbag Sensor RH Recognition ErrorCurtain airbag sensor (RH) is misinstalled. Airbag control module is faulty.Refer to DTC B16F6 CURTAIN AIRBAG SENSOR RH RECOGNITION ERROR .
B16F7Curtain Airbag Sensor LH Recognition ErrorCurtain airbag sensor (LH) is misinstalled. Airbag control module is faulty.Refer to DTC B16F7 CURTAIN AIRBAG SENSOR LH RECOGNITION ERROR .
B1642Side Satellite Sensor Bus RH Lost CommunicationOpen or short circuit in harness (RH) between airbag control module and curtain airbag sensor. Side airbag sensor (RH) is faulty. Curtain airbag sensor (RH) is faulty. Front door impact sensor (RH) is faulty. Airbag control module is faulty.Refer to DTC B1642 SIDE SATELLITE SENSOR BUS RH LOST COMMUNICATION .
B1647Side Satellite Sensor Bus LH Lost CommunicationOpen or short circuit in harness (LH) between airbag control module and curtain airbag sensor. Side airbag sensor (LH) is faulty. Curtain airbag sensor (LH) is faulty. Front door impact sensor (LH) is faulty. Airbag control module is faulty.Refer to DTC B1647 SIDE SATELLITE SENSOR BUS LH LOST COMMUNICATION .
B1650Occupant Classification System MalfunctionOccupant detection sensor is faulty. Occupant detection control module is faulty. Occupant detection harness is faulty. Rear airbag harness (RH) is faulty. Fuse No. 25 is blown.Refer to DTC B1650 OCCUPANT CLASSIFICATION SYSTEM MALFUNCTION .
B1655Front Buckle Switch RH FailureBuckle switch (RH) circuit is open, shorted or shorted to ground. Occupant detection system is faulty. Occupant detection harness is faulty.Refer to DTC B1655 FRONT BUCKLE SWITCH RH FAILURE .
B1660Passenger's Airbag ON Indicator FailurePassenger's airbag indicator is faulty. Airbag control module is faulty. Airbag main harness circuit is open, shorted or shorted to ground. Body harness circuit is open.Refer to DTC B1660 PASSENGER'S AIRBAG ON INDICATOR FAILURE .
B16F9Door Sensor RH Recognition ErrorFront door impact sensor (RH) is misinstalled. Airbag control module is faulty.Refer to DTC B16F9 DOOR SENSOR RH RECOGNITION ERROR .
B1690Door Sensor RH FailureFront door impact sensor (RH) is faulty.Refer to DTC B1690 DOOR SENSOR RH FAILURE .
B1692Lost Communication With Door Sensor RHOpen or short circuit in harness between curtain airbag sensor and front door impact sensor. Front door impact sensor (RH) is faulty. Curtain airbag sensor (RH) is faulty. Airbag control module is faulty.Refer to DTC B1692 LOST COMMUNICATION WITH DOOR SENSOR RH .
B1693Door Sensor RH Initialization IncompleteRefer to DTC B1693 DOOR SENSOR RH INITIALIZATION INCOMPLETE .
B16FADoor Sensor LH Recognition ErrorFront door impact sensor (LH) is misinstalled. Airbag control module is faulty.Refer to DTC B16FA LOST COMMUNICATION WITH DOOR SENSOR LH .
B1695Door Sensor LH FailureFront door impact sensor (LH) is faulty.Refer to DTC B1695 DOOR SENSOR LH FAILURE .
B1697Lost Communication With Door Sensor LHOpen or short circuit in harness between curtain airbag sensor and front door impact sensor. Front door impact sensor (LH) is faulty. Curtain airbag sensor (LH) is faulty. Airbag control module is faulty.Refer to DTC B1697 LOST COMMUNICATION WITH DOOR SENSOR LH .
B1698Door Sensor LH Initialization IncompleteRefer to DTC B1698 DOOR SENSOR LH INITIALIZATION INCOMPLETE .
B161ALost Communication with Front Satellite Sensor BusOpen or short circuit in harness between airbag control module and front sub sensor. Front sub sensor is faulty. Airbag control module is faulty.Refer to DTC B161A LOST COMMUNICATION WITH FRONT SATELLITE SENSOR BUS .
B16EEOccupant Detection System Calibration errorOccupant detection control module is faulty. Calibration of occupant detection control module is initial setting or faulty.Refer to DTC B16EE ODS CALIBRATION ERROR .
B16EFOccupant Detection System wrong partsSpecification of occupant detection control module is improper. Occupant detection control module is faulty.Refer to DTC B16EF ODS SYSTEM WRONG PARTS .
B16F1Passenger's Seat Belt Warning FailureAirbag control module is faulty. Body integrated unit is faulty. Harness circuits between body integrated unit and airbag control module are open, shorted or shorted to ground.Refer to DTC B16F1 PASSENGER'S SEAT BELT WARNING FAILURE .
B16F0Passenger's Airbag OFF Indicator FailureAirbag warning light is faulty. Open or short circuit in harness between airbag control module and airbag warning light. Poor contact of airbag main harness and instrument panel harness. Ground circuit is faulty. Airbag control module is faulty.Refer to DTC B16F0 PASSENGER'S AIRBAG OFF INDICATOR FAILURE .
B1800Short in Driver's AirbagAirbag main harness circuit is shorted. Airbag module harness (driver's side) circuit is shorted. Roll connector circuit is shorted. Driver's airbag module is faulty. Airbag control module is faulty.Refer to DTC B1800 SHORT IN DRIVER'S AIRBAG .
B1801Open in Driver's AirbagAirbag main harness circuit is open. Airbag module harness circuit (driver's side) is open. Roll connector circuit is open. Driver's airbag module is faulty. Airbag control module is faulty.Refer to DTC B1801 OPEN IN DRIVER'S AIRBAG .
B1802Short in Driver's Airbag (to Ground)Airbag main harness circuit is shorted to ground. Airbag module harness (driver's side) circuit is shorted to ground. Roll connector circuit is shorted to ground. Driver's airbag module is faulty. Airbag control module is faulty.Refer to DTC B1802 SHORT IN DRIVER'S AIRBAG (TO GROUND) .
B1803Short in Driver's Airbag (to +B)Airbag main harness circuit is shorted to power supply. Airbag module harness circuit (driver's side) is shorted to power supply. Roll connector circuit is shorted to power supply. Airbag module is faulty. Airbag control module is faulty.Refer to DTC B1803 SHORT IN DRIVER'S AIRBAG (TO +B) .
B1805Short in Passenger's AirbagAirbag main harness circuit is shorted. Airbag module harness circuit (passenger's side) is shorted. Passenger's airbag module is faulty. Airbag control module is faulty.Refer to DTC B1805 SHORT IN PASSENGER'S AIRBAG .
B1806Open in Passenger's AirbagAirbag main harness circuit is open. Airbag module harness circuit (passenger's side) is open. Passenger's airbag module is faulty. Airbag control module is faulty.Refer to DTC B1806 OPEN IN PASSENGER'S AIRBAG .
B1807Short in Passenger's Airbag (to Ground)Airbag main harness circuit is shorted to ground. Airbag module harness (passenger's side) circuit is shorted to ground. Passenger's airbag module is faulty. Airbag control module is faulty.Refer to DTC B1807 SHORT IN PASSENGER'S AIRBAG (TO GROUND) .
B1808Short in Passenger's Airbag (to +B)Airbag main harness circuit is shorted to power supply. Airbag module harness (passenger's side) circuit is shorted to power supply. Passenger's airbag module is faulty. Airbag control module is faulty.Refer to DTC B1808 SHORT IN PASSENGER'S AIRBAG (TO +B) .
B1810Short in Driver's Airbag Dual Stage - 2nd StepAirbag main harness circuit is shorted. Airbag module harness (driver's side) circuit is shorted. Roll connector circuit is shorted. Driver's airbag module is faulty. Airbag control module is faulty.Refer to DTC B1810 SHORT IN DRIVER'S AIRBAG DUAL STAGE - 2ND STEP .
B1811Open in Driver's Airbag Dual Stage - 2nd StepAirbag main harness circuit is open. Airbag module harness circuit (driver's side) is open. Roll connector circuit is open. Driver's airbag module is faulty. Airbag control module is faulty.Refer to DTC B1811 OPEN IN DRIVER'S AIRBAG DUAL STAGE - 2ND STEP .
B1812Short in Driver's Airbag Dual Stage - 2nd Step (to Ground)Airbag main harness circuit is shorted to ground. Airbag module harness (driver's side) circuit is shorted to ground. Roll connector circuit is shorted to ground. Driver's airbag module is faulty. Airbag control module is faulty.Refer to DTC B1812 SHORT IN DRIVER'S AIRBAG DUAL STAGE - 2ND STEP (TO GROUND) .
B1813Short in Driver's Airbag Dual Stage - 2nd Step Circuit (to +B)Airbag main harness circuit is shorted to power supply. Airbag module harness circuit (driver's side) is shorted to power supply. Roll connector circuit is shorted to power supply. Airbag module is faulty. Airbag control module is faulty.Refer to DTC B1813 SHORT IN DRIVER'S AIRBAG DUAL STAGE - 2ND STEP CIRCUIT (TO +B) .
B1815Short in Passenger's Airbag Dual Stage - 2nd StepAirbag main harness circuit is shorted. Airbag module harness circuit (passenger's side) is shorted. Passenger's airbag module is faulty. Airbag control module is faulty.Refer to DTC B1815 OPEN IN PASSENGER'S AIRBAG DUAL STAGE - 2ND STEP .
B1816Open in Passenger's Airbag Dual Stage - 2nd StepAirbag main harness circuit is open. Airbag module harness circuit (passenger's side) is open. Passenger's airbag module is faulty. Airbag control module is faulty.Refer to DTC B1816 OPEN IN PASSENGER'S AIRBAG DUAL STAGE - 2ND STEP .
B1817Short in Passenger's Airbag Dual Stage - 2nd Step (to Ground)Airbag main harness circuit is shorted to ground. Airbag module harness (passenger's side) circuit is shorted to ground. Passenger's airbag module is faulty. Airbag control module is faulty.Refer to DTC B1817 SHORT IN PASSENGER'S AIRBAG DUAL STAGE - 2ND STEP (TO GROUND) .
B1818Short in Passenger's Airbag Dual Stage - 2nd Step Circuit (to +B)Airbag main harness circuit is shorted to power supply. Airbag module harness (passenger's side) circuit is shorted to power supply. Passenger's airbag module is faulty. Airbag control module is faulty.Refer to DTC B1818 SHORT IN PASSENGER'S AIRBAG DUAL STAGE - 2ND STEP CIRCUIT (TO +B) .
B1820Short in Side Airbag RHSide airbag harness (RH) circuit is shorted. Side airbag module (RH) is faulty. Airbag control module is faulty.Refer to DTC B1820 SHORT IN SIDE AIRBAG RH .
B1821Open in Side Airbag RHSide airbag harness (RH) circuit is open. Side airbag module (RH) is faulty. Airbag control module is faulty.Refer to DTC B1821 OPEN IN SIDE AIRBAG RH .
B1822Short in Side Airbag RH (to Ground)Side airbag harness (RH) circuit is shorted to ground. Side airbag module (RH) is faulty. Airbag control module is faulty.Refer to DTC B1822 SHORT IN SIDE AIRBAG RH (TO GROUND) .
B1823Short in Side Airbag RH(to +B)Side airbag harness (RH) circuit is shorted to power supply. Side airbag module (RH) is faulty. Airbag control module is faulty.Refer to DTC B1823 SHORT IN SIDE AIRBAG RH (TO +B) .
B1825Short in Side Airbag LHSide airbag harness (LH) circuit is shorted. Side airbag module (LH) is faulty. Airbag control module is faulty.Refer to DTC B1825 SHORT IN SIDE AIRBAG LH .
B1826Open in Side Airbag LHSide airbag harness (LH) circuit is open. Side airbag module (LH) is faulty. Airbag control module is faulty.Refer to DTC B1826 OPEN IN SIDE AIRBAG LH .
B1827Short in Side Airbag LH (to Ground)Side airbag harness (LH) circuit is shorted to ground. Side airbag module (LH) is faulty. Airbag control module is faulty.Refer to DTC B1827 SHORT IN SIDE AIRBAG LH (TO GROUND) .
B1828Short in Side Airbag LH (to +B)Side airbag harness (LH) circuit is shorted to power supply. Side airbag module (LH) is faulty. Airbag control module is faulty.Refer to DTC B1828 SHORT IN SIDE AIRBAG LH (TO +B) .
B1830Short in Curtain Airbag RH Squib CircuitCurtain airbag harness (RH) circuit is shorted. Curtain airbag module (RH) is faulty. Airbag control module is faulty.Refer to DTC B1830 SHORT IN CURTAIN AIRBAG RH SQUIB CIRCUIT .
B1831Open in Curtain Airbag RH Squib CircuitCurtain airbag harness (RH) circuit is open. Curtain airbag module (RH) is faulty. Airbag control module is faulty.Refer to DTC B1831 OPEN IN CURTAIN AIRBAG RH SQUIB CIRCUIT .
B1832Short in Curtain Airbag RH Squib Circuit (to Ground)Curtain airbag harness (RH) circuit is shorted to ground. Curtain airbag module (RH) is faulty. Airbag control module is faulty.Refer to DTC B1832 SHORT IN CURTAIN AIRBAG RH SQUIB CIRCUIT (TO GROUND) .
B1833Short in Curtain Airbag RH Squib Circuit (to +B)Curtain airbag harness (RH) is shorted to power supply. Curtain airbag module (RH) is faulty. Airbag control module is faulty.Refer to DTC B1833 SHORT IN CURTAIN SHIELD AIRBAG RH SQUIB CIRCUIT (TO +B) .
B1835Short in Curtain Airbag LH Squib CircuitCurtain airbag harness (LH) circuit is shorted. Curtain airbag module (LH) is faulty. Airbag control module is faulty.Refer to DTC B1835 SHORT IN CURTAIN AIRBAG LH SQUIB CIRCUIT .
B1836Open in Curtain Airbag LH Squib CircuitCurtain airbag harness (LH) circuit is open. Curtain airbag module (LH) is faulty. Airbag control module is faulty.Refer to DTC B1836 OPEN IN CURTAIN AIRBAG LH SQUIB CIRCUIT .
B1837Short in Curtain Airbag LH Squib Circuit (to Ground)Curtain airbag harness (LH) circuit is shorted to ground. Curtain airbag module (LH) is faulty. Airbag control module is faulty.Refer to DTC B1837 SHORT IN CURTAIN AIRBAG LH SQUIB CIRCUIT (TO GROUND) .
B1838Short in Curtain Airbag LH Squib Circuit (to +B)Curtain airbag harness (LH) is shorted to power supply. Curtain airbag module (LH) is faulty. Airbag control module is faulty.Refer to DTC B1838 SHORT IN CURTAIN SHIELD AIRBAG LH SQUIB CIRCUIT (TO +B) .
B1900Short in Front P/T RHSeat belt pretensioner (RH) circuit is shorted. Pretensioner (RH) is faulty. Pretensioner harness (RH) is shorted. Airbag control module is faulty.Refer to DTC B1900 SHORT IN FRONT P/T RH .
B1901Open in Front P/T RHSeat belt pretensioner (RH) circuit is open. Pretensioner (RH) is faulty. Pretensioner harness (RH) is shorted. Airbag control module is faulty.Refer to DTC B1901 OPEN IN FRONT P/T RH .
B1902Short in Front P/T RH (to Ground)Seat belt pretensioner (RH) circuit is shorted to ground. Pretensioner (RH) is faulty. Pretensioner harness (RH) is shorted. Airbag control module is faulty.Refer to DTC B1902 SHORT IN FRONT P/T RH (TO GROUND) .
B1903Short in Front P/T RH (to +B)Seat belt pretensioner (RH) circuit is shorted to power supply. Pretensioner (RH) is faulty. Pretensioner harness (RH) is shorted. Airbag control module is faulty.Refer to DTC B1903 SHORT IN FRONT P/T RH (TO +B) .
B1905Short in Front P/T LHSeat belt pretensioner (LH) circuit is shorted. Pretensioner (LH) is faulty. Pretensioner harness (LH) is shorted. Airbag control module is faulty.Refer to DTC B1905 SHORT IN FRONT P/T LH .
B1906Open in Front P/T LHSeat belt pretensioner (LH) circuit is open. Pretensioner (LH) is faulty. Pretensioner harness (LH) is shorted. Airbag control module is faulty.Refer to DTC B1906 OPEN IN FRONT P/T LH .
B1907Short in Front P/T LH (to Ground)Seat belt pretensioner (LH) circuit is shorted to ground. Pretensioner (LH) is faulty. Pretensioner harness (LH) is shorted. Airbag control module is faulty.Refer to DTC B1907 SHORT IN FRONT P/T LH (TO GROUND) .
B1908Short in Front P/T LH (to +B)Seat belt pretensioner (LH) circuit is shorted to power supply. Pretensioner (LH) is faulty. Pretensioner harness (LH) is shorted. Airbag control module is faulty.Refer to DTC B1908 SHORT IN FRONT P/T LH (TO +B) .
B19F0Short in Front P/T 2 RHLap seat belt pretensioner (RH) circuit is shorted. Lap seat belt pretensioner (RH) is faulty. Lap seat belt pretensioner harness (RH) is shorted. Airbag control module is faulty.Refer to DTC B19F0 SHORT IN FRONT P/T 2 RH .
B19F1Open in Front P/T 2 RHLap seat belt pretensioner (RH) circuit is open. Lap seat belt pretensioner (RH) is faulty. Lap seat belt pretensioner harness (RH) is open. Airbag control module is faulty.Refer to DTC B19F1 OPEN IN FRONT P/T 2 RH .
B19F2Short in Front P/T 2 RH (to Ground)Lap seat belt pretensioner (RH) circuit is shorted to ground. Lap seat belt pretensioner (RH) is faulty. Lap seat belt pretensioner harness (RH) is shorted to ground. Airbag control module is faulty.Refer to DTC B19F2 SHORT IN FRONT P/T RH (TO GROUND) .
B19F3Short in Front P/T 2 RH (to +B)Lap seat belt pretensioner (RH) circuit is shorted to power supply. Lap seat belt pretensioner (RH) is faulty. Lap seat belt pretensioner harness (RH) is shorted to power supply. Airbag control module is faulty.Refer to DTC B19F3 SHORT IN FRONT P/T 2 RH (TO +B) .
B19F4Short in Front P/T 2 LHLap seat belt pretensioner (LH) circuit is shorted. Lap seat belt pretensioner (LH) is faulty. Lap seat belt pretensioner harness (LH) is shorted. Airbag control module is faulty.Refer to DTC B19F4 SHORT IN FRONT P/T 2 LH .
B19F5Open in Front P/T 2 LHLap seat belt pretensioner (LH) circuit is open. Lap seat belt pretensioner (LH) is faulty. Lap seat belt pretensioner harness (LH) is open. Airbag control module is faulty.Refer to DTC B19F5 OPEN IN FRONT P/T 2 LH .
B19F6Short in Front P/T 2 LH (to Ground)Lap seat belt pretensioner (LH) circuit is shorted to ground. Lap seat belt pretensioner (LH) is faulty. Lap seat belt pretensioner harness (LH) is shorted to ground. Airbag control module is faulty.Refer to DTC B19F6 SHORT IN FRONT P/T LH (TO GROUND) .
B19F7Short in Front P/T 2 LH (to +B)Lap seat belt pretensioner (LH) circuit is shorted to power supply. Lap seat belt pretensioner (LH) is faulty. Lap seat belt pretensioner harness (LH) is shorted to power supply. Airbag control module is faulty.Refer to DTC B19F7 SHORT IN FRONT P/T 2 LH (TO +B) .

More articles — Air Bag System (Diagnostics)
