Lighting System: Wiring Subaru Outback BR

Exterior Lights 6 illustrations ~551 words

WIRING DIAGRAM

Refer to "Headlight System" in the WIRING DIAGRAM. Ref. to HEADLIGHTS , WIRING DIAGRAM, Headlight System .

Refer to "Headlight System" in the WIRING DIAGRAM. Ref. to HEADLIGHTS , WIRING DIAGRAM, Headlight System .

Refer to "Clearance Light and Illumination Light System" in the WIRING DIAGRAM. Ref. to INTERIOR LIGHTS , WIRING DIAGRAM, Clearance Light and Illumination Light System .

Refer to "Front Fog Light System" in the WIRING DIAGRAM. Ref. to HEADLIGHTS , WIRING DIAGRAM, Front Fog Light System .

Refer to "Turn Signal and Hazard Light System" in the WIRING DIAGRAM. Ref. to EXTERIOR LIGHTS , WIRING DIAGRAM, Turn Signal Light and Hazard Light System .

Refer to "Back-up Light System" in the WIRING DIAGRAM. Ref. to EXTERIOR LIGHTS , WIRING DIAGRAM, Back-up Light System .

Scheme 62

Scheme 62: CHECK BACK-UP LIGHT SWITCH (MT MODEL)
Scheme 62: CHECK BACK-UP LIGHT SWITCH (MT MODEL)
  1. Disconnect the back-up light switch connector.
  2. Measure the resistance between back-up light switch terminals. Preparation tool: Circuit tester SPECIFICATION CHART Terminal No. Inspection conditions Specification 1 - 2 When shift lever is set in reverse position Less than 1 ohms Other positions 1 Mohms or more
  3. Replace the back-up light switch if the inspection result is not within the standard value.

Scheme 63

Scheme 63: CHECK INHIBITOR SWITCH (CVT MODEL)
Scheme 63: CHECK INHIBITOR SWITCH (CVT MODEL)
  1. Disconnect the inhibitor switch connector.
  2. Measure the resistance between inhibitor switch terminals. Preparation tool: Circuit tester SPECIFICATION CHART Terminal No. Inspection conditions Specification 7 - 8 When the selector lever is in the "R" range Less than 1 ohms Other positions 1 Mohms or more
  3. Replace the inhibitor switch if the inspection result is not within the standard value.

Refer to "Stop Light System" in the WIRING DIAGRAM. Ref. to EXTERIOR LIGHTS , WIRING DIAGRAM, Stop Light System .

Scheme 64

Scheme 64: CHECK STOP LIGHT SWITCH
Scheme 64: CHECK STOP LIGHT SWITCH
  1. Disconnect the stop light switch connector.
  2. Measure the resistance between stop light switch terminals. Preparation tool: Circuit tester SPECIFICATION CHART Terminal No. Inspection conditions Specification 2 - 3 When brake pedal is depressed Less than 1 ohms When brake pedal is released 1 Mohms or more
  3. Replace the stop light switch if the inspection result is not within the standard value.

Refer to "Interior Light System" in the WIRING DIAGRAM. Ref. to INTERIOR LIGHTS , WIRING DIAGRAM, Interior Light System .

Scheme 65

Scheme 65: CHECK DOOR SWITCH
Scheme 65: CHECK DOOR SWITCH
  1. Remove the door switch.
  2. Measure the resistance between door switch terminals. Preparation tool: Circuit tester SPECIFICATION CHART Terminal No. Inspection conditions Specification 2 - 3 When door is opened Less than 1 ohms When door is closed 1 Mohms or more
  3. Replace the door switch if the inspection result is not within the standard value.

Scheme 66

Scheme 66: CHECK REAR GATE LATCH SWITCH
Scheme 66: CHECK REAR GATE LATCH SWITCH
  1. Disconnect the rear gate latch switch connector.
  2. Measure the resistance between rear gate latch switch terminals. Preparation tool: Circuit tester SPECIFICATION CHART Terminal No. Inspection conditions Specification 3 - 4 When rear gate is opened Less than 1 ohms When rear gate is closed 1 Mohms or more
  3. If the inspection result is not within the standard value, replace the rear gate latch and actuator assembly.

Scheme 67

Scheme 67: CHECK TRUNK LID SWITCH
Scheme 67: CHECK TRUNK LID SWITCH
  1. Disconnect the trunk lid switch connector.
  2. Measure the resistance between trunk lid switch terminals. Preparation tool: Circuit tester SPECIFICATION CHART Terminal No. Inspection conditions Specification 2 - 3 When trunk lid is opened Less than 1 ohms When trunk lid is closed 1 Mohms or more
  3. If the inspection result is not within the standard value, replace the trunk lid latch and actuator assembly.
