Lighting System: Removal & Installation Subaru Outback BR

REMOVAL

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

1. Set the front wheels in straight ahead position.
2. Turn the ignition switch to OFF.
3. Disconnect the ground cable from battery and wait for at least 60 seconds before starting work.
4. Remove the driver's airbag module assembly. Preparation tool: TORX® T30 Loosen the TORX® bolts located on the sides of the steering wheel. Disconnect the horn harness and airbag connector and remove the airbag module assembly. Ref. to «PROCEDURE»(ref-371944-S34749869132010091900000) , Airbag Connector.
5. Remove the steering wheel. CAUTION: If the steering wheel has been removed, make sure that the roll connector is not turned from the original position. Disconnect the connector and remove the nut. Put alignment marks and remove the steering wheel using a steering puller.
6. Remove the steering column cover. Lower the lever of the steering column. Release the claws and remove the screws, then detach the steering column lower cover. Separate the steering column upper cover and steering upper cover, and remove the steering column upper cover.
7. Remove the wiper switch assembly. Disconnect the connector from the wiper switch. Release the claws, and pull out the wiper switch assembly. CAUTION: Do not press the claws with excessive force. They may be damaged.
8. Remove the combination switch (light). Disconnect the connector. Remove the screws and detach the combination switch (light).

INSTALLATION

1. Align the center position of the roll connector. Ref. to «ADJUSTMENT»(ref-371944-S42660943702010091900000) , Roll Connector.
2. Align the alignment marks on the steering wheel and steering shaft.
3. Install each part in the reverse order of removal. Tightening torque: Combination switch (light): 3.5 N.m (0.36 kgf-m, 2.6 ft-lb) Driver's airbag module: 10 N.m (1.0 kgf-m, 7.4 ft-lb) Steering wheel: 39 N.m (4.0 kgf-m, 28.8 ft-lb) Clearance between column cover and steering wheel: 2 - 4 mm (0.08 - 0.16 in)

Scheme 44

1. Disconnect the combination switch (light) connector.
2. Measure the resistance between combination switch (light) connector terminals. Preparation tool: Circuit tester
3. Replace the combination switch (light) if the inspection result is not within the standard value.

Note. The light control sensor is integrated with the sunload sensor.

Scheme 45

Scheme 46

1. Disconnect the ground cable from battery.
2. Remove the light control sensor. CAUTION: Be careful not to damage the sensors and interior trims when removing. Release the claws and clips, then detach the side speaker cover (RH). Push out the light control sensor by pressing the left and right claws. Disconnect the connector, and remove the light control sensor.

Install each part in the reverse order of removal.

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

1. Disconnect the ground cable from battery.
2. Remove the clips and remove the air intake duct. (When removing the headlight RH).
3. Remove the front bumper face assembly. Ref. to «REMOVAL»(ref-371913-S11677829322010091900000) , Front Bumper.
4. Remove the fender cover assembly UPR. Remove the clip. Release the claws of the fender cover assembly UPR by pulling it forward and remove the fender cover.
5. Remove the headlight assembly. Remove the bolts and clips, and pull out the headlight assembly to the front of the vehicle. Disconnect the connector and remove the headlight assembly. Headlight connector RH Headlight connector LH

Install each part in the reverse order of removal.

Tightening torque

Headlight ASSY: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Note. When installing the back cover, turn it to the position shown in the figure to lock while pressing the entire periphery of the cover.

Scheme 52

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Tightening torque

Front fog light assembly: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Scheme 53

Scheme 54

1. Before checking the fog light beam level, be sure of the following: The area around the fog light has not sustained any accident, damage or other type of deformation. Vehicle is parked on a level surface. The inflation pressure of tires is correct. Vehicle's fuel tank is fully filled.
2. Bounce the vehicle several times to normalize the suspension.
3. Make certain that someone is seated in the driver's seat.
4. Place the vehicle with the front end facing to the measurement panel. AIMING SPECIFICATION h mm (in) at 3 m (10 ft) 40 (1.58)
5. Adjust the fog light beam. Remove the clips and turn over the front end of front mud guard. Adjust the beam direction by turning the aiming screw from the bottom of front bumper face.

Scheme 55

1. Disconnect the ground cable from battery.
2. Remove the clips and turn over the front end of front mud guard.
3. From the bottom of bumper face, remove the front fog light bulb. Disconnect the connector. Remove the bulb.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Tightening torque

Rear combination light ASSY: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Install each part in the reverse order of removal.

Tightening torque

Rear combination light ASSY: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Install each part in the reverse order of removal.

Tightening torque

Rear combination light ASSY: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Install each part in the reverse order of removal.

Tightening torque

Rear finisher light assembly: 4.5 N.m (0.45 kgf-m, 3.3 ft-lb)

Scheme 56

1. Disconnect the ground cable from battery.
2. Release the lock and remove the bulb inspection cover of trunk room trim.
3. Remove the bulb socket and back-up light bulb.

Scheme 57

1. Disconnect the ground cable from battery.
2. Release the claws and remove the bulb inspection cover of rear gate trim
3. Remove the bulb socket and back-up light bulb.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Tightening torque

High-mounted stop light: 4.5 N.m (0.46 kgf-m, 3.3 ft-lb)

Note. The spot map light is a single unit with the overhead console.

Scheme 58

Scheme 59

1. Disconnect the ground cable from battery.
2. Remove the overhead console assembly. Push and open the rear end of the overhead console lid, and remove the screws. Remove the clips and pull out the overhead console to disconnect the connectors.
3. Release the claws, then detach the spot map light cover and bulb.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Tightening torque

Daytime running resistor: 13 N.m (1.33 kgf-m, 9.6 ft-lb)

From behind the bumper, release the claws and remove the reflex reflector.

Scheme 60

Install each part in the reverse order of removal.

Scheme 61

1. Disconnect the ground cable from battery.
2. Remove the door switch. Remove the screws, and pull out the door switch. Disconnect the connector and remove the door switch.

Install each part in the reverse order of removal.
