HEADLIGHT BEAM ADJUSTMENT
| CAUTION | Turn off the light before adjusting the headlight beam level. If it is necessary to inspect the beam level, do not keep the light on for two minutes or more. |
Scheme 1
Scheme 2
Scheme 3
- Before checking the headlight beam level, be sure of the following: the area around the headlight has not sustained any scratches, damage or other type of deformation. Vehicle is parked on a level surface. The inflation pressure of tires is correct. Vehicle's fuel tank is fully filled.
- For vehicle with a manual leveler, set the headlight beam leveler switch to the "0" position.
- Bounce the vehicle several times to normalize the suspension.
- Make certain that someone is seated in the driver's seat.
- Measure the distance between the low beam bulb centers, and the height of the bulb center.
- Place the vehicle with the front end facing to the measurement panel. AIMING SPECIFICATION W mm (in) h mm (in) at 3 m (10 ft) 1,404 (55.28) 21 (0.83)
- Adjust the headlight low beam by turning the aiming screw. NOTE: When using a tester, follow the instructions of the tester manual.
