Engine Cooling System - Cooling (H4SO): Removal & Installation Subaru Outback BP рестайлинг

REMOVAL

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

1. Set the vehicle on a lift.
2. Disconnect the ground cable from the battery.
3. Lift up the vehicle.
4. Remove the under cover.
5. Remove the heat shield cover from radiator. (AT model)
6. Drain engine coolant completely. DRAINING OF ENGINE COOLANT, REPLACEMENT, Engine Coolant .>
7. Disconnect the radiator main fan motor connector (A) and sub fan motor connector (B).
8. Disconnect the radiator outlet hose from thermostat cover.
9. Disconnect the ATF cooler hoses from ATF pipes. (AT model) Plug the ATF pipe to prevent ATF from leaking.
10. Lower the vehicle.
11. Disconnect the over flow hose.
12. Remove the reservoir tank. REMOVAL, Reservoir Tank .>
13. Remove the hood stay holder.
14. Remove the air intake duct. REMOVAL , Air Intake Duct .>
15. Disconnect the radiator inlet hoses from the engine.
16. Remove the radiator upper brackets.
17. Lift the radiator up and away from vehicle.

Scheme 48

1. Attach the radiator lower cushion to the hole on the radiator lower bracket.
2. Install the radiator to vehicle. NOTE: Make pins on the lower side of radiator be fitted into the radiator lower cushions on body side.
3. Install the radiator upper brackets and tighten the bolts. Tightening torque: 12 N.m (1.2 kgf-m, 8.9 ft-lb)
4. Connect the radiator inlet hose.
5. Install the air intake duct. INSTALLATION , Air Intake Duct .>
6. Install the hood stay holder.
7. Install the reservoir tank. INSTALLATION, Reservoir Tank .>
8. Connect the over flow hose.
9. Lift up the vehicle.
10. Connect the ATF cooler hoses. (AT model)
11. Connect the radiator outlet hose.
12. Connect the radiator main fan motor connector (A) and sub fan motor connector (B).
13. Install the heat shield cover. (AT model) Tightening torque: 3 N.m (0.3 kgf-m, 2.2 ft-lb)
14. Install the under cover.
15. Lower the vehicle.
16. Connect the battery ground cable to battery.
17. Fill engine coolant. FILLING OF ENGINE COOLANT, REPLACEMENT, Engine Coolant .>
18. Check the ATF level. INSPECTION , Automatic Transmission Fluid .>

Scheme 49

1. Remove the radiator cap, fill the radiator with engine coolant, and then install the tester to the installation position of cap.
2. Apply a pressure of 157 kPa (1.6 kg/cm 2 , 23 psi) to the radiator and check the following points

1. Leakage from the radiator or its vicinity
2. Leakage from the hose or its connections CAUTION: Engine should be turned off. Wipe engine coolant from check points in advance. Be careful of engine coolant from spurting out when removing the tester. Be careful not to deform the filler neck of radiator when installing and removing the tester.

Scheme 50

1. Attach the radiator cap to tester.
2. Increase pressure until the tester gauge pointer stops. Radiator cap is functioning properly if it holds the service limit pressure for five to six seconds. Specified pressure: 93 - 123 kPa (0.95 - 1.25 kg/cm 2 , 14 - 18 psi) Service limit pressure: 83 kPa (0.85 kg/cm 2 , 12 psi) CAUTION: Be sure to remove foreign matter and rust from the cap in advance. Otherwise, results of pressure test will be incorrect.

Scheme 51

1. Set the vehicle on a lift.
2. Disconnect the ground cable from the battery.
3. Lift up the vehicle.
4. Remove the under cover.
5. Disconnect the connector (A) of the main fan motor.
6. Remove the heat shield cover. (AT model)
7. Remove the ATF hose from the clip of the radiator main fan motor assembly. (AT model)
8. Lower the vehicle.
9. Disconnect the over flow hose.
10. Remove the reservoir tank. REMOVAL, Reservoir Tank .>
11. Remove the bolts which hold the radiator main fan shroud to the radiator.
12. Remove the radiator main fan motor assembly.

INSTALLATION

Install in the reverse order of removal.

Note. If the installation of the radiator main fan motor assembly is difficult, attempt installation after loosening the bolts which hold the radiator sub fan motor assembly.

Tightening torque

7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Scheme 52

Scheme 53

1. Remove the clip which holds motor connector onto the shroud.
2. Remove the nuts which hold the fan to the fan motor.
3. Remove the bolts which hold fan motor onto shroud.

Install in the reverse order of removal.

Tightening torque

7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Scheme 54

1. Remove the clip which holds the fan motor connector to the shroud.
2. Remove the nuts which hold the fan to the fan motor.
3. Remove the bolts which hold fan motor onto shroud.

Install in the reverse order of removal.
