Engine Cooling System - Cooling (H4DOTC): Removal & Installation Subaru Outback BP рестайлинг

Cooling Fan 18 illustrations ~1243 words

REMOVAL

CAUTIONWait until engine cools down before working on the radiator because the radiator is pressurized.

Scheme 74

Scheme 74
Scheme 74

Scheme 75

Scheme 75
Scheme 75

Scheme 76

Scheme 76
Scheme 76

Scheme 77

Scheme 77
Scheme 77

Scheme 78

Scheme 78
Scheme 78

Scheme 79

Scheme 79
Scheme 79

Scheme 80

Scheme 80
Scheme 80

Scheme 81

Scheme 81
Scheme 81
  1. Set the vehicle on a lift.
  2. Remove the collector cover.
  3. Disconnect the ground cable from the battery.
  4. Lift up the vehicle.
  5. Remove the under cover.
  6. Remove the heat shield cover from radiator. (AT model)
  7. Drain engine coolant completely. DRAINING OF ENGINE COOLANT, REPLACEMENT, Engine Coolants .>
  8. Disconnect the connectors of radiator main fan (A) and sub fan motor (B).
  9. Disconnect the radiator outlet hose from thermostat cover.
  10. Disconnect the ATF cooler hoses from ATF pipes. Plug the ATF pipe to prevent ATF from leaking. (AT model)
  11. Lower the vehicle.
  12. Remove the air intake duct. REMOVAL , Air Intake Duct .>
  13. Disconnect the over flow hose.
  14. Remove the reservoir tank. REMOVAL, Reservoir Tank .>
  15. Disconnect the radiator inlet hose (A) from the radiator.
  16. Remove the hood stay holder (B).
  17. Disconnect the two coolant filler tank hoses from the radiator.
  18. Remove the radiator upper brackets.
  19. Move the radiator to the left while lifting it upward.
  20. Lift the radiator up and away from vehicle.

Scheme 82

Scheme 82: INSTALLATION
Scheme 82: INSTALLATION

Scheme 83

Scheme 83
Scheme 83
  1. Attach the radiator lower cushion to the hole on the radiator lower bracket.
  2. Install the radiator to vehicle. NOTE: Make pins on the lower side of radiator be fitted into the radiator lower cushions on body side.
  3. Install the radiator upper brackets and tighten the bolts. Tightening torque: 12 N.m (1.2 kgf-m, 8.9 ft-lb)
  4. Connect the two coolant filler tank hoses to the radiator.
  5. Connect the radiator inlet hose (A).
  6. Install the hood stay holder (B). Tightening torque: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
  7. Install the reservoir tank. INSTALLATION, Reservoir Tank .>
  8. Connect the over flow hose.
  9. Install the air intake duct. INSTALLATION , Air Intake Duct .>
  10. Lift up the vehicle.
  11. Connect the ATF cooler hoses. (AT model)
  12. Connect the radiator outlet hose.
  13. Connect the connectors to the radiator main fan motor (A) and sub fan motor (B).
  14. Install the heat shield cover to the radiator. (AT model) Tightening torque: 3 N.m (0.3 kgf-m, 2.2 ft-lb)
  15. Install the under cover.
  16. Lower the vehicle.
  17. Connect the battery ground cable to battery.
  18. Fill engine coolant. FILLING OF ENGINE COOLANT, REPLACEMENT, Engine Coolant .>
  19. Check the ATF level. INSPECTION , Automatic Transmission Fluid .>
  20. Install the collector cover.

Scheme 84

Scheme 84: INSPECTION
Scheme 84: INSPECTION
  1. Remove the coolant filler tank cap, fill the coolant filler tank with engine coolant, then install the tester to the installation position of the cap.
  2. Apply a pressure of 122 kPa (1.2 kg/ 2 , 18 psi) to the radiator and check the following points: Leakage from the radiator or its vicinity Leakage from the hose or its connections CAUTION: Inspection must be carried out at the side of coolant filler tank, not at the side of radiator. Engine should be turned off. Wipe engine coolant from check points in advance. Be careful of the spurt of engine coolant when removing the tester. Be careful not to deform the filler neck of the coolant filler tank when installing and removing the tester.

Scheme 85

Scheme 85: INSPECTION
Scheme 85: INSPECTION
  1. Attach the radiator cap to tester.
  2. Increase pressure until the tester gauge pointer stops. Radiator cap is functioning properly if it holds the service limit pressure for five to six seconds. Coolant filler tank side Specified pressure: 93 - 123 kPa (0.95 - 1.25 kg/ 2 , 14 - 18 psi) Service limit pressure: 83 kPa (0.85 kg/ 2 , 12 psi) Radiator side Specified pressure: 122 - 152 kPa (1.24 - 1.55 kg/ 2 , 18 - 22 psi) Service limit pressure: 112 kPa (1.14 kg/ 2 , 16 psi) CAUTION: Be sure to remove foreign matter and rust from the cap in advance. Otherwise, results of pressure test will be incorrect. Do not confuse the cap of coolant filler tank and cap of radiator.

Scheme 86

Scheme 86
Scheme 86

Scheme 87

Scheme 87
Scheme 87
  1. Set the vehicle on a lift.
  2. Remove the collector cover.
  3. Disconnect the ground cable from the battery.
  4. Lift up the vehicle.
  5. Remove the under cover.
  6. Disconnect the main fan motor connector (A).
  7. Remove the heat shield cover from radiator. (AT model)
  8. Drain the coolant about 1 G (1.06 US qt, 0.88 lmp qt). DRAINING OF ENGINE COOLANT, REPLACEMENT, Engine Coolant .>
  9. Remove the ATF hose from the clip of the radiator main fan motor assembly. (AT model)
  10. Lower the vehicle.
  11. Remove the air intake duct.
  12. Disconnect the overflow hose.
  13. Remove the over flow pipe.
  14. Remove the reservoir tank. REMOVAL, Reservoir Tank .>
  15. Remove the mounting bolts from radiator main fan motor assembly.
  16. Disconnect the radiator inlet hose (A) from the radiator.
  17. Remove the hood stay holder (B).
  18. Remove the radiator main fan motor assembly from vehicle.

INSTALLATION

  1. Install the radiator main fan motor assembly to the vehicle.
  2. Connect the radiator inlet hose (A) to the radiator.
  3. Install the hood stay holder (B). Tightening torque: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
  4. Install the mounting bolts to radiator main fan motor assembly. Tightening torque: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
  5. Install the reservoir tank. INSTALLATION, Reservoir Tank .>
  6. Install the over flow pipe.
  7. Connect the over flow hose.
  8. Install the air intake duct.
  9. Lift up the vehicle.
  10. Connect the ATF hose to the clip of the radiator main fan motor assembly. (AT model)
  11. Install the heat shield cover to the radiator. (AT model) Tightening torque: 3 N.m (0.3 kgf-m, 2.2 ft-lb)
  12. Connect the main fan motor connector (A).
  13. Install the under cover.
  14. Lower the vehicle.
  15. Connect the battery ground cable to battery.
  16. Fill engine coolant. FILLING OF ENGINE COOLANT, REPLACEMENT, Engine Coolant .>
  17. Install the collector cover.

Scheme 88

Scheme 88: DISASSEMBLY
Scheme 88: DISASSEMBLY

Scheme 89

Scheme 89
Scheme 89
  1. Remove the clip which holds the fan motor connector onto the shroud.
  2. Remove the nuts which hold the fan to the fan motor.
  3. Remove the bolts which hold fan motor onto shroud.
  1. Install the radiator sub fan motor assembly to the vehicle.
  2. Connect the radiator inlet hose (A) to the radiator.
  3. Install the hood stay holder (B). Tightening torque: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
  4. Install the mounting bolts to the radiator sub fan motor assembly. Tightening torque: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
  5. Install the reservoir tank. INSTALLATION, Reservoir Tank .>
  6. Install the over flow pipe.
  7. Connect the over flow hose.
  8. Install the air intake duct.
  9. Lift up the vehicle.
  10. Connect the ATF hose to the clip of the radiator sub fan motor assembly. (AT model)
  11. Install the heat shield cover to the radiator. (AT model) Tightening torque: 3 N.m (0.3 kgf-m, 2.2 ft-lb)
  12. Connect the sub fan motor connector (B).
  13. Install the under cover.
  14. Lower the vehicle.
  15. Connect the battery ground cable to battery.
  16. Fill engine coolant. FILLING OF ENGINE COOLANT, REPLACEMENT, Engine Coolant .>
  17. Install the collector cover.

Scheme 90

Scheme 90: DISASSEMBLY
Scheme 90: DISASSEMBLY
  1. Remove the clip which holds the fan motor connector onto the shroud.
  2. Remove the nuts which hold the fan to the fan motor.
  3. Remove the bolts which hold fan motor onto shroud.

Install in the reverse order of removal.

WARNINGThe radiator is pressurized. Wait until engine cools down before working on the radiator.

Scheme 91

Scheme 91
Scheme 91
  1. Remove the collector cover.
  2. Drain the coolant about 3.0 l (3.2 US qt, 2.6 lmp qt). DRAINING OF ENGINE COOLANT, REPLACEMENT, Engine Coolant .>
  3. Disconnect the engine coolant hoses from coolant filler tank.
  4. Remove the bolts which install the coolant filler tank.
  5. Disconnect the engine coolant hose which connects the under side of coolant filler tank.
  6. Remove the coolant filler tank.
  1. Install in the reverse order of removal. Tightening torque: 16 N.m (1.6 kgf-m, 11.8 ft-lb)
  2. Fill engine coolant. FILLING OF ENGINE COOLANT, REPLACEMENT, Engine Coolant .>
