Engine Cooling System - Cooling (H4DOTC): Overhaul Subaru Outback BP рестайлинг

ASSEMBLY

Assemble in the reverse order of disassembly.

Tightening torque: 5 N.m (0.5 kgf-m, 3.6 ft-lb)

Tightening torque: 3.4 N.m (0.35 kgf-m, 2.5 ft-lb)

Scheme 92

1. Set the vehicle on a lift.
2. Remove the collector cover.
3. Disconnect the ground cable from the battery.
4. Lift up the vehicle.
5. Remove the under cover.
6. Disconnect the sub fan motor connector (B).
7. Remove the heat shield cover from radiator. (AT model)
8. Drain the coolant about 1 0 (1.06 US qt, 0.88 lmp qt). DRAINING OF ENGINE COOLANT, REPLACEMENT, Engine Coolant .>
9. Remove the ATF hose from the clip of the radiator sub fan motor assembly. (AT model)
10. Lower the vehicle.
11. Remove the air intake duct.
12. Disconnect the overflow hose.
13. Remove the over flow pipe.
14. Remove the reservoir tank. REMOVAL, Reservoir Tank .>
15. Remove the mounting bolts from the radiator sub fan motor assembly.
16. Disconnect the radiator inlet hose (A) from the radiator.
17. Remove the hood stay holder (B).
18. Remove the radiator sub fan motor assembly from the vehicle.

Assemble in the reverse order of disassembly.

Tightening torque: 5 N.m (0.5 kgf-m, 3.6 ft-lb)

Tightening torque: 3.4 N.m (0.35 kgf-m, 2.5 ft-lb)

Scheme 93

1. Remove the collector cover.
2. Disconnect the over flow hose (A).
3. Pull out the reservoir tank to the arrow direction while pushing the claw (B).
