SPECIFICATION
| Cooling system | Electric fan + Forced engine coolant circulation system | |||
|---|---|---|---|---|
| Total engine coolant capacity | L (US qt, lmp qt) | MT: approx. 7.3 (7.7, 6.4) AT: approx. 7.2 (7.6, 6.3) | ||
| Water pump | Type | Centrifugal impeller type | ||
| Discharge performance I | Discharge rate | L (US gal, lmp gal) / min | 20 (5.3, 4.4) | |
| Pump speed - Discharge pressure | 760 rpm - 2.9 kPa (0.3 mAq) | |||
| Engine coolant temperature | 80°C (176°F) | |||
| Discharge performance II | Discharge rate | L (US gal, lmp gal) / min | 100 (26.4, 22.0) | |
| Pump speed - Discharge pressure | 3,000 rpm - 49.0 kPa (5.0 mAq) | |||
| Engine coolant temperature | 80°C (176°F) | |||
| Discharge performance III | Discharge rate | L (US gal, lmp gal) / min | 200 (52.8, 44.0) | |
| Pump speed - Discharge pressure | 6,000 rpm - 225.4 kPa (23.0 mAq) | |||
| Engine coolant temperature | 80°C (176°F) | |||
| Impeller diameter | Mm (in) | 76 (2.99) | ||
| Number of impeller vanes | 8 | |||
| Pump pulley diameter | Mm (in) | 60 (2.36) | ||
| Clearance between impeller and case | Standard | Mm (in) | 0.5 - 1.5 (0.020 - 0.059) | |
| Thermostat | Type | Wax pellet type | ||
| Starting temperature to open | 76 - 80°C (169 - 176°F) | |||
| Fully opens | 91°C (196°F) | |||
| Valve lift | Mm (in) | 9.0 (0.354) or more | ||
| Valve bore | Mm (in) | 35 (1.38) | ||
| Radiator fan | Motor input | Main fan W | 120 | |
| Sub fan W | 120 | |||
| Fan diameter / Blade | Main fan | 320 mm (12.6 in)/5 | ||
| Sub fan | 320 mm (12.6 in)/7 | |||
| Radiator | Type | Down flow | ||
| Core dimensions | Width x Height x Thickness | Mm (in) | 687.4 x 340 x 16 (27.06 x 13.39 x 0.63) | |
| Pressure range in which cap valve is open | Coolant filler tank side | KPa (kg/cm 2 , psi) | Above: 108±15 (1.1±0.15, 16±2) Below: -1.0 to -4.9 (-0.01 - -0.05, -0.1 - -0.7) | |
| Radiator side | KPa (kg/ 2 , psi) | Above only: 137±14.7 (1.40±.0.15, 20±2.1) | ||
| Fins | Corrugated fin type | |||
| Reservoir tank | Capacity | L (US qt, lmp qt) | 0.45 (0.48, 0.40) | |
GENERAL SPECIFICATION
| Coolant | Recommended materials | Item number | Alternative |
|---|---|---|---|
| Coolant | SUBARU coolant | 000016218 | Phosphoric acid (non-amine) type |
| Water for dilution | Distilled water | Soft water or tap water | |
| Cooling system protective agent | Cooling system conditioner | SOA345001 | None |
GENERAL SPECIFICATION
| Vehicle speed | A/C compressor load | Engine coolant temperature | ||
|---|---|---|---|---|
| Increase: 94°C (201°F) or less Decrease: 91°C (196°F) or less | Increase: 95 - 96°C (203 - 205°F) Decrease: 92 - 94°C (198 -201°F) | Increase: 97°C (207°F) or more Decrease: 95°C (203°F) or more | ||
| Radiator fan operation | Radiator fan operation | Radiator fan operation | ||
| During acceleration: 19 km/h (12MPH) or less During deceleration: 10 km/h (6 MPH) or less | OFF | OFF | Low-Speed | High-Speed |
| Low | Low-Speed | Low-Speed | High-Speed | |
| High | High-Speed | High-Speed | High-Speed | |
| During acceleration: 20 - 69 km/h (12 - 43MPH) During deceleration: 11 - 64 km/h (7 - 40 MPH) | OFF | OFF | Low-Speed | High-Speed |
| Low | High-Speed | High-Speed | High-Speed | |
| High | High-Speed | High-Speed | High-Speed | |
| During acceleration: 70 - 105 km/h (43 - 65 MPH) During deceleration: 65 - 103 km/h (40 - 64 MPH) | OFF | OFF | Low-Speed | High-Speed |
| Low | High-Speed | High-Speed | High-Speed | |
| High | High-Speed | High-Speed | High-Speed | |
| During acceleration: 106 km/h (66 MPH) or more During deceleration: 104 km/h (65 MPH) or more | OFF | OFF | High-Speed | High-Speed |
| Low | High-Speed | High-Speed | High-Speed | |
| High | High-Speed | High-Speed | High-Speed | |
ENGINE COOLANT TEMPERATURE SPECIFICATION
