Scheme 565
Scheme 566
OPERATION OF SHIFT SELECT LEVER
Make sure there is no abnormal noise, dragging or contact pattern in each select lever range.
| WARNING | Stop the engine while checking operation of the selector lever. |
Scheme 567
Scheme 568
Scheme 569
Scheme 570
Scheme 571
Scheme 572
Scheme 573
Scheme 574
Scheme 575
| Number | Description |
|---|---|
| 1 | Soleniod 1 |
| 2 | Solenoid 2 |
| 3 | Line Pressure Duty Solenoid |
| 4 | Low Clutch Timing Solenoid |
| 5 | Lock-Up Duty Solenoid |
| 6 | 2-4 Brake Duty Solenoid |
| 7 | 2-4 Brake Timing Solenoid |
| 8 | Transfer Duty Solenoid |
LEGEND FOR (Scheme 575)
Scheme 576
Scheme 577
Scheme 578
Scheme 579
Scheme 580
Scheme 581
Scheme 582
Scheme 583
Scheme 584
Scheme 585
Scheme 586
Scheme 587
Scheme 588
Scheme 589
- Prepare the Subaru Select Monitor kit.
- Connect the diagnosis cable to Subaru Select Monitor.
- Insert the cartridge into Subaru Select Monitor. See «PREPARATION TOOL»(ref-175447-S30877743832005042100000) .
- Connect the Subaru Select Monitor to data link connector. Data link connector located in the lower portion of the instrument panel (on the driver's side). Connect the diagnosis cable to data connector. CAUTION: Do not connect scan tools except for Subaru Select Monitor and OBD-II general scan tool.
- Turn the ignition switch to ON (engine OFF) and Subaru Select Monitor switch to ON.
- On the << Main Menu >> display screen, select the {Each System Check} and press the [YES] key.
- On the << System Selection Menu >> display screen, select the {Transmission Control System} and press the [YES] key.
- Press the [YES] key after displayed the information of transmission type.
- On the << Transmission Diagnosis >> display screen, select the {Diagnostic Code(s) Display} and press the [YES] key.
- On the << Diagnostic Code(s) Display >> display screen, select the {Latest Diagnostic Code(s)} or {Memorized Diagnostic Code(s)} and press the [YES] key. NOTE: For detailed operation procedure, refer to the SUBARU SELECT MONITOR OPERATION MANUAL. For details concerning diagnostic trouble codes, see «DIAGNOSTIC PROCEDURE WITH DIAGNOSTIC TROUBLE CODE (DTC)»(ref-175447-S28040102302005042100000) .
Scheme 590
- On the << Main Menu >> display screen, select the {Each System Check} and press the [YES] key.
- On the << System Selection Menu >> display screen, select the {Transmission Control System} and press the [YES] key.
- Press the [YES] key after displayed the information of transmission type.
- On the << Transmission Diagnosis >> display screen, select the {Current Data Display & Save} and press the [YES] key.
- On the << Data Display Menu >> display screen, select the {Data Display} and press the [YES] key.
- Using the scroll key, move the display screen up or down until the desired data is shown. A list of the support data is shown in the following table. NOTE: For detailed operation procedure, refer to the SUBARU SELECT MONITOR OPERATION MANUAL.
OPERATION
Raise the vehicle using a garage jack and place on safety stands or drive the vehicle onto free rollers.
| WARNING | Before raising the vehicle, ensure parking brakes are applied. Do not use a pantograph jack in place of a safety stand. Secure a rope or wire to the front and rear towing or tie-down hooks to prevent the lateral runout of front wheels. Do not abruptly depress/release clutch pedal or accelerator pedal during works even when the engine is operating at low speeds since this may cause vehicle to jump off free rollers. In order to prevent the vehicle from slipping due to vibration, do not place any wooden blocks or similar items between the safety stands and the vehicle. Since the rear wheels will also rotate, do not place anything near them. Also, make sure that nobody goes in front of the vehicle. |
