SPECIFICATION
| Model | 2.5 L | |||
|---|---|---|---|---|
| Engine | Cylinder arrangement | Horizontally opposed, liquid cooled, 4-cylinder, 4-stroke gasoline engine | ||
| Valve system mechanism | Belt driven, single over-head camshaft, 4-valve/cylinder | |||
| Bore x Stroke | Mm (in) | 99.5 x 79.0 (3.917 x 3.110) | ||
| Displacement | Cm 3 (cu in) | 2,457 (150) | ||
| Compression ratio | 10.0 | |||
| Compression pressure (at 350 rpm) | KPa (kgf/cm 2 , psi) | 1,020 - 1,275 (10.4 - 13.0, 148 - 185) | ||
| Number of piston rings | Pressure ring: 2, Oil ring: 1 | |||
| Intake valve timing | Fixed | Open | BTDC 0° | |
| Close | ABDC 58° | |||
| Low speed | Open | BTDC 0° | ||
| Close | ABDC -50° | |||
| High speed | Open | BTDC 14° | ||
| Close | ABDC 62° | |||
| Exhaust valve timing | Open | BBDC 54° | ||
| Close | ATDC 14° | |||
| Valve clearance | Mm (in) | Intake | 0.20±0.04 (0.0079±0.0016) | |
| Exhaust | 0.25±0.04 (0.0098±0.0016) | |||
| Idle speed [at neutral position on MT, or "P" or "N" range on AT] | Rpm | MT | 650±100 (No load) 850±100 (A/C ON) | |
| AT | 700±100 (No load) 850±100 (A/C ON) | |||
| Ignition order | 1 --> 3 --> 2 --> 4 | |||
| Ignition timing | BTDC/rpm | MT | 10°±8°/650 | |
| AT | 15°±/700 | |||
| US: undersize OS: oversize | ||||
ENGINE SPECIFICATION CHART
| Belt tension adjuster | Protrusion of adjuster rod | Mm (in) | 5.2 - 6.2 (0.205 - 0.244) | |||
|---|---|---|---|---|---|---|
| Belt tensioner | Spacer O.D. | Mm (in) | 17.955 - 17.975 (0.7069 - 0.7077) | |||
| Tensioner bushing I.D. | Mm (in) | 18.00 - 18.08 (0.7087 - 0.7118) | ||||
| Clearance between spacer and bushing | Mm (in) | Standard | 0.025 - 0.125 (0.0010 - 0.0049) | |||
| Limit | 0.175 (0.069) | |||||
| Side clearance of spacer | Mm (in) | Standard | 0.20 - 0.55 (0.0079 - 0.0217) | |||
| Limit | 0.81 (0.0319) | |||||
| Valve rocker arm | Clearance between shaft and arm | Mm (in) | Intake | Fixed | Standard | 0.020 - 0.054 (0.0008 - 0.0021) |
| Limit | 0.10 (0.0039) | |||||
| Low speed | Standard | 0.010 - 0.038 (0.0004 - 0.0015) | ||||
| Limit | 0.10 (0.0039) | |||||
| High speed | Standard | 0.010 - 0.038 (0.0004 - 0.0015) | ||||
| Limit | 0.10 (0.0039) | |||||
| Exhaust | Standard | 0.020 - 0.054 (0.0008 - 0.0021) | ||||
| Limit | 0.10 (0.0039) | |||||
| Camshaft | Bend limit | Mm (in) | 0.025 (0.0010) | |||
| Thrust clearance | Mm (in) | Standard | 0.030 - 0.090 (0.0012 - 0.0035) | |||
| Limit | 0.10 (0.0039) | |||||
| Cam lobe height | Mm (in) | Intake | Fixed | Standard | 40.075 - 40.175 (1.5778 - 1.5817) | |
| Limit | 39.975 (1.5738) | |||||
| Low speed | Standard | 35.182 - 35.282 (1.3851 - 1.3891) | ||||
| Limit | 35.082 (1.3812) | |||||
| High speed | Standard | 40.315 - 40.415 (1.5872 - 1.5911) | ||||
| Limit | 40.215 (1.5833) | |||||
| Exhaust | Standard | 40.149 - 40.249 (1.5807 - 1.5846) | ||||
| Limit | 40.049 (1.5767) | |||||
| Camshaft journal O.D. | Mm (in) | 31.928 - 31.945 (1.2570 - 1.2577) | ||||
| Camshaft journal hole I.D. | Mm (in) | 32.000 - 32.018 (1.2598 - 1.2605) | ||||
| Oil clearance | Mm (in) | Standard | 0.055 - 0.090 (0.0022 - 0.0035) | |||
| Limit | 0.10 (0.0039) | |||||
| Cylinder head | Surface warping limit: (mating with cylinder block) | Mm (in) | 0.03 (0.001) | |||
| Grinding limit | Mm (in) | 0.1 (0.004) | ||||
| Standard height | Mm (in) | 97.5 (3.84) | ||||
| Valve seat | Refacing angle | 90° | ||||
| Contacting width | Mm (in) | Intake | Standard | 0.8 - 1.4 (0.03 - 0.055) | ||
| Limit | 1.7 (0.067) | |||||
| Exhaust | Standard | 1.2 - 1.8 (0.047 - 0.071) | ||||
| Limit | 2.2 (0.087) | |||||
| Valve guide | Inside diameter | Mm (in) | 6.000 - 6.012 (0.2362 - 0.2367) | |||
| Protrusion above head | Mm (in) | Intake | 20.0 - 21.0 (0.787 - 0.827) | |||
| Exhaust | 16.5 - 17.5 (0.650 - 0.689) | |||||
| Valve | Head edge thickness | Mm (in) | Intake | Standard | 0.8 - 1.2 (0.03 - 0.047) | |
| Limit | 0.6 (0.024) | |||||
| Exhaust | Standard | 1.0 - 1.4 (0.039 - 0.055) | ||||
| Limit | 0.6 (0.024) | |||||
| Stem outer diameters | Mm (in) | Intake | 5.950 - 5.965 (0.2343 - 0.2348) | |||
| Exhaust | 5.945 - 5.960 (0.2341 - 0.2346) | |||||
| Valve stem gap | Mm (in) | Standard | Intake | 0.035 - 0.062 (0.0014 - 0.0024) | ||
| Exhaust | 0.040 - 0.067 (0.0016 - 0.0026) | |||||
| Limit | 0.15 (0.059) | |||||
| Overall length | Mm (in) | Intake | 120.6 (4.75) | |||
| Exhaust | 121.7 (4.79) | |||||
| Valve spring | Free length | Mm (in) | 55.2 (2.173) | |||
| Squareness | 2.5°, 2.4 mm (0.094 in) or less | |||||
| Tension/spring height | N (kgf, lbf)/mm (in) | Set | 235.3 - 270.7 (24 - 27.6, 52.9 - 60.8)/45.0 (1.772) | |||
| Lift | 578.9 - 639.9 (59.1 - 65.3, 130.3 - 143.9)/34.7 (1.366) | |||||
| Cylinder block | Surface warpage limit (mating with cylinder head) | Mm (in) | 0.025 (0.00098) | |||
| Grinding limit | Mm (in) | 0.1 (0.004) | ||||
| Standard height | Mm (in) | 201.0 (7.91) | ||||
| Cylinder inner diameter | Mm (in) | Standard | A | 99.505 - 99.515 (3.9175 - 3.9179) | ||
| B | 99.495 - 99.505 (3.9171 - 3.9175) | |||||
| Taper | Mm (in) | Standard | 0.015 (0.0006) | |||
| Limit | 0.050 (0.0020) | |||||
| Out-of-roundness | Mm (in) | Standard | 0.010 (0.0004) | |||
| Limit | 0.050 (0.0020) | |||||
| Piston clearance | Mm (in) | Standard | 0.010 - 0.010 (-0.00039 - 0.00039) | |||
| Limit | 0.030 (0.0012) | |||||
| Cylinder boring limit (diameter) | Mm (in) | 100.005 (3.937) | ||||
| Piston | Outer diameter | Mm (in) | Standard | A | 99.505 - 99.515 (3.9175 - 3.9179) | |
| B | 99.495 - 99.505 (3.9171 - 3.9175) | |||||
| 0.25 (0.0098) OS | 99.745 - 99.765 (3.9270 - 3.9278) | |||||
| 0.50 (0.0197) OS | 99.995 - 100.015 (3.9368 - 3.9376) | |||||
| Piston pin standard diameter | Mm (in) | 23.000 - 23.006 (0.9055 - 0.9057) | ||||
| Piston pin | Outer diameter | Mm (in) | 22.994 - 23.000 (0.9053 - 0.9055) | |||
| Clearance between piston and piston pin | Mm (in) | Standard | 0.004 - 0.008 (0.0002 - 0.0003) | |||
| Limit | 0.020 (0.0008) | |||||
| Degree of fit | Piston pin must be fitted into position with thumb at 20°C (68°F). | |||||
| Piston Ring | Ring closed gap | Mm (in) | Top ring | Standard | 0.20 - 0.35 (0.0079 - 0.0138) | |
| Limit | 1.0 (0.039) | |||||
| Second ring | Standard | 0.37 - 0.52 (0.0144 - 0.0203) | ||||
| Limit | 1.0 (0.039) | |||||
| Oil ring | Standard | 0.20 - 0.50 (0.0079 - 0.0197) | ||||
| Limit | 1.5 (0.059) | |||||
| Ring groove gap | Mm (in) | Top ring | Standard | 0.040 - 0.080 (0.0016 - 0.0031) | ||
| Limit | 0.15 (0.0059) | |||||
| Second ring | Standard | 0.030 - 0.070 (0.0012 - 0.0028) | ||||
| Limit | 0.15 (0.0059) | |||||
| Connecting rod | Bend twist per 100 mm (3.94 in) in length | Mm (in) | Limit | 0.10 (0.0039) | ||
| Side clearance of large end | Mm (in) | Standard | 0.070 - 0.330 (0.0028 - 0.0130) | |||
| Limit | 0.4 (0.016) | |||||
| Bearing of large end | Oil clearance | Mm (in) | Standard | 0.016 - 0.044 (0.00063 - 0.0017) | ||
| Limit | 0.05 (0.0020) | |||||
| Bearing size (Thickness at center) | Mm (in) | Standard | 1.492 - 1.501 (0.0587 - 0.0591) | |||
| 0.03 (0.0012) US | 1.510 - 1.513 (0.0594 - 0.0596) | |||||
| 0.05 (0.0020) US | 1.520 - 1.523 (0.0598 - 0.0600) | |||||
| 0.25 (0.0098) US | 1.620 - 1.623 (0.0638 - 0.0639) | |||||
| Bushing of small end | Clearance between piston pin and bushing | Mm (in) | Standard | 0 - 0.022 (0 - 0.0009) | ||
| Limit | 0.030 (0.0012) | |||||
| Crankshaft | Bend limit | Mm (in) | 0.035 (0.0014) | |||
| Crank pin | Out-of-roundness | Mm (in) | 0.003 (0.0001) | |||
| Cylindrically | Mm (in) | 0.004 (0.0002) | ||||
| Grinding limit (dia.) | Mm (in) | To 51.750 (2.0374) | ||||
| Crank journal | Out-of-roundness | Mm (in) | 0.005 (0.0002) | |||
| Cylindrically | Mm (in) | 0.006 (0.0002) | ||||
| Grinding limit (dia.) | Mm (in) | To 59.750 (2.3524) | ||||
| Crank pin outer diameter | Mm (in) | Standard | 51.984 - 52.000 (2.0466 - 2.0472) | |||
| 0.03 (0.0012) US | 51.954 - 51.970 (2.0454 - 2.0461) | |||||
| 0.05 (0.0020) US | 51.934 - 51.950 (2.0446 - 2.0453) | |||||
| 0.25 (0.0098) US | 51.734 - 51.750 (2.0368 - 2.0374) | |||||
| Crank journal outer diameter | Mm (in) | Standard | 59.992 - 60.008 (2.3619 - 2.3625) | |||
| 0.03 (0.0012) US | 59.962 - 59.978 (2.3607 - 2.3613) | |||||
| 0.05 (0.0020) US | 59.942 - 59.958 (2.3599 - 2.3605) | |||||
| 0.25 (0.0098) US | 59.742 - 59.758 (2.3520 - 2.3527) | |||||
| Side clearance | Mm (in) | Standard | 0.030 - 0.115 (0.0012 - 0.0045) | |||
| Limit | 0.25 (0.0098) | |||||
| Oil clearance | Mm (in) | Standard | 0.010 - 0.030 (0.0004 - 0.0012) | |||
| Limit | 0.40 (0.0016) | |||||
| Main bearing | Main bearing mm (in) | #1, #3 | Standard | 1.998 - 2.011 (0.0787 - 0.0792) | ||
| 0.03 (0.0012) US | 2.017 - 2.020 (0.0794 - 0.0795) | |||||
| 0.05 (0.0020) US | 2.027 - 2.030 (0.0798 - 0.0799) | |||||
| 0.25 (0.0098) US | 2.127 - 2.130 (0.0837 - 0.0839) | |||||
| #2, #4, #5 | Standard | 2.000 - 2.013 (0.0787 - 0.0793) | ||||
| 0.03 (0.0012) US | 2.019 - 2.022 (0.0795 - 0.0796) | |||||
| 0.05 (0.0020) US | 2.029 - 2.032 (0.0799 - 0.0800) | |||||
| 0.25 (0.0098) US | 2.129 - 2.132 (0.0838 - 0.0839) | |||||
| US: undersize OS: oversize | ||||||
ENGINE SPECIFICATION CHART - US: UNDERSIZE OS: OVERSIZE
Exploded View Of Timing Belt With Torque Specifications. Scheme 41
Exploded View Of Cylinder Head And Camshaft With Torque Specifications. Scheme 42
Identifying Valve Rocker Assembly Components With Torque Specifications. Scheme 43
Identifying Cylinder Head And Valve Assembly Components. Scheme 44
Identifying Cylinder Block Components With Torque Specifications. Scheme 45
Identifying Crankshaft And Piston Components With Torque Specifications. Scheme 46
Identifying Engine Mounting Bracket And Front Cushion Rubber With Torque Specifications. Scheme 47
For the removal and installation procedure of intake and exhaust valve, refer to "Cylinder Head". < Ref. to REMOVAL, Cylinder Head. > < Ref. to INSTALLATION, Cylinder Head. >
For the removal and installation procedure of piston, refer to "Cylinder Block". < Ref. to REMOVAL, Cylinder Block. > < Ref. to INSTALLATION, Cylinder Block. >
For the removal and installation procedure of connecting rod, refer to "Cylinder Block". < Ref. to REMOVAL, Cylinder Block. > < Ref. to INSTALLATION, Cylinder Block. >
For the removal and installation procedure of crankshaft, refer to "Cylinder Block". < Ref. to REMOVAL, Cylinder Block. > < Ref. to INSTALLATION, Cylinder Block. >
