Intake (Induction) (H4DOTC): Overhaul Subaru Forester SG рестайлинг

Mechanical 8 illustrations ~349 words

ASSEMBLY

Assemble in the reverse order of disassembly.

Note. Be careful not to pinch the O-ring.

Tightening torque

16 N.m (1.6 kgf-m, 11.6 ft-lb)

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64
  1. Set the vehicle on a lift.
  2. Disconnect the ground cable from battery. see scheme 28: Disconnecting Battery Ground Cable
  3. Remove the collector cover.
  4. Remove the center exhaust pipe. REMOVAL Center Exhaust Pipe. >
  5. Lower the vehicle.
  6. Separate the turbocharger joint pipe from turbocharger. (Scheme 58): Locating Turbocharger Bolts
  7. Disconnect the engine coolant hose which is connected to coolant filler tank. (Scheme 59): Locating Engine Coolant Hose
  8. Loosen the clamp which secures turbocharger to intake duct. (Scheme 60): Identifying Bolts Securing Turbocharger To Intake Duct
  9. Remove the bolts which secure oil pipe bracket to turbocharger.
  10. Remove the oil inlet pipe from turbocharger. (Scheme 61): Exploded View Of Oil Inlet Pipe (Scheme 62): Locating Oil Pipe
  11. Remove the turbocharger bracket. (Scheme 63): Locating Turbocharger Bracket Bolts
  12. Disconnect the oil outlet hose from pipe. (Scheme 64): Locating Oil Outlet Hose Clamp
  13. Take out the turbocharger from engine compartment.

Scheme 65

Scheme 65
Scheme 65
  1. Connect the oil outlet hose to outlet pipe. see scheme 36: Locating Oil Outlet Hose Clamp
  2. Install the turbocharger to intake duct. Tightening torque: 3 N.m (0.3 kgf-m, 2.2 ft-lb) see scheme 37: Identifying Bolts Securing Turbocharger To Intake Duct
  3. Install the oil inlet pipe to turbocharger. NOTE: Use a new gasket. Tightening torque: T1: 16 N.m (1.6 kgf-m, 11.6 ft-lb) T2: 20 N.m (2.0 kgf-m, 14.5 ft-lb) T3: 4.9 N.m (0.50 kgf-m, 3.6 ft-lb) (Scheme 65): Exploded View Of Oil Inlet Pipe
  4. Install the joint pipe to turbocharger. NOTE: Use a new gasket. Tightening torque: 35 N.m (3.6 kgf-m, 25.8 ft-lb) see scheme 39: Locating Turbocharger Bolts
  5. Install the turbocharger bracket. Tightening torque: 33 N.m (3.4 kgf-m, 24.6 ft-lb) see scheme 40: Locating Turbocharger Bracket Bolts
  6. Connect the engine coolant hose which is connected to the coolant filler tank. see scheme 41: Locating Engine Coolant Hose
  7. Lift-up the vehicle.
  8. Install the center exhaust pipe. INSTALLATION Center Exhaust Pipe. >
