Intake (Induction) (H4DOTC): Other Subaru Forester SG рестайлинг

CAUTION

1. Wear work clothing, including a cap, protective goggles and protective shoes during operation.
2. Remove contamination including dirt and corrosion before removal, installation or disassembly.
3. Keep the disassembled parts in order and protect them from dust and dirt.
4. Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly and replacement.
5. Be careful not to burn your hands, because each part on the vehicle is hot after running.
6. Be sure to tighten fasteners including bolts and nuts to the specified torque.
7. Place shop jacks or rigid racks at the specified points.
8. Before disconnecting connectors of sensors or units, be sure to disconnect the ground cable from battery.

Scheme 66

Scheme 67

Scheme 68

1. Disconnect the ground cable from battery. (Scheme 66): Disconnecting Battery Ground Cable
2. Disconnect the connector from mass air flow sensor. (Scheme 67): Identifying Mass Air Flow Sensor Connector
3. Loosen the clamps (A) which connect the air intake boot and the intake duct.
4. Remove the clip (B) from air cleaner upper cover. (Scheme 68): Identifying Air Cleaner Upper Cover Clip And Clamp
5. Remove the air cleaner upper cover.
6. Remove the air cleaner element.
7. Remove the air cleaner lower case.

Locating Air Cleaner Lower Case Bolts. Scheme 69
