CAUTION

1. Wear work clothing, including a cap, protective goggles and protective shoes during operation.
2. Remove contamination including dirt and corrosion before removal, installation or disassembly.
3. Keep the disassembled parts in order and protect them from dust and dirt.
4. Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly and replacement.
5. Be careful not to burn yourself, because each part on the vehicle is hot after running.
6. Be sure to tighten fasteners including bolts and nuts to the specified torque.
7. Place shop jacks or rigid racks at the specified points.
8. Before disconnecting connectors of sensors or units, be sure to disconnect the ground cable from battery.
9. All parts should be thoroughly cleaned, paying special attention to engine oil passages, pistons and bearings.
10. Rotating parts and sliding parts such as piston, bearing and gear should be coated with oil prior to assembly.
11. Be careful not to let oil, grease or coolant contact the timing belt, clutch disc and flywheel.
12. All removed parts, if to be reused, should be reinstalled in the original positions and directions.
13. Bolts, nuts and washers should be replaced with new ones as required.
14. Even if necessary inspections have been made in advance, proceed with assembly work while making re-checks.
15. Remove or install the engine in an area where chain hoists, lifting devices, etc. are available for ready use.
16. Be sure not to damage coated surfaces of body panels with tools, or not to stain seats and windows with coolant or oil. Place a cover over fender, as required, for protection.
17. Prior to starting work, prepare the following: Service tools, clean cloth, containers to catch coolant and oil, wire ropes, chain hoist, transmission jacks, etc.
18. Lift-up or lower the vehicle when necessary. Make sure to support the correct positions.

GENERAL TOOL

GENERAL TOOLS DESCRIPTION

PROCEDURE

It is possible to conduct the following service procedures with engine on vehicle, however, the procedures described in this information are based on the condition that the engine is removed from vehicle.

1. V-belt
2. Timing belt
3. Valve rocker assembly
4. Camshaft
5. Cylinder head

FRONT SIDE BELT

1. Install a V-belt (C), and tighten the slider bolt so as to obtain the specified belt tension. INSPECTION, V-BELT. >
2. Tighten the lock bolt (A).
3. Tighten the slider bolt (B). Tightening torque: Lock bolt (A) 25 N.m (2.5 kgf-m, 18.1 ft-lb) Slider bolt (B) 8 N.m (0.8 kgf-m, 5.8 ft-lb) see scheme 58: Locating Lock Bolt And Slider Bolt

REAR SIDE BELT

1. Install the belt tensioner.
2. Install a V belt, and tighten the slider bolt (B) so as to obtain the specified belt tension. INSPECTION, V-BELT. >
3. Tighten the lock nut (A). Tightening torque: Lock nut (A) 23 N.m (2.3 kgf-m, 17.0 ft-lb)

Scheme 238

Scheme 239

1. Replace the belts, if crack, fraying or wear is found.
2. Remove the V-belt cover and reservoir tank, (with belt tension gauge)
3. Check the V-belt tension and adjust it if necessary by changing the generator installing position or idler pulley installing position. Belt tension (with belt tension gauge): (A) When installing new parts 618 - 755 N (63 - 77 kgf, 139 - 170 lb) At inspection 490 - 640 N (50.0 - 65.3 kgf, 110.2 - 143.9 lb) (B) When installing new parts 740 - 880 N (75.5 - 89.7 kgf, 166 - 198 lb) At inspection 350 - 450 N (35.7 - 45.9 kgf, 78.7 - 101.2 lb) see scheme 60: Checking V-Belt Tension Belt tension (without belt tension gauge): (A) When installing new parts 7 - 9 mm (0.276 - 0.354 in) At inspection 9 - 11 mm (0.354 - 0.433 in) (B) When installing new parts 7.5 - 8.5 mm (0.295 - 0.335 in) At inspection 9.0 - 10.0 mm (0.354 - 0.394 in) see scheme 61: Checking V-Belt Tension

Scheme 240

1. Remove the V-belts. REMOVAL, V-BELT. >
2. Remove the crank pulley bolt. To lock the crankshaft, use ST. ST 499977100 CRANK PULLEY WRENCH see scheme 62: Removing Crank Pulley Bolt Using Crank Pulley Wrench ST499977100
3. Remove the crank pulley.

BELT TENSION PULLEY

1. Check the mating surfaces of timing belt and contact point of adjuster rod for abnormal wear or scratches. Replace the automatic belt tension adjuster assembly if faulty.
2. Check the belt tension pulley for smooth rotation. Replace if noise or excessive play occurs.
3. Check the belt tension pulley for grease leakage.

BELT IDLER

1. Check the belt idler for smooth rotation. Replace if noise or excessive play occurs.
2. Check the outer contacting surfaces of idler pulley for abnormal wear and scratches.
3. Check the belt idler for grease leakage.

Scheme 241

Scheme 242

1. Remove the V-belts. REMOVAL, V-BELT. >
2. Remove the crank pulley. REMOVAL, CRANK PULLEY. >
3. Remove the timing belt cover. REMOVAL, TIMING BELT COVER. >
4. Remove the timing belt. REMOVAL, TIMING BELT. >
5. Remove the camshaft position sensor. REMOVAL, Camshaft Position Sensor. >
6. Remove the cam sprocket No. 2. To lock the camshaft, use the ST. ST 18231AA010 CAM SPROCKET WRENCH NOTE: CAM SPROCKET WRENCH (499207100) can also be used. see scheme 88: Removing Cam Sprocket No 2 Using Cam Sprocket Wrench ST18231AA010
7. Remove the cam sprocket No. 1. To lock the camshaft, use the ST. ST 499207400 CAM SPROCKET WRENCH see scheme 89: Removing Cam Sprocket No 1 Using Cam Sprocket Wrench ST499207400

VALVE SEAT

Inspect the intake and exhaust valve seats, and correct the contact surfaces with a valve seat cutter if they are defective or when valve guides are replaced.

Valve seat width W

Standard

Intake (A)

0.8 - 1.4 mm (0.03 - 0.055 in) Exhaust (B)

1.2 - 1.8 mm (0.047 - 0.071 in)

Service limit

Intake (A)

1.7 mm (0.067 in)

Exhaust (B)

2.2 mm (0.087 in)

Identifying Rear Oil Seal, Crankshaft, Crankshaft Bearing And O-Ring. Scheme 243

Scheme 244

Scheme 245

Scheme 246

Scheme 247

Scheme 248

Scheme 249

Scheme 250

Scheme 251

1. Check the clearance between valve guide and stem. The clearance can be checked by measuring respectively the outer diameter of valve stem with a micrometer and the inner diameter of valve guide with a caliper gauge. Clearance between the valve guide and valve stem: Standard: Intake 0.035 - 0.062 mm (0.0014 - 0.0024 in) Exhaust 0.040 - 0.067 mm (0.0016 - 0.0026 in) Service limit: 0.15 mm (0.0059 in) see scheme 135: Checking Clearance Between Valve Guide And Stem see scheme 136: Measuring Outer Diameter Of Valve Stem With Micrometer
2. If the clearance between valve guide and stem exceeds the limit, replace the valve guide or valve itself whichever shows greater amount of wear. See the following procedure for valve guide replacement. Valve guide inner diameter: 6.000 - 6.012 mm (0.2362 - 0.2367 in) Valve stem outer diameters: Intake 5.950 - 5.965 mm (0.2343 - 0.2348 in) Exhaust 5.945 - 5.960 mm (0.2341 - 0.2346 in) Place the cylinder head on ST1 with the combustion chamber upward so that valve guides fit the holes in ST1. Insert the ST2 into valve guide and press it down to remove the valve guide. ST1 498267800 CYLINDER HEAD TABLE ST2 499767200 VALVE GUIDE REMOVER see scheme 137: Measuring Valve Guide Inner Diameter Turn the cylinder head upside down and place the ST as shown in the figure. Intake side ST 499767700 VALVE GUIDE ADJUSTER Exhaust side ST 499767800 VALVE GUIDE ADJUSTER see scheme 138: Identifying Valve Guide Before installing a new valve guide, make sure that neither scratches nor damages exist on the inner surface of valve guide holes in cylinder head. Put a new valve guide, coated with sufficient oil, in cylinder, and insert the ST1 into valve guide. Press in until the valve guide upper end is flush with the upper surface of ST2. ST1 499767200 VALVE GUIDE REMOVER Intake side ST2 499767700 VALVE GUIDE ADJUSTER Exhaust side ST2 499767800 VALVE GUIDE ADJUSTER see scheme 139: Identifying Valve Guide Adjuster ST2 499767700 And Valve Guide Remover ST1 499767200 Check the valve guide protrusion. Valve guide protrusion L: Intake 20.0 - 21.0 mm (0.787 - 0.827 in) Exhaust 16.5 - 77.5 mm (0.650 - 0.689 in) see scheme 140: Identifying Valve Guide Protrusion Ream the inside of valve guide using ST. Put the reamer in valve guide, and rotate the reamer slowly clockwise while pushing it lightly. Bring the reamer back while rotating it clockwise. After reaming, clean the valve guide to remove chips. CAUTION: Apply engine oil to the reamer when reaming. If the inner surface of the valve guide is torn, the edge of the reamer should be slightly ground with an oil stone. If the inner surface of valve guide becomes lustrous and the reamer does not chip, use a new reamer or remedy the reamer. ST 499767400 VALVE GUIDE REAMER see scheme 141: Reaming Inside Of Valve Guide Recheck the contact condition between valve and valve seat after replacing the valve guide.

Scheme 252

1. Inspect the flange and stem of valve, and replace if damaged, worn, or deformed, or if H is outside of the specified limit. H: Intake Standard: 0.8 - 1.2 mm (0.03 - 0.047 in) Limit: 0.6 mm (0.024 in) Exhaust Standard: 1.0 - 1.4 mm (0.039 - 0.055 in) Limit: 0.6 mm (0.024 in) Valve overall length: Intake 120.6 mm (4.75 in) Exhaust 121.7 mm (4.79 in) see scheme 142: Identifying Intake And Exhaust Valve Dimension
2. Put a small amount of grinding compound on the seat surface, and lap the valve seat.

Scheme 253

1. Check the valve springs for damage, free length, and tension. Replace the valve spring if it is not within the standard value presented in the table.
2. To measure the squareness of the valve spring, stand the spring on a surface plate and measure its deflection at the top of spring using a try square. VALVE SPRING FREE LENGTH AND TENSION/SPRING HEIGHT SPECIFICATION Free length mm (in) 55.2 (2.173) Tension/spring height N (kgf, lb)/mm (in) Set 235.3 - 270.7 (24 - 27.6, 52.9 - 60.8)/45.0 (1.772) Lift 578.9 - 639.9 (59.1 - 65.3, 130.3 - 143.9)/34.7 (1.366) Squareness Less than 2.5°, 2.4 mm (0.094 in) see scheme 143: Measuring Squareness Of Valve Spring

INTAKE AND EXHAUST VALVE OIL SEAL

In the following case, pinch and remove the oil seal from valve using pliers, and then replace it with a new one.

1. When the lip is damaged.
2. When the spring is out of the specified position.
3. When readjusting the surfaces of intake valve and valve sheet.
4. When replacing the intake valve guide.

1. Place the cylinder head on ST1.
2. Using the ST2, press-fit the oil seal.

ST1 498267800 CYLINDER HEAD TABLE

ST2 498857100 VALVE OIL SEAL GUIDE

Color of rubber part

Intake [Gray]

Exhaust [Green]

Scheme 254

CYLINDER BLOCK

1. Visually check for cracks and damage. Especially, inspect the important parts using liquid penetrant tester.
2. Check the oil passages for clogging.
3. Inspect the cylinder block surface that mates with cylinder head for warping by using a straight edge, and correct by grinding if necessary. Warping limit: 0.025 mm (0.00098 in) Grinding limit: 0.1 mm (0.004 in) Standard height of cylinder block: 201.0 mm (7.91 in)

Scheme 255

Scheme 256

Scheme 257

1. The cylinder bore size is stamped on the cylinder block front upper surface. NOTE: Measurement should be performed at a temperature of 20°C (68°F). Standard sized pistons are classified into two grades, "A" and "B". These grades should be used as guide lines in selecting a standard piston. Standard diameter: A: 99.505 - 99.515 mm (3.9175 - 3.9179 in) B: 99.495 - 99.505 mm (3.9171 - 3.9175 in) see scheme 194: Identifying Cylinder Bore Size Stamped On Cylinder Block Front Upper Surface
2. How to measure the inner diameter of each cylinder Measure the inner diameter of each cylinder in both the thrust and piston pin directions at the heights as shown in the figure, using a cylinder bore gauge. NOTE: Measurement should be performed at a temperature of 20°C (68°F). Taper: Standard: 0.015 mm (0.0006 in) Service limit: 0.050 mm (0.0020 in) Out-of-roundness: Standard: 0.010 mm (0.0004 in) Service limit: 0.050 mm (0.0020 in) see scheme 195: Identifying Inner Diameter Of Cylinder
3. When the piston is to be replaced due to general or cylinder wear, determine a suitable sized piston by measuring the piston clearance.
4. How to measure the outer diameter of each cylinder: Measure the outer diameter of each piston at the height as shown in the figure. (Thrust direction) NOTE: Measurement should be performed at a temperature of 20°C (68°F). Piston grade point H: 38.2 mm (1.504 in) Standard: A: 99.505 - 99.515 mm (3.9175 - 3.9179 in) B: 99.495 - 99.505 mm (3.9171 - 3.9175 in) 0.25 mm (0.0098 in) oversize: 99.745 - 99.765 mm (3.9270 - 3.9278 in) 0.50 mm (0.0197 in) oversize: 99.995 - 100.015 mm (3.9368 - 3.9376 in) see scheme 196: Measuring Outer Diameter Of Piston
5. Calculate the clearance between cylinder and piston. NOTE: Measurement should be performed at a temperature of 20°C (68°F). Cylinder to piston clearance at 20°C (68°F): Standard: -0.010 - 0.010 mm (-0.00039 - 0.00039 in) Service limit: 0.030 mm (0.0012 in)
6. Boring and honing If any of the measured value of taper, out-of-roundness or cylinder-to-piston clearance is not standard or if there is any damage on the cylinder wall, rebore it to use an oversize piston. CAUTION: When any of the cylinders needs reboring, all other cylinders must be bored at the same time, and use oversize pistons. Do not perform boring on one cylinder only. Nor use an oversize piston for one cylinder only. If the cylinder inner diameter exceeds the limit after boring and honing, replace the cylinder block. Limit of cylinder inner diameter: 100.015 mm (3.9376 in) NOTE: Immediately after reboring, the cylinder diameter may differ from its real diameter due to temperature rise. Thus, pay attention when measuring the cylinder diameter.

Scheme 258

Scheme 259

Scheme 260

1. Check the pistons and piston pins for damage, cracks and wear, and the piston ring grooves for wear and damage. Replace if faulty.
2. Measure the piston-to-cylinder clearance at each cylinder. CYLINDER AND PISTON, INSPECTION, CYLINDER BLOCK. >lf any of the clearances is not within the standard value, replace the piston and bore the cylinder to enable use of the oversize piston.
3. Make sure that the piston pin can be inserted into the piston pin hole with a thumb at 20°C (68°F). Replace if faulty. Clearance between piston hole and piston pin: Standard: 0.004 - 0.008 mm (0.0002 - 0.0003 in) Service limit: 0.020 mm (0.0008 in) see scheme 197: Measuring Inner Diameter Of Piston Hole see scheme 198: Measuring Piston Pin Diameter
4. Check the snap ring installation groove (A) on the piston for burr. If necessary, remove burr from the groove so that the piston pin can lightly move. see scheme 199: Identifying Snap Ring Installation Groove
5. Check the piston pin snap ring for distortion, cracks and wear.

Scheme 261

Scheme 262

Scheme 263

1. If the piston ring is broken, damaged or worn, or if its tension is insufficient, or when the piston is replaced, replace the piston ring with a new one of the same size as piston. CAUTION: Marks are displayed on the end of top and second rings. When installing the rings to piston, face these marks upward. Oil ring consists of the upper rail, expander and lower rail. Be careful about the direction of rail when installing the oil ring to piston. see scheme 200: Identifying Oil Rings
2. Clean the piston ring groove and piston ring.
3. Squarely place the piston ring and oil ring in cylinder, and measure the piston ring gap with a thickness gauge. PISTON RING GAP SPECIFICATION mm (in) Standard Limit Piston ring gap Top ring 0.20 - 0.35 (0.0079 - 0.0138) 1.0 (0.039) Second ring 0.37 - 0.52 (0.0144 - 0.0203) Oil ring rail 0.20 - 0.50 (0.0079 - 0.0197) 1.5 (0.059) see scheme 201: Measuring Piston Ring Gap
4. Measure the clearance between piston ring and piston ring groove with a thickness gauge. CLEARANCE SPECIFICATION BETWEEN PISTON RING AND PISTON RING GROOVE mm (in) Standard Limit Clearance between piston ring and piston ring groove Top ring 0.040 - 0.080 (0.0016 - 0.0031) 0.15 (0.059) Second ring 0.030 - 0.070 (0.0012 - 0.0028) see scheme 202: Measuring Clearance Between Piston Ring And Piston Ring Groove

Scheme 264

Scheme 265

Scheme 266

Scheme 267

1. Replace the connecting rod, if the large or small end thrust surface is damaged.
2. Check for bend or twist using a connecting rod aligner. Replace the connecting rod if the bend or twist exceeds the limit. Limit of bend or twist per 100 mm (3.94 in) in length: 0.10 mm (0.0039 in) see scheme 203: Checking Connecting Rod For Bend Or Twist
3. Install the connecting rod fitted with bearing to crankshaft and measure the side clearance (thrust clearance). Replace the connecting rod if the side clearance exceeds the specified limit. Connecting rod side clearance: Standard: 0.070 - 0.330 mm (0.0028 - 0.0130 in) Service limit: 0.4 mm (0.016 in) see scheme 204: Measuring Connecting Rod Side Clearance
4. Inspect the connecting rod bearing for scar, peeling, seizure, melting, wear, etc.
5. Measure the oil clearance on each connecting rod bearing using plastigauge. If any oil clearance is not within the standard, replace the defective bearing with a new one of standard size or under-size as necessary. (See the «CONNECTING ROD OIL CLEARANCE SPECIFICATION»(ref-274164-S27136442652007121400000) below.) Connecting rod oil clearance: Standard: 0.016 - 0.044 mm (0.00063 - 0.0017 in) Service limit: 0.05 mm (0.0020 in) BEARING THICKNESS AND CRANK PIN OUTER DIAMETER SPECIFICATION Unit: mm (in) Bearing Bearing size (Thickness at center) Outer diameter of crank pin Standard 1.492 - 1.501 (0.0587 - 0.0591) 51.984 - 52.000 (2.0466 - 2.0472) 0.03 (0.0012) Undersize 1.510 - 1.513 (0.0594 - 0.0596) 51.954 - 51.970 (2.0454 - 2.0461) 0.05 (0.0020) Undersize 1.520-1.523 (0.0598 - 0.0600) 51.934 - 51.950 (2.0446 - 2.0453) 0.25 (0.0098) Undersize 1.620 - 1.623 (0.0638 - 0.0639) 51.734 - 51.750 (2.0368 - 2.0374)
6. Inspect the bushing at connecting rod small end, and replace if worn or damaged. Also measure the piston pin clearance at connecting rod small end. Clearance between piston pin and bushing: Standard: 0 - 0.022 mm (0 - 0.0009 in) Service limit: 0.030 mm (0.0012 in) see scheme 205: Measuring Connecting Rod Small End Diameter see scheme 206: Measuring Piston Pin Diameter
7. Replacement procedure is as follows. Remove the bushing from connecting rod with ST and press. Press the bushing with ST after applying oil on the periphery of bushing. ST 499037100 CONNECTING ROD BUSHING REMOVER & INSTALLER see scheme 207: Pressing Bushing With Connecting Rod Bushing Remover & Installer ST499037100 Make two 3 mm (0.12 in) holes in bushing. Ream the inside of bushing. After completion of reaming, clean the bushing to remove chips.

Scheme 268

Scheme 269

Scheme 270

1. Clean the crankshaft completely, and check it for cracks using liquid penetrant tester. Replace if faulty.
2. Measure the bend of crankshaft. If it exceeds the limit, repair or replace it. NOTE: If a suitable V-block is not available, install #1 and #5 crankshaft bearing on cylinder block, position the crankshaft on these bearings, and then measure the crankshaft bend using a dial gauge. Crankshaft bend limit: 0.035 mm (0.0014 in) see scheme 208: Measuring Bend Of Crankshaft
3. Inspect the crank journal and crank pin for wear. If they are not within the specification, replace the bearing with a suitable (undersize) one, and replace or readjust crankshaft as necessary. When grinding the crank journal or crank pin, finish them to the specified dimensions according to the undersize bearing to be used. Crank pin Out-of-roundness: 0.003 mm (0.0001 in) Cylindricality: 0.004 mm (0.0002 in) Grinding limit: To 51.750 mm (2.0374 in) dia. Crank journal Out-of-roundness: 0.005 mm (0.0002 in) Cylindricality: 0.006 mm (0.0002 in) Grinding limit: To 59.750 mm (2.3524 in) dia. see scheme 209: Inspecting Crank Journal CRANK JOURNAL AND CRANK PIN OUTER DIAMETER SPECIFICATION Unit: mm (in) Crank journal outer diameter Crank pin outer diameter #1,#3 #2, #4, #5 Standard Journal O.D. 59.992 - 60.008 (2.3619 - 2.3625) 59.992 - 60.008 (2.3619 - 2.3625) 51.984 - 52.000 (2.0466 - 2.0472) Bearing size (Thickness at center) 1.998 - 2.011 (0.0787 - 0.0792) 2.000 - 2.013 (0.0787 - 0.0793) 1.492 - 1.501 (0.0587 - 0.0591) 0.03 (0.0012) Undersize Journal O.D. 59.962 - 59.978 (2.3607 - 2.3613) 59.962 - 59.978 (2.3607 - 2.3613) 51.954 - 51.970 (2.0454 - 2.0461) Bearing size (Thickness at center) 2.017 - 2.020 (0.0794 - 0.0795) 2.019 - 2.022 (0.0795 - 0.0796) 1.510 - 1.513 (0.0594 - 0.0596) 0.05 (0.0020) Undersize Journal O.D. 59.942 - 59.958 (2.3599 - 2.3605) 59.942 - 59.958 (2.3599 - 2.3605) 51.934 - 51.950 (2.0446 - 2.0453) Bearing size (Thickness at center) 2.027 - 2.030 (0.0798 - 0.0799) 2.029 - 2.032 (0.0799 - 0.0800) 1.520 - 1.523 (0.0598 - 0.0600) 0.25 (0.0098) Undersize Journal O.D. 59.742 - 59.758 (2.3520 - 2.3527) 59.742 - 59.758 (2.3520 - 2.3527) 51.734 - 51.750 (2.0368 - 2.0374) Bearing size (Thickness at center) 2.127 - 2.130 (0.0837 - 0.0839) 2.129 - 2.132 (0.0838 - 0.0839) 1.620 - 1.623 (0.0638 - 0.0639)
4. Measure the thrust clearance of crankshaft at center bearing. If clearance outside of standard value, replace the bearing. Crankshaft thrust clearance: Standard: 0.030 - 0.115 mm (0.0012 - 0.0045 in) Service limit: 0.25 mm (0.0098 in) see scheme 210: Measuring Thrust Clearance Of Crankshaft
5. Inspect individual crankshaft bearings for signs of flaking, seizure, melting and wear.
6. Measure the oil clearance on each crankshaft bearing using plastigauge. If the measured value is out of standard, replace the defective bearing with an undersize one, and replace or recondition the crankshaft as necessary. Crankshaft oil clearance: Standard: 0.010 - 0.030 mm (0.0004 - 0.0012 in) Service limit: 0.040 mm (0.0016 in)

Scheme 271

1. Disconnect the ground cable from battery. see scheme 211: Disconnecting Battery Ground Cable
2. Remove the air intake chamber. REMOVAL, Air Intake Chamber. >
3. Remove the engine harness connector from the bracket. see scheme 212: Identifying Engine Harness Connector
4. Disconnect the connector from the oil switching solenoid valve.
5. Remove the oil switching solenoid valve.
6. Remove the variable valve lift diagnosis oil pressure switch. REMOVAL, Variable Valve Lift Diagnosis Oil Pressure Switch. >
7. Remove the oil temperature sensor. REMOVAL, Oil Temperature Sensor. >
8. Remove the oil switching solenoid valve holder from the cylinder head. see scheme 213: Identifying Oil Temperature Sensor And Oil Switching Solenoid Valve

Scheme 272

1. Disconnect the ground cable from battery. see scheme 214: Disconnecting Battery Ground Cable
2. Remove the V-belts. REMOVAL, V-BELT. >
3. Remove the crank pulley. REMOVAL, CRANK PULLEY. >
4. Remove the timing belt cover. REMOVAL, TIMING BELT COVER. >
5. Remove the timing belt. REMOVAL, TIMING BELT. >
6. Remove the cam sprocket. REMOVAL, CAM SPROCKET. >
7. Remove the timing belt cover No. 2 (LH).
8. Disconnect the connector from the oil switching solenoid valve.
9. Remove the oil switching solenoid valve.
10. Remove the variable valve lift diagnosis oil pressure switch. REMOVAL, Variable Valve Lift Diagnosis Oil Pressure Switch. >
11. Remove the oil switching solenoid valve holder from the cylinder head. see scheme 215: Identifying Variable Valve Lift Diagnostic Oil Pressure Switch And Oil Switching Solenoid Valve

RH SIDE

Install in the reverse order of removal.

Note. Use a new gasket.

Tightening torque

T1

6.4 N.m (0.65 kgf-m, 4.7 ft-lb)

T2

10 N.m (1.0 kgf-m, 7.4 ft-lb)

Scheme 273

LH SIDE

Install in the reverse order of removal.

Note. Use a new gasket.

Tightening torque

T1

6.4 N.m (0.65 kgf-m, 4.7 ft-lb)

T2

10 N.m (1.0 kgf-m, 7.4 ft-lb)

Identifying Oil Switching Solenoid Valve Holder And Oil Switching Solenoid Valve. Scheme 274
