Engine Control System (Service Information): Overview Scion xB II рестайлинг

Testing & Diagnostics 11 illustrations ~537 words

Scheme 30

Scheme 30: ILLUSTRATION
Scheme 30: ILLUSTRATION

Scheme 31

Scheme 31: ILLUSTRATION
Scheme 31: ILLUSTRATION

Scheme 32

Scheme 32: REMOVAL
Scheme 32: REMOVAL

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35
  1. REMOVE WINDSHIELD WIPER ARM COVER. Refer to «REMOVAL - Step 1»(ref-511405-S42301251392012102600000)
  2. REMOVE FRONT WIPER ARM AND BLADE ASSEMBLY LH. Refer to «REMOVAL - Step 2»(ref-511405-S42301251392012102600000)
  3. REMOVE FRONT WIPER ARM AND BLADE ASSEMBLY RH. Refer to «REMOVAL - Step 3»(ref-511405-S42301251392012102600000)
  4. REMOVE HOOD TO COWL TOP SEAL. Refer to «REMOVAL - Step 4»(ref-511405-S42301251392012102600000)
  5. REMOVE COWL TOP VENTILATOR LOUVER RH. Refer to «REMOVAL - Step 5»(ref-511405-S42301251392012102600000)
  6. REMOVE COWL TOP VENTILATOR LOUVER LH. Refer to «REMOVAL - Step 6»(ref-511405-S42301251392012102600000)
  7. REMOVE FRONT WIPER MOTOR AND LINK. Refer to «REMOVAL - Step 7»(ref-511405-S42301251392012102600000)
  8. REMOVE OUTER COWL TOP PANEL Separate the wire harness. Remove the 10 bolts and remove the cowl top panel outer.
  9. REMOVE NO. 1 ENGINE COVER SUB-ASSEMBLY See step 2
  10. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Remove the bolt and remove the vacuum hose clamp. Disconnect the oil control valve connector. Remove the bolt and oil control valve.

Scheme 36

Scheme 36: INSPECTION
Scheme 36: INSPECTION

Scheme 37

Scheme 37
Scheme 37
  1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Measure the resistance between the terminals. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20 °C (68 °F) 6.9 to 7.9 ohms If the result is not as specified, replace the oil control valve assembly. Check the operation. Connect the positive (+) battery lead to terminal 1 and the negative (-) lead to terminal 2, and check the movement of the valve. OK Condition Specified Condition Battery positive (+) voltage applied Valve moves to the left as shown in the illustration Battery positive (+) voltage cut off Valve moves to the right as shown in the illustration If the result is not as specified, replace the oil control valve. NOTE: If the valve cannot return properly because of foreign matter intrusion, a small amount of leakage in the advanced direction may occur and a DTC may be output.

Scheme 38

Scheme 38: INSTALLATION
Scheme 38: INSTALLATION
  1. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Apply a light coat of engine oil to the O-ring on the camshaft oil control valve assembly. Install the camshaft oil control valve assembly with the bolt. Torque: 9.0 N*m (92 kgf*cm, 80 in.*lbf) Connect the camshaft oil control valve assembly connector. Install the vacuum hose clamp with the bolt. Torque: 8.5 N*m (87 kgf*cm, 75 in.*lbf)
  2. INSTALL OUTER COWL TOP PANEL Install the cowl top panel outer with the 10 bolts. Torque: 6.0 N*m (61 kgf*cm, 53 in.*lbf) Install the wire harness.
  3. INSTALL FRONT WIPER MOTOR AND LINK. Refer to «INSTALLATION - Step 2»(ref-511405-S37507933542012102600000)
  4. INSTALL COWL TOP VENTILATOR LOUVER LH. Refer to «INSTALLATION - Step 3»(ref-511405-S37507933542012102600000)
  5. INSTALL COWL TOP VENTILATOR LOUVER RH. Refer to «INSTALLATION - Step 4»(ref-511405-S37507933542012102600000)
  6. INSTALL HOOD TO COWL TOP SEAL. Refer to «INSTALLATION - Step 5»(ref-511405-S37507933542012102600000)
  7. INSTALL FRONT WIPER ARM AND BLADE ASSEMBLY LH. Refer to «INSTALLATION - Step 6»(ref-511405-S37507933542012102600000)
  8. INSTALL FRONT WIPER ARM AND BLADE ASSEMBLY RH. Refer to «INSTALLATION - Step 7»(ref-511405-S37507933542012102600000)
  9. INSTALL WINDSHIELD WIPER ARM COVER. Refer to «INSTALLATION - Step 8»(ref-511405-S37507933542012102600000)
  10. INSPECT FOR OIL LEAK
  11. INSTALL NO. 1 ENGINE COVER SUB-ASSEMBLY See step 5

Scheme 39

Scheme 39: ILLUSTRATION
Scheme 39: ILLUSTRATION

Scheme 40

Scheme 40: ILLUSTRATION
Scheme 40: ILLUSTRATION
