Smart Key System (Keyless Start) (Diagnostics - Introduction): Diagnosis Scion FR-S I

HOW TO PROCEED WITH TROUBLESHOOTING [12/2013 - ]

HINT

1. Use the following procedure to troubleshoot the smart key system (for start function).
2. *: Use the Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS CHECK HINT: In troubleshooting, confirm that the problem symptoms have been accurately identified. Preconceptions should be discarded in order to make an accurate judgment. To clearly understand what the problem symptoms are, it is extremely important to ask the customer about the problem and the conditions at the time the malfunction occurred. Gather as much information as possible for reference. Past problems that seem unrelated may also help in some cases. The following 5 items are important points for problem analysis: What Vehicle model, system name When Date, time, occurrence frequency Where Road conditions Under what conditions? Running conditions, driving conditions, weather conditions How did it happen? Problem symptoms* *: Be sure to ask the customer in detail about the following points concerning the vehicle operating conditions, environment and problem, and then check for DTCs. If the entry lock/unlock function does not operate for all doors. If the entry lock function does not operate. If the entry unlock function does not operate. If both the entry lock and unlock functions do not operate. If the wireless lock and unlock functions do not operate. If there is no power even when the engine switch is pressed [does not turn on (ACC)]. If the engine does not start with the entry ignition function. If the outside warning buzzers do not sound. If the customer attempted to start the engine by touching the electrical key to the engine switch and pressing the engine switch. If the interior warning buzzers do not sound. If the steering does not unlock. Any other details concerning the problem. If it is thought that wave interference is likely, be sure to ask the customer in detail about the following points concerning the vehicle operating conditions, environment and problem. Specific locations where the system does not operate (such as near TV towers, large video displays, wireless garage door opener systems, wireless security cameras, home security systems, etc.). Specific times when the system does not operate: Whether or not symptoms occurred immediately after purchase or only recently. Whether or not the symptoms occurred even when the key was near the vehicle (electrical key antenna). If the system does not operate only when near specific vehicles (there may be an effect from electric waves from the wireless systems of other vehicles). If the system operates intermittently. If the key is bundled together with other items. If the key is carried together with other electronic devices, such as cell phones, personal computers, portable music players, other electrical keys, etc. (keep the key at least 0.1 m (0.33 ft.) away from such items). Where the key is being kept when not in use: Whether or not the key being placed within 1 m (3.28 ft.) of items such as TVs, DVD recorders, induction cookers, rice cookers, dishwashers, modems, cell phones, personal computers, microwave ovens, desk or floor lamps, cordless telephones, etc. If there are electronic devices that transmit electric waves placed in the vehicle. When the key battery was last replaced (when the battery is low): The key battery can be checked using the "Key Low Battery" item in the Data List. Refer to «DATA LIST / ACTIVE TEST [12/2013 - ]»(ref-612241-S41627078902014042900000) . If the customer installed any optional components (theft deterrent devices, wireless fog lights, etc.) to the vehicle. NEXT: Go to next step
3. INSPECT BASIC OPERATION Inspect battery voltage. Standard voltage 11 to 14 V NOTE: If the voltage is below 11 V, recharge or replace the battery before proceeding. Check for blown fuses, open or shorted wire harnesses, improperly connected connectors and other problems in areas that can be visually inspected. NEXT: Go to next step
4. INSPECT COMMUNICATION FUNCTION OF CAN COMMUNICATION SYSTEM* Use the Techstream to check if the CAN communication system is functioning normally. Refer to «DIAGNOSIS SYSTEM [12/2013 - ]»(ref-612381-S29831877552014042900000) . RESULT Result Proceed to CAN DTC is not output A CAN DTC is output B B --> GO TO CAN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [12/2013 - ]»(ref-612381-S31527157402014042900000) A: Go to next step
5. CHECK COMMUNICATION FUNCTION OF LIN COMMUNICATION SYSTEM* Use the Techstream to check if the LIN communication system is functioning normally. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612424-S37216714312014042900000) . RESULT Result Proceed to LIN DTC is not output A LIN DTC is output B B --> GO TO LIN COMMUNICATION SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-612424-S22318455712014042900000) A: Go to next step
6. CHECK FOR DTC* Check for DTCs and note any codes that are output. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-612242-S17246768852014042900000) . RESULT Result Proceed to DTC is not output A Steering lock system DTC is output B Engine immobiliser system DTC is output C Smart key system (for Entry Function) DTC is output D Smart key system (for Start Function) DTC is output E B --> GO TO STEERING LOCK SYSTEM (DIAGNOSTIC TROUBLE CODE CHART). Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-612423-S01466921822014042900000) C --> GO TO ENGINE IMMOBILISER SYSTEM (DIAGNOSTIC TROUBLE CODE CHART). Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-612251-S22318121652014042900000) D --> GO TO SMART KEY SYSTEM (for Entry Function) (DIAGNOSTIC TROUBLE CODE CHART). Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-612241-S25643961602014042900000) E --> GO TO DIAGNOSTIC TROUBLE CODE CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-612242-S07869224502014042900000) A: Go to next step
7. PROBLEM SYMPTOMS TABLE Refer to Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE [12/2013 - ]»(ref-612242-S28340212412014042900000) . RESULT Result Proceed to Fault is not listed in the Problem Symptoms Table A Fault is listed in the Problem Symptoms Table B B --> Go to step 9 A: Go to next step
8. OVERALL ANALYSIS AND TROUBLESHOOTING* Operation Check. Refer to «OPERATION CHECK [12/2013 - ]»(ref-612242-S39700400382014042900000) . Data List/Active Test. Refer to «DATA LIST / ACTIVE TEST [12/2013 - ]»(ref-612242-S38223996292014042900000) . Terminals of ECU. Refer to «TERMINALS OF ECU [12/2013 - ]»(ref-612242-S39994939052014042900000) . NEXT: Go to next step
9. REPAIR OR REPLACE NEXT: Go to next step
10. CHECK FOR DTC* Clear the DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-612242-S17246768852014042900000) . Recheck for DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-612242-S17246768852014042900000) . HINT: Before checking for DTCs, perform the "DTC Output Confirmation Operation" procedure. RESULT Result Proceed to DTC is not output A DTC is output B B --> GO TO DIAGNOSTIC TROUBLE CODE CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-612242-S07869224502014042900000) A --> END

Scheme 9

Scheme 10

Scheme 11

1. OPERATION DESCRIPTION Entry ignition function (for Automatic Transmission): When the electrical key transmitter sub-assembly is in the detection area inside the vehicle and the brake pedal is depressed, the engine is started by pressing the engine switch. When the electrical key transmitter sub-assembly is in the detection area inside the vehicle and the brake pedal is not depressed, the power source mode is changed by pressing the engine switch. The power source mode changes in the following order every time the engine switch is pressed: off --> on (ACC) --> on (IG) --> off. After getting into the vehicle while carrying the electrical key transmitter sub-assembly when the engine switch is off, if the engine switch is pressed while not depressing the brake pedal, the power source mode changes to ACC and the entry key indicator light in the combination meter assembly blinks green. After getting into the vehicle while carrying the electrical key transmitter sub-assembly when the engine switch is off, if the brake pedal is depressed while the shift lever is in P or N*, the entry key indicator light in the combination meter assembly illuminates green. *: Only when the steering wheel is unlocked. The engine starts if the engine switch is pressed when the entry key indicator light in the combination meter assembly illuminates green. Changing the power source mode when the electrical key transmitter sub-assembly does not operate correctly due to wave interference or electrical key transmitter sub-assembly battery depletion (for Automatic Transmission): Unlock the door using the built-in mechanical key and get into the vehicle while carrying the electrical key transmitter sub-assembly. While depressing the brake pedal, hold the ornament side of the electrical key transmitter sub-assembly against the engine switch. When a buzzer sound is heard from the buzzer, release the brake pedal within 10 seconds. By pressing the engine switch while not depressing the brake pedal, the power source mode changes in the following order every time the engine switch is pressed: off --> on (IG) --> off. HINT: If the entry cancel function is set in customizing, the power source mode changes to on (ACC). Starting the engine when the electrical key transmitter sub-assembly does not operate correctly due to wave interference or electrical key transmitter sub-assembly battery depletion (for Automatic Transmission): Unlock the door using the built-in mechanical key and get into the vehicle while carrying the electrical key transmitter sub-assembly. While depressing the brake pedal with the shift lever in P, hold the ornament side of the electrical key transmitter sub-assembly against the engine switch. When a buzzer sound is heard from the buzzer and the entry key indicator light in the combination meter assembly illuminates green, press the engine switch while keeping the brake pedal depressed to start the engine. Entry ignition function (for Manual Transmission): When the electrical key transmitter sub-assembly is in the detection area inside the vehicle and the clutch pedal is depressed, the engine is started by pressing the engine switch. When the electrical key transmitter sub-assembly is in the detection area inside the vehicle and the clutch pedal is not depressed, the power source mode is changed by pressing the engine switch. The power source mode changes in the following order every time the engine switch is pressed: off --> on (ACC) --> on (IG) --> off. After getting into the vehicle while carrying the electrical key transmitter sub-assembly when the engine switch is off, if the engine switch is pressed while not depressing the clutch pedal, the power source mode changes to ACC and the entry key indicator light in the combination meter assembly blinks green. After getting into the vehicle while carrying the electrical key transmitter sub-assembly when the engine switch is off, if the clutch pedal is depressed, while the entry key indicator light in the combination meter assembly illuminates green. The engine starts if the engine switch is pressed when the entry key indicator light in the combination meter assembly illuminates green. Changing the power source mode when the electrical key transmitter sub-assembly does not operate correctly due to wave interference or electrical key transmitter sub-assembly battery depletion (for Manual Transmission): Unlock the door using the built-in mechanical key and get into the vehicle while carrying the electrical key transmitter sub-assembly. While depressing the clutch pedal, hold the ornament side of the electrical key transmitter sub-assembly against the engine switch. When a buzzer sound is heard from the buzzer, release the clutch pedal within 10 seconds. By pressing the engine switch while not depressing the clutch pedal, the power source mode changes in the following order every time the engine switch is pressed: off --> on (IG) --> off. HINT: If the entry cancel function is set in customizing, the power source mode changes to on (ACC). Starting the engine when the electrical key transmitter sub-assembly does not operate correctly due to wave interference or electrical key transmitter sub-assembly battery depletion (for Manual Transmission): Unlock the door using the built-in mechanical key and get into the vehicle while carrying the electrical key transmitter sub-assembly. While depressing the clutch pedal, hold the ornament side of the electrical key transmitter sub-assembly against the engine switch. When a buzzer sound is heard from the buzzer and the entry key indicator light in the combination meter assembly illuminates green, press the engine switch while keeping the clutch pedal depressed to start the engine.
2. CHECK ENTRY IGNITION FUNCTION Check the entry ignition function (for Automatic Transmission). With the engine switch off, move the shift lever to P, depress the brake pedal while carrying the electrical key transmitter sub-assembly and check that the entry key indicator light in the combination meter assembly illuminates green. Then, with the entry key indicator light in the combination meter assembly illuminates green, press the engine switch and check that the engine starts. With the brake pedal released and the engine switch off, press the engine switch while carrying the electrical key transmitter sub-assembly and check that the power source mode changes as follows: off --> on (ACC) --> on (IG) --> off. However, if the shift lever is in any position other than P while the engine switch is on (IG), the power source mode will not change to off, but to on (ACC). Stop the vehicle, press the engine switch and check that the power source mode changes to off (the engine stops and all electrical systems are off). However, if the shift lever is in any position other than P, even if the engine switch is pressed while the vehicle is stationary, the power source mode will not change to off, but to on (ACC). Move the shift lever to P, open the door and check that the steering lock operates. Inspect the entry ignition operating range (front floor). Place the electrical key transmitter sub-assembly on the front seat at either inspection point so that it is facing in the direction shown in the illustration and check that the engine can be started. TEXT IN ILLUSTRATION *a Inspection Point NOTE: Even if the electrical key transmitter sub-assembly is in the vehicle interior key detection area, the electrical key transmitter sub-assembly may not be properly detected if it is on the instrument panel, accessory box of the instrument panel, package tray trim panel, or in/near the front cup holder, in the glove box or on the floor. Communication may not be possible if the electrical key transmitter sub-assembly is within 0.2 m (0.66 ft.) of the shift lever. HINT: Perform the inspection for both inspection points. Inspect the entry ignition operating range (rear floor). Place the electrical key transmitter sub-assembly at either inspection point and check that the engine can be started. TEXT IN ILLUSTRATION *a Inspection Point NOTE: Even if the electrical key transmitter sub-assembly is in the vehicle interior key detection area, the electrical key transmitter sub-assembly may not be properly detected if it is on the instrument panel, accessory box of the instrument panel, package tray trim panel, or in/near the front cup holder, in the glove box or on the floor. Communication may not be possible if the electrical key transmitter sub-assembly is within 0.2 m (0.66 ft.) of the center of the rear seat cushion. HINT: Perform the inspection for both inspection points. Check the entry ignition function (for Manual Transmission). With the engine switch off, depress the clutch pedal while carrying the electrical key transmitter sub-assembly and check that the entry key indicator light in the combination meter assembly illuminates green. Then, with the entry key indicator light in the combination meter assembly illuminates green, press the engine switch and check that the engine starts. With the clutch pedal released and the engine switch off, press the engine switch while carrying the electrical key transmitter sub-assembly and check that the power source mode changes as follows: off --> on (ACC) --> on (IG) --> off. Stop the vehicle, press the engine switch and check that the power source mode changes to off (the engine stops and all electrical systems are off). Open the door and check that the steering lock operates. Inspect the entry ignition operating range (front floor). Place the electrical key transmitter sub-assembly on the front seat at either inspection point so that it is facing in the direction shown in the illustration and check that the engine can be started. TEXT IN ILLUSTRATION *a Inspection Point NOTE: Even if the electrical key transmitter sub-assembly is in the vehicle interior key detection area, the electrical key transmitter sub-assembly may not be properly detected if it is on the instrument panel, accessory box of the instrument panel, package tray trim panel, or in/near the front cup holder, in the glove box or on the floor. Communication may not be possible if the electrical key transmitter sub-assembly is within 0.2 m (0.66 ft.) of the shift lever. HINT: Perform the inspection for both inspection points. Inspect the entry ignition operating range (rear floor). Place the electrical key transmitter sub-assembly at either inspection point and check that the engine can be started. TEXT IN ILLUSTRATION *a Inspection Point NOTE: Even if the electrical key transmitter sub-assembly is in the vehicle interior key detection area, the electrical key transmitter sub-assembly may not be properly detected if it is on the instrument panel, accessory box of the instrument panel, package tray trim panel, or in/near the front cup holder, in the glove box or on the floor. Communication may not be possible if the electrical key transmitter sub-assembly is within 0.2 m (0.66 ft.) of the center of the rear seat cushion. HINT: Perform the inspection for both inspection points.
3. CHECK POWER SOURCE MODE CHANGING FUNCTION Check the engine switch. for Automatic Transmission: Check that the power source mode changes according to the chart below. Shift Position Brake Pedal Power Source Mode when Engine Switch Pressed P Released Off --> on (ACC) --> on (IG) --> off P Released Engine running --> off P Released On (ACC)*1 --> off P Depressed Off --> engine starts P Depressed On (ACC) --> engine starts P Depressed On (IG) --> engine starts P Depressed Engine running --> off P Depressed On (ACC)*1 --> off N Released Off --> on (ACC) --> on (IG) (after power source mode changes to on [IG], power source mode changes between on [IG] and on [ACC] every time engine switch is pressed) N Released Engine running --> on (ACC) N Depressed Off --> engine starts*2 N Depressed On (ACC) --> engine starts*2 N Depressed On (IG) --> engine starts*2 N Depressed Engine running --> on (ACC) Not P or N Released Off --> on (ACC) --> on (IG) (after power source mode changes to on [IG], power source mode changes between on [IG] and on [ACC] every time engine switch is pressed) Not P or N Released Engine running --> on (ACC) Not P or N Depressed Off --> on (IG) Not P or N Depressed On (ACC) --> on (IG) Not P or N Depressed Engine running --> on (ACC) HINT: *1: This situation is only applicable when the power source mode has changed from on (IG) to on (ACC) (Excludes an emergency stop by pressing the engine switch 3 times quickly or pressing and holding the engine switch for 2 seconds or more). *2: Only when the steering lock is unlocked. for Manual Transmission: Check that the power source mode changes according to the chart below. Clutch pedal Power Source Mode when Engine Switch Pressed Released Off --> on (ACC) --> on (IG) --> off Released Engine running --> off Depressed Off --> engine starts Depressed On (ACC) --> engine starts Depressed On (IG) --> engine starts Depressed Engine running --> off
4. CHECK POWER SOURCE MODE INDICATION Check the entry key indicator. INDICATOR INSPECTION Engine Switch Indicator Off (Excludes condition in which engine can be started) Off On (ACC) (Excludes condition in which engine can be started) Blinking in green On (IG) (Excludes condition in which engine can be started) Blinking in green Condition in which engine can be started* and shift lever is in P Illuminated in green Engine started Off HINT: for Automatic Transmission *: CONDITION IN WHICH ENGINE CAN BE STARTED IS AS FOLLOWS: The engine can be started by pressing the engine switch when either of the following conditions are met. Condition 1 All conditions are met: The power source mode has changed from on (IG) to on (ACC). The key is verified* or the Engine immobiliser unset (engine switch on (ACC) or on (IG)) The shift lever is in N (steering lock is unlocked). The stop light switch is on. Condition 2 All conditions are met: The power source mode has not changed from on (IG) to on (ACC). The key is verified* or the Engine immobiliser unset (engine switch on (ACC) or on (IG)) The shift lever is in P or N. The stop light switch is on. for Manual Transmission The engine can be started by pressing the engine switch when the following conditions are met. Condition All conditions are met: The key is verified* or the engine switch is on (ACC) or on (IG). The clutch start switch is on. *: When the electrical key transmitter sub-assembly is in the vehicle, the ID code sent as a result from communication between the electrical key transmitter sub-assembly and certification ECU (smart key ECU assembly) and the ID code calculated by the certification ECU (smart key ECU assembly) are compared. If the ID codes match each other, the vehicle recognizes that the electrical key transmitter sub-assembly is in the vehicle. Indicator Condition Chart Indicator Vehicle State Off Either condition is met: The engine is running. The engine switch is off and the vehicle is in a state in which the engine does not start if the engine switch is pressed. Illuminated in green All conditions below are met and the vehicle is in a state in which the engine can be started if the engine switch is pressed: The electrical key transmitter sub-assembly is inside the vehicle, the stop light switch assembly*1 or clutch start switch assembly*2 is on and the shift lever is in P*1. Blinking in green (blinking slowly) The engine switch is on (ACC) or on (IG), and the vehicle is in a state in which the engine does not start if the engine switch is pressed. Blinking in green (blinking rapidly) When the power is being turned on or the engine is being started, the steering fails to unlock (steering lock is stuck). The indicator starts blinking when the steering fails to unlock. The indicator stops blinking when 30 seconds elapse after blinking starts, or when the power is being turned on or the engine is being started again. Blinking in orange The steering lock ECU has an internal malfunction. The indicator starts blinking when the steering lock ECU or certification ECU (smart key ECU assembly) is determined to have an internal malfunction. The indicator stops blinking when the ECU returns to normal or 15 seconds elapse after blinking starts. *1: for Automatic Transmission *2: for Manual Transmission HINT: The engine can be started up with the shift lever in N only when the steering wheel is unlocked. (for Automatic Transmission)

PROBLEM SYMPTOMS TABLE [12/2013 - ]

HINT

1. Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
2. Inspect the fuses and relays related to the system before inspecting the suspected areas below.

SMART KEY SYSTEM

DIAGNOSIS SYSTEM [12/2013 - ]

1. DESCRIPTION Smart key system (for start function) data and the Diagnostic Trouble Codes (DTCs) can be read through the Data Link Connector 3 (DLC3) of the vehicle. When the system seems to be malfunctioning, use the Techstream to check for malfunctions and perform repairs.
2. CHECK DLC3 Check DLC3. Refer to «GENERAL INFORMATION [07/2013 - ]»(ref-612229-S35930398492014042900000) .
3. INSPECT BATTERY VOLTAGE If the voltage is below 11 V, recharge or replace the battery before proceeding. Standard voltage 11 to 14 V

DTC CHECK / CLEAR [12/2013 - ]

Note. When using the Techstream with the vehicle engine switch off, connect the Techstream to the vehicle and turn a courtesy light switch on and off at intervals of 1.5 seconds or less until communication between the Techstream and the vehicle begins. Then select the vehicle type under manual mode and enter the following menus: Body Electrical / Smart Key. While using the Techstream, periodically turn a courtesy light switch on and off at intervals of 1.5 seconds or less to maintain communication between the Techstream and the vehicle.

1. CHECK DTC (POWER SOURCE CONTROL) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Power Source Control / Trouble Codes. Check for DTCs. HINT: Refer to the Techstream operator's manual for further details.
2. CHECK DTC (SMART KEY) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Smart Key / Trouble Codes. Check for DTCs. HINT: Refer to the Techstream operator's manual for further details.
3. CHECK DTC (ENGINE) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. HINT: Refer to the Techstream operator's manual for further details.
4. CLEAR DTC (POWER SOURCE CONTROL) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Power Source Control / Trouble Codes. Clear the DTCs by following the directions on the Techstream display. HINT: Refer to the Techstream operator's manual for further details.
5. CLEAR DTC (SMART KEY) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Smart Key / Trouble Codes. Clear the DTCs by following the directions on the Techstream display. HINT: Refer to the Techstream operator's manual for further details.
6. CLEAR DTC (ENGINE) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Clear the DTCs by following the directions on the Techstream display. HINT: Refer to the Techstream operator's manual for further details.

Scheme 12

Scheme 13

Scheme 14

Scheme 15

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / (desired system) / Data List. According to the display on the Techstream, read the Data List. POWER SOURCE CONTROL Tester Display Measurement Item/Range Normal Condition Diagnostic Note Shift P Signal*1 Shift position (P) / OFF or ON OFF: Shift lever not in P ON: Shift lever in P Use this item to determine if the shift position switch is malfunctioning. Steering Unlock Switch State of steering unlock sensor signal output from steering lock ECU (steering lock actuator assembly) / OFF or ON OFF: Steering locked ON: Steering unlocked When the shift lever is in P*1 and the engine switch is off, if any door is opened or closed, the steering is locked. When the key is inside the vehicle and the engine switch is turned on (ACC) or on (IG), the steering unlocks. The engine cannot be started when the steering unlock signal is off. Stop Light Switch1*1 State of brake pedal / OFF or ON OFF: Brake pedal released ON: Brake pedal depressed Use this item to determine whether the stop light switch is malfunctioning. The engine cannot be started when this item is "OFF". When this item is malfunctioning, the engine can be started by pressing and holding the engine switch for a certain period of time. Start Switch1 Condition of engine switch contact 1 / OFF or ON OFF: Engine switch not pressed ON: Engine switch pressed If the engine switch is pressed for a short time, the display may not change. Use this item to determine whether the engine switch input signal is malfunctioning. Start Switch2 Condition of engine switch contact 2 / OFF or ON OFF: Engine switch not pressed ON: Engine switch pressed Backup for engine switch 1. However, when the engine switch is pressed and held, the control functions only when both engine switch 1 and 2 are normal. Behaves the same way as engine switch 1. Neutral SW/ Clutch SW*1 Shift position (P, N) / OFF or ON OFF: Shift lever not in P or N ON: Shift lever in P or N Use this item to help determine if the park/neutral position switch is malfunctioning. The engine cannot be started when this item is "OFF". Neutral SW/ Clutch SW*2 State of clutch pedal / OFF or ON OFF: clutch pedal released ON: clutch pedal depressed Use this item to help determine if the clutch position switch is malfunctioning. The engine cannot be started when this item is "OFF". Latch Circuit Condition of IG related backup circuit (IG hold circuit) / OFF or ON OFF: Engine switch off ON: Engine switch on (IG) Displays in almost the same manner as the IG1 and IG2 relays. When the engine switch is on (ACC), OFF is displayed. IG1 Relay Monitor(Outside) IG1 relay coil voltage monitor status / OFF or ON OFF: IG1 relay off ON: IG1 relay on Use this item to determine whether the IG1 relay is malfunctioning. When the engine switch is on (ACC), OFF is displayed. IG1 Relay Monitor(Inside) IG1 relay activation / OFF or ON OFF: IG1 relay off ON: IG1 relay on Use this item to determine whether the IG1 relay is malfunctioning. When the engine switch is on (ACC), OFF is displayed. IG2 Relay Monitor(Outside) IG2 relay coil voltage monitor status / OFF or ON OFF: IG2 relay off ON: IG2 relay on Use this item to determine whether the IG2 relay is malfunctioning. When the engine switch is on (ACC), OFF is displayed. IG2 Relay Monitor(Inside) IG2 relay activation / OFF or ON OFF: IG2 relay off ON: IG2 relay on Use this item to determine whether the IG2 relay is malfunctioning. When the engine switch is on (ACC), OFF is displayed. Starter Request Signal Condition of engine start command signal / OFF or ON OFF: Engine switch released after approximately 1 second elapses ON: Engine switch pressed and held while carrying electrical key transmitter sub-assembly with shift lever in P*1 and brake pedal*1 or clutch pedal*2 depressed When the engine cannot be started due to a start request signal malfunction, OFF is displayed. When the engine switch is pressed, the duration of time that ON is displayed will be extremely short. As such, the engine switch needs to be pressed and held for a certain amount of time. ACC Relay Monitor ACC relay activation / OFF or ON OFF: ACC relay off ON: ACC relay on When the engine switch is on (IG), ON is displayed. While the engine is cranking, OFF is displayed. ACC Relay Cut Signal ACC relay cut signal / OFF or ON OFF: ACC relay on ON: ACC relay off - Engine Condition Condition of engine / Stop or Run Run: Engine running Stop: Engine stopped - Vehicle Speed Signal Vehicle moving or stationary / Stop or Run Run: Vehicle moving at 5 km/h (3 mph) or more Stop: Vehicle stopped - Power Supply Condition State of power supply / All OFF, IG1 ON or ACC ON, IG2 ON, ST ON, All OFF: Engine switch off (ACC and IG) ACC ON: Engine switch on (ACC) IG1 ON: Engine switch on (IG) (IG1 relay on) IG2 ON: Engine switch on (IG) (IG2 relay on) ST ON: Sending engine start request signal Since IG1 ON and IG2 ON turn on at approximately the same time, IG1 ON may not be displayed (IG1 ON turns on for a very short time). Powertrain Type Vehicle identification / HV-AT, Cnv-MT, Cnv-AT, Cnv-MMT, S&S-MT, S&S-AT, S&S-MMT Cnv-MT: Conventional M/T (M/T vehicle not equipped with hybrid system) Cnv-AT: Conventional CVT (CVT vehicle not equipped with hybrid system) Cnv-MMT: Conventional MMT (MMT vehicle not equipped with hybrid system) S&S-MT: Stop and start M/T (M/T vehicle not equipped with hybrid system) S&S-AT: Stop and start CVT (CVT vehicle not equipped with hybrid system) - IG1 Circuit IG1 relay coil circuit malfunction / OK or NG OK: Circuit normal NG: Circuit malfunctioning Use this item when determining whether the IG1 relay is malfunctioning. When the engine cannot be started due to an IG1 relay malfunction, OFF is displayed. IG2 Circuit IG2 relay coil circuit malfunction / OK or NG OK: Circuit normal NG: Circuit malfunctioning Use this item when determining whether the IG2 relay is malfunctioning. When the engine cannot be started due to an IG2 relay malfunction, NG is displayed. Starter SW Sig Mismatch Engine switch signal 1 and 2 do not match / No or Yes No: Switch normal Yes: Switch malfunctioning (engine switch signal 1 and 2 do not match) The engine can be started even if the result is Yes. However, emergency engine off while driving by pressing and holding the engine switch and, when the brakes are malfunctioning, emergency engine starting by pressing and holding the engine switch cannot be performed. Park Signal Mismatch*1 Shift position (P) signal malfunction / No or Yes No: Signal normal Yes: Signal malfunction (CAN communication and direct line signal do not match) Even when Yes is displayed, it is still possible to turn the engine switch off (the power source mode will not be stuck in on (ACC) or on (IG)). Str Lock/Unlock Wait T-Out Steering lock or unlock malfunction / No or Yes No: Lock and unlock normal Yes: Lock or unlock malfunction (e.g. steering lock is stuck etc.) When the engine cannot be started due to a steering lock or unlock malfunction, Yes is displayed. Key Certif Wait T-Out Key verification malfunction / No or Yes No: Verification normal Yes: Verification error (detected due to the electrical key transmitter sub-assembly ID code and the ID code stored in the certification ECU (smart key ECU assembly) not matching) When the engine cannot be started due to a key verification error, Yes is displayed. Number of Diagnosis Code Number of DTCs / 0 to 255 - - *1: for Automatic Transmission *2: for Manual Transmission Data List Display During Engine Switch Operation (for Automatic Transmission) HINT: To check if the Data List display changes, get into the vehicle while carrying an electrical key transmitter sub-assembly and perform the following operations with the engine switch off and the shift lever in P. *1: Without depressing the brake pedal, press the engine switch and check that the power source mode turns on (ACC). *2: Without depressing the brake pedal, press the engine switch and check that the power source mode turns on (IG). *3: Depress the brake pedal (the stop light switch turns on). *4: With the brake pedal depressed, press the engine switch and check that the engine starts. *5: Press the engine switch and check that the power source mode turns off. *6: Release the brake pedal. *7: Open a door. Data List Display During Engine Switch Operation (for Manual Transmission) HINT: To check if the Data List display changes, get into the vehicle while carrying an electrical key transmitter sub-assembly and perform the following operations with the engine switch off. *1: Without depressing the clutch pedal, press the engine switch and check that the power source mode turns on (ACC). *2: Without depressing the clutch pedal, press the engine switch and check that the power source mode turns on (IG). *3: Depress the clutch pedal (the clutch start switch turns on). *4: With the clutch pedal depressed, press the engine switch and check that the engine starts. *5: Press the engine switch and check that the power source mode turns off. *6: Release the clutch pedal. *7: Open a door. SMART KEY Tester Display Measurement Item/Range Normal Condition Diagnostic Note Ignition Switch Certification ECU (smart key ECU assembly) IG power supply input status / OFF or ON OFF: Engine switch off ON: Engine switch on (IG) When the engine switch is on (ACC), OFF is displayed. #Codes Number of DTCs / 0 to 255 - - Immobiliser Engine immobiliser system determined by certification ECU (smart key ECU assembly) / Set or Unset Set: Engine immobiliser set (engine start prohibited) (engine switch off) Unset: Engine immobiliser unset (engine start permitted) (engine switch on (ACC) or on (IG)) When the immobiliser cannot be unset, this item can be used to determine whether the certification ECU (smart key ECU assembly) is part of the problem. The engine cannot be started when this item displays "Set" Steering Lock Sleep Cond Steering lock ECU (steering lock actuator assembly) sleep condition / No or Yes No: Sleep not available Yes: Sleep available - Steering Lock Start Cond Steering lock ECU (steering lock actuator assembly) wake up signal status / No or Yes No: Wake up signal not sent Yes: Wake up signal sent - Sensor Value History of malfunction of position sensor in steering lock ECU (steering lock actuator assembly) / OK or NG(Past) OK: History of malfunction for the lock or unlock sensor in the steering lock ECU (steering lock actuator assembly) does not exist. NG(Past): History of both the lock and unlock sensors in the steering lock ECU (steering lock actuator assembly) being on exists (Under normal operation, neither sensor is on). When this item displays "NG", the sensor inside the steering lock ECU (steering lock actuator assembly) may be malfunctioning, or there may be a mechanical malfunction. Power Supply Short History of signal error (short) sent from certification ECU (smart key ECU assembly) to steering lock ECU (steering lock actuator assembly) / OK or NG (Past) OK: History of motor power source short does not exist NG (Past): History of motor power source short exists This item displays history when a malfunction exists in the circuit between the certification ECU (smart key ECU assembly) and the steering lock ECU (steering lock actuator assembly). Motor Driver Short History of malfunction (short) in the steering lock ECU (steering lock actuator assembly) motor circuit (DTC B2781 is stored) / OK or NG (Past) OK: History of short in the motor circuit does not exist NG (Past): History of short in the motor circuit exists History of a malfunction in the steering lock motor circuit in the steering lock ECU (steering lock actuator assembly). Lock/Unlock Receive History of receiving an unlock request signal / No or Yes No: History of receiving an unlock request signal does not exist Yes: History of receiving an unlock request signal exists - Lock Bar Stuck Error History of the steering wheel not being able to unlock properly when the steering lock operates for a certain amount of time / OK or NG (Past) OK: History of steering lock being stuck does not exist NG (Past): History of steering lock being stuck exists - Push Start Error History of push start malfunction due to steering lock ECU (steering lock actuator assembly) / OK or NG (Past) OK: History of push start malfunction does not exist NG (Past): History of push start malfunction exists - CPU Error Status of steering lock ECU (steering lock actuator assembly) /OFF or ON ON: Steering lock ECU (steering lock actuator assembly) is malfunction OFF: Steering lock ECU (steering lock actuator assembly) is normal - Engine Start Request Status of engine start permission signal determined by steering lock ECU (steering lock actuator assembly) and sent to certification ECU (smart key ECU assembly) / OK or NG OK: Signal received NG: Signal not received When this item displays "OK", the certification ECU (smart key ECU assembly) has received an unlock confirmation signal from the steering lock ECU (steering lock actuator assembly) and has permitted fuel injection and engine combustion. The engine cannot be started when this item displays "NG". S Code Check*1 Verification result between certification ECU (smart key ECU assembly) and ID code box (immobiliser code ECU) / OK or NG OK: Verification result normal NG: Verification result abnormal When NG is displayed: S code has not been registered for the certification ECU (smart key ECU assembly) or ID code box (immobiliser code ECU). Steering wheel cannot be locked. Steering wheel cannot be unlocked (the engine cannot be started). L Code Check Verification result between ID code box (immobiliser code ECU)*1 or certification ECU (smart key ECU assembly)*2 and steering lock ECU (steering lock actuator assembly) / OK or NG OK: Verification result normal NG: Verification result abnormal When NG is displayed: L code has not been registered for the ID code box (immobiliser code ECU)*1 or certification ECU (smart key ECU assembly)*2 or steering lock ECU (steering lock actuator assembly). Steering wheel cannot be locked. Steering wheel cannot be unlocked (the engine cannot be started). Unlock Request Receive Unlock request signal received state / OK or NG HINT: The reception state is maintained for 10 seconds. When 10 seconds or more elapse after receiving the signal, the item changes to "NG". OK: Within 10 seconds of turning the engine switch on (IG) or on (ACC), or of an engine start operation being performed NG: Engine switch on (IG) or on (ACC), or engine start operation not performed The engine cannot be started when an unlock request signal cannot be received. If Received (10 seconds) is not displayed even though the steering unlock conditions are met, the certification ECU (smart key ECU assembly) may be malfunctioning. Lock Request Receive Lock request signal received state / OK or NG HINT: The reception state is maintained for 10 seconds. When 10 seconds or more elapse after receiving the signal, the item changes to "NG". OK: Lock request signal received for 10 sec. of any of the doors being opened with shift lever in P and engine switch off. NG: Except above If Received (10 s) is not displayed even though the steering lock conditions are met, the certification ECU (smart key ECU assembly) may be malfunctioning. S Code Check(Past)*1 Verification result between certification ECU (smart key ECU assembly) and ID code box (immobiliser code ECU) (Past) / OK or NG(Past) OK: History of abnormal verification result does not exist NG(Past): History of abnormal verification result exists - L Code Check(Past) Verification result history between the ID code box (immobiliser code ECU)*1 or certification ECU (smart key ECU assembly)*2 and steering lock ECU (steering lock actuator assembly) / OK or NG(Past) OK: History of abnormal verification result does not exist NG(Past): History of abnormal verification result exists - *1: w/ ID Code Box *2: w/o ID Code Box HINT: To check if the Data List display changes, get into the vehicle while carrying an electrical key transmitter sub-assembly and perform the following operations with the engine switch off and the shift lever in P. *1: Without depressing the brake pedal*5 or clutch pedal*6, press the engine switch and check that the power source mode turns on (ACC). *2: Without depressing the brake pedal*5 or clutch pedal*6, press the engine switch and check that the power source mode turns on (IG). *3: Press the engine switch and check that the power source mode turns off. *4: Release the brake pedal*5 or clutch pedal*6, open the driver side door and check that the steering locks. *5: for Automatic Transmission *6: for Manual Transmission ENGINE Tester Display Measurement Item/Range Normal Condition Diagnostic Note Engine Speed Engine speed / 0 to 16383 r/min Fluctuates in accordance with engine speed - Starter Signal Starter request signal monitor / OFF or ON OFF: Starting control switch off ON: Starting control switch on When malfunctioning, the engine will not crank. Starter Control Starter activation request / OFF or ON OFF: Starter activation not requested ON: Starter activation requested When malfunctioning, the engine will not crank. Shift SW Status (P Range)* Condition of park/neutral position switch / OFF or ON OFF: Shift lever not in P ON: Shift lever in P When malfunctioning, the engine will not crank. Shift SW Status (N Range)* Condition of park/neutral position switch / OFF or ON OFF: Shift lever not in N ON: Shift lever in N When malfunctioning, the engine will not crank. Starter Relay Starter relay voltage monitor / OFF or ON OFF: ST relay off ON: ST relay on OFF is displayed when the engine cannot crank. ST1 Stop light switch assembly status / OFF or ON OFF: Brake pedal released ON: Brake pedal depressed - Ignition Status IG2 status / OFF or ON OFF: IG2 relay off ON: IG2 relay on - # Codes (Include History) Number of DTCs / 0 to 255 - - *: for Automatic Transmission HINT: *: With the engine switch on (IG), the shift lever in P*1 or N*1and the brake pedal*1 or clutch pedal*2 depressed, press the engine switch and check that the engine starts. *1: for Automatic Transmission *2: for Manual Transmission Enter the following menus: Chassis / ABS/VSC/TRC / Data List. ABS/VSC/TRC Tester Display Measurement Item/Range Normal Condition Diagnostic Note Vehicle Speed Vehicle speed/Min.: 0 km/h (0 mph), Max.: 326.4 km/h (202 mph) Almost same as actual vehicle speed
2. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / (desired system) / Active Test. According to the display on the Techstream, perform the Active Test. POWER SOURCE CONTROL Tester Display Test Part Control Range Diagnostic Note P Supply for Steering Lock Certification ECU (smart key ECU assembly) OFF/ON HINT: OFF: Power is not supplied. ON: Power is supplied. When performing this Active Test, make sure the following condition is met: The engine switch is on (IG). SMART KEY Tester Display Test Part Control Range Diagnostic Note Power/Engine SW Light Engine switch light OFF/ON When performing this Active Test, make sure the following condition is met: The engine switch illumination is off (15 seconds or more have elapsed since it turned from on to off) and the engine switch is on (ACC) or on (IG), or the engine is running.

DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]
