Lighting System (Interior) (Diagnostics & Circuit Tests): Diagnosis Scion FR-S I

HOW TO PROCEED WITH TROUBLESHOOTING [07/2013 - 12/2013]

HINT

1. Use the following procedure to troubleshoot the lighting system.
2. *: Use the Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS AND SYMPTOM CHECK NEXT: Go to next step
3. INSPECT BATTERY VOLTAGE Measure the battery voltage with the ignition switch off. Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding to the next step. NEXT: Go to next step
4. PROBLEM SYMPTOMS TABLE RESULT Result Proceed to Fault is not listed in Problem Symptoms Table. A Fault is listed in Problem Symptoms Table. B B --> Go to step 6 A: Go to next step
5. OVERALL ANALYSIS AND TROUBLESHOOTING* Data List / Active Test. Refer to «DATA LIST / ACTIVE TEST [07/2013 - 12/2013]»(ref-612235-S29546595192014042900000) Terminals of ECU. Refer to «TERMINALS OF ECU [07/2013 - 12/2013]»(ref-612235-S06669705942014042900000) NEXT: Go to next step
6. ADJUST, REPAIR OR REPLACE NEXT: Go to next step
7. CONFIRMATION TEST NEXT --> END

HOW TO PROCEED WITH TROUBLESHOOTING [12/2013 - ]

HINT

1. Use the following procedure to troubleshoot the lighting system.
2. *: Use the Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS AND SYMPTOM CHECK NEXT: Go to next step
3. INSPECT BATTERY VOLTAGE Measure the battery voltage with the ignition switch off. Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding to the next step. NEXT: Go to next step
4. CHECK VEHICLE SPECIFICATIONS Check the vehicle specifications. RESULT Result Proceed to w/ Smart Key System A w/o Smart Key System B B --> Go to step 6 A: Go to next step
5. INSPECT CAN COMMUNICATION SYSTEM* Use the Techstream to check if the CAN communication system is functioning normally. RESULT Result Proceed to CAN communication system DTC is not output. A CAN communication system DTC is output. B B --> GO TO CAN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [12/2013 - ]»(ref-612381-S31527157402014042900000) A: Go to next step
6. PROBLEM SYMPTOMS TABLE RESULT Result Proceed to Fault is not listed in Problem Symptoms Table. A Fault is listed in Problem Symptoms Table. B B --> Go to step 8 A: Go to next step
7. OVERALL ANALYSIS AND TROUBLESHOOTING* Data List / Active Test. Refer to «DATA LIST / ACTIVE TEST [12/2013 - ]»(ref-612235-S36119918572014042900000) Terminals of ECU. Refer to «TERMINALS OF ECU [12/2013 - ]»(ref-612235-S08427253492014042900000) NEXT: Go to next step
8. ADJUST, REPAIR OR REPLACE NEXT: Go to next step
9. CONFIRMATION TEST NEXT --> END

PROBLEM SYMPTOMS TABLE [07/2013 - 12/2013]

HINT

Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.

ILLUMINATED ENTRY SYSTEM (INTERIOR LIGHT CONTROL)

MAP LIGHT

BATTERY SAVING CONTROL

IGNITION KEY CYLINDER LIGHT

LUGGAGE COMPARTMENT ROOM LIGHT

PROBLEM SYMPTOMS TABLE [12/2013 - ]

HINT

Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.

ILLUMINATED ENTRY SYSTEM (INTERIOR LIGHT CONTROL)

1. *1: w/ Smart Key System
2. *2: w/o Smart Key System

MAP LIGHT

BATTERY SAVING CONTROL

1. *1: w/ Smart Key System

IGNITION KEY CYLINDER LIGHT

1. *1: w/o Smart Key System

LUGGAGE COMPARTMENT ROOM LIGHT

Scheme 11

1. CHECK INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY AND MAIN BODY ECU (NETWORK GATEWAY ECU) TEXT IN ILLUSTRATION *1 Instrument Panel Junction Block Assembly *2 Main Body ECU (Network Gateway ECU) Disconnect the 3A, 3C, 3E, A73 and D6 instrument panel junction block assembly and main body ECU (network gateway ECU) connectors. Measure the voltage according to the value(s) in the table below. Terminal No. Wiring Color Terminal Description Condition Specified Condition 3A-15 - Body ground W - Body ground IG power supply Ignition switch ON 11 to 14 V Ignition switch off Below 1 V 3A-20 - Body ground SB - Body ground ACC power supply Ignition switch ACC 11 to 14 V Ignition switch off Below 1 V 3A-27 - Body ground G-R - Body ground Battery power supply Always 11 to 14 V 3C-19 - Body ground L-R - Body ground Battery power supply Always 11 to 14 V 3E-1 - Body ground B-R - Body ground Battery power supply Always 11 to 14 V If the result is not as specified, there may be a malfunction in the wire harness. Measure the resistance according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition 3A-12 - Body ground B - Body ground Ground Always Below 1 ohms 3A-13 - Body ground B - Body ground Ground Always Below 1 ohms A73-4 (GND) - Body ground B-Y - Body ground Ground Always Below 1 ohms D6-1 (GND) - Body ground B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the 3A, 3C, 3E, A73 and D6 instrument panel junction block assembly and main body ECU (network gateway ECU) connectors. Measure the voltage and check for pulses according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition 3A-28 - Body ground V - Body ground Front door courtesy light switch LH input Front door LH open Below 1 V Front door LH closed 11 to 14 V 3B-13 - Body ground GR - Body ground Front door courtesy light switch RH input Front door RH open Below 1 V Front door RH closed 11 to 14 V 3D-26 - Body ground SB - Body ground Luggage compartment door courtesy light switch input Luggage compartment door open Below 1 V Luggage compartment door closed 11 to 14 V D5-7 (DOMR) - Body ground L - Body ground Illuminated entry drive output (to map light assembly) Map light switch in DOOR position and map light assembly on Below 1 V Map light switch in DOOR position and map light assembly off 11 to 14 V D5-28 (ILL) - Body ground Y - Body ground Ignition key cylinder light drive output Ignition switch off, ignition key cylinder light off (when operated by illuminated entry system) 11 to 14 V Ignition switch off, ignition key cylinder light on (when operated by illuminated entry system) Below 1 V If the result is not as specified, the main body ECU (network gateway ECU) or instrument panel junction block assembly may have a malfunction.

Scheme 12

1. CHECK INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY AND MAIN BODY ECU (NETWORK GATEWAY ECU) TEXT IN ILLUSTRATION *1 Instrument Panel Junction Block Assembly *2 Main Body ECU (Network Gateway ECU) Disconnect the D5 main body ECU (network gateway ECU) connector. Measure the voltage according to the value(s) in the table below. Terminal No. Wiring Color Terminal Description Condition Specified Condition D5-22 (ACC)*1 - Body ground W - Body ground ACC power supply Ignition switch ACC 11 to 14 V Ignition switch off Below 1 V *1: w/ Smart Key System Disconnect the 3A, 3C, 3E, A73 and D6 instrument panel junction block assembly and main body ECU (network gateway ECU) connectors. Measure the voltage according to the value(s) in the table below. Terminal No. Wiring Color Terminal Description Condition Specified Condition 3A-15 - Body ground W - Body ground IG power supply Ignition switch ON 11 to 14 V Ignition switch off Below 1 V 3A-20 - Body ground SB - Body ground ACC power supply Ignition switch ACC 11 to 14 V Ignition switch off Below 1 V 3A-27 - Body ground G-R - Body ground Battery power supply Always 11 to 14 V 3C-19 - Body ground L-R - Body ground Battery power supply Always 11 to 14 V 3E-1 - Body ground B-R - Body ground Battery power supply Always 11 to 14 V If the result is not as specified, there may be a malfunction in the wire harness. Measure the resistance according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition 3A-12 - Body ground B - Body ground Ground Always Below 1 ohms 3A-13 - Body ground B - Body ground Ground Always Below 1 ohms A73-4 (GND) - Body ground B-Y - Body ground Ground Always Below 1 ohms D6-1 (GND) - Body ground B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the 3A, 3C, 3E, A73 and D6 instrument panel junction block assembly and main body ECU (network gateway ECU) connectors. Measure the voltage and check for pulses according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition 3A-28 - Body ground V - Body ground Front door courtesy light switch LH input Front door LH open Below 1 V Front door LH closed 11 to 14 V 3B-13 - Body ground GR - Body ground Front door courtesy light switch RH input Front door RH open Below 1 V Front door RH closed 11 to 14 V 3D-26 - Body ground SB - Body ground Luggage compartment door courtesy light switch input Luggage compartment door open Below 1 V Luggage compartment door closed 11 to 14 V D5-7 (DOMR) - Body ground L - Body ground Illuminated entry drive output (to map light assembly) Map light switch in DOOR position and map light assembly on Below 1 V Map light switch in DOOR position and map light assembly off 11 to 14 V D5-28 (ILL)*2 - Body ground Y - Body ground Ignition key cylinder light drive output Ignition switch off, ignition key cylinder light off (when operated by illuminated entry system) 11 to 14 V Ignition switch off, ignition key cylinder light on (when operated by illuminated entry system) Below 1 V D6-11 (LSFD)*1 - Body ground W - Body ground Front door unlock detection switch LH input Ignition switch off, all doors closed and front door LH locked Pulse generation Front door LH unlocked Below 1 V D6-12 (LSFP)*1 - Body ground SB - Body ground Front door unlock detection switch RH input Ignition switch off, all doors closed and front door RH locked Pulse generation Front door RH unlocked Below 1 V *1: w/ Smart Key System *2: w/o Smart Key System If the result is not as specified, the main body ECU (network gateway ECU) or instrument panel junction block assembly may have a malfunction.
2. CHECK CERTIFICATION ECU (SMART KEY ECU ASSEMBLY) Disconnect the D41 and D48 certification ECU (smart key ECU assembly) connectors. Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D48-2 (+B) - D48-11 (GND) R - B +B power supply Always 9.5 to 16 V If the result is not as specified, there may be a malfunction in the wire harness. Measure the resistance according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D48-11 (GND) - Body ground B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the D41 and D48 certification ECU (smart key ECU assembly) connectors. Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D41-16 (SWIL) - D41-24 (AGND) LG - B Engine switch illumination drive output Engine switch illumination on 11 to 14 V Engine switch illumination off Below 1 V If the result is not as specified, the certification ECU (smart key ECU assembly) may have a malfunction.

DATA LIST / ACTIVE TEST [07/2013 - 12/2013]

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the following table, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Enter the following menus: Body Electrical / Main Body / Data List. Read the Data List according to the display on the Techstream. MAIN BODY Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door Courtesy SW Driver side door courtesy light switch signal/ON or OFF ON: Driver side door closed OFF: Driver side door open - P Door Courtesy SW Passenger side door courtesy light switch signal/ON or OFF ON: Passenger side door closed OFF: Passenger side door open - Luggage Courtesy SW Luggage compartment door courtesy switch signal/ON or OFF ON: Luggage compartment door open OFF: Luggage compartment door closed - IG SW Ignition switch ON signal/ON or OFF ON: Ignition switch ON OFF: Ignition switch off - ACC SW Ignition switch ACC signal/ON or OFF ON: Ignition switch ACC OFF: Ignition switch off - Room Light Output Map light assembly output signal/ON or OFF ON: Map light assembly on OFF: Map light assembly off - Key Illumination Output Ignition key cylinder light output signal/ON or OFF ON: Ignition key cylinder light on OFF: Ignition key cylinder light off - Lighting Time Lighting time of the delay control function (illuminated entry system)/15s, 7.5s or 30s 15s: 15 seconds 7.5s: 7.5 seconds 30s: 30 seconds Customized value is displayed I/L when ACC OFF Function that lights up the interior lights when the ignition switch is turned from on (ACC or IG) to off/OFF or ON OFF: Function disabled ON: Function enabled Customized value is displayed I/L ON W/Door Key Unlock Function that lights up the interior lights when the doors are unlocked/OFF or ON OFF: Function disabled ON: Function enabled Customized value is displayed Interior Light Control Operation of the illuminated entry system/OFF or ON OFF: System not operated ON: System operated Customized value is displayed
2. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Enter the following menus: Body Electrical / Main Body / Active Test. Perform the Active Test according to the display on the Techstream. MAIN BODY Tester Display Test Part Control Range Diagnostic Note Illuminated Entry System Map light assembly Ignition key cylinder light ON/OFF Map light assembly switch in DOOR position Key Ring Light Ignition key cylinder light ON/OFF

DATA LIST / ACTIVE TEST [12/2013 - ]

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the following table, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Body Electrical / Main Body / Data List. Read the Data List according to the display on the Techstream. MAIN BODY Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door Courtesy SW Driver side door courtesy light switch signal/ON or OFF ON: Driver side door closed OFF: Driver side door open - D-Door Lock Pos SW Driver side door unlock detection switch signal/LOCK or UNLOCK LOCK: Driver side door locked UNLOCK: Driver side door unlocked - P Door Courtesy SW Passenger side door courtesy light switch signal/ON or OFF ON: Passenger side door closed OFF: Passenger side door open - P-Door Lock Pos SW Passenger side door unlock detection switch signal/LOCK or UNLOCK LOCK: Passenger side door locked UNLOCK: Passenger side door unlocked - Luggage Courtesy SW Luggage compartment door courtesy switch signal/ON or OFF ON: Luggage compartment door open OFF: Luggage compartment door closed - IG SW Ignition switch ON signal/ON or OFF ON: Ignition switch ON OFF: Ignition switch off - ACC SW Ignition switch ACC signal/ON or OFF ON: Ignition switch ACC OFF: Ignition switch off - Room Light Output Map light assembly output signal/ON or OFF ON: Map light assembly on OFF: Map light assembly off - Key Illumination Output Ignition key cylinder light output signal/ON or OFF ON: Ignition key cylinder light on OFF: Ignition key cylinder light off - Lighting Time Lighting time of the delay control function (illuminated entry system)/15s, 7.5s or 30s 15s: 15 seconds 7.5s: 7.5 seconds 30s: 30 seconds Customized value is displayed I/L when ACC OFF Function that lights up the interior lights when the ignition switch is turned from ON or ACC to off/OFF or ON OFF: Function disabled ON: Function enabled Customized value is displayed I/L ON W/Door Key Unlock Function that lights up the interior lights when the doors are unlocked/OFF or ON OFF: Function disabled ON: Function enabled Customized value is displayed Interior Light Control Operation of the illuminated entry system/OFF or ON OFF: System not operated ON: System operated Customized value is displayed
2. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Body Electrical / Main Body / Active Test. Perform the Active Test according to the display on the Techstream. MAIN BODY Tester Display Test Part Control Range Diagnostic Note Illuminated Entry System Map light assembly Engine switch*1 Ignition key cylinder light*2 ON/OFF Map light assembly switch in DOOR position Key Ring Light*2 Ignition key cylinder light ON/OFF - *1: w/ Smart Key System *2: w/o Smart Key System

INSPECTION PROCEDURE

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Note. Before performing the following inspection, check that the engine switch illumination has not been turned off using the rheostat function. The engine switch illumination can be turned off by using the rheostat knob to select the minimum illuminance level with the taillights on.
