- REMOVE MAP LIGHT ASSEMBLY Disengage the 2 claws. Disengage the 2 guides and disconnect the map light assembly. Disconnect the connector and remove the map light assembly.
- REMOVE NO. 1 MAP LIGHT LENS Using a screwdriver with its tip wrapped in protective tape, disengage the 2 claws and remove the No. 1 map light lens. TEXT IN ILLUSTRATION *1 Protective Tape
- REMOVE MAP LIGHT BULB Remove the map light bulb from the map light body.
Scheme 32
- INSPECT MAP LIGHT ASSEMBLY Check the map light assembly operation. Apply battery voltage to the terminals and check that the light comes on. OK: Condition Switch Condition Specified Condition Battery positive (+) - 2 (+B) Battery negative (-) - 1 (GND) Map light switch ON Map light comes on Battery positive (+) - 2 (+B) Battery negative (-) - 3 (DOOR SW) Map light switch DOOR Map light comes on If the result is not specified, replace the map light bulb or map light assembly. TEXT IN ILLUSTRATION *a Component without harness connected (Map Light Assembly)
