Data Communications: Removal & Installation Saab 9-7X I

Communication Devices 7 illustrations ~562 words

Removal Procedure

IMPORTANTThe ignition switch should be in the OFF position when connecting or disconnecting the connectors to the body control module (BCM). Always disconnect the 40-way body wiring extension FIRST, the 32-way tan connector SECOND and the 24-way gray electrical connector LAST. Always connect the 24-way gray electrical connector FIRST, the 32-way tan connector SECOND and the 40-way body wiring extension LAST. The BCM can set DTCs with the ignition switch in the OFF position. The BCM has battery run down protection for the courtesy lamp circuit. The BCM battery run down protection cannot detect shorts on inputs or other circuits which the BCM does not control. Use the scan tool in order to activate the POWER DOWN NOW mode. Use the POWER DOWN NOW mode in order to check for current draws on circuits that are not controlled by the BCM, or controlled by the battery run down protection system. Do not touch the exposed electrical contacts of the body wiring extension.
CAUTIONRefer to Battery Disconnect Caution .

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24
  1. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(ref-268108-S09012939602007101800000) .
  2. Position the left hand second seat to a cargo position.
  3. Remove the rear electrical center cover.
  4. Press down and hold the locking tab (1).
  5. Disengage the sliding latch retaining the BCM to the rear electrical center. Slide the latch inboard until fully extended, approximately 40 mm (1.6 in).
  6. Disconnect the body wiring extension (1) from the BCM.
  7. Disconnect the 32-way tan electrical connector (2) from the BCM.
  8. Disconnect the 24-way gray electrical connector (1) from the BCM.
  9. With an upward motion, disconnect the body wiring extension (1) from the rear electrical center.
  10. Remove the body wiring extension from the vehicle.

Installation Procedure

IMPORTANTEnsure the sliding latch is fully extended before connecting the body wiring extension to the rear electrical center.
  1. Using a downward motion, install the body wiring extension (1) to the rear electrical center.
  2. Connect the 24-way gray electrical connector (1) to the BCM.
  3. Connect the 32-way tan electrical connector (2) to the BCM.
  4. Connect the body wiring extension (1) to the BCM.
  5. Engage the sliding latch fastening the BCM to the rear electrical center. Slide the latch outboard until the locking tab (1) is fully seated.
  6. Install the rear electrical center cover.
  7. Position the left hand second seat to a passenger position.
  8. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(ref-268108-S09012939602007101800000) .
IMPORTANTThe ignition switch should be in the OFF position when connecting or disconnecting the connectors to the body control module (BCM). Always disconnect the 40-way body wiring extension FIRST, the 32-way tan connector SECOND and the 24-way gray electrical connector LAST. Always connect the 24-way gray electrical connector FIRST, the 32-way tan connector SECOND and the 40-way body wiring extension LAST. The BCM can set DTCs with the ignition switch in the OFF position. The BCM has battery run down protection for the courtesy lamp circuit. The BCM battery run down protection cannot detect shorts on inputs or other circuits which the BCM does not control. Use the scan tool in order to activate the POWER DOWN NOW mode. Use the POWER DOWN NOW mode in order to check for current draws on circuits that are not controlled by the BCM, or controlled by the battery run down protection system. Do not touch the exposed electrical contacts of the body wiring extension. Do not open the BCM housing. The module does not have any serviceable components. The module may be replaced only as an assembly.
CAUTIONRefer to Battery Disconnect Caution .

Scheme 25

Scheme 25
Scheme 25
  1. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(ref-268108-S09012939602007101800000) .
  2. Position the left hand second seat to a cargo position.
  3. Remove the rear electrical center cover.
  4. Press down and hold the locking tab (1).
  5. Disengage the sliding latch retaining the BCM to the rear electrical center. Slide the latch inboard until fully extended, approximately 40 mm (1.6 in).
  6. Disconnect the 40-way body wiring extension (1) from the BCM.
  7. Disconnect the 32-way tan electrical connector (2) from the BCM.
  8. Disconnect the 24-way gray electrical connector (1) from the BCM.
  9. With an upward motion, remove the BCM (1) from the rear electrical center.
  1. Index the slots on the BCM (1) to the rear electrical center.
  2. Using a downward motion, install the BCM to the rear electrical center.
  3. Connect the 24-way gray electrical connector (1) to the BCM.
  4. Connect the 32-way tan electrical connector (2) to the BCM.
  5. Connect the 40-way body wiring extension (1) to the BCM.
  6. Engage the sliding latch fastening the BCM to the rear electrical center. Slide the latch outboard until the locking tab (1) is fully seated.
  7. Install the rear electrical center cover.
  8. Position the left hand second seat to a passenger position.
  9. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(ref-268108-S09012939602007101800000) .
  10. If installing a replacement BCM, program the BCM. Refer to «Control Module References»(ref-268114-S32850434302007101800000) .

Scheme 26

Scheme 26: Removal Procedure
Scheme 26: Removal Procedure
  1. Remove the liftgate trim panel. Refer to «Liftgate Trim Panel Replacement»(ref-268081-S38630741292007101800000) .
  2. Disconnect the electrical connectors (3) from the module as necessary.
  3. Remove the bolts that retain the module to the liftgate.
  4. Remove the module from the liftgate.
  1. Install the module to the liftgate. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
  2. Install the bolts that retain the module to the liftgate. Tighten: Tighten the bolts to 10 N.m (89 lb in).
  3. Connect the electrical connectors (3) as necessary.
  4. Install the liftgate trim panel. Refer to «Liftgate Trim Panel Replacement»(ref-268081-S38630741292007101800000) .
  5. Program the liftgate control module. Refer to «Control Module References»(ref-268114-S32850434302007101800000) .
