Automatic Transmission: Diagnosis Saab 9-5 II

Diagnosis

The control module has diagnosis for internal faults. The solenoids are diagnosed with respect to open circuits and short circuits. They are also pulsed and the inductive voltage peak is analyzed to make sure the coil is not partially shorted. The speed sensor and temperature sensor circuits and plausibility are checked. High speed bus communication is checked to make sure no necessary messages are missing. Mechanical faults (slipping or wrong gear) are detected by comparing speed sensor values with the engaged gear.

Diagnostic Instructions

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC Descriptor

DTC P0218

Transmission Fluid Overtemperature

Diagnostic Fault Information

Conditions for Running the DTC

1. The ignition voltage is between 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Transmission control module (TCM) communication is normal.

Conditions for Setting the DTC

1. Vehicle speed less than 180 km/h (112 MPH) and transmission fluid temperature more than 150°C (302°F) for more than 10 s
2. Vehicle speed more than 180 km/h (112 MPH) and transmission fluid temperature more than 150°C (302°F) for more than 60 s

Action Taken When the DTC Sets

1. DTC P0218 is a Type C DTC.
2. Warning message to the driver via CAN bus

Conditions for Clearing the DTC

1. DTC P0218 is a Type C DTC.
2. Vehicle speed less than 170 km/h (106 MPH) and transmission fluid temperature less than 140°C (284°F) for more than 3 s
3. Vehicle speed more than 170 km/h (106 MPH) and transmission fluid temperature less than 140°C (284°F) for more than 3 s

Diagnostic Aids

Ask the customer whether their typical day-to-day driving include

1. Trailer towing
2. Trailer towing should occur in D 4th gear.
3. Hauling or vehicle overloading
4. Hot climate driving
5. Extended idling
6. Extreme off-road conditions
7. Ensure the engine cooling system is functioning normally.

DTC Type Reference

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

Scan Tool Reference

CONTROL MODULE REFERENCES for scan tool information

Dynamic Test

1. Inspect the transmission cooling system for restrictions or damage, inducing any auxiliary cooler if equipped.
2. Perform the Transmission Fluid Cooler Flushing and Flow Test to verify proper transmission oil cooler flow.
3. If a concern is found, repair or replace the damaged components as necessary.
4. Perform the «LINE PRESSURE CHECK»(ref-653642-S38889312902014090100000) to verify proper transmission line pressure.
5. If a concern is found, repair or replace the damaged components as necessary.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC Descriptors

DTC P0500

Vehicle Speed Sensor Circuit

DTC P0501

Vehicle Speed Sensor Performance

DTC P0502

Vehicle Speed Sensor Circuit Low Voltage

DTC P0503

Vehicle Speed Sensor Circuit Intermittent

1. Engine coolant temperature is more than 39.8°C (104°F).
2. No engine coolant temperature DTC is set.
3. No engine speed sensor DTC is set.
4. The DTCs runs continuously when the above condition are met.

P0500

The ECM detects the vehicle speed is less than 5 km/h (3 MPH) for more than 5 s.

P0501

The ECM detects the CAN signal is not valid for more than 2 s.

P0502

The ECM detects the actual vehicle speed is equal to the last vehicle speed for more than 10 s.

P0503

The ECM detects the vehicle speed is greater than 275 km/h (171 MPH) for more than 0.2 s.

1. DTCs P0500, P0502, and P0503 are Type B DTCs.
2. DTC P0501 is a Type C DTC.

1. DTCs P0500, P0502, and P0503 are Type B DTCs.
2. DTC P0501 is a Type C DTC.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0601

Control Module Read Only Memory Performance

DTC P0602

Control Module Not Programmed

DTC P0603

Control Module Long Term Memory Reset

DTC P0604

Control Module Random Access Memory Performance

The TCM runs the program to detect an internal condition at key ON. The only requirements are voltage and ground. This program runs even if the voltage is out of the valid operating range.

P0601

The read only memory (ROM) test has failed 5 or more times.

P0602

The TCM has been unable to detected the start program.

P0603

The TCM has detected a memory checksum error.

P0604

The TCM random access memory (RAM) test has failed 5 or more times.

P0601, P0602, P0603, P0604

1. DTCs P0601, P0603, P0604 are Type A DTCs.
2. The TCM commands maximum line pressure.
3. The TCM forces the torque converter clutch (TCC) OFF.
4. The TCM inhibits TCC engagement.
5. The TCM freezes transmission adaptive functions.
6. The TCM commands an immediate landing to 2nd gear.

DTCs P0601, P0602, P0603, P0604 are Type A DTCs.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0700

Transmission Control Module Requested MIL Illumination

1. The ignition is ON.
2. DTC P0700 runs continuously.

The TCM is requesting MIL illumination.

DTC P0700 is a Type A DTC.

DTC P0700 is a Type A DTC.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0706

Park/Neutral Position Switch Circuit

DTC P0707

Park/Neutral Position Switch Circuit Low Voltage

DTC P0708

Park/Neutral Position Switch Circuit High Voltage

1. Ignition voltage is 6-15.5 V.
2. TCM is not in service mode.

P0706

Sum of two position sensor voltage has deviation over 0.29 V from standard value 5 V.

P0707

Voltage on position switch 1 and position switch 2 is less than 0.127 V for 100 ms continuously after 2 consecutive times.

P0708

Voltage on position switch 1 and position switch 2 is more than 4.87 V for 100 ms continuously after 2 consecutive times.

1. DTCs P0706, P0707, and P0708 are Type A DTCs.
2. The TCM freezes transmission adaptive functions.
3. If output speed sensor is 0 RPM, Range is D, 2nd gear is hold and service mode will be set.
4. The engine start is locked after engine has stopped.

1. DTCs P0706, P0707, and P0708 are Type A DTCs.
2. Voltage of two selector position sensor are within 0.127-4.87 V and sum of two position sensor voltage has deviation within 0.29 V from standard value 5 V.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0711

Transmission Fluid Temperature Sensor Performance

DTC P0712

Transmission Fluid Temperature Sensor Circuit Low Voltage

DTC P0713

Transmission Fluid Temperature Sensor Circuit High Voltage

P0711

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. TCM communication is normal.
4. DTCs P0712, P0713 are not set.
5. The transmission is not in emergency mode.
6. The engine speed is greater than 400 RPM for 10 min.
7. Vehicle speed was 40 km/h (25 MPH) or greater at once.

P0712

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.

P0713

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. Driving time is more than 10 min.
6. TCM communication is normal.

P0711

The automatic transmission fluid temperature is less than 20°C (36°F) after 10 min driving or more.

P0712

The automatic transmission fluid temperature is more than 200°C (473°F) for 10 s or more after consecutive 30 times.

P0713

The automatic transmission fluid temperature is lower than -43°C (-45°F) for 1 s or more after consecutive 12 times.

1. The TCM will default the transmission oil temperature to 80°C (353°F).
2. No lock-up slip control
3. No neutral control
4. No self learning control

P0711, P0712, and P0713

These are Type C DTCs.

P0712, P0713

The automatic transmission fluid temperature is between 20-150°C (68-302°F) for 10 s or more.

A correct transmission fluid level is required for a proper function. The automatic transmission fluid temperature sensor is located inside the transmission at the valve body. To ensure that the shown oil temperature is correct, measure the oil temperature with an external thermometer.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

Circuit/System Testing

Operate the vehicle within the conditions for running and setting the DTC to verify the DTC does not reset. You may also operate the vehicle within the conditions that you observed from the Freeze Frame/Failure Records data.

Static Test

1. Ignition OFF, remove the K71 Transmission Control Module.
2. Ignition OFF, test for infinite resistance between the low reference circuit terminal 7 X2 and ground.
3. If less than the specified range, replace the wiring harness.
4. Ignition OFF, test for infinite resistance between the signal circuit terminal 8 X2 and ground.
5. If less than the specified range, replace the wiring harness.
6. Test for infinite resistance between each terminal and the low reference circuit terminal 7 X2 and also to the signal circuit terminal 8 X2.
7. If less than the specified range, replace the wiring harness.
8. Test for the resistance between the B13 Automatic Transmission Fluid Temperature Sensor signal circuit terminal 7 X2 and the low reference circuit terminal 8 X2. Refer to «TRANSMISSION FLUID TEMPERATURE SENSOR SPECIFICATIONS»(ref-653642-S04876720762014090100000) for the resistance values.
9. If not within the specified range, replace the wiring harness.
10. If the circuit test normal, replace the K71 Transmission Control Module.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0717

Input Speed Sensor Circuit No Signal

P0717

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. Current gear 2nd or higher.
6. TCM communication is normal.
7. Output speed multiplied with current gear ratio is more than 600 RPM.

P0717

1. No input shaft sensor pulse while receiving pulses on the output speed sensor.
2. Deviation from calculated output speed is more than 300 RPM.
3. No input shaft sensor pulse when vehicle speed from ABS is more than 20 km/h (13 MPH) for 300 ms.

1. DTC P0717 is Type A DTC.
2. The TCM freezes transmission adaptive functions.
3. The TCM turns OFF all solenoids.
4. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

1. DTC P0717 is Type A DTC.
2. Output speed is greater than 300 RPM for more than 70 s.
3. Deviation from calculated output speed is less than 5% for more than 1 s.

Damage or misalignment of the C2 drum machined teeth surface may cause a speed sensor malfunction.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Ignition OFF, remove the K71 Transmission Control Module.
2. Test for more than 1 Mohms between the low reference circuit terminal 13 X2 and the voltage supply circuit terminal 12 X2.
3. If less than the specified range, test the wiring harness for internal short. If the circuit tests normal, replace the automatic transmission.
4. Test for infinite resistance between each terminal and the low reference circuit terminal 13 X2 and also to the voltage supply circuit terminal 12 X2.
5. If less than the specified range, replace the wiring harness.
6. If all circuits test normal, test or replace the K71 Transmission Control Module. Verify the DTC does not reset.
7. If the DTC resets, replace the automatic transmission.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0722

Output Speed Sensor Circuit No Signal

P0722

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. TCM communication is normal.
5. Driving in D range.

P0722

1. Deviation from calculated output speed is more than 300 RPM.
2. No output speed sensor pulse while receiving pulses on the input speed sensor.
3. No output speed sensor pulse when vehicle speed from ABS is more than 20 km/h (13 MPH) for 300 ms.

1. DTC P0722 is Type A DTC.
2. The TCM freezes transmission adaptive functions.
3. The TCM turns OFF all solenoids.
4. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

1. DTC P0722 is Type A DTC.
2. Output speed is greater than 300 RPM for more than 70 s.
3. Deviation from calculated output speed is less than 5% for more than 1 s.

1. Damage or misalignment of the counter drive gear machined teeth surface may cause a speed sensor malfunction.
2. Proper torque of the output shaft sensor mounting bolt is critical to proper output shaft sensor operation.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Ignition OFF, remove the K71 Transmission Control Module.
2. Test for more than 1 Mohms between the low reference circuit terminal 20 X2 and the voltage supply circuit terminal 19 X2.
3. If less than the specified range, test the wiring harness for internal short. If the circuit tests normal, replace the automatic transmission.
4. Test for infinite resistance between each terminal and the low reference circuit terminal 20 X2 and also to the voltage supply circuit terminal 19 X2.
5. If less than the specified range, replace the wiring harness.
6. If all circuits test normal, test or replace the K71 Transmission Control Module. Verify the DTC does not reset.
7. If the DTC resets, replace the automatic transmission.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0729

6th Gear Ratio Incorrect

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. TCM communication is normal.
5. Transmission fluid temperature is higher than 20°C (68°F).
6. DTCs P0716. P0717, P0721 and P0722 are not set.

1. Driving in D range, 6th gear.
2. Output speed more than 500 RPM.
3. Throttle position more than 10%.
4. Measured gear ratio deviates more than 20% from expected ratio.
5. Measured gear ratio deviates within 4% from 4th or 5th gear ratio.
6. Determined after 12 times lasting 1 s or more.

1. DTC P0729 is a Type C DTC.
2. Torque limitation in "D" range 150 Nm (110 lb ft), in "R" range 170 Nm (125 lb ft).
3. The TCM freezes transmission adaptive functions.
4. The TCM turns OFF all solenoids.
5. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

1. DTC P0729 is a Type C DTC.
2. Measured gear ratio deviates less than 4% from expected ratio.

Ensure the transmission fluid level, color and odor is correct and there are no leaks. If there are any other transmission DTCs set, diagnose those first.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Perform the line pressure check. Refer to «LINE PRESSURE CHECK»(ref-653642-S38889312902014090100000) .
2. Perform the transmission fluid check. Refer to «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-653642-S41840466012014090100000) .
3. If all circuits test normal, replace the K71 Transmission Control Module. Verify the DTC does not reset.
4. If the DTC resets replace the control valve body.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0731

1st Gear Ratio Incorrect

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. TCM communication is normal.
5. Transmission fluid temperature is higher than 20°C (68°F).
6. DTCs P0716. P0717, P0721 and P0722 are not set.

1. Driving in D range, 1st gear.
2. Measured gear ratio deviates more than 20% from expected ratio.
3. Determined after 12 times lasting 1 s or more.

1. DTC P0731 is a Type C DTC
2. Torque limitation in "D" range 150 Nm (110 lb ft), in "R" range 170 Nm (125 lb ft).
3. The TCM freezes transmission adaptive functions.
4. The TCM turns OFF all solenoids.
5. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

1. DTC P0731 is a Type C DTC
2. Measured gear ratio deviates less than 4% from expected ratio.

Ensure the transmission fluid level, color and odor is correct and there are no leaks. If there are any other transmission DTCs set, diagnose those first.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Perform the line pressure check. Refer to «LINE PRESSURE CHECK»(ref-653642-S38889312902014090100000) .
2. Perform the transmission fluid check. Refer to «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-653642-S41840466012014090100000) .
3. If all circuits test normal, replace the K71 Transmission Control Module. Verify the DTC does not reset.
4. If the DTC resets replace the control valve body.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0732

2nd Gear Ratio Incorrect

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. TCM communication is normal.
5. Transmission fluid temperature is higher than 20°C (68°F).
6. DTCs P0716. P0717, P0721 and P0722 are not set.

1. Driving in D range, 2nd gear.
2. Output speed more than 500 RPM.
3. Throttle position more than 10%.
4. Measured gear ratio deviates more than 20% from expected ratio.
5. Measured gear ratio deviates within 4% from 1st, 3rd, 4th or 6th gear ratio.
6. Determined after 12 times lasting 1 s or more.

1. DTC P0732 is a Type C DTC.
2. Torque limitation in "D" range 150 Nm (110 lb ft), in "R" range 170 Nm (125 lb ft).
3. The TCM freezes transmission adaptive functions.
4. The TCM turns OFF all solenoids.
5. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

1. DTC P0732 is a Type C DTC.
2. Measured gear ratio deviates less than 4% from expected ratio.

When attempting to set transmission performance DTCs, observe the Freeze Frame/Failure Records to assist in duplicating the inoperative or affected conditions. Ensure the transmission fluid level, color and odor is correct and there are no leaks. If there are any other transmission DTCs set, diagnose those first.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Perform the line pressure check. Refer to «LINE PRESSURE CHECK»(ref-653642-S38889312902014090100000) .
2. Perform the transmission fluid check. Refer to «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-653642-S41840466012014090100000) .
3. If all circuits test normal, replace the K71 Transmission Control Module. Verify the DTC does not reset.
4. If the DTC resets replace the control valve body.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0733

3rd Gear Ratio Incorrect

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. TCM communication is normal.
5. Transmission fluid temperature is higher than 20°C (68°F).
6. DTCs P0716. P0717, P0721 and P0722 are not set.

1. Driving in D range, 3rd gear.
2. Output speed more than 500 RPM.
3. Throttle position more than 10%.
4. Measured gear ratio deviates more than 20% from expected ratio.
5. Measured gear ratio deviates within 4% from 1st, 4th or 5th gear ratio.
6. Determined after 12 times lasting 1 s or more.

1. DTC P0733 is a Type C DTC.
2. Torque limitation in "D" range 150 Nm (110 lb ft), in "R" range 170 Nm (125 lb ft).
3. The TCM freezes transmission adaptive functions.
4. The TCM turns OFF all solenoids.
5. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

1. DTC P0733 is a Type C DTC.
2. Measured gear ratio deviates less than 4% from expected ratio.

When attempting to set transmission performance DTCs, observe the Freeze Frame/Failure Records to assist in duplicating the inoperative or affected conditions. Ensure the transmission fluid level, color and odor is correct and there are no leaks. If there are any other transmission DTCs set, diagnose those first.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Perform the line pressure check. Refer to «LINE PRESSURE CHECK»(ref-653642-S38889312902014090100000) .
2. Perform the transmission fluid check. Refer to «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-653642-S41840466012014090100000) .
3. If all circuits test normal, replace the K71 Transmission Control Module. Verify the DTC does not reset.
4. If the DTC resets replace the control valve body.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0734

4th Gear Ratio Incorrect

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. TCM communication is normal.
5. Transmission fluid temperature is higher than 20°C (68°F).
6. DTCs P0716. P0717, P0721 and P0722 are not set.

1. Driving in D range, 4th gear.
2. Output speed more than 500 RPM.
3. Throttle position more than 10%.
4. Measured gear ratio deviates more than 20% from expected ratio.
5. Measured gear ratio deviates within 4% from 1st, 5th or 6th gear ratio.
6. Determined after 12 times lasting 1 s or more.

1. DTC P0734 is a Type C DTC.
2. Torque limitation in "D" range 150 Nm (110 lb ft), in "R" range 170 Nm (125 lb ft).
3. The TCM freezes transmission adaptive functions.
4. The TCM turns OFF all solenoids.
5. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

1. DTC P0734 is a Type C DTC.
2. Measured gear ratio deviates less than 4% from expected ratio.

Ensure the transmission fluid level, color and odor is correct and there are no leaks. If there are any other transmission DTCs set, diagnose those first.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Perform the line pressure check. Refer to «LINE PRESSURE CHECK»(ref-653642-S38889312902014090100000) .
2. Perform the transmission fluid check. Refer to «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-653642-S41840466012014090100000) .
3. If all circuits test normal, replace the K71 Transmission Control Module. Verify the DTC does not reset.
4. If the DTC resets replace the control valve body.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0735

5th Gear Ratio Incorrect

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. TCM communication is normal.
5. Transmission fluid temperature is higher than 20°C (68°F).
6. DTCs P0716. P0717, P0721 and P0722 are not set.

1. Driving in D range, 5th gear.
2. Output speed more than 500 RPM.
3. Throttle position more than 10%.
4. Measured gear ratio deviates more than 20% from expected ratio.
5. Measured gear ratio deviates within 4% from 4th or 6th gear ratio.
6. Determined after 12 times lasting 1 s or more.

1. DTC P0735 is a Type C DTC.
2. Torque limitation in "D" range 150 Nm (110 lb ft), in "R" range 170 Nm (125 lb ft).
3. The TCM freezes transmission adaptive functions.
4. The TCM turns OFF all solenoids.
5. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

1. DTC P0735 is a Type C DTC.
2. Measured gear ratio deviates less than 4% from expected ratio.

Ensure the transmission fluid level, color and odor is correct and there are no leaks. If there are any other transmission DTCs set, diagnose those first.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Perform the line pressure check. Refer to «LINE PRESSURE CHECK»(ref-653642-S38889312902014090100000) .
2. Perform the transmission fluid check. Refer to «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-653642-S41840466012014090100000) .
3. If all circuits test normal, replace the K71 Transmission Control Module. Verify the DTC does not reset.
4. If the DTC resets replace the control valve body.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0736

Reverse Ratio Incorrect

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. TCM communication is normal.
5. Transmission fluid temperature is higher than 20°C (68°F).
6. DTCs P0716. P0717, P0721 and P0722 are not set.

1. Driving in Reverse gear.
2. Output speed more than 500 RPM.
3. Throttle position more than 10%.
4. Measured gear ratio deviates more than 20% from expected ratio.
5. Determined after 12 times lasting 1 s or more.

1. DTC P0736 is a Type C DTC.
2. Torque limitation in "D" range 150 Nm (110 lb ft), in "R" range 170 Nm (125 lb ft).
3. The TCM freezes transmission adaptive functions.
4. The TCM turns OFF all solenoids.
5. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

1. DTC P0736 is a Type C DTC.
2. Measured gear ratio deviates less than 4% from expected ratio.

Ensure the transmission fluid level, color and odor is correct and there are no leaks. If there are any other transmission DTCs set, diagnose those first.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Perform the line pressure check. Refer to «LINE PRESSURE CHECK»(ref-653642-S38889312902014090100000) .
2. Perform the transmission fluid check. Refer to «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-653642-S41840466012014090100000) .
3. If all circuits test normal, replace the K71 Transmission Control Module. Verify the DTC does not reset.
4. If the DTC resets replace the control valve body.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0741

Torque Converter Clutch (TCC) System Stuck Off

DTC P0742

Torque Converter Clutch (TCC) System Stuck On

P0741

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater less 4 000 RPM.
3. Engine torque is more than 0 Nm (0 lb ft).
4. The transmission is not in emergency mode.
5. Driving in D range.
6. TCM communication is normal.
7. DTCs P0716, P0717, P0721, P0722, P2759, P2762, P2763, P2764 are not set.

P0742

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM.
3. Output speed is 0 RPM.
4. The transmission is not in emergency mode.
5. Driving in D range.
6. TCM communication is normal.
7. DTCs P0716, P0717, P0721, P0722, P2759, P2762, P2763, P2764 are not set.

P0741

Detected slip speed is more than 100 RPM 2 s after lockup control is turned on.

P0742

1. Detected slip speed is less than 100 RPM 2 s after lockup control is turned off.
2. Detects no slip speed in engine stall avoidance control after engine stall detected or no slip speed detected during no lockup control.

1. DTC P0741 is a Type B DTC.
2. DTC P0742 is a Type B DTC.
3. The TCM inhibits TCC.
4. The TCM freezes transmission adaptive functions.

P0741

1. DTC P0741 is a Type B DTC.
2. Deviation between Engine speed and output speed is less than 30 RPM during lockup control is turned on.
3. DTC P0742 is a Type B DTC.
4. Deviation between Engine speed and output speed is more than 100 RPM during lockup control is turned off.

Ensure the transmission fluid level, color and odor is correct and there are no leaks. If there are any other transmission DTCs set, diagnose those first.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Perform the line pressure check. Refer to «LINE PRESSURE CHECK»(ref-653642-S38889312902014090100000) .
2. Perform the transmission fluid check. Refer to «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-653642-S41840466012014090100000) .
3. If all circuits test normal, replace the K71 Transmission Control Module. Verify the DTC does not reset.
4. If the DTC resets, go to «COMPONENT TESTING»(ref-653642-S13200099182014090100000) .

1. Inspect the valve body assembly for a stuck valve, debris, or damage.
2. If a stuck open or closed valve is found, replace the valve body assembly.
3. Inspect the torque converter assembly for damage or discoloration.
4. If you find a torque converter assembly concern, replace the torque converter assembly as necessary.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0748

Line Pressure Control Solenoid Valve System Performance

DTC P0961

Line Pressure Control Solenoid Valve System Performance

DTC P0962

Line Pressure Control Solenoid Valve Control Circuit Low Voltage

DTC P0963

Line Pressure Control Solenoid Valve Control Circuit High Voltage

P0748

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. DTCs P0962 and P0963 are not set.

P0961

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. The Automatic Transmission Fluid Temperature is more than 20°C (68°F)
7. SLT current is more than 0.85 A.
8. SLT current is not changed.

P0962

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. DTC P0963 is not set.

P0963

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. DTC P0962 is not set.

P0748

Deviation between commanded current and feedback current.

P0961

The TCM detects the error current more than 80 mA for 2.75 ms.

P0962

The TCM detects at least 5 times less than 23 mA current consumption of the SLT control circuit for 100 ms.

P0963

The TCM detects at least 5 times more than 1.333 A current consumption of the SLT control circuit for 100 ms.

P0748, P0961

1. DTC P0961 is a Type B DTC.
2. The TCM turns OFF all solenoids.
3. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

P0962, P0963

1. DTCs P0962 and P0963 are Type B DTCs.
2. No self learning function.
3. The TCM turns OFF all solenoids.
4. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

P0748, P0961

1. DTC P0963 is a Type B DTC.
2. The TCM detects the error current less than 50 mA for 2.75 ms.

P0962, P0963

1. DTCs P0962 and P0963 are Type B DTCs.
2. The current consumption of the SLT control circuit is 0.1-1.1 A for 500 ms.

When attempting to set solenoid electrical DTCs, ensure the TCM is warmed up and the transmission is operated in 2nd gear long enough to ensure a 3°C (5°F) increase in TCM substrate temperature. This will place the TCM under the optimal conditions to test solenoid electrical DTCs.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

Command the Line Pressure Control Solenoid Valve with a scan tool. The value should change from 0.0-1.1 A.

1. Ignition OFF, remove the K71 Transmission Control Module.
2. Test for 5-5.6 ohms at 20°C (68°F) between the low reference circuit terminal 1 X2 and the voltage supply circuit terminal 3 X2.
3. If less than the specified range, test the wiring harness for internal short. If the circuit test normal, replace the Q23 Line Pressure Control Solenoid Valve.
4. Test for infinite resistance between each terminal and the low reference circuit terminal 1 X2 and also to the voltage supply circuit terminal 3 X2.
5. If less than the specified range, replace the wiring harness.
6. If all circuit test normal, perform the «CONTROL SOLENOID VALVE INSPECTION (M36 AND MXE)»(ref-653642-S39433622442014090100000) .
7. If the inspection test normal, replace the valve body assembly.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0778

Pressure Control Solenoid Valve 1 System Performance

DTC P0965

Pressure Control Solenoid Valve 1 System Performance

DTC P0966

Pressure Control Solenoid Valve 1 Control Circuit Low Voltage

DTC P0967

Pressure Control Solenoid Valve 1 Control Circuit High Voltage

P0778

1. The ignition voltage is between 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. DTCs P0966 and P0967 are not set.

P0965

1. The ignition voltage is between 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. The automatic transmission fluid temperature is more than 20°C (68°F).
7. SLC1 current is more than 0.85 A.
8. SLC1 target current is not changed.

P0966

1. The ignition voltage is between 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. DTC P0967 is not set.

P0967

1. The ignition voltage is between 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. DTC P0966 is not set.

P0778

Deviation between commanded current and feedback current.

P0965

The TCM detects the error current more than 80 mA for 2.75 ms.

P0966

The TCM detects at least 5 times less than 23 mA current consumption of the SLC1 control circuit for 100 ms.

P0967

The TCM detects at least 5 times more than 1.333 A current consumption of the SLC1 control circuit for 100 ms.

P0778, P0965

1. DTC P0965 is a Type B DTC.
2. The TCM turns OFF all solenoids.
3. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

P0966, P0967

1. DTCs P0966 and P0967 are Type B DTCs.
2. No self learning function.
3. The TCM turns OFF all solenoids.
4. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

P0778, P0965

1. DTC P0967 is a Type B DTC.
2. The TCM detects the error current less than 50 mA for 2.75 ms.

P0966, P0967

1. DTCs P0966 and P0967 are Type B DTCs.
2. The current consumption of the SLC1 control circuit is 0.1-1.1 A for 500 ms.

When attempting to set solenoid electrical DTCs, ensure the TCM is warmed up and the transmission is operated in 2nd gear long enough to ensure a 3°C (5°F) increase in TCM substrate temperature. This will place the TCM under the optimal conditions to test solenoid electrical DTCs.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

Command the Clutch Pressure Control Solenoid Valve 1 with a scan tool. The value should change from 0.0-1.0 A.

1. Ignition OFF, remove the K71 Transmission Control Module.
2. Test for 5-5.6 ohms at 20°C (68°F) between the low reference circuit terminal 10 X2 and the voltage supply circuit terminal 11 X2.
3. If less than the specified range, test the wiring harness for internal short. If the circuit test normal, replace the Q27A Pressure Control Solenoid Valve 1.
4. Test for infinite resistance between each terminal and the low reference circuit terminal 10 X2 and also to the voltage supply circuit terminal 11 X2.
5. If less than the specified range, replace the wiring harness.
6. If all circuit test normal, perform the «CONTROL SOLENOID VALVE INSPECTION (M36 AND MXE)»(ref-653642-S39433622442014090100000) .
7. If the inspection test normal, replace the control valve body.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0780

Incorrect Shift Pattern

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 500 RPM for 2 s.
3. The transmission is not in emergency mode.
4. TCM communication is normal.
5. Transmission fluid temperature is higher than 65°C (149°F).
6. DTCs P0716. P0717, P0721 and P0722 are not set.

1. Driving in D range.
2. Output speed is greater than 300 RPM.
3. After 10 times of unusual shifting, long time shifting or rapid shifting

1. DTC P0780 is a Type C DTC
2. Torque limitation in "D" range 150 Nm (110 lb ft), in "R" range 170 Nm (125 lb ft).
3. The TCM freezes transmission adaptive functions.
4. The TCM turns OFF all solenoids.
5. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

DTC P0780 is a Type C DTC

Ensure the transmission fluid level, color and odor is correct and there are no leaks. If there are any other transmission DTCs set, diagnose those first.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Perform the «LINE PRESSURE CHECK»(ref-653642-S38889312902014090100000) .
2. Perform the «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-653642-S41840466012014090100000) .
3. If all circuits test normal, replace the K71 Transmission Control Module. Verify the DTC does not reset.
4. If the DTC resets replace the control valve body.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0798

Pressure Control Solenoid Valve 2 System Performance

DTC P0969

Pressure Control Solenoid Valve 2 System Performance

DTC P0970

Pressure Control Solenoid Valve 2 Control Circuit Low Voltage

DTC P0971

Pressure Control Solenoid Valve 2 Control Circuit High Voltage

P0798

1. The ignition voltage is between 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. DTCs P0970 and P0971 are not set.

P0969

1. The ignition voltage is between 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. The Automatic Transmission Fluid Temperature is more than 20°C (68°F)
7. SLC2 current is more than 0.85 A.
8. SLC2 current is not changed.

P0970

1. The ignition voltage is between 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. DTC P0971 is not set.

P0971

1. The ignition voltage is between 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. DTC P0970 is not set.

P0798

Deviation between commanded current and feedback current.

P0969

The TCM detects the error current more than 80 mA for 2.75 ms.

P0970

The TCM detects at least 5 times less than 23 mA current consumption of the SLC2 control circuit for 100 ms.

P0971

The TCM detects at least 5 times more than 1.333 A current consumption of the SLC2 control circuit for 100 ms.

P0798, P0969

1. DTC P0969 is a Type B DTC.
2. The TCM turns OFF all solenoids.
3. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

P0970, P0971

1. DTCs P0970 and P0971 are Type B DTCs.
2. No self learning function.
3. The TCM turns OFF all solenoids.
4. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

P0798, P0969

1. DTC P0971 is a Type B DTC.
2. The TCM detects the error current less than 50 mA for 2.75 ms.

P0970, P0971

1. DTCs P0970 and P0971 are Type B DTCs.
2. The current consumption of the SLC2 control circuit is 0.1-1.1 A for 500 ms.

When attempting to set solenoid electrical DTCs, ensure the TCM is warmed up and the transmission is operated in 2nd gear long enough to ensure a 3°C (5°F) increase in TCM substrate temperature. This will place the TCM under the optimal conditions to test solenoid electrical DTCs.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

Command the Clutch Pressure Control Solenoid Valve 2 with a scan tool. The value should change from 0.0-1.0 A.

1. Ignition OFF, remove the K71 Transmission Control Module.
2. Test for 5-5.6 ohms at 20°C (68°F) between the low reference circuit terminal 18 X2 and the voltage supply circuit terminal 17 X2.
3. If less than the specified range, test the wiring harness for internal short. If the circuit test normal, replace the Q27B Pressure Control Solenoid Valve 2.
4. Test for infinite resistance between each terminal and the low reference circuit terminal 18 X2 and also to the voltage supply circuit terminal 17 X2.
5. If less than the specified range, replace the wiring harness.
6. If all circuit test normal, perform the «CONTROL SOLENOID VALVE INSPECTION (M36 AND MXE)»(ref-653642-S39433622442014090100000) .
7. If the inspection test normal, replace the control valve body.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0817

Brake Transmission Shift Interlock Solenoid Actuator

P0817

1. The ignition voltage is 6.0-16.0 V.
2. The transmission is not in emergency mode.

P0817

1. Start lock is output as "On" and start lock monitor signal indicates "Off" for more than 100 ms.
2. After consecutive 2 times of above detection.

P0817

1. DTCs P0817 is Type D DTC.
2. No engine start possible.

P0817

1. DTCs P0817 is Type D DTC.
2. Start lock is output as "On" and start lock monitor signal indicates "On" and start lock is output as "Off" and start lock monitor signal indicates "Off" for more than 1 s.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

Ignition ON, observe the scan tool Transmission Range Switch parameter while selecting each transmission range: P, R, N, D. Each selected transmission range should correspond to the correct scan tool parameter displayed.

1. Ignition OFF, remove the wiring harness connector from K71 Transmission Control Module.
2. Test the starter inhibit circuit 5 X1 for a short to ground, an open/high resistance, or a short to voltage.
3. If the circuit test normal, replace the K71 Transmission Control Module.
4. Verify the DTC does not reset. If the DTC resets, replace the K9 Body Control Module.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0973

Shift Solenoid Valve 2 Control Circuit Low Voltage

DTC P0974

Shift Solenoid Valve 2 Control Circuit High Voltage

P0973

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. 10 ms after solenoid output changed.

P0974

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. 10 ms after solenoid output changed.

P0973

The TCM detects an ON signal (12 V) of the 2 circuit when the 2 is commanded OFF (0 V) for 100 ms continuously after 5 times.

P0974

The TCM detects an OFF signal (0 V) of the 2 circuit when the 2 is commanded ON (12 V) for 100 ms continuously after 5 times.

1. DTCs P0973 and P0974 are Type A DTCs.
2. The TCM freezes transmission adaptive functions.
3. The TCM turns OFF all solenoids.
4. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

1. DTCs P0973 and P0974 are Type A DTCs.
2. The TCM detects an ON signal (12 V) of the Shift Solenoid Valve 2 circuit when the Shift Solenoid Valve 2 is commanded ON (12 V) for 1 s continuously.
3. The TCM detects an OFF signal (0 V) of the Shift Solenoid Valve 2 circuit when the Shift Solenoid Valve 2 is commanded OFF (0 V) for 1 s continuously.

When attempting to set solenoid electrical DTCs, ensure the control solenoid valve assembly is warmed up and the transmission is operated long enough to ensure a 3°C (5° F) increase in temperature. This will place the TCM under the optimal conditions to test solenoid electrical DTCs.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Ignition OFF, remove the K71 Transmission Control Module.
2. Test for 11-15 ohms between the Shift Solenoid Control circuit terminal 2 X2 and ground.
3. If not within the specified range, test the wiring harness for internal short, or interruption. If the circuit test normal, replace the Q32B Shift Solenoid Valve 2.
4. Test for infinite resistance between each terminal and the Shift Solenoid Control circuit terminal 2 X2.
5. If less than the specified range, replace the wiring harness.
6. If all circuits test normal, test or replace the Q32B Shift Solenoid Valve 2. Verify the DTC does not reset.
7. If the DTC resets, replace the K71 Transmission Control Module.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P0985

Shift Solenoid Valve 1 Control Circuit Low Voltage

DTC P0986

Shift Solenoid Valve 1 Control Circuit High Voltage

P0985

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. 10 ms after solenoid output changed.

P0986

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. 10 ms after solenoid output changed.

P0985

The TCM detects an ON signal (12 V) of the shift solenoid valve 1 circuit when the shift solenoid valve 1 is commanded OFF (0 V) for 100 ms continuously after 5 times.

P0986

The TCM detects an OFF signal (0 V) of the shift solenoid valve 1 circuit when the shift solenoid valve 1 is commanded ON (12 V) for 100 ms continuously after 5 times.

1. DTCs P0985 and P0986 are Type A DTCs.
2. The TCM freezes transmission adaptive functions.
3. The TCM turns OFF all solenoids.
4. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

1. DTCs P0985 and P0986 are Type A DTCs.
2. The TCM detects an ON signal (12 V) of the shift solenoid valve 1 circuit when the shift solenoid valve 1 is commanded ON (12 V) for 1 s continuously.
3. The TCM detects an OFF signal (0 V) of the 1 circuit when the shift solenoid valve 1 is commanded OFF (0 V) for 1 s continuously.

When attempting to set solenoid electrical DTCs, ensure the control solenoid valve assembly is warmed up and the transmission is operated long enough to ensure a 3°C (5° F) increase in temperature. This will place the TCM under the optimal conditions to test solenoid electrical DTCs.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Ignition OFF, remove the K71 Transmission Control Module.
2. Test for 11-15 ohms between the Shift Solenoid Control circuit terminal 5 X2 and ground.
3. If not within the specified range, test the wiring harness for internal short, or interruption. If the circuit test normal, replace the Q32A Shift Solenoid Valve 1.
4. Test for infinite resistance between each terminal and the Shift Solenoid Control circuit terminal 5 X2.
5. If less than the specified range, replace the wiring harness.
6. If all circuits test normal, test or replace the Q32A Shift Solenoid Valve 1. Verify the DTC does not reset.
7. If the DTC resets, replace the K71 Transmission Control Module.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P1701

Transmission Fluid Pressure Valve Position Switch Indicates Park/Neutral With Drive Ratio

P1701

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D or R range.
5. Transmission control module (TCM) communication is normal.
6. Transmission Fluid temperature is more than 0°C (32°F).
7. Output speed more than 500 RPM.

P1701

Difference between engine speed and transmission input speed is below 150 RPM and not in 1st or reverse gear detected. Determined after 3 time lasting more than 0.8 s.

P1701

1. DTC P1701 is Type B DTC.
2. No self learning function
3. No neutral control
4. No adaptive shift
5. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

P1701

1. DTC P1701 is Type B DTC.
2. Measured gear ratio deviates less than 4% from expected ratio.

When attempting to set solenoid electrical DTCs, ensure the TCM is warmed up and the transmission is operated in 2nd gear long enough to ensure a 3°C (5°F) increase in TCM substrate temperature. This will place the TCM under the optimal conditions to test solenoid electrical DTCs.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Perform the «LINE PRESSURE CHECK»(ref-653642-S38889312902014090100000) .
2. Perform the «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-653642-S41840466012014090100000) .
3. If all circuits test normal, replace the K71 Transmission Control Module. Verify the DTC does not reset.
4. If the DTC resets replace the control valve body.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P1702

DTC Transmission Clutch 1 Stuck On

DTC P1703

Transmission Clutch 1 Performance

DTC P1704

Transmission Clutch 1 Slip Detected

P1702, P1703, P1704

1. The ignition voltage is between 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. Transmission control module (TCM) communication is normal.
6. Transmission fluid temperature is more than 10°C (50°F).

P1702

1. Clutch C1 hydraulic pressure is less than 26 kPa (3.8 PSI).
2. Input revolution is less than 400 RPM for more than 5 s.

P1703

1. Clutch C1 in neutral control
2. Clutch C1 hydraulic pressure is more than 350 kPa (51 PSI).
3. Input revolution is more than 400 RPM for more than 0.6 s.

P1704

1. Clutch C1 apply control
2. C1 hydraulic pressure command value is more than 300 kPa (44 PSI).
3. Determined after 1 time lasting more than 0.3 s.

P1702, P1703

1. DTCs P1702, P1703 are Type C DTC.
2. No self learning function
3. No neutral control
4. No adaptive shift
5. Inhibit of Neutral control and garage shift control (N-D, D-N, N-R, R-N)

P1704

1. DTC P1704 is Type B DTC.
2. Torque limitation
3. The TCM turns OFF all solenoids.
4. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

P1702

1. DTC P1702 is Type C DTC.
2. Clutch C1 in neutral control
3. Clutch C1 pressure is more than 26 kPa (3.8 PSI).

P1703

1. DTC P1703 is Type C DTC.
2. Clutch C1 in neutral control
3. Clutch C1 hydraulic pressure is less than 350 kPa (51 PSI).

P1704

1. DTC P1704 is Type B DTC.
2. C1 hydraulic pressure command value is less than 300 kPa (44 PSI).

When attempting to set solenoid electrical DTCs, ensure the TCM is warmed up and the transmission is operated in 2nd gear long enough to ensure a 3°C (5°F) increase in TCM substrate temperature. This will place the TCM under the optimal conditions to test solenoid electrical DTCs.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

Command the Clutch Pressure Control Solenoid Valve 1 with a scan tool. The value should change from 0.0-1.0 A.

1. Perform the line pressure check. Refer to «LINE PRESSURE CHECK»(ref-653642-S38889312902014090100000) .
2. If the line pressure check fails, replace the control valve body.
3. Verify the line pressure check does not fail.
4. If the line pressure check fails, replace the replace the K71 Transmission Control Module.
5. Perform the «CONTROL SOLENOID VALVE INSPECTION (M36 AND MXE)»(ref-653642-S39433622442014090100000) .
6. If the inspection fails, replace the control valve body.
7. If all circuit test normal, replace the K71 Transmission Control Module.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P1731

1st Gear Ratio Incorrect - with Engine Brake

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 500 RPM for 2 s.
3. The transmission is not in emergency mode.
4. TCM communication is normal.
5. Transmission fluid temperature is higher than 20°C (68°F).
6. DTCs P0716. P0717, P0721 and P0722 are not set.

1. Driving in D range, 1st gear with engine break.
2. Engine torque is less than 1 Nm (0.75 lb ft).
3. Measured gear ratio deviates more than 20% from expected ratio.
4. Determined after 12 times lasting 1 s or more.

1. DTC P1731 is a Type C DTC
2. Torque limitation in "D" range 150 Nm (110 lb ft), in "R" range 170 Nm (125 lb ft).
3. The TCM freezes transmission adaptive functions.
4. The TCM turns OFF all solenoids.
5. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

1. DTC P1731 is a Type C DTC
2. Measured gear ratio deviates less than 4% from expected ratio.

Ensure the transmission fluid level, color and odor is correct and there are no leaks. If there are any other transmission DTCs set, diagnose those first.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

1. Perform the «LINE PRESSURE CHECK»(ref-653642-S38889312902014090100000) .
2. Perform the «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-653642-S41840466012014090100000) .
3. If all circuits test normal, replace the K71 Transmission Control Module. Verify the DTC does not reset.
4. If the DTC resets replace the control valve body.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P2716

Pressure Control Solenoid Valve 3 System Performance

DTC P2719

Pressure Control Solenoid Valve 3 System Performance

DTC P2720

Pressure Control Solenoid Valve 3 Control Circuit Low Voltage

DTC P2721

Pressure Control Solenoid Valve 3 Control Circuit High Voltage

P2716

1. The ignition voltage is between 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. DTCs P2720 and P2721 are not set.

P2719

1. The ignition voltage is between 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. The Automatic Transmission Fluid Temperature is more than 20°C (68°F)
7. SLC3 current is more than 0.85 A.
8. SLC3 current is not changed.

P2720

1. The ignition voltage is between 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. DTC P2721 is not set.

P2721

1. The ignition voltage is between 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. DTC P2720 is not set.

P2716

Deviation between commanded current and feedback current

P2719

The TCM detects the error current more than 80 mA for 2.75 ms.

P2720

The TCM detects at least 5 times less than 23 mA current consumption of the SLC3 control circuit for 100 ms.

P2721

The TCM detects at least 5 times more than 1.333 A current consumption of the SLC3 control circuit for 100 ms.

P2716, P2719

1. DTCs P2716 and P2719 are Type B DTCs.
2. The TCM turns OFF all solenoids.
3. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

P2720, P2721

1. DTCs P2720 and P2721 are Type B DTCs.
2. No self learning function
3. The TCM turns OFF all solenoids.
4. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

P2716, P2719

1. DTCs P2716 and P2719 are Type B DTCs.
2. The TCM detects the error current less than 50 mA for 2.75 ms.

P2720, P2721

1. DTCs P2720 and P2721 are Type B DTCs.
2. The current consumption of the SLC3 control circuit is 0.1-1.1 A for 500 ms.

When attempting to set solenoid electrical DTCs, ensure the TCM is warmed up and the transmission is operated in 2nd gear long enough to ensure a 3°C (5°F) increase in TCM substrate temperature. This will place the TCM under the optimal conditions to test solenoid electrical DTCs.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

Command the Clutch Pressure Control Solenoid Valve 3 with a scan tool. The value should change from 0.0-1.0 A.

1. Ignition OFF, remove the K71 Transmission Control Module.
2. Test for 5-5.6 ohms at 20°C (68°F) between the low reference circuit terminal 22 X2 and the voltage supply circuit terminal 14 X2.
3. If less than the specified range, test the wiring harness for internal short. If the circuit test normal, replace the Q27C Pressure Control Solenoid Valve 3.
4. Test for infinite resistance between each terminal and the low reference circuit terminal 22 X2 and also to the voltage supply circuit terminal 14 X2.
5. If less than the specified range, replace the wiring harness.
6. If all circuit test normal, perform the «CONTROL SOLENOID VALVE INSPECTION»(ref-653642-S39433622442014090100000) . Refer to «CONTROL SOLENOID VALVE INSPECTION (M36 AND MXE)»(ref-653642-S39433622442014090100000) .
7. If the inspection test normal, replace the control valve body.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P2725

Brake Band Pressure Control Solenoid Valve Control Circuit Shorted

DTC P2728

Brake Band Pressure Control Solenoid Valve Performance

DTC P2729

Brake Band Pressure Control Solenoid Valve Control Circuit Low Voltage

DTC P2730

Brake Band Pressure Control Solenoid Valve Control Circuit High Voltage

P2725

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. DTCs P2729 and P2730 are not set.

P2728

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. The automatic transmission fluid temperature is more than 20°C (68°F).
7. SLB1 current is more than 0.85 A.
8. SLB1 current is not changed.

P2729

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. DTC P2730 is not set.

P2730

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. DTC P2729 is not set.

P2725

Deviation between commanded current and feedback current.

P2728

The TCM detects the error current more than 80 mA for 2.75 ms.

P2729

The TCM detects at least 5 times less than 23 mA current consumption of the SLB1 control circuit for 100 ms.

P2730

The TCM detects at least 5 times more than 1.333 A current consumption of the SLB1 control circuit for 100 ms.

P2725, P2728

1. DTC P2725 and P2728 are Type B DTC.
2. The TCM turns OFF all solenoids.
3. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

P2729, P2730

1. DTCs P2729 and P2730 are Type B DTCs.
2. No self learning function.
3. The TCM turns OFF all solenoids.
4. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

P2725, P2728

1. DTC P2725 and P2728 are Type B DTC.
2. The TCM detects the error current less than 50 mA for 2.75 ms.

P2729, P2730

1. DTCs P2729 and P2730 are Type B DTCs.
2. The current consumption of the SLB1 control circuit is 0.1-1.1 A for 500 ms.

When attempting to set solenoid electrical DTCs, ensure the TCM is warmed up and the transmission is operated in 2nd gear long enough to ensure a 3°C (5°F) increase in TCM substrate temperature. This will place the TCM under the optimal conditions to test solenoid electrical DTCs.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES

Command the Shift Brake Pressure Control Solenoid Valve with a scan tool. The value should change from 0.0-1.0 A.

1. Ignition OFF, remove the K71 Transmission Control Module.
2. Test for 5-5.6 ohms at 20°C (68°F) between the low reference circuit terminal 16 X2 and the voltage supply circuit terminal 21 X2.
3. If less than the specified range, test the wiring harness for internal short. If the circuit test normal, replace the Q27E Pressure Control Solenoid Valve 5.
4. Test for infinite resistance between each terminal and the low reference circuit terminal 16 X2 and also to the voltage supply circuit terminal 21 X2.
5. If less than the specified range, replace the wiring harness.
6. If all circuit test normal, perform the «CONTROL SOLENOID VALVE INSPECTION (M36 AND MXE)»(ref-653642-S39433622442014090100000) .
7. If the inspection test normal, replace the control valve body.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC P2759

Torque Converter Clutch (TCC) Pressure Control Solenoid Valve Performance

DTC P2762

Torque Converter Clutch (TCC) Pressure Control Solenoid Valve Performance

DTC P2763

Torque Converter Clutch (TCC) Pressure Control Solenoid Valve Control Circuit High Voltage

DTC P2764

Torque Converter Clutch (TCC) Pressure Control Solenoid Valve Control Circuit Low Voltage

P2759

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. Transmission control module (TCM) communication is normal.
6. DTCs P2763 and P2764 are not set.

P2762

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. The Automatic Transmission Fluid Temperature is more than 20°C (68°F)
7. SLU current is more than 0.85 A.
8. SLU current is not changed.

P2763

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. DTC P2764 is not set.

P2764

1. The ignition voltage is 10.2-15.5 V.
2. The engine speed is greater than 400 RPM for 2 s.
3. The transmission is not in emergency mode.
4. Driving in D range.
5. TCM communication is normal.
6. DTC P2763 is not set.

P2759

Deviation between commanded current and feedback current

P2762

The TCM detects the error current more than 80 mA for 2.75 ms.

P2763

The TCM detects at least 5 times less than 23 mA current consumption of the SLU control circuit for 100 ms.

P2764

The TCM detects at least 5 times more than 1.333 A current consumption of the SLU control circuit for 100 ms.

P2759, P2762

1. DTCs P2759 and P2762 are Type B DTCs.
2. The TCM turns OFF all solenoids.
3. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

P2763, P2764

1. DTCs P2763 and P2764 are Type B DTCs.
2. No self learning function.
3. The TCM turns OFF all solenoids.
4. The TCM allows the vehicle after a stop to operate only in the second gear and "R" range.

P2759, P2762

1. DTCs P2759 and P2762 are Type B DTCs.
2. The TCM detects the error current less than 50 mA for 2.75 ms.

P2763, P2764

1. DTCs P2763 and P2764 are Type B DTCs.
2. The current consumption of the SLU control circuit is 0.1-1.1 A for 500 ms.

When attempting to set solenoid electrical DTCs, ensure the TCM is warmed up and the transmission is operated in 2nd gear long enough to ensure a 3°C (5°F) increase in TCM substrate temperature. This will place the TCM under the optimal conditions to test solenoid electrical DTCs.

POWERTRAIN DIAGNOSTIC TROUBLE CODE (DTC) TYPE DEFINITIONS

CONTROL MODULE REFERENCES for scan tool information

Command the TCC Solenoid Valve increase and decrease with a scan tool. The value should rise from 0.1-1.1 A and return to 0.1 A.

1. Ignition OFF, remove the K71 Transmission Control Module.
2. Test for 5-5.6 ohms at 20°C (68°F) between the low reference circuit terminal 4 X2 and the voltage supply circuit terminal 9 X2.
3. If less than the specified range, test the wiring harness for internal short. If the circuit test normal, replace the Q27D Pressure Control Solenoid Valve 4.
4. Test for infinite resistance between each terminal and the low reference circuit terminal 4 X2 and also to the voltage supply circuit terminal 9 X2.
5. If less than the specified range, replace the wiring harness.
6. If all circuit test normal, perform the «CONTROL SOLENOID VALVE INSPECTION»(ref-653642-S39433622442014090100000) . Refer to «CONTROL SOLENOID VALVE INSPECTION (M36 AND MXE)»(ref-653642-S39433622442014090100000) .
7. If the inspection test normal, replace the control valve body.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

DTC B270A 01

Park Lock Solenoid Control Circuit Short to Voltage

DTC B270A 02

Park Lock Solenoid Control Circuit Short to Ground

DTC B270A 04

Park Lock Solenoid Control Circuit Open

1. The ignition is in the ON position.
2. The brake pedal is pressed.
3. The transmission is in the PARK position.
4. The DTC runs continuously when the above conditions are met.

B270A 01

The body control module detects a short to voltage in the automatic transmission park lock control solenoid control circuit for 1 second.

B270A 02

The body control module detects a short to ground in the automatic transmission park lock control solenoid control circuit for 1 second.

B270A 04

The body control module detects an open in the automatic transmission park lock control solenoid control circuit for 1 second.

The body control module will not attempt to enable the voltage supply circuit of the automatic transmission park lock control solenoid until the next key cycle.

1. A current DTC B270A will clear when the malfunction is no longer present and the ignition switch is cycled.
2. A history DTC will clear after 100 ignition cycles with no current DTC active during the 100 ignition cycles.

CONTROL MODULE REFERENCES for scan tool information

1. Ignition OFF, disconnect the harness connector at the S3 shift lock actuator.
2. Ignition OFF, test for less than 1.0 ohms between the ground circuit terminal 2 and ground.
3. If greater than the specified range, test the ground circuit for an open/high resistance.
4. Install a test lamp between the ground circuit terminal 2 and the control circuit terminal 4.
5. Ignition ON, command the scan tool Shift Lock Solenoid Actuator ON and OFF. The test lamp should turn ON and OFF when changing between the commanded states.
6. If the test lamp is always ON, test the control circuit for short to voltage. If the circuit tests normal, replace the K9 Body Control Module.
7. If the test lamp is always OFF, test the control circuit for short to ground or an open/high resistance. If the circuit tests normal, replace the K9 Body Control Module.
8. If all circuits test normal, test or replace the S3 shift lock actuator.

Visual/Physical Inspection

Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Symptom List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

1. Fluid Diagnosis «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-653642-S41840466012014090100000) «AUTOMATIC TRANSMISSION FLUID LEAKS»(ref-653642-S09091551372014090100000) «FLUID LEAK DIAGNOSIS»(ref-653642-S18078315522014090100000)
2. Noise and Vibration Diagnosis «NOISE AND VIBRATION ANALYSIS»(ref-653642-S32382562112014090100000)
3. Symptom Not Found or No Symptom Detected «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-653642-S41840466012014090100000) «ROAD TEST»(ref-653642-S01991452742014090100000)

Scheme 9

The torque converter stator roller clutch can have two different malfunctions.

1. Inspect the control solenoid (w/body and TCM) valve assembly connectors and pins (A, B, C) for the following conditions: Damage Bent pins Debris Broken retaining tab Contamination
2. Ensure no metallic debris is inside the connectors near the terminal pins.
3. Inspect the control solenoid (w/body and TCM) valve assembly solenoid leads for contamination or metallic debris.
4. Inspect for oil leakage from any of the gaskets.

1. Perform the Diagnostic System Check - Vehicle prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. Diagnostic Procedure Instructions provides an overview of each diagnostic category.

Powertrain Diagnostic Trouble Code (DTC) Type Definitions

Control Module References for scan tool information

Note. You must perform the CIRCUIT/SYSTEM VERIFICATION before proceeding with circuit/system testing.

1. Ignition OFF, disconnect the X5 harness connector at the K9 Body Control Module.
2. Ignition ON, verify the sport mode LED is OFF.
3. If the sport mode LED does not turn OFF, test the control circuit for a short to voltage.

Note. You must perform the CIRCUIT/SYSTEM VERIFICATION before proceeding with circuit/system testing.

1. Ignition OFF, disconnect the S48C Multifunction Switch 1 - Instrument Panel harness connector.
2. Test for less than 5 ohms between S48C Multifunction Switch 1 - Instrument Panel terminal 2 and ground.
3. If not within the specified value, test the wiring harness for an open/high resistance.
4. Ignition ON, test for less than 5 ohms between S48C Multifunction Switch 1 - Instrument Panel terminal 6 and ground.
5. If not within the specified value, test the wiring harness for a short to voltage or an open/high resistance. If the circuit test normal, replace the K9 Body Control Module.
6. Ignition ON, observe the scan tool Suspension System Mode parameter while installing a 3 A fused jumper wire between the S48C Multifunction Switch 1 - Instrument Panel terminal 5 and ground. Verify the reading changes between Normal/Sport Mode.
7. If the parameter does not change between the specified values, test the wiring harness for short to voltage, short to ground or an open/high resistance. If the circuit test normal, replace the K9 Body Control Module.
8. Ignition OFF, connect a test lamp to S48C Multifunction Switch 1 - Instrument Panel terminal 6 and ground.
9. Ignition ON, the test lamp has to illuminate while installing a 3 A fused jumper wire between the S48C Multifunction Switch 1 - Instrument Panel terminal 5 and ground.
10. If the test lamp does not illuminate, test the sport mode LED signal circuit for a short to ground or an open/high resistance.
11. If the circuit test normal, replace the S48C Multifunction Switch 1 - Instrument Panel.

Inspect

Note. Due to the risk of overheating, checking at full load must not take longer than 5 seconds. Add a pause for cooling down. The oil level in the gearbox must be correct.

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. Raise the vehicle.
2. Remove the lower engine cover. WARNING: An electric fan under the hood can start up even when the engine is not running and can injure you. Keep hands, clothing and tools away from any underhood electric fan.
3. Remove the upper plug (A). (The front torque rod has been removed in the illustration to give a better view of the connections.)
4. Fit adapter (A) DT-8792301.
5. Fit DT-8791600 equipment (B) on connection (A).
6. Lower the car to the floor.
7. Connect the scan tool and check the oil temperature. NOTE: The oil temperature must be between 50°C (122°F) and 80°C (176°F).
8. Check the oil pressure in selector lever position "D". Start the engine. Move the selector lever to position "D". Check the oil pressure at idling speed and at full load - air conditioning and lighting disengaged. Desired value idling speed (foot brake not applied): 370-410 kPa (53.6-59.5 psi). Desired value full load: 1350-1460 kPa (195.8-211.7 psi). Switch off the engine after the check.
9. Raise the vehicle.
10. Remove the oil pressure gauge (B).
11. Remove the connection (A).
12. Refer to «FASTENER CAUTION»(ref-653635-S22306564902014090100000) . Fit the upper plug (A) with a new sealing ring. Refer to «FASTENER TIGHTENING SPECIFICATIONS»(ref-653642-S00347098112014090100000) and tighten to 10 Nm (7.4 lb ft) .
13. Remove the lower plug (B).
14. Fit adapter (A) DT-87 92 301.
15. Fit DT-8791600 equipment (B) on connection (A)
16. Lower the car to the floor.
17. Connect the scan tool and check the oil temperature. NOTE: The oil temperature must be between 50°C (122°F) and 80°C (176°F).
18. Check the oil pressure in selector lever position "R". Start the engine. Move the selector lever to position "R". Check the oil pressure at idling speed and at full load - air conditioning and lighting disengaged. Desired value idling speed (foot brake not applied): 570-660 kPa (82.7-95.7 psi). Desired value full load: 190-213 kPa (27.5-30.9 psi). Switch off the engine after the check.
19. Raise the vehicle.
20. Remove the oil pressure gauge (B).
21. Remove the connection (A).
22. Fit the lower plug (B) with a new sealing ring and tighten to 10 NM (7.4 lb ft) .
23. Lower the car to the floor.
24. Remove the scan tool.

Road Test

Note. The Road Test Procedure should be performed only as part of the Symptom Diagnosis. Refer to SYMPTOMS - AUTOMATIC TRANSMISSION .

The following test provides a method of evaluating the condition of the automatic transmission. The test is structured so that most driving conditions would be achieved. The test is divided into the following parts

1. Visual Inspection of Transmission Fluid Leaks
2. Electrical Function Check
3. Adaptive Learning
4. Confirm Customer Complaint by Driving
5. Check Oil Level and Oil Quality

Note. Complete the test in the sequence given. Incomplete testing cannot guarantee an accurate evaluation.

Before the road test, ensure the following

1. The engine is performing properly.
2. Tire pressure is correct.
3. Vent hose is correctly mounted

During the road test

1. Perform the test only when traffic conditions permit.
2. Operate the vehicle in a controlled, safe manner.
3. Observe all traffic regulations.
4. NOTE: Take along qualified help in order to operate the vehicle safely. View the scan tool data while conducting this test.
5. Observe any unusual sounds or smells.

After the road test, check the following

1. Inspect for proper transmission fluid level and check oil quality. Refer to «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-653642-S41840466012014090100000) .
2. Inspect for any diagnostic trouble codes (DTCs) that may have set during the testing. Refer to the applicable DTC.
3. Monitor the scan tool data for any abnormal readings or data.
4. Inspect for fluid leaks. Refer to «OIL LEAK DIAGNOSIS»(ref-653636-S39556486642014090100000) .

1. Inspect for aftermarket devices which could affect the operation of the automatic transmission shift lock control. Refer to «CHECKING AFTERMARKET ACCESSORIES»(ref-653659-S25218301212014090100000) .
2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Refer to a symptom diagnostic procedure in order to diagnose the symptom

TRANSMISSION CONTROL LEVER MALFUNCTION

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) prior to using this diagnostic procedure.
2. Review «STRATEGY BASED DIAGNOSTICS»(ref-653639-S15685196292014090100000) for an overview of the diagnostic approach.
3. «DIAGNOSTIC PROCEDURE INSTRUCTIONS»(ref-653639-S39457439302014090100000) provides an overview of each diagnostic category.

CONTROL MODULE REFERENCES for scan tool information

1. Ignition OFF, disconnect the harness connector at the S3 shift lock actuator.
2. Ignition OFF, test for less than 1.0 ohms between the ground circuit terminal 2 and ground.
3. If greater than the specified range, test the ground circuit for an open/high resistance.
4. Install a test lamp between the ground circuit terminal 2 and the control circuit terminal 4.
5. Ignition ON, command the scan tool Shift Lock Solenoid Actuator ON and OFF. The test lamp should turn ON and OFF when changing between the commanded states.
6. If the test lamp is always ON, test the control circuit for short to voltage. If the circuit tests normal, replace the K9 Body Control Module.
7. If the test lamp is always OFF, test the control circuit for short to ground or an open/high resistance. If the circuit tests normal, replace the K9 Body Control Module.
8. If all circuits test normal, test or replace the S3 shift lock actuator.
