Automatic Transmission: Other Saab 9-5 II

Shifting

The TCM can determine whether to leave a gear engaged or to change up or down. What it does is determined mainly by the gear that is currently engaged, the speed of the output shaft and the position of the accelerator pedal. The TCM changes gear by applying or releasing a friction element in the transmission. The application is regulated with PWM from the respective solenoid.

The gear can also be changed manually with the selector lever in D position if using the Tap Up/Tap Down switch. The switch is hardwired to the BCM which converts the information into a HSCAN message that is used by the TCM.

The maximum shift speed is at 7000 rpm.

Lock Up

The torque converter clutch is activated at a steady speed when there is no need of torque amplification. If the brakes are applied or acceleration increases, the function will be deactivated.

Safety Features

To protect the transmission there are temperature programs to prevent overheating. The TCM can choose to raise the shift points and activate lock up more often if the oil temperature is too high.

The reverse gear will not be activated if the car is travelling faster than 7 km/h (4 mph). If the power supply to the solenoids fails, it is still possible to drive the car. The gear position D/M gives 2nd gear and P-R-N will work as usual. In case of a major fault in the transmission, mechanical or electrical, the TCM will cut the supply to the solenoids in a controlled manner (limp home).

In case the TCM detects a failure it will go into emergency mode.

Special Gear Change Program

If an uphill gradient is detected, the gears will change at higher engine speeds and each gear will remain engaged for longer periods.

The Sport Mode can be engaged by a switch. Upon detecting the sport mode request TCM adapts the shift lines in order to enable a more progressive driving.

Mechanical Components

1. Torque converter with lock-up clutch
2. 2 planetary gear units, of which the rear is double.
3. 3 disc clutches
4. 1 band type brake
5. 1 multi-disc brake
6. 1 free wheel
7. Final drive with differential

Scheme 117

1. Torque converter housing
2. Torque converter clutch
3. Turbine
4. Impeller
5. Stator
6. Free wheel
7. Input shaft

Scheme 118

1. Torque Converter
2. Valve housing (2a) Solenoid valve (2b) Linear solenoid (2c) Control valve
3. Clutch, brake
4. Oil Cooler
5. Oil Pump
6. Planetary gear
7. Oil Pressure
8. Gearbox oil, inlet
9. Gearbox oil, return
10. Operating pressure
11. Lubrication
12. Oil flow to pump

Control System

1. Linear solenoids
2. PWM solenoids
3. Speed sensors
4. Temperature Sensor
5. Transmission Control Module including gear position sensor
6. Gear shift lever
7. Sport Mode Switch

General

The changing duration is calculated in real time by comparing the speeds of the input shaft and output shaft. The control module knows the gear ratio for the current gear and the target gear and can follow the change in gear ratio until the changing process is complete. The time it took to change gear is then compared with the desired value for the gear change and an adaptation is made.

The adaptation is done by correcting the requested pressure for the applied friction element solenoid and the correction is then used the next time a change is made between these gears. The adaptation value is saved in a non-volatile memory and must be zeroed using a scan tool each time the TCM, transmission or valve housing is changed and after SPS programming.

After zeroing with a scan tool, it will usually only require a road test, see below, for the TCM to be able to adapt itself to the new conditions.

Transmission Indicators and Messages

The following transmission-related indicators and messages may be displayed on the Driving Information Center (DIC). For a complete listing and description of all vehicle indicators and messages, refer to INDICATOR/WARNING MESSAGE DESCRIPTION AND OPERATION .

TRANSMISSION HOT IDLE ENGINE: This message is displayed if the temperature exceeds 150°C for longer than 2 seconds.

SERVICE TRANSMISSION: This message displays when there is a problem with the transmission.

CHANGE TRANSMISSION FLUID: This message displays when the transmission oil needs to be changed.

Scheme 119

1. Rotating magnet
2. Stator magnet
3. IC circuit, Hall sensor
4. Coil
5. Magnetic field

The TCM is mounted directly on top of the transmission. The selector lever is integrated in the control module. The TCM is mounted so that the selector lever shaft goes through the control module. The selector lever position is calibrated with a scan tool, there is no mechanical adjustment.

An exterior 16-pin connector connects to the car's electrical system. Underneath the control module is another connector (22-pin) that connects directly to the transmission. The TCM makes contact with all the transmission solenoids and sensors here.

Note. Magnetic fields from e.g. magnets and from high-current cables, such as starter cables and cables to auxiliary equipment, can interfere with the gear position sensor. A rule of thumb is max 1A per mm in distance from the control module. A starter cable carrying a current of 200A must therefore be kept at least 20 cm away from the control module.

The TCM has a microprocessor with clock, RAM memory and a programmable ROM. An internal bus connects the processor and memory with the I/O unit. The I/O unit reads values from the A/D converter for analogue inputs, digital inputs and bus, as well as activates the transistors' output stages.

Adaptive values are saved in a non-volatile memory (ROM). When changing transmission, these values must be zeroed using scan tool. After changing TCM they will be zeroed automatically after adding the control module using the scan tool.

Scheme 120

1. On
2. Off

1. (s1) Solenoid Valve S1
2. (s2) Solenoid Valve S2

The normally open solenoid valve is fitted in the gearbox valve housing and is used by the TCM for activating C2. The pressure to SLC2 is then increased from system pressure to D-pressure. The valve is also used to supply pressure to the brake B2 for engine braking in 1st gear.

The control module activates the valve by applying B+ to it. The valve is powered from control module pin 5 in the connector in direct contact with the transmission on the bottom of the control module. The valve is grounded in the valve housing.

Scheme 121

1. On
2. Off

1. (s1) Solenoid Valve S1
2. (s2) Solenoid Valve S2

The normally closed solenoid valve is mounted in the transmission valve housing and is used together with S1 to apply pressure to brake B2 for engine braking in 1st gear.

The control module activates the valve by applying B+ to it. The valve is powered from control module pin 2 in the connector in direct contact with the transmission on the bottom of the control module. The valve is grounded in the valve housing.

Scheme 122

1. On
2. Off
3. Ex

1. (slc1) Solenoid Valve SLC1
2. (slc2) Solenoid Valve SLC2
3. (slc3) Solenoid Valve SLC3
4. (slb1) Solenoid Valve SLB1

The PWM controlled solenoid valve is mounted in the transmission valve housing and controls the pressure in brake B1. The valve is active in gear positions P, R, N, D (gears 1, 3, 4 and 5).

The control module activates the valve by pulsing it with B+ (300 Hz PWM). The valve is powered from control module pin 21 in the connector that makes contact directly with the transmission on the bottom of the control module. The valve is grounded from pin 16. The current varies between 0-1000mA. The solenoid is normally open and the hydraulic pressure drops as the current increases.

Scheme 123

1. On
2. Off
3. Ex

1. (slc1) Solenoid Valve SLC1
2. (slc2) Solenoid Valve SLC2
3. (slc3) Solenoid Valve SLC3
4. (slb1) Solenoid Valve SLB1

The PWM controlled solenoid valve is mounted in the transmission valve housing and controls the pressure in clutch C1. The valve is active in gear positions P, R, N, D (gears 5 and 6).

The control module activates the valve by pulsing it with B+ (300 Hz PWM). The valve is powered from control module pin 11 in the connector that makes contact directly with the transmission on the bottom of the control module. The valve is grounded from pin 10. The current varies between 0-1000 mA. The solenoid is normally open and the hydraulic pressure drops as the current increases.

Scheme 124

1. On
2. Off
3. Ex

1. (slc1) Solenoid Valve SLC1
2. (slc2) Solenoid Valve SLC2
3. (slc3) Solenoid Valve SLC3
4. (slb1) Solenoid Valve SLB1

The PWM controlled solenoid valve is mounted in the transmission valve housing and controls the pressure in clutch C2. The valve is active in gear positions P, R, N, D (gears 1, 2 and 3).

The control module activates the valve by pulsing it with B+ (300 Hz PWM). The valve is powered from control module pin 17 in the connector that makes contact directly with the transmission on the bottom of the control module. The valve is grounded from pin 18. The current varies between 0-1000mA. The solenoid is normally open and the hydraulic pressure drops as the current increases.

Scheme 125

1. On
2. Off
3. Ex

1. (slc1) Solenoid Valve SLC1
2. (slc2) Solenoid Valve SLC2
3. (slc3) Solenoid Valve SLC3
4. (slb1) Solenoid Valve SLB1

The PWM controlled solenoid valve is mounted in the transmission valve housing and controls the pressure in clutch C3. The valve is active in gear positions P, N, D (gears 1, 2, 4 and 6).

The control module activates the valve by pulsing it with B+ (300 Hz PWM). The valve is powered from control module pin 14 in the connector that makes contact directly with the transmission on the bottom of the control module. The valve is grounded from pin 22. The current varies between 0-1000mA. The solenoid is normally open and the hydraulic pressure drops as the current increases.

Scheme 126

1. On
2. Off
3. Ex

1. (slu) Solenoid Valve SLU
2. (slt) Solenoid Valve SLT

The PWM controlled solenoid valve is mounted in the transmission valve housing and controls the transmission system pressure. The value is controlled so that it is not higher than what is currently needed for any friction element. Brake B2 does not have its own pressure control valve and is therefore supplied by SLT.

The control module activates the valve by pulsing it with B+ (300 Hz PWM). The valve is powered from control module pin 3 in the connector that makes contact directly with the transmission on the bottom of the control module. The valve is grounded from pin 1. The current varies between 0-1000mA. The solenoid is normally open and the hydraulic pressure drops as the current increases.

Scheme 127

1. On
2. Off
3. Ex

1. (slu) Solenoid Valve SLU
2. (slt) Solenoid Valve SLT

The solenoid valve is mounted in the transmission valve housing.

The valve controls the pressure used for the torque converter clutch. The pressure is modulated so that full, partial or no engagement is achieved.

The control module activates the valve by pulsing it with B+ (300 Hz PWM). The valve is powered from control module pin 9 in the connector that makes contact directly with the transmission on the bottom of the control module. The valve is grounded from pin 4. The current varies between 0-1000mA. The solenoid is normally closed and the hydraulic pressure rises as the current increases.

Scheme 128

1. Output shaft gear with output speed sensor
2. C2 clutch drum with input speed sensor

The sensor is mounted inside the valve housing in the front part of the transmission and measures the speed of the transmission input shaft. This value is used by TCM to calculate the actual gearchange time and to regulate lock up. The Hall sensor measures a toothed wheel with 36 teeth.

The sensor is powered from TCM pin 12 and is grounded through pin 13.

Scheme 129

1. Output shaft gear with output speed sensor
2. C2 clutch drum with input speed sensor

The sensor is mounted inside the valve housing in the rear part of the transmission and measures the transmission output shaft speed. This value is used by TCM mainly to determine the gearchange points. The hall sensor measures a toothed wheel with 56 teeth.

The sensor is powered from TCM pin 19 and is grounded through pin 20.

Transmission Oil Temperature Sensor

The temperature sensor is mounted in the transmission valve housing and informs the control module about the current temperature. The value is used to correct the PWM ratio to the solenoids so that the gear changes are not affected by the viscosity of the oil. It is also used to activate the special gearchange program in case of overheating.

Scheme 130

The sensor comprises an NTC resistor built into a plastic casing. The NTC resistor characteristic means that the resistance drops as the temperature rises. The NTC resistor is supplied with 5V through a pull up from control module pin 8 and is grounded through pin 7.

Scheme 131

The AF 40-6 (1) automatic gearbox is an electronic, 6-speed automatic gearbox with lockup function. The gearbox is fitted directly against the engine and has a final drive gear with integrated differential. The power unit is transverse mounted with all-wheel drive. Gear positions P-R-N-D are selected with the selector lever mounted in the centre console. Manual up/downshifting is possible.

Gearbox functions can be divided into three parts

1. Mechanical
2. Hydraulic
3. Control System

Mechanical

The main mechanical components of the AF40-6 automatic transmission

1. Torque converter with lock-up clutch
2. 2 planetary gear units, of which the rear is double
3. 3 disc clutches
4. 1 band type brake
5. 1 multi-disc brake
6. 1 free wheel
7. Final drive with differential

Scheme 132

The transmission is electronically controlled by a control unit (TCM, Transmission Control Module). The TCM (1) is mounted directly on top of the transmission (2) and has one connector to the car's electrical system and one to the transmission. The gear position sensor is Hall type and integrated in the control module. The TCM is mounted so that the selector lever shaft goes through the control module. The gear lever sensor position is calibrated in position N with a scan tool, there is no mechanical adjustment. TCM controls the solenoids to maintain or change gear. The solenoids are controlled with PWM (Pulse Width Modulation) to achieve a variable flow of oil.

The determining factors for changing gear are two values; current gear and target gear. Current gear is the one engaged at the moment and the target gear is the one TCM wants to change to. As long as these to values are the same there will be no gear change. Gear changing is initiated only when the target gear differs from the current gear. It is mainly the vehicle speed and acceleration that determines the target gear in automatic transmissions. The vehicle speed is taken from a special sensor, output speed, while the acceleration is taken from the engine management system (ECM) via the high speed bus.

Gear changing must also follow a permitted schedule. If a direct change to the target gear is not present in the schedule, there will be an intermediate gear change. For example, if the vehicle is driven in fifth gear and the accelerator pedal suddenly indicates second gear as target gear (kickdown), shifting is from fifth to third and third to second. This is because shifting directly from fifth gear to second gear is not allowed.

When a gear change is carried out, TCM will calculate a requested pressure for each solenoid circuit. The pressure is converted to a requested current that later results in a PWM ratio. The requested pressure is modulated according to a predetermined procedure so that the gear change is made comfortable without unnecessary wear. Current engine torque taken from ECM via the high speed bus is used for this purpose. A higher pressure is required for higher engine torque.

TCM reads the resulting current to each solenoid and can finely adjust the PWM ratio so that the requested pressure (current) agrees with the actual current. The transmission does not have a pressure sensor so current pressure cannot be sent back to the control system. For this reason, the solenoids are calibrated very precisely.

Manual gear changing can be accomplished with the selector lever in position D using the up/down switch in the lever. A manual gear change must be fully completed before TCM will accept a new change command. The current gear is shown in the driver information center (DIC). The highest permitted gear for start is third. For safety's sake, there is an automatic downshift from sixth, fifth and fourth after kickdown if engine speed is below 2000 rpm.

TCM sends continuous information on the high speed bus concerning the engine torque allowed by the transmission. When changing gear this value drops and ECM limits engine torque if it exceeds this value.

The torque converter clutch is activated at steady speed in gears 3-6 when there is no need for any torque amplification. The slipping in procedure is regulated by comparing the speed on the input shaft with the engine speed obtained from ECM via the high speed bus. Lock up will not work at temperatures below 15°C (56°F). If the brake is depressed or acceleration increases, the function will be activated.

A reverse detent function prevents reverse gear being engaged if the car is travelling faster than 7 km/h when the selector lever is moved from N to R. Overrevving in gear position M will be prevented by not allowing changing down to take place if the speed is too high.

For high engine loads without a corresponding increase in speed one of two hill-climbing programs will be chosen. Gear changing is done at higher engine speeds and the gear will remain engaged for longer periods until the extra load ceases. These gearchange programs are used to avoid changing up and down unnecessarily, e.g. when driving up long inclines with trailer and to avoid overheating the transmission oil. The Sport Mode can be engaged by a switch. Upon detecting the sport mode request TCM adapts the shift lines in order to enable a more progressive driving. Special gear change programs are not activated at speeds above 150 km/h (93 mph). If a special gear change program is active when the speed increases to over 150 km/h (93 mph), the program will continue, however, until the load has normalized.

Limp Home

If the power supply to TCM or to the solenoids is cut, the car can still be driven. Gear position D/M will give 2nd gear and P-R-N will work as normal but the gear will be engaged roughly as there is no regulation.

In case of a major fault in the transmission, mechanical or electrical, TCM will cut the supply to the solenoids in a controlled manner. In most cases, the control module will attempt to maintain the current gear until the car has stopped. Subsequently, the control module will attempt to engage 2nd gear if D/M is selected. After this, the supply to the solenoids will be cut and the transmission will lose all electrical control.

If an invalid gear ratio or the wrong gear is detected, the engine torque will be limited to 170 Nm in reverse and 150 Nm forward. For other faults, the torque will be limited to higher values depending on failure.

Towing

The car may only be towed with the front pointing in the direction of travel. The selector lever must be in position N. National regulations concerning towing speeds must be adhered to. If legislation allows, the highest permitted towing speed is 50 km/h (30 mph) with all four wheels on the ground. The longest permitted towing distance is 50 km (30 miles). If the car should require towing for longer distances as 50 km (30 miles), the front wheels must be raised from the ground. If the front wheels has been raised, the highest permitted towing speed is 50 km/h (30 mph).

The engine cannot be started by pushing or towing the car.

The automatic transmission park lock control system is a safety system that prevents accidental shifting from the PARK position. The driver must depress the brake pedal before the park lever can be moved from the PARK position. The system consists of the following components

1. The automatic transmission park lock solenoid (serviced as the automatic transmission shift lock actuator), is located within the floor shift control assembly.
2. The body control module, which controls the voltage supply circuit of the park lock control solenoid.
3. The engine control module.

The body control module controls the voltage to the park lock control solenoid through the park lock control solenoid controlled voltage circuit. The following conditions must be met before the body control module will supply voltage to the park lock solenoid

1. The ignition is in the ON position.
2. The engine control module sends an input via GMLAN serial data to the body control module indicating the transmission is in the PARK position.
3. The body control module determines the brake pedal is applied according the brake pedal position.

Since the park lock control solenoid is permanently grounded, the body control module supplies voltage to the automatic transmission park lock control solenoid, unlocking the park lever allowing the driver to move the park lever out of the PARK position as the solenoid energizes. When the brake pedal is not applied, the body control module turns the control voltage output of the park lock control solenoid OFF, de-energizing the park lock control solenoid. The de-energized solenoid mechanically locks the park lever in the PARK position.

Fault code index

FAULT CODE INDEX

Electrical Information Reference

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

Circuit/System Verification

1. Verify the transmission fluid level, color and odor is correct.
2. Review the Freeze Frame when the DTC set.
3. If the engine coolant temperature (ECT) was above 125°C (257°F) when the DTC set, refer to «ENGINE OVERHEATING»(ref-653648-S31146724822014090100000) and correct that concern first.

Repair Instructions

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-653642-S41840466012014090100000)
2. «TRANSMISSION FLUID COOLER HOSE/PIPE QUICK-CONNECT FITTING DISCONNECTION AND CONNECTION»(ref-653642-S16838510782014090100000)
3. Control valve body-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) .
4. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) .
5. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Ignition On, observe the DTC information with a scan tool. Verify no TCM or communication DTCs are set.
2. If any TCM or communication DTCs are set, refer to «Fault code index»(ref-653642-S15860119912014111000000) for further diagnosis.
3. Raise the drive wheels.
4. WARNING: Support the lower control arms in the normal horizontal position in order to avoid damage to the drive axles. Do not operate the vehicle in gear with the wheels hanging down at full travel. Support the lower control arms so that the drive axles are in a horizontal position.
5. Engine running, place the transmission into 2nd gear.
6. Observe the scan tool Vehicle Speed parameter. The following should display a similar vehicle speed once the drive wheels are at a speed above 5 km/h (3 MPH): The scan tool Vehicle Speed parameter The odometer value
7. Operate the vehicle within the conditions for running the DTC to verify the DTC does not reset. You may also operate the vehicle within the conditions that you observed from the Freeze Frame/Failure Records data.
8. If the DTC resets, replace the ECM.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. ECM or TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
2. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

1. Engine running. Let the engine run for at least 1 min.
2. Ignition OFF for at least 30 s to allow for the complete shutdown of the TCM.
3. Ignition ON, verify that DTC P0602 is not set.
4. If the DTC is set, program the TCM. If the DTC resets, replace the TCM.
5. Check the DTC Info with a scan tool. Diagnostic trouble codes P0601, P0603 and P0604 must not be activated.
6. If a DTC sets, replace the TCM.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for TCM replacement, setup, and programming.
2. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

Note. Correct any engine controls DTCs before diagnosing TCM DTCs.

DTC P0700 is an informational diagnostic trouble code. If there are no engine controls DTCs, refer to Fault code index for diagnosis of TCM DTCs.

Transmission Range Switch

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. If there are any other transmission DTCs set, diagnose those DTCs first. Refer to «Fault code index»(ref-653642-S15860119912014111000000) .
2. NOTE: It is especially important to closely observe the Park and Neutral to Drive transitional positions while moving the shift lever and observing for possible misalignment or slack in the shifter mechanism. Ignition ON, observe the scan tool Transmission Range Switch parameter while slowly moving the gear shift lever from Park and through all ranges. Verify the gear shift lever position matches the scan tool parameter.
3. If not within the specified value, refer to «RANGE SELECTOR LEVER CABLE ADJUSTMENT»(ref-653642-S17011504072014090100000) and «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .
4. Ignition ON, observe the scan tool Transmission Range Switch parameter while slowly moving the gear shift lever from Park and through all ranges. Verify the gear shift lever position matches the scan tool parameter.
5. If not within the specified value, replace the K71 Transmission Control Module.
6. Operate the vehicle within the conditions for running the DTC to verify the DTC does not reset. You may also operate the vehicle within the conditions that you observed from the Freeze Frame/Failure Records data.
7. If the DTC resets, replace the K71 Transmission Control Module.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

TCM-Refer to CONTROL MODULE REFERENCES for replacement, setup and programming.

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Perform the «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-653642-S41840466012014090100000) to verify correct fluid level.
2. Engine idling at operating temperature, observe the scan tool Transmission Fluid Temperature parameter. The reading should be between -40 to +215°C (-40 to +488°F) and change.
3. Operate the vehicle at about 60 km/h (37 MPH) for 10 min. Verify the scan tool Transmission Fluid Temperature parameter varies by more than 2°C (3.5°F) to verify that the sensor is not stuck.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Wiring harness-Refer to «AUTOMATIC TRANSMISSION WIRING HARNESS REPLACEMENT»(ref-653642-S35243757312014090100000) for replacement.
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

Transmission Input Shaft Sensor

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Engine idling, observe the scan tool Transmission ISS parameter while varying the engine speed. The Transmission ISS parameter should change with the engine speed and not drop out.
2. Operate the vehicle within the conditions for running the DTC to verify the DTC does not reset. You may also operate the vehicle within the conditions that you observed from the Freeze Frame/Failure Records data.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Automatic transmission replacement-Refer to «TECHNICAL DATA»(ref-653635-S21313218492014090100000) .
2. Control valve body-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement.
3. Wiring harness-Refer to «AUTOMATIC TRANSMISSION WIRING HARNESS REPLACEMENT»(ref-653642-S35243757312014090100000) for replacement.
4. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
5. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

Transmission Output Shaft Sensor

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Operate the vehicle at 16-32 km/h (10-20 MPH) while observing the scan tool Transmission OSS parameter. The Transmission OSS should vary with the vehicle speed and not drop out.
2. Operate the vehicle within the conditions for running the DTC to verify the DTC does not reset. You may also operate the vehicle within the conditions that you observe from the Freeze Frame/Failure Records data.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Automatic transmission replacement-Refer to «TECHNICAL DATA»(ref-653635-S21313218492014090100000) .
2. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) .
3. Wiring harness-Refer to «AUTOMATIC TRANSMISSION WIRING HARNESS REPLACEMENT»(ref-653642-S35243757312014090100000) .
4. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) .
5. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Verify the transmission fluid level, color and odor is correct.
2. Operate the vehicle to induce a shift from fifth to sixth gear while observing the following scan tool parameters. The scan tool parameters has to change the proper value referring to the current gear, compare the proper values with: transmission system description and operation. Refer to «TRANSMISSION SYSTEM DESCRIPTION AND OPERATION (M36 AND MXE)»(ref-653642-S13459438242014090100000) . Perform this action 2 times. Clutch Pressure Control Solenoid Valve 1 Current Clutch Pressure Control Solenoid Valve 2 Current Clutch Pressure Control Solenoid Valve 3 Current Brake Band Pressure Control Solenoid Valve Current Shift Solenoid Valve 1 Shift Solenoid Valve 2
3. If the scan tool parameter does not change the proper value and no other DTCs than P0729, P0731, P0732, P0733, P0734, P0735, P0736, P0780, P1731 is set, go to «CIRCUIT/SYSTEM TESTING»(ref-653642-S32417475762014090100000) .
4. If any other DTC is set, diagnose that DTC first.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement, setup, and programming.
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Verify the transmission fluid level, color and odor is correct.
2. Operate the vehicle to induce a shift from fifth to sixth gear while observing the following scan tool parameters. The scan tool parameters have to change the proper value referring to the current gear. Compare the proper values with: «TRANSMISSION SYSTEM DESCRIPTION AND OPERATION (M36 AND MXE)»(ref-653642-S13459438242014090100000) . Perform this action 2 times. Clutch Pressure Control Solenoid Valve 1 Current Clutch Pressure Control Solenoid Valve 2 Current Clutch Pressure Control Solenoid Valve 3 Current Brake Band Pressure Control Solenoid Valve Current Shift Solenoid Valve 1 Shift Solenoid Valve 2
3. If the scan tool parameter does not change the proper value and no other DTCs than P0729, P0731, P0732, P0733, P0734, P0735, P0736, P0780, P1731 is set, go to «CIRCUIT/SYSTEM TESTING»(ref-653642-S04170450402014090100000) .
4. If any other DTC is set, diagnose that DTC first.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement, setup, and programming.
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Verify the transmission fluid level, color and odor is correct.
2. Operate the vehicle to induce a shift from fifth to sixth gear while observing the following scan tool parameters. The scan tool parameters has to change the proper value referring to the current gear, compare the proper values with: «TRANSMISSION SYSTEM DESCRIPTION AND OPERATION (M36 AND MXE)»(ref-653642-S13459438242014090100000) . Perform this action 2 times. Clutch Pressure Control Solenoid Valve 1 Current Clutch Pressure Control Solenoid Valve 2 Current Clutch Pressure Control Solenoid Valve 3 Current Brake Band Pressure Control Solenoid Valve Current Shift Solenoid Valve 1 Shift Solenoid Valve 2
3. If the scan tool parameter does not change the proper value and no other DTCs than P0729, P0731, P0732, P0733, P0734, P0735, P0736, P0780, P1731 is set, go to «CIRCUIT/SYSTEM TESTING»(ref-653642-S18795359192014090100000) .
4. If any other DTC is set, diagnose that DTC first.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement, setup, and programming.
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Verify the transmission fluid level, color and odor is correct.
2. Operate the vehicle to induce a shift from fifth to sixth gear while observing the following scan tool parameters. The scan tool parameters has to change the proper value referring to the current gear, compare the proper values with: «TRANSMISSION SYSTEM DESCRIPTION AND OPERATION (M36 AND MXE)»(ref-653642-S13459438242014090100000) . Perform this action 2 times. Clutch Pressure Control Solenoid Valve 1 Current Clutch Pressure Control Solenoid Valve 2 Current Clutch Pressure Control Solenoid Valve 3 Current Brake Band Pressure Control Solenoid Valve Current Shift Solenoid Valve 1 Shift Solenoid Valve 2
3. If the scan tool parameter does not change the proper value and no other DTCs than P0729, P0731, P0732, P0733, P0734, P0735, P0736, P0780, P1731 is set, go to «CIRCUIT/SYSTEM TESTING»(ref-653642-S15270814672014090100000) .
4. If any other DTC is set, diagnose that DTC first.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement, setup, and programming.
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Verify the transmission fluid level, color and odor is correct.
2. Operate the vehicle to induce a shift from fifth to sixth gear while observing the following scan tool parameters. The scan tool parameters has to change the proper value referring to the current gear, compare the proper values with: «TRANSMISSION SYSTEM DESCRIPTION AND OPERATION (M36 AND MXE)»(ref-653642-S13459438242014090100000) . Perform this action 2 times. Clutch Pressure Control Solenoid Valve 1 Current Clutch Pressure Control Solenoid Valve 2 Current Clutch Pressure Control Solenoid Valve 3 Current Brake Band Pressure Control Solenoid Valve Current Shift Solenoid Valve 1 Shift Solenoid Valve 2
3. If the scan tool parameter does not change the proper value and no other DTCs than P0729, P0731, P0732, P0733, P0734, P0735, P0736, P0780, P1731 is set, go to «CIRCUIT/SYSTEM TESTING»(ref-653642-S22352780882014090100000) .
4. If any other DTC is set, diagnose that DTC first.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement, setup, and programming.
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Verify the transmission fluid level, color and odor is correct.
2. Operate the vehicle to induce a shift from fifth to sixth gear while observing the following scan tool parameters. The scan tool parameters has to change the proper value referring to the current gear, compare the proper values with: transmission system description and operation. Refer to «TRANSMISSION SYSTEM DESCRIPTION AND OPERATION (M36 AND MXE)»(ref-653642-S13459438242014090100000) . Clutch Pressure Control Solenoid Valve 1 Current Clutch Pressure Control Solenoid Valve 2 Current Clutch Pressure Control Solenoid Valve 3 Current Brake Band Pressure Control Solenoid Valve Current Shift Solenoid Valve 1 Shift Solenoid Valve 2
3. If the scan tool parameter does not change the proper value and no other DTCs than P0729, P0731, P0732, P0733, P0734, P0735, P0736, P0780, P1731 is set, go to «CIRCUIT/SYSTEM TESTING»(ref-653642-S11167517282014090100000) .
4. If any other DTC is set, diagnose that DTC first.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement, setup, and programming.
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Verify the transmission fluid level, color and odor is correct.
2. Operate the vehicle to induce a shift from fifth to sixth gear while observing the following scan tool parameters. The scan tool parameters has to change the proper value referring to the current gear, compare the proper values with: transmission system description and operation. Refer to «TRANSMISSION SYSTEM DESCRIPTION AND OPERATION (M36 AND MXE)»(ref-653642-S13459438242014090100000) . Perform this action 2 times. Clutch Pressure Control Solenoid Valve 1 Current Clutch Pressure Control Solenoid Valve 2 Current Clutch Pressure Control Solenoid Valve 3 Current Brake Band Pressure Control Solenoid Valve Current Shift Solenoid Valve 1 Shift Solenoid Valve 2
3. If the scan tool parameter does not change the proper value and no other DTCs than P0729, P0731, P0732, P0733, P0734, P0735, P0736, P0780, P1731 is set, go to «CIRCUIT/SYSTEM TESTING»(ref-653642-S09385325242014090100000) .
4. If any other DTC is set, diagnose that DTC first.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement, setup, and programming.
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

Operate the vehicle in drive with the calculated throttle position greater than 8% and ensure TCC is commanded ON and OFF a minimum of 5 times.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Perform the torque converter diagnosis. Refer to «TORQUE CONVERTER DIAGNOSIS»(ref-653642-S09598861692014090100000) .
2. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement, setup, and programming.
3. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
4. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

Line Pressure Control Solenoid Valve

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Ensure the transmission fluid temperature is between 50-80°C (122-176°F).
2. Operate the vehicle in 2nd gear long enough to ensure at least a 3°C (5° F) rise in transmission fluid temperature, then operate the vehicle in Park for 5 s.
3. Observe the scan tool's Line Pressure Control Solenoid Current parameter. The reading should be between 0.1 and 1.1 A.
4. If the parameter in not within specified range or if the DTC resets, go to «CIRCUIT/SYSTEM TESTING»(ref-653642-S19810365942014090100000) .

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement, setup, and programming.
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .
4. Wiring harness-Refer to «AUTOMATIC TRANSMISSION WIRING HARNESS REPLACEMENT»(ref-653642-S35243757312014090100000) for replacement.

Pressure Control Solenoid Valve

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Ensure the transmission fluid temperature is between 50-80°C (122-176° F).
2. Operate the vehicle in 2nd gear long enough to ensure at least a 3°C (5° F) rise in transmission fluid temperature, then operate the vehicle in Park for 5 s.
3. Observe the scan tool's Clutch Pressure Control Solenoid Valve 1 parameter. The reading should be between 0.1 and 1.1 A.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement, setup, and programming.
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .
4. Wiring harness-Refer to «AUTOMATIC TRANSMISSION WIRING HARNESS REPLACEMENT»(ref-653642-S35243757312014090100000) for replacement.

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Verify the transmission fluid level, color and odor is correct.
2. Operate the vehicle to induce a shift from fifth to sixth gear while observing the following scan tool parameters. Perform this action 2 times. Clutch Pressure Control Solenoid Valve 1 Current Clutch Pressure Control Solenoid Valve 2 Current Clutch Pressure Control Solenoid Valve 3 Current Brake Band Pressure Control Solenoid Valve Current Shift Solenoid Valve 1 Shift Solenoid Valve 2
3. If the scan tool parameter does not change the proper value and no other DTCs than P0729, P0731, P0732, P0733, P0734, P0735, P0736, P0780, P1731 is set, go to «CIRCUIT/SYSTEM TESTING»(ref-653642-S35341002072014090100000) .
4. If any other DTC is set, diagnose that DTC first.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement, setup, and programming.
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Ensure the transmission fluid temperature is between 50-80°C (122-176° F).
2. Operate the vehicle in 2nd gear long enough to ensure at least a 3°C (5° F) rise in transmission fluid temperature, then operate the vehicle in Park for 5 s.
3. Observe the scan tool's Clutch Pressure Control Solenoid Valve 2 parameter. The reading should be between 0.1 and 1.1 A.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement, setup, and programming.
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .
4. Wiring harness-Refer to «AUTOMATIC TRANSMISSION WIRING HARNESS REPLACEMENT»(ref-653642-S35243757312014090100000) for replacement.

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. The engine has to start in range position P and N.
2. The engine must not start in all other range positions.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
2. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .
3. BCM-Refer to «BODY CONTROL MODULE REPLACEMENT (RIGHT HAND DRIVE)»(ref-653639-S28483150132014090100000) or «BODY CONTROL MODULE REPLACEMENT (LEFT HAND DRIVE)»(ref-653639-S00602260772014090100000) for replacement, setup and programming.

Shift Solenoid Valve 2

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Ensure the transmission fluid temperature is between 50-80°C (122-176° F).
2. Operate the vehicle in 2nd gear long enough to ensure at least a 3°C (5° F) rise in oil temperature.
3. Place the gear selector in Reverse for 5 s and then idle vehicle for 5 s.
4. Observe the scan tool data Shift Solenoid Valve 2 parameter. The parameter should display ON.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement, setup, and programming.
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .
4. Wiring harness-Refer to «AUTOMATIC TRANSMISSION WIRING HARNESS REPLACEMENT»(ref-653642-S35243757312014090100000) for replacement.

Shift Solenoid Valve 1

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Ensure the transmission fluid temperature is between 50-80°C (122-176° F).
2. Operate the vehicle in 2nd gear long enough to ensure at least a 3°C (5° F) rise in oil temperature.
3. Place the gear selector in Reverse for 5 s and then idle vehicle for 5 s.
4. Observe the scan tool data Shift Solenoid Valve 1 parameter. The parameter should display ON.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement, setup, and programming.
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .
4. Wiring harness-Refer to «AUTOMATIC TRANSMISSION WIRING HARNESS REPLACEMENT»(ref-653642-S35243757312014090100000) for replacement.

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Verify the transmission fluid level, color and odor is correct.
2. Operate the vehicle to induce a shift from fifth to sixth gear while observing the following scan tool parameters. The scan tool parameters have to change the proper value referring to the current gear. Compare the proper values with «TRANSMISSION SYSTEM DESCRIPTION AND OPERATION (M36 AND MXE)»(ref-653642-S13459438242014090100000) . Perform this action 2 times. Clutch Pressure Control Solenoid Valve 1 Current Clutch Pressure Control Solenoid Valve 2 Current Clutch Pressure Control Solenoid Valve 3 Current Brake Band Pressure Control Solenoid Valve Current
3. If the scan tool parameter does not change the proper value and no other DTC than P0729, P0731, P0732, P0733, P0734, P0735, P0736, P0780, P1701, P1731 is set, go to «CIRCUIT/SYSTEM TESTING»(ref-653642-S24373014252014090100000) .
4. If any other DTC is set, diagnose that DTC first.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement, setup, and programming.
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

Clutch Pressure Control Solenoid Valve 1 Current

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Ensure the transmission fluid temperature is between 50-80°C (122-176° F).
2. Operate the vehicle in 2nd gear long enough to ensure at least a 3°C (5° F) rise in transmission fluid temperature, then operate the vehicle in Park for 5 s.
3. Observe the scan tool's Clutch Pressure Control Solenoid Valve 1 parameter. The reading should be between 0.1 and 1.1 A.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) .
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) .
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Verify the transmission fluid level, color and odor is correct.
2. Operate the vehicle to induce a shift from fifth to sixth gear while observing the following scan tool parameters. The scan tool parameters has to change the proper value referring to the current gear, compare the proper values with: «TRANSMISSION SYSTEM DESCRIPTION AND OPERATION (M36 AND MXE)»(ref-653642-S13459438242014090100000) . Perform this action 2 times. Clutch Pressure Control Solenoid Valve 1 Current Clutch Pressure Control Solenoid Valve 2 Current Clutch Pressure Control Solenoid Valve 3 Current Brake Band Pressure Control Solenoid Valve Current Shift Solenoid Valve 1 Shift Solenoid Valve 2
3. If the scan tool parameter does not change the proper value and no other DTCs than P0729, P0731, P0732, P0733, P0734, P0735, P0736, P0780, P1731 is set, go to «CIRCUIT/SYSTEM TESTING»(ref-653642-S21635202362014090100000) .
4. If any other DTC is set, diagnose that DTC first.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement, setup, and programming.
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .

Clutch Pressure Control Solenoid Valve

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Ensure the transmission fluid temperature is between 50-80°C (122-176° F).
2. Operate the vehicle in 2nd gear long enough to ensure at least a 3°C (5° F) rise in transmission fluid temperature, then operate the vehicle in Park for 5 s.
3. Observe the scan tool Clutch Pressure Control Solenoid Valve 3 Current parameter. The reading should be between 0.1-1.1 A.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) .
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) .
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .
4. Wiring harness-Refer to «AUTOMATIC TRANSMISSION WIRING HARNESS REPLACEMENT»(ref-653642-S35243757312014090100000) .

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Ensure the transmission fluid temperature is between 50-80°C (122-176° F).
2. Operate the vehicle in 2nd gear long enough to ensure at least a 3°C (5° F) rise in transmission fluid temperature, then operate the vehicle in Park for 5 s.
3. Observe the scan tool Brake Band Pressure Control Solenoid Valve Current parameter. The reading should be between 0.1-1.1 A.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) .
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) .
3. Wiring harness-Refer to «AUTOMATIC TRANSMISSION WIRING HARNESS REPLACEMENT»(ref-653642-S35243757312014090100000) .

TCC Pressure Control Solenoid Valve Current

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Ensure the transmission fluid temperature is between 50-80°C (122-176° F).
2. Operate the vehicle in 2nd gear long enough to ensure at least a 3°C (5°F) rise in transmission fluid temperature, then operate the vehicle in Park for 5 s.
3. Observe the scan tool data TCC Pressure Control Solenoid Valve Current parameter. The reading should be between 0.1-1.1 A.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. Control valve body replacement-Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-653642-S35597355512014090100000) for replacement, setup, and programming.
2. TCM-Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for replacement, setup and programming.
3. Perform the «TRANSMISSION ADAPTIVE FUNCTIONS»(ref-653642-S14713079032014090100000) .
4. Wiring harness-Refer to «AUTOMATIC TRANSMISSION WIRING HARNESS REPLACEMENT»(ref-653642-S35243757312014090100000) for replacement.

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Ignition ON, observe the scan tool Brake Applied Output Signal parameter while pressing and releasing the brake pedal. The parameter should change from ON to OFF when the brake pedal is depressed.
2. If the parameter does not change, refer to «STOP LAMPS MALFUNCTION»(ref-653643-S21471608742014090100000) .
3. While pressing the brake pedal, the vehicle operator should be able to move the shifter lever out of the park position.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «TRANSMISSION CONTROL REPLACEMENT»(ref-653642-S04152637442014090100000)
2. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for ECM replacement, setup, and programming.

Note. Use the symptom tables only if the following conditions are met: Refer to DIAGNOSTIC STARTING POINT - VEHICLE . There are no DTCs set. The control modules can communicate via the serial data link. Review the system operation in order to familiarize yourself with the system functions. Refer to TRANSMISSION GENERAL DESCRIPTION and TRANSMISSION COMPONENT AND SYSTEM DESCRIPTION .

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS .

Suspension System Mode

1. Circuit Testing
2. Connector Repairs
3. Testing for Intermittent Conditions and Poor Connections
4. Wiring Repairs

1. Verify no communication related DTC is set.
2. If any communication DTC is set, diagnose those first.
3. Ignition ON, observe the scan tool Suspension System Mode parameter while pressing and releasing one after the other S48C Multifunction Switch 1 - Instrument Panel, Sport Mode and Tour Mode. Verify the reading changes between Normal/Comfort/Sport Mode.
4. If the parameter does not change between the specified values, go to «CIRCUIT/SYSTEM TESTING»(ref-653642-S35392464942014090100000) .
5. Observe the sport mode LED and the tour mode LED while pressing and releasing one after the other S48C Multifunction Switch 1 - Instrument Panel, Sport Mode and Tour Mode. The sport mode LED and the tour mode LED should turn ON and OFF.
6. If the LED does not change between the specified values, go to «CIRCUIT/SYSTEM TESTING»(ref-653642-S35392464942014090100000) .

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. PSD SIE TITLE Error: SIE linked to empty Cell ID 183965
2. Control Module References for BCM replacement, setup and programming

Electrical Function Check

Perform this procedure first in order to ensure the electronic transmission components are functioning properly. If these components are not checked, a simple electrical condition could be misdiagnosed.

1. Connect diagnostic tool.
2. Ensure the gear selector is in PARK and set the parking brake.
3. Start the engine.
4. Verify that scan tool data can be obtained. Refer to «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for typical data values. Data that is questionable may indicate a concern.
5. Monitor the TCC Brake Switch parameter while applying and releasing the brake pedal. The scan tool should display: Open when the brake pedal is applied. Closed when the brake pedal is released.
6. Check the garage shifts. Apply the brake pedal and ensure the parking brake is set. Move the gear selector through the following ranges: PARK to REVERSE REVERSE to NEUTRAL NEUTRAL to DRIVE Pause 2 to 3 seconds in each gear position. NOTE: Harsh engagement may be caused by any of the following conditions: Verify the gear engagements are immediate and not harsh. High engine idle speed-Compare engine idle speed to desired idle speed. High pressure will cause harsh shifts. A default condition caused by certain DTCs that result in maximum line pressure to prevent clutch slippage. NOTE: Soft or delayed engagement may be caused by any of the following conditions: Low idle speed-Compare engine idle speed to desired idle speed. Low fluid level Low pressure will cause soft or delayed shifts. Cold transmission fluid temperature (TFT)-Use the scan tool to determine TFT. Selector linkage-Inspect and adjust as necessary. Verify the gear engagements are immediate and not harsh.
7. Monitor transmission range on the scan tool, engine data list. 7.1. Apply the brake pedal and ensure the parking brake is set. 7.2. Move the gear selector through all ranges. 7.3. Pause 2 to 3 seconds in each range. 7.4. Return gear selector to PARK. 7.5. Verify that all selector positions match the scan tool display.
8. Check throttle position input. 8.1. Apply the brake pedal and ensure the parking brake is set. 8.2. Ensure the gear selector is in PARK. 8.3. Monitor the scan tool Calc. Throttle Position while increasing and decreasing engine speed with the throttle pedal. The scan tool Calc. Throttle Position percentage should increase and decrease with engine speed. If any of the above checks do not perform properly, record the result for reference after completion of the road test.

Adaptive Learning

Start driving the car and make the adaptive learning. Refer to TRANSMISSION ADAPTIVE FUNCTIONS .

Confirm Customer Complaint by Driving

Continue driving to verify the customer complaint. It might be useful to use manual shifting in order to verify the problem.

Check Oil Level and Oil Quality

After the driving is finalized and the complaint has been recorded

1. Check fluid level. Refer to «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-653642-S41840466012014090100000) .
2. Check oil quality. If the oil is milky there is a water leakage into the transmission. Check the vent hose. If the oil smells burnt and its color is dark some disc may have been overloaded.
3. If the oil quality is too bad, change oil, make a new adaptive driving and the check if the problem is still there.

Poor Acceleration at Low Speed

If the stator is freewheeling at all times, the car tends to have poor acceleration from a standstill. At speeds above 50-55 km/h (30-35 mph), the car may act normally. For poor acceleration, you should first determine that the exhaust system is not blocked, and the transmission is in First gear when starting out.

If the engine freely accelerates to high RPM in NEUTRAL, you can assume that the engine and the exhaust system are normal. Check for poor performance in DRIVE and REVERSE to help determine if the stator is freewheeling at all times.

Poor Acceleration at High Speed

If the stator is locked up at all times, performance is normal when accelerating from a standstill. Engine RPM and car speed are limited or restricted at high speeds. Visual examination of the converter may reveal a blue color from overheating.

If the converter has been removed, you can check the stator roller clutch by inserting a finger into the splined inner race of the roller clutch and trying to turn the race in both directions. You should be able to freely turn the inner race clockwise, but you should have difficulty in moving the inner race counterclockwise or you may be unable to move the race at all.

If Shudder Occurs After TCC has Applied

If shudder occurs after the TCC has applied, most of the time there is nothing wrong with the transmission.

As mentioned above, the TCC is not likely to slip after the TCC has been applied. Engine problems may go unnoticed under light throttle and load, but they become noticeable after the TCC apply when going up a hill or accelerating. This is due to the mechanical coupling between the engine and the transmission.

Once TCC is applied, there is no torque converter, fluid coupling, assistance. Engine or driveline vibrations could be unnoticeable before TCC engagement.

Inspect the following components in order to avoid misdiagnosis of TCC shudder. An inspection will also avoid the unnecessary disassembly of a transmission or the unnecessary replacement of a torque converter.

1. Spark plugs - Inspect for cracks, high resistance or a broken insulator.
2. Coil - Look for a black discoloration on the bottom of the coil. This indicates arcing while the engine is misfiring.
3. Fuel injector - The filter may be plugged.
4. Vacuum leak - The engine will not get a correct amount of fuel. The mixture may run rich or lean depending on where the leak occurs.
5. EGR valve (Petrol) - The valve may let in too much or too little unburnable exhaust gas and could cause the engine to run rich or lean.
6. MAP sensor - Like a vacuum leak, the engine will not get the correct amount of fuel for proper engine operation.
7. Carbon on the intake valves - Carbon restricts the proper flow of air/fuel mixture into the cylinders.
8. Flat cam - Valves do not open enough to let the proper fuel/air mixture into the cylinders.
9. Oxygen sensor - This sensor may command the engine too rich or too lean for too long.
10. Fuel pressure - This may be too low.
11. Engine mounts - Vibration of the mounts can be multiplied by TCC engagement.
12. Axle joints - Check for vibration.
13. TP Sensor (Petrol) - The TCC apply and release depends on the TP Sensor in many engines. If the TP Sensor is out of specification, TCC may remain applied during initial engine loading.
14. Cylinder balance - Bad piston rings or poorly sealing valves can cause low power in a cylinder.
15. Fuel contamination - This causes poor engine performance.

General Method

1. Verify that the leak is transmission fluid.
2. Thoroughly clean the suspected leak area.
3. Operate the vehicle for 24 km (15 mi), or until normal operating temperatures are reached.
4. Park the vehicle over clean paper or cardboard.
5. Switch off the engine.
6. Look for fluid spots on the paper.
7. Make the necessary repairs.

Powder Method

1. Thoroughly clean the suspected leak area with solvent.
2. Apply an aerosol type leak tracing powder to the suspected leak area.
3. Operate the vehicle for 24 km (15 mi), or until normal operating temperatures are reached.
4. Switch off the engine.
5. Inspect the suspected leak area.
6. Trace the leak path through the powder in order to find the source of the leak.
7. Make the necessary repairs.

Dye and Black Light Method

A fluid dye and black light kit is available from various tool manufacturers.

1. Follow the manufacturer instructions in order to determine the amount of dye to use.
2. Operate the vehicle for 24 km (15 mi), or until normal operating temperatures are reached.
3. Detect the leak with the black light.
4. Make the necessary repairs.

Find the Cause of the Leak

Pinpoint the leak and trace the leak back to the source. You must determine the cause of the leak in order to repair the leak properly. For example, if you replace a gasket, but the sealing flange is bent, the new gasket will not repair the leak. You must also repair the bent flange. Before you attempt to repair a leak, check for the following conditions, and make repairs as necessary

Gaskets

1. Fluid level/pressure is too high.
2. Plugged vent or drain-back holes.
3. Improperly tightened fasteners.
4. Dirty or damaged threads.
5. Warped flanges or sealing surface.
6. Scratches, burrs, or other damage to the sealing surface.
7. Damaged or worn gasket.
8. Cracking or porosity of the component.
9. Improper sealant used, where applicable.
10. Incorrect gasket.

Seals

1. Fluid level/pressure is too high.
2. Plugged vent or drain-back holes.
3. Damaged or worn seal.
4. Cracks in component.
5. Manual shaft or output shaft surface is scratched, nicked, or damaged.
6. Loose or worn bearing causing excess seal wear.

Transmission Valve Body Cover

1. Incorrectly tightened bolts.
2. Improperly installed or damaged gasket/seal.
3. Damaged mounting face.
4. Incorrect gasket seal.

Transmission Case Leak

1. Loose or damaged oil cooler lines/seals.
2. Worn or damaged axle shaft oil seal.
3. Loose line pressure pipe plug or fluid level pipe plug.

Leak at the Transmission Vent

1. Overfilled system.
2. Water or coolant in the fluid. The fluid will appear milky. Check vent hose mounting.
3. Plugged vent.

Transmission Overheats

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
2. Review the system operation in order to familiarize yourself with the system functions. Refer to «AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL DESCRIPTION AND OPERATION»(ref-653642-S39016328762014090100000) .

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Ignition ON, observe the scan tool Brake Applied Output Signal parameter while pressing and releasing the brake pedal. The parameter should change from ON to OFF when the brake pedal is depressed.
2. If the parameter does not change, refer to «STOP LAMPS MALFUNCTION»(ref-653643-S21471608742014090100000) .
3. While pressing the brake pedal, the vehicle operator should be able to move the shifter lever out of the park position.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «TRANSMISSION CONTROL REPLACEMENT»(ref-653642-S04152637442014090100000)
2. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for ECM replacement, setup, and programming.

Time studies - Gear selector mechanism

Correction

1. 01 - Replacement
2. 02 - Removal - Refit
3. 03 - Renovate
4. 04 - Paint
5. 05 - Adjust
6. 06 - Change comp. unit
7. 07 - Lubricate - Clean - Polish
8. 08 - Check/Fault search
9. 09 - Expose
10. 10 - Install new
11. 11 - Transfer

1. 01 - Replacement
2. 02 - Removal - Refit
3. 03 - Renovate
4. 04 - Paint
5. 05 - Adjust
6. 06 - Change comp. unit
7. 07 - Lubricate - Clean - Polish
8. 08 - Check/Fault search
9. 09 - Expose
10. 10 - Install new
11. 11 - Transfer

Master Electrical Component List

Link to end views of connectors: COMPONENT CONNECTOR END VIEWS

MODULE POWER, GROUND, DATA COMMUNICATION, MIL AND UP/DOWN SHIFTING

SPEED SENSORS, TRANSMISSION FLUID TEMPERATURE, PRESSURE CONTROLS AND SHIFT CONTROLS

TRANSMISSION SHIFT LEVER POSITION INDICATOR AND MODE SWITCH

Shift lock control, diagram

SHIFT LOCK CONTROL

Scheme 133

List of components

Scheme 134

Scheme 135

Scheme 136

VEHICLES CONCERNED

Saab 9-5 (650) only year MY 2011 with 4 cylinder Petrol & Bio Power engine (A20 NFT) equipped with automatic transmission AF40, Gen II.

BACKGROUND

If the engine has stopped when the "D" or "R" mode is engaged, the transmission will not engage the clutch after a re start if the engine rpm is below 2000 rpm.

CONDITIONS

This problem is due to a software (SW) parameter, set by the supplier in the Transmission Control Module (TCM) unit.

ACTION

1. Start the engine, engage the transmission, and increase the rpm to 2000 rpm: The transmission will now engage the clutch.
2. Drive the car until the engine reaches normal temperature, and the transmission oil is warm then maintain a speed of minimum 50 km/h (30 mph) to make sure that the transmission lock up function is activated.
3. Confirm that the gearshift performs as expected before returning the car to the customer.

Note. If car does not behave as expected in point 3, repeat points 2-3.
