Automatic Climate Control, Acc: Component Locations Saab 9-5 II

Automatic HVAC System 34 illustrations ~104 words

Location (pos)

  1. 01 - Front
  2. 02 - Rear
  3. 03 - Left
  4. 04 - Right
  5. 05 - All
  6. 06 - Upper
  7. 07 - Centre
  8. 08 - Lower
  9. 09 - Service Information

Scheme 110

Scheme 110: Heater and Air Conditioning Control Replacement
Scheme 110: Heater and Air Conditioning Control Replacement
CalloutComponent Name
Preliminary Procedure Remove the front floor console cover. Refer to FRONT FLOOR CONSOLE COVER REPLACEMENT .
1Instrument Panel Lower Center Trim Panel Fastener Refer to FASTENER CAUTION .
2Instrument Panel Lower Center Trim Panel Procedure Use a flat-bladed plastic trim tool in order to release the retaining clips securing the upper center trim panel to the instrument panel. Disconnect the electrical connectors. If replacing the lower center trim panel, transfer parts as necessary.

Scheme 111

Scheme 111: Air Conditioning Module Wiring Harness Replacement
Scheme 111: Air Conditioning Module Wiring Harness Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel upper trim panel. Refer to INSTRUMENT PANEL UPPER TRIM PANEL REPLACEMENT . Remove the instrument panel compartment. Refer to GLOVE COMPARTMENT, REPLACEMENT Remove the heater and air conditioning remote control. Refer to HEATER AND AIR CONDITIONING REMOTE CONTROL REPLACEMENT . Remove the radio. Refer to RADIO REPLACEMENT .
1Air Conditioning Module Wiring Harness Procedure Disconnect the electrical connections from the actuators and the temperature sensors.

Scheme 112

Scheme 112: Heater and Blower and Air Conditioning Control Module Replacement
Scheme 112: Heater and Blower and Air Conditioning Control Module Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel compartment. Refer to GLOVE COMPARTMENT, REPLACEMENT Remove the floor air outlet duct. Refer to FLOOR AIR OUTLET DUCT REPLACEMENT - RIGHT SIDE . Disconnect the heater and blower and air conditioning control module electrical connectors.
1Heater and Blower and Air Conditioning Control Module Fastener (Qty: 2)
2Heater and Blower and Air Conditioning Control Module

Scheme 113

Scheme 113: Auxiliary Heater and Air Conditioning Control Module Replacement
Scheme 113: Auxiliary Heater and Air Conditioning Control Module Replacement
CalloutComponent Name
Preliminary Procedure Remove the front floor console. Refer to FRONT FLOOR CONSOLE REPLACEMENT . Disconnect the auxiliary heater and blower and air conditioning control module electrical connectors.
1Auxiliary Heater and Blower and Air Conditioning Control Module Screws (Qty: 2) Refer to FASTENER CAUTION . Tighten 1, 5 Nm (13 lb in)
2Auxiliary Heater and Blower and Air Conditioning Control Module

Scheme 114

Scheme 114: Mode Valve Lever Replacement
Scheme 114: Mode Valve Lever Replacement
CalloutComponent Name
Preliminary Procedure Remove the mode control cam actuator. Refer to MODE CONTROL CAM ACTUATOR REPLACEMENT (RIGHT HAND DRIVE) or MODE CONTROL CAM ACTUATOR REPLACEMENT (LEFT HAND DRIVE) . Remove the mode control cam. Refer to MODE CONTROL CAM REPLACEMENT .
1Mode Valve Lever Procedure Move the valve to the middle position and mark the position of the mode valve lever notch to the mode valve gear. NOTE: Use the indentation for the correct positioning of the lever arms.
NOTE
Use the indentation for the correct positioning of the lever arms.

Scheme 115

Scheme 115: Vent Valve Lever Replacement
Scheme 115: Vent Valve Lever Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel compartment. Refer to GLOVE COMPARTMENT, REPLACEMENT Remove the air inlet valve actuator. Refer to AIR INLET VALVE ACTUATOR REPLACEMENT (RIGHT HAND DRIVE) or AIR INLET VALVE ACTUATOR REPLACEMENT (LEFT HAND DRIVE) . Remove the heater and blower and air conditioning control module. Refer to HEATER AND BLOWER AND AIR CONDITIONING CONTROL MODULE REPLACEMENT . Remove the air inlet valve and inside air valve control cam. Refer to AIR INLET VALVE AND INSIDE AIR VALVE CONTROL CAM REPLACEMENT .
1Vent Valve Lever Procedure Move the valve to the middle position and mark the position of the vent valve lever notch to the vent valve gear. NOTE: Use the indentation for the correct positioning of the lever arms.
NOTE
Use the indentation for the correct positioning of the lever arms.

Scheme 116

Scheme 116: Mode Valve Gear Replacement
Scheme 116: Mode Valve Gear Replacement
CalloutComponent Name
Preliminary Procedure Remove the mode control cam actuator. Refer to MODE CONTROL CAM ACTUATOR REPLACEMENT (RIGHT HAND DRIVE) or MODE CONTROL CAM ACTUATOR REPLACEMENT (LEFT HAND DRIVE) . Remove the mode control cam. Refer to MODE CONTROL CAM REPLACEMENT .
1Mode Valve Lever Procedure Move the valve to the middle position and mark the position of the mode valve lever notch to the mode valve gear. Remove the mode valve lever.
2Mode Valve Gear Procedure Release and remove the mode valve gear. NOTE: When replacing the valve gear, transfer the mark to the new part. The mode valve gear can only be fitted in one position. Use the indentation for the correct positioning of the lever arms.
NOTE
When replacing the valve gear, transfer the mark to the new part. The mode valve gear can only be fitted in one position. Use the indentation for the correct positioning of the lever arms.

Scheme 117

Scheme 117: Air Inlet Valve Actuator Gear Replacement
Scheme 117: Air Inlet Valve Actuator Gear Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel compartment. Refer to GLOVE COMPARTMENT, REPLACEMENT
1Air Inlet Valve Actuator Gear Procedure Pull off the actuator gear.

Scheme 118

Scheme 118: Air Inlet Valve Actuator Replacement (Right Hand Drive)
Scheme 118: Air Inlet Valve Actuator Replacement (Right Hand Drive)
CalloutComponent Name
Preliminary Procedure Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECTION AND CONNECTION . Remove the instrument panel compartment. Refer to GLOVE COMPARTMENT, REPLACEMENT Remove the body control module. Refer to BODY CONTROL MODULE REPLACEMENT (RIGHT HAND DRIVE) or BODY CONTROL MODULE REPLACEMENT (LEFT HAND DRIVE) . Remove the inside air valve actuator. Refer to INSIDE AIR VALVE ACTUATOR REPLACEMENT (RIGHT HAND DRIVE) .
1Air Inlet Valve Actuator Fastener (Qty: 2) Procedure Disconnect the air inlet valve actuator electrical connector.
2Air Inlet Valve Actuator NOTE: Actuator is self-calibrating when connecting the battery.
NOTE
Actuator is self-calibrating when connecting the battery.

Scheme 119

Scheme 119: Air Inlet Valve Actuator Replacement (Left Hand Drive)
Scheme 119: Air Inlet Valve Actuator Replacement (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECTION AND CONNECTION . Remove the temperature valve actuator - right side. Refer to TEMPERATURE VALVE ACTUATOR REPLACEMENT - RIGHT SIDE (LEFT HAND DRIVE) . Remove the heater and blower and air conditioning control module. Refer to HEATER AND BLOWER AND AIR CONDITIONING CONTROL MODULE REPLACEMENT . Remove the recirculation actuator. Refer to INSIDE AIR VALVE ACTUATOR REPLACEMENT (RIGHT HAND DRIVE) .
1Air Inlet Valve Actuator Fastener (Qty: 3) Refer to FASTENER CAUTION . Procedure Disconnect the air inlet valve actuator electrical connector.
2Air Inlet Valve Actuator NOTE: Actuator is self-calibrating when connecting the battery.
NOTE
Actuator is self-calibrating when connecting the battery.

Scheme 120

Scheme 120: Air Inlet Valve and Inside Air Valve Control Cam Replacement
Scheme 120: Air Inlet Valve and Inside Air Valve Control Cam Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel compartment. Refer to GLOVE COMPARTMENT, REPLACEMENT Remove the air inlet valve actuator. Refer to AIR INLET VALVE ACTUATOR REPLACEMENT (RIGHT HAND DRIVE) or AIR INLET VALVE ACTUATOR REPLACEMENT (LEFT HAND DRIVE) . Remove the heater and blower and air conditioning control module. Refer to HEATER AND BLOWER AND AIR CONDITIONING CONTROL MODULE REPLACEMENT .
1Air Inlet Valve and Inside Air Valve Control Cam Procedure Release and pull off the control cam. The air inlet valve and inside air valve control cam can only be fitted in one position.

Scheme 121

Scheme 121: Inside Air Valve Actuator Replacement (Right Hand Drive)
Scheme 121: Inside Air Valve Actuator Replacement (Right Hand Drive)
CalloutComponent Name
Preliminary Procedure Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECTION AND CONNECTION . Remove the instrument panel compartment. Refer to GLOVE COMPARTMENT, REPLACEMENT Remove the body control module. Refer to BODY CONTROL MODULE REPLACEMENT (RIGHT HAND DRIVE) or BODY CONTROL MODULE REPLACEMENT (LEFT HAND DRIVE) .
1Inside Air Valve Actuator Fastener (Qty: 2) Procedure Disconnect the inside air valve actuator electrical connector.
2Inside Air Valve Actuator NOTE: The actuator is self-calibrating when connecting the battery.
NOTE
The actuator is self-calibrating when connecting the battery.

Scheme 122

Scheme 122: Mode Control Cam Actuator Replacement (Right Hand Drive)
Scheme 122: Mode Control Cam Actuator Replacement (Right Hand Drive)
CalloutComponent Name
Preliminary Procedure Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECTION AND CONNECTION . Remove the instrument panel compartment. Refer to GLOVE COMPARTMENT, REPLACEMENT Remove the floor air outlet duct. Refer to FLOOR AIR OUTLET DUCT REPLACEMENT - RIGHT SIDE . Remove the Instrument Panel Compartment Air and Radio Cooling Duct. Refer to INSTRUMENT PANEL COMPARTMENT AIR AND RADIO COOLING DUCT REPLACEMENT .
1Mode Control Cam Actuator Fastener (Qty: 2) Refer to FASTENER CAUTION . Procedure Disconnect the mode control cam actuator electrical connector.
2Mode Control Cam Actuator NOTE: The actuator is self-calibrating when connecting the battery.
NOTE
The actuator is self-calibrating when connecting the battery.

Scheme 123

Scheme 123: Mode Control Cam Actuator Replacement (Left Hand Drive)
Scheme 123: Mode Control Cam Actuator Replacement (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECTION AND CONNECTION . Remove the floor air outlet duct - left side. Refer to FLOOR AIR OUTLET DUCT REPLACEMENT - LEFT SIDE . Remove the Instrument Panel Compartment Air and Radio Cooling Duct. Refer to INSTRUMENT PANEL COMPARTMENT AIR AND RADIO COOLING DUCT REPLACEMENT .
1Mode Control Cam Actuator Fastener (Qty: 2) Refer to FASTENER CAUTION . Procedure Disconnect the mode control cam actuator electrical connector.
2Mode Control Cam Actuator NOTE: The actuator is self-calibrating when connecting the battery.
NOTE
The actuator is self-calibrating when connecting the battery.

Scheme 124

Scheme 124: Mode Control Cam Replacement
Scheme 124: Mode Control Cam Replacement
CalloutComponent Name
Preliminary Procedure Remove the floor air outlet duct - driver side. Refer to FLOOR AIR OUTLET DUCT REPLACEMENT - LEFT SIDE . Remove the mode control cam actuator. Refer to MODE CONTROL CAM ACTUATOR REPLACEMENT (RIGHT HAND DRIVE) or MODE CONTROL CAM ACTUATOR REPLACEMENT (LEFT HAND DRIVE) .
1Mode Control Cam Procedure Release and pull off the control cam. The mode control cam can only be fitted in one position.

Scheme 125

Scheme 125: Temperature Valve Actuator Replacement - Right Side (Left Hand Drive)
Scheme 125: Temperature Valve Actuator Replacement - Right Side (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECTION AND CONNECTION . Remove the instrument panel compartment. Refer to GLOVE COMPARTMENT, REPLACEMENT Remove the floor air outlet duct - right side. Refer to FLOOR AIR OUTLET DUCT REPLACEMENT - RIGHT SIDE .
1Temperature Valve Actuator Fastener (Qty: 2) Procedure Disconnect the temperature actuator electrical connector.
2Temperature Valve Actuator NOTE: Actuator is self-calibrating when connecting the battery.
NOTE
Actuator is self-calibrating when connecting the battery.

Scheme 126

Scheme 126: Temperature Valve Actuator Replacement - Left Side (Right Hand Drive)
Scheme 126: Temperature Valve Actuator Replacement - Left Side (Right Hand Drive)
CalloutComponent Name
Preliminary Procedure Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECTION AND CONNECTION . Remove the instrument panel compartment. Refer to GLOVE COMPARTMENT, REPLACEMENT Remove the floor air outlet duct passenger side. Refer to FLOOR AIR OUTLET DUCT REPLACEMENT - RIGHT SIDE . Remove the Instrument Panel Compartment Air and Radio Cooling Duct. Refer to INSTRUMENT PANEL COMPARTMENT AIR AND RADIO COOLING DUCT REPLACEMENT .
1Temperature Valve Actuator Fastener (Qty: 2) Refer to FASTENER CAUTION . Procedure Disconnect the temperature actuator electrical connector.
2Temperature Valve Actuator NOTE: The actuator is self-calibrating when connecting the battery.
NOTE
The actuator is self-calibrating when connecting the battery.

Scheme 127

Scheme 127: Temperature Valve Actuator Replacement - Left Side (Left Hand Drive)
Scheme 127: Temperature Valve Actuator Replacement - Left Side (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECTION AND CONNECTION . Remove the floor air outlet duct - left side. Refer to FLOOR AIR OUTLET DUCT REPLACEMENT - LEFT SIDE .
1Temperature Valve Actuator Fastener (Qty: 2) Refer to FASTENER CAUTION . Procedure Disconnect the temperature actuator electrical connector.
2Temperature Valve Actuator NOTE: Actuator is self-calibrating when connecting the battery.
NOTE
Actuator is self-calibrating when connecting the battery.

Scheme 128

Scheme 128: Auxiliary Temperature Valve Actuator Replacement
Scheme 128: Auxiliary Temperature Valve Actuator Replacement
CalloutComponent Name
Preliminary Procedure Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECTION AND CONNECTION . Remove the instrument panel lower trim panel insulator - driver side. Refer to Refer to INSTRUMENT PANEL LOWER TRIM PANEL INSULATOR REPLACEMENT - DRIVER SIDE . Loosen the carpet in the range of the front floor console and instrument panel on the left side.
1Temperature Valve Actuator Screw (Qty: 2) Refer to FASTENER CAUTION . Tighten 1, 5 Nm (13 lb in)
2Temperature Valve Actuator Procedure Disconnect the temperature actuator electrical connector. NOTE: Actuator is self-calibrating when connecting the battery.
NOTE
Actuator is self-calibrating when connecting the battery.

Scheme 129

Scheme 129: Auxiliary Mode Valve Actuator Replacement
Scheme 129: Auxiliary Mode Valve Actuator Replacement
CalloutComponent Name
Preliminary Procedure Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECTION AND CONNECTION . Loosen the carpet in the range of the front floor console and instrument panel on the left side.
1Inside Air Valve Actuator Screw (Qty: 2) Refer to FASTENER CAUTION . Tighten 1, 5 Nm (13 lb in)
2Inside Air Valve Actuator Procedure Disconnect the recirculation actuator electrical connector. NOTE: Actuator is self-calibrating when connecting the battery.
NOTE
Actuator is self-calibrating when connecting the battery.

Scheme 130

Scheme 130: Air Conditioning Refrigerant Temperature Sensor Replacement (Right Hand Drive)
Scheme 130: Air Conditioning Refrigerant Temperature Sensor Replacement (Right Hand Drive)
CalloutComponent Name
Preliminary Procedure Remove the floor air outlet duct driver side. Refer to FLOOR AIR OUTLET DUCT REPLACEMENT - LEFT SIDE .
1Air Conditioning Refrigerant Temperature Sensor Procedure Disconnect the refrigerant temperature sensor electrical connector. Twist and pull the refrigerant temperature sensor from the HVAC module assembly.

Scheme 131

Scheme 131: Air Conditioning Refrigerant Temperature Sensor Replacement (Left Hand Drive)
Scheme 131: Air Conditioning Refrigerant Temperature Sensor Replacement (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure Remove the instrument panel compartment. Refer to GLOVE COMPARTMENT, REPLACEMENT Remove the floor air outlet duct - right side. Refer to FLOOR AIR OUTLET DUCT REPLACEMENT - RIGHT SIDE .
1Air Conditioning Refrigerant Temperature Sensor Procedure Disconnect the refrigerant temperature sensor electrical connector. Twist and pull the refrigerant temperature sensor from the HVAC module assembly.

Scheme 132

Scheme 132: Duct Air Temperature Sensor Replacement - Upper Right Side (Right Hand Drive)
Scheme 132: Duct Air Temperature Sensor Replacement - Upper Right Side (Right Hand Drive)
CalloutComponent Name
Preliminary Procedure Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECTION AND CONNECTION . Remove the temperature valve actuator - right side. Refer to TEMPERATURE VALVE ACTUATOR REPLACEMENT - RIGHT SIDE (LEFT HAND DRIVE) . Remove the heater and blower and air conditioning control module. Refer to HEATER AND BLOWER AND AIR CONDITIONING CONTROL MODULE REPLACEMENT . Remove the recirculation actuator. Refer to INSIDE AIR VALVE ACTUATOR REPLACEMENT (RIGHT HAND DRIVE) .
1Duct Air Temperature Sensor - Upper Right Side Procedure Disconnect the duct air temperature sensor electrical connector. Twist and pull the upper air temperature sensor from the HVAC module assembly.

Scheme 133

Scheme 133: Duct Air Temperature Sensor Replacement - Upper Right Side (Left Hand Drive)
Scheme 133: Duct Air Temperature Sensor Replacement - Upper Right Side (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECTION AND CONNECTION . Remove the temperature valve actuator - right side. Refer to TEMPERATURE VALVE ACTUATOR REPLACEMENT - RIGHT SIDE (LEFT HAND DRIVE) . Remove the heater and blower and air conditioning control module. Refer to HEATER AND BLOWER AND AIR CONDITIONING CONTROL MODULE REPLACEMENT . Remove the recirculation actuator. Refer to INSIDE AIR VALVE ACTUATOR REPLACEMENT (RIGHT HAND DRIVE) .
1Duct Air Temperature Sensor - Upper Right Side Procedure Disconnect the duct air temperature sensor electrical connector. Twist and pull the upper air temperature sensor from the HVAC module assembly.

Scheme 134

Scheme 134: Duct Air Temperature Sensor Replacement - Upper Left Side (Left Hand Drive)
Scheme 134: Duct Air Temperature Sensor Replacement - Upper Left Side (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure Remove the floor air outlet duct - left side. Refer to FLOOR AIR OUTLET DUCT REPLACEMENT - LEFT SIDE . Remove the instrument cluster. Refer to INSTRUMENT CLUSTER REPLACEMENT .
1Duct Air Temperature Sensor - Upper Left Side Procedure Disconnect the air temperature sensor electrical connector. Twist and pull the upper air temperature sensor from the HVAC module assembly.

Scheme 135

Scheme 135: Duct Air Temperature Sensor Replacement - Lower Left Side (Right Hand Drive)
Scheme 135: Duct Air Temperature Sensor Replacement - Lower Left Side (Right Hand Drive)
CalloutComponent Name
Preliminary Procedure Remove the instrument panel compartment. Refer to GLOVE COMPARTMENT, REPLACEMENT Remove the floor air outlet duct passenger side. Refer to FLOOR AIR OUTLET DUCT REPLACEMENT - RIGHT SIDE . Remove the radio cooling duct. Refer to INSTRUMENT PANEL COMPARTMENT AIR AND RADIO COOLING DUCT REPLACEMENT .
1Duct Air Temperature Sensor - Lower Left Side Procedure Twist and pull the lower air temperature sensor from the HVAC module assembly. Disconnect the duct air temperature sensor electrical connector.

Scheme 136

Scheme 136: Duct Air Temperature Sensor Replacement - Lower Left Side (Left Hand Drive)
Scheme 136: Duct Air Temperature Sensor Replacement - Lower Left Side (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure Remove the floor air outlet duct - left side. Refer to FLOOR AIR OUTLET DUCT REPLACEMENT - LEFT SIDE .
1Duct Air Temperature Sensor - Lower Left Side Procedure Disconnect the duct air temperature sensor electrical connector. Twist and pull the lower air temperature sensor from the HVAC module assembly.

Scheme 137

Scheme 137: Duct Air Temperature Sensor Replacement - Lower Right Side (Left Hand Drive)
Scheme 137: Duct Air Temperature Sensor Replacement - Lower Right Side (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure Remove the instrument panel compartment. Refer to GLOVE COMPARTMENT, REPLACEMENT Remove the floor air outlet duct - right side. Refer to FLOOR AIR OUTLET DUCT REPLACEMENT - RIGHT SIDE .
1Duct Air Temperature Sensor - Lower Right Side Procedure Disconnect the duct air temperature sensor electrical connector. Twist and pull the lower air temperature sensor from the HVAC module assembly.

Scheme 138

Scheme 138: Ambient Air Quality Sensor Replacement
Scheme 138: Ambient Air Quality Sensor Replacement
CalloutComponent Name
Preliminary Procedure Remove the plenum water deflector. Refer to PLENUM WATER DEFLECTOR REPLACEMENT .
1Ambient Air Quality Sensor Procedure Unsnap the ambient air quality sensor and move it forward. Disconnect the electrical connector.

Scheme 139

Scheme 139: Ambient Air Temperature Sensor Replacement
Scheme 139: Ambient Air Temperature Sensor Replacement
CalloutComponent Name
Preliminary Procedure Remove the splash shield on the left side. Refer to FRONT COMPARTMENT SPLASH SHIELD REPLACEMENT .
1Ambient Air Temperature Sensor Procedure Disconnect the electrical connector.

Scheme 140

Scheme 140: Inside Air Temperature Sensor Replacement (CJ4 Front)
Scheme 140: Inside Air Temperature Sensor Replacement (CJ4 Front)
CalloutComponent Name
Preliminary Procedure Remove the floor panel carpet. Refer to FRONT FLOOR PANEL CARPET REPLACEMENT .
1Inside Air Temperature Sensor (CJ4 Front) Preliminary Procedure Disconnect the duct air temperature sensor electrical connector.

Scheme 141

Scheme 141: Inside Air Temperature Sensor Replacement (CJ4)
Scheme 141: Inside Air Temperature Sensor Replacement (CJ4)
CalloutComponent Name
Preliminary Procedure Remove floor console. Refer to FRONT FLOOR PANEL CARPET REPLACEMENT . Disconnect the inside air temperature sensor electrical connectors.
1Inside Air Temperature Sensor Procedure Disconnect the duct air temperature sensor electrical connector. Twist and pull the duct air temperature sensor from the HVAC module assembly.

Scheme 142

Scheme 142: Inside Air Moisture and Windshield Temperature Sensor Replacement
Scheme 142: Inside Air Moisture and Windshield Temperature Sensor Replacement
CalloutComponent Name
Preliminary Procedure Remove the inside rearview mirror mount plate cover. Refer to INSIDE REARVIEW MIRROR MOUNT PLATE COVER REPLACEMENT .
1Inside Air Moisture and Windshield Temperature Sensor Retainer
2Inside Air Moisture and Windshield Temperature Sensor

Scheme 143

Scheme 143: Sun Load Temperature and Headlamp Automatic Control Ambient Light Sensor Replacement
Scheme 143: Sun Load Temperature and Headlamp Automatic Control Ambient Light Sensor Replacement
CalloutComponent Name
Preliminary Procedure Remove the front radio speaker grille. Refer to RADIO FRONT SPEAKER GRILLE REPLACEMENT
1Sun Load Temperature and Headlamp Automatic Control Ambient Light Sensor Procedure Disconnect the electrical connector. Twist the sensor counterclockwise to remove.

More articles — Automatic Climate Control, Acc
