Intake System: Overview Saab 9-5 I рестайлинг

Scheme 806

Scheme 807

1. Remove the engine cover.
2. Remove the bypass pipe with valve, keeping the O-ring from the connection to the turbocharger inlet pipe.
3. Unplug the connector from the temperature/pressure sensor on the charge air pipe.
4. Detach the charge air pipe from the throttle body.
5. Raise the car.
6. Detach the charge air pipe from the charge air cooler leaving the clip to hang on the cooler.
7. Lower the car to the floor.
8. Remove the charge air pipe.

Scheme 808

Scheme 809

1. Fit the charge air pipe.
2. Raise the car.
3. Fit the charge air pipe to the charge air cooler with the clip.
4. Lower the car to the floor.
5. Connect the charge air pipe to the throttle body.
6. Plug in the connector for the temperature/pressure sensor on the charge air pipe.
7. Fit the bypass pipe with valve using a new O-ring for the connection to the turbocharger inlet pipe.
8. Fit the engine cover.

Scheme 810

1. Raise the car.
2. Remove the air cleaner cover.
3. Lower away the cover and remove the filter element.

Short Description

The air induction system consists of an air cleaner, mass air flow sensor, connecting pipes hoses, turbocharger and air cooler. The system is connected to the throttle body.

The filer element removes particles of dust from the intake air and also functions as an intake air silencer.

The mass air flow sensor provides the engine management system's control module with continuous information on the air mass consumed by the engine. The mass air flow sensor's signals are processed by the control module which monitors the fuel-air mixture needs of the engine.

Scheme 811

1. Check valve
2. Filter element
3. Mass air flow sensor
4. Turbocharger
5. Charge air cooler
6. Bypass valve
7. Solenoid valve
8. Throttle body
9. Charge air absolute pressure sensor/Intake air temperature sensor
10. Manifold absolute pressure sensor
11. Engine
12. Crankcase ventilation oil trap
13. Check valves
14. Purge valve
15. EVAP canister
16. Wastegate valve
17. Charge air regulator
18. Charge air control valve
19. Oxygen sensor
20. Pre-catalytic converter
21. Main catalytic converter
22. Front silencer
23. Rear silencer
24. Brake vacuum strenghtener
25. Brake servo
26. Check valve

Scheme 812

1. Air intake pipe
2. Air cleaner consisting of
3. Cover
4. Filter element
5. Air cleaner casing
6. Mass air flow sensor
7. Connecting hose
8. Pipe connector to turbo unit and charge air cooler
9. Bypass pipe
10. Charge air bypass valve
11. Pressure/temperature sensor
12. Throttle valve

The air induction system consists of an air cleaner, mass air flow sensor, connecting pipes hoses, turbocharger and air cooler. The system is connected to the throttle body.

The filer element removes particles of dust from the intake air and also functions as an intake air silencer.

The mass air flow sensor provides the engine management system's control module with continuous information on the air mass consumed by the engine. The mass air flow sensor's signals are processed by the control module which monitors the fuel-air mixture needs of the engine.

Scheme 813
