Dice: Overview Saab 9-5 I рестайлинг 2

Communication Devices 32 illustrations ~1036 words

Scheme 1

Scheme 1: To remove
Scheme 1: To remove

Scheme 2

Scheme 2
Scheme 2
  1. Remove lower panel from driver's side.
  2. Remove the fuse cover (To be better able to see what you're doing).
  3. Unplug the connector from on the control module.
  4. Remove 2 screws (Torx 25) holding DICE.
  5. Pull the DICE control module straight out.

Scheme 3

Scheme 3: To fit
Scheme 3: To fit

Scheme 4

Scheme 4
Scheme 4
  1. Fit the control module in place.
  2. Screw tight with 2 screws.
  3. Plug in the connector to the control module.
  4. Refit the fuse cover.
  5. Refit the lower panel.
  6. After the DICE control module is replaced, it must be programmed into the car. See «MENU "PROGRAMMING"»(ref-278628-S06690819872008013000000) .

Scheme 5

Scheme 5: SYSTEM OVERVIEW, DICE
Scheme 5: SYSTEM OVERVIEW, DICE
  1. Exterior lighting. See «SYSTEM OVERVIEW, EXTERIOR LIGHTING»(ref-278628-S32609735602008013000000) . For detailed information, see «LIGHT AND SIGNAL SYSTEM»(ref-278621)
  2. Interior lighting. See «SYSTEM OVERVIEW, INTERIOR LIGHTING»(ref-278628-S12439726682008013000000) . For detailed information, see: 4D and 5D. See «SYSTEM OVERVIEW, INTERIOR LIGHTING»(ref-278628-S12439726682008013000000) .
  3. Lighting for buttons and controls. See «SYSTEM OVERVIEW, BUTTON ILLUMINATION AND LIGHTING FOR CONTROLS»(ref-278628-S35456936192008013000000) and «MAIN COMPONENTS, BUTTON ILLUMINATION AND LIGHTING FOR CONTROLS»(ref-278628-S17304539112008013000000) . For detailed information, see «LIGHTING FOR BUTTONS AND CONTROLS»(ref-278628-S40579224962008013000000) .
  4. Intermittent wiper, windscreen. See «WIPER/WASHER SYSTEMS»(ref-278627) . For detailed information, see «WIPER/WASHER SYSTEMS»(ref-278627)
  5. Wash/wipe systems, rain sensor. See «WINDSCREEN WIPERS WITH RAIN SENSOR»(ref-278627-S38010967912008013000000) . For detailed information, see «WASH AND WIPER SYSTEMS»(ref-278627) .
  6. Washer fluid system. See «WIPER/WASHER SYSTEMS»(ref-278627) . For detailed information, see «WASH AND WIPER SYSTEMS»(ref-278627) .
  7. Intermittent wiper operation, rear window 5D. See «REAR WINDOW WIPER (5D)»(ref-278627-S01932660412008013000000) . For detailed information, see «WASH AND WIPER SYSTEMS»(ref-278627) .
  8. Headlamp wipers. See «HEADLAMP WASHERS»(ref-278627-S29705985462008013000000) . For detailed information, see «WASH AND WIPER SYSTEMS»(ref-278627) .
  9. Electrically heated rear window and door mirrors 4D. Car with ACC. See «SYSTEM OVERVIEW, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (CARS WITH ACC) (4D)»(ref-278628-S16624095392008013000000) . Car with MCC. See «SYSTEM OVERVIEW, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (CARS WITH MCC) (4D)»(ref-278628-S07342922752008013000000) . Principal components. See «MAIN COMPONENTS, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (4D)»(ref-278628-S24470736862008013000000) . For detailed information, see «GLASS, WINDOWS AND MIRRORS»(ref-278629) .
  10. Electrically heated rear window and door mirrors 5D. Car with ACC. See «SYSTEM OVERVIEW, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (CARS WITH ACC) (5D)»(ref-278628-S26202486002008013000000) . Car with MCC. See «SYSTEM OVERVIEW, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (CARS WITH MCC) (5D)»(ref-278628-S28301231322008013000000) . Principal components. See «MAIN COMPONENTS, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (5D)»(ref-278628-S11206050242008013000000) . For detailed information, see «GLASS, WINDOWS AND MIRRORS»(ref-278629) .
  11. Radiator fan system. For detailed information, see: Car with A/C. See «SYSTEM OVERVIEW, RADIATOR FAN SYSTEM (CARS WITH A/C)»(ref-278628-S39360145452008013000000) . Car without A/C. See «SYSTEM OVERVIEW, RADIATOR FAN SYSTEM (CARS WITHOUT A/C)»(ref-278628-S29163096952008013000000) . Principal components. See «COOLING SYSTEM -- SAAB 9-5»(ref-274824) . For detailed information, see «COOLING SYSTEM -- SAAB 9-5»(ref-274824) .
  12. Air conditioning Car with ACC. See «SYSTEM OVERVIEW, A/C FUNCTION (CARS WITH ACC)»(ref-278628-S24969936952008013000000) . Principal components. See «MAIN COMPONENTS, A/C FUNCTION»(ref-278628-S22158468872008013000000) . For detailed information, see «HEATING AND VENTILATION, A/C»(ref-278630) .

Scheme 6

Scheme 6: SYSTEM OVERVIEW, EXTERIOR LIGHTING
Scheme 6: SYSTEM OVERVIEW, EXTERIOR LIGHTING
  1. Control module, DICE (628)
  2. Lights, switch (10)
  3. Dipswitch (215)
  4. Front fog lights, switch (88)
  5. Rear fog lights, switch (161)
  6. Direction indicators, switch (24)
  7. Switch, hazard flashers (25)
  8. Reversing lights, switch (31)
  9. Selector lever position switch 2, automatic transmission (239)
  10. Control module, TWICE (632)

Scheme 7

Scheme 7: MAIN COMPONENTS, EXTERIOR LIGHTING
Scheme 7: MAIN COMPONENTS, EXTERIOR LIGHTING

Scheme 8

Scheme 8: SYSTEM OVERVIEW, INTERIOR LIGHTING
Scheme 8: SYSTEM OVERVIEW, INTERIOR LIGHTING
  1. Control module, DICE (628)
  2. Cabin lighting switch (53)
  3. Dome lamps (50)
  4. Front/rear reading lamps (225)
  5. Vanity mirror lamp (359)
  6. Glove box lamp (19)
  7. Front floor lighting, lamps (613)
  8. Courtesy lighting, lamps (209)
  9. Luggage compartment lighting switch (56)
  10. Luggage compartment lamp (55)
  11. Control module, TWICE (632)
  12. Door switches (54)
  13. Car key

Scheme 9

Scheme 9: MAIN COMPONENTS, INTERIOR LIGHTING
Scheme 9: MAIN COMPONENTS, INTERIOR LIGHTING

Scheme 10

Scheme 10: SYSTEM OVERVIEW, BUTTON ILLUMINATION AND LIGHTING FOR CONTROLS
Scheme 10: SYSTEM OVERVIEW, BUTTON ILLUMINATION AND LIGHTING FOR CONTROLS
  1. Control module DICE (628)
  2. SID (541)
  3. Control module, TWICE (632)
  4. Instrument illumination rheostat (16)

Scheme 11

Scheme 11: MAIN COMPONENTS, BUTTON ILLUMINATION AND LIGHTING FOR CONTROLS
Scheme 11: MAIN COMPONENTS, BUTTON ILLUMINATION AND LIGHTING FOR CONTROLS

Scheme 12

Scheme 12: SYSTEM OVERVIEW, INTERMITTENT WIPER OPERATION, WINDSCREEN
Scheme 12: SYSTEM OVERVIEW, INTERMITTENT WIPER OPERATION, WINDSCREEN
  1. Control module, DICE (628)
  2. Stalk switch, windscreen wipers (61)
  3. Intermittent wiper relay (83)
  4. Intermittent wiper rheostat (618)
  5. Windscreen wiper motor (62F)

Scheme 13

Scheme 13: MAIN COMPONENTS, INTERMITTENT WIPER OPERATION, WINDSCREEN
Scheme 13: MAIN COMPONENTS, INTERMITTENT WIPER OPERATION, WINDSCREEN

Scheme 14

Scheme 14: SYSTEM OVERVIEW, WASH/WIPE SYSTEMS, RAIN SENSOR
Scheme 14: SYSTEM OVERVIEW, WASH/WIPE SYSTEMS, RAIN SENSOR
  1. Rain sensor (649)
  2. Relay, rain sensor (650)
  3. Stalk switch, windscreen wipers (61, 618)
  4. Windscreen wiper motor (62F)
  5. Motor, washer fluid (63a, 63b)
  6. Motor, headlamp wipers (66FR, 66FL)
  7. Intermittent wiper relay (83)
  8. Control module, DICE (628)
  9. SID (541)

Scheme 15

Scheme 15: MAIN COMPONENTS, WASH/WIPE SYSTEMS, RAIN SENSOR
Scheme 15: MAIN COMPONENTS, WASH/WIPE SYSTEMS, RAIN SENSOR

Scheme 16

Scheme 16: SYSTEM OVERVIEW, WASHER FLUID SYSTEM
Scheme 16: SYSTEM OVERVIEW, WASHER FLUID SYSTEM
  1. Control module, DICE (628)
  2. Stalk switch, windscreen wipers (61)
  3. Switch, rear window wiper 5D (61a)
  4. Relay, washer fluid pump (432)
  5. Motor, pump, washer fluid, rear window (63a)
  6. Motor, pump, washer fluid, windscreen (63b)

Scheme 17

Scheme 17: PRINCIPAL COMPONENTS, WASHER FLUID SYSTEM
Scheme 17: PRINCIPAL COMPONENTS, WASHER FLUID SYSTEM

Scheme 18

Scheme 18: SYSTEM OVERVIEW, INTERMITTENT WIPER OPERATION, REAR WINDOW (5D)
Scheme 18: SYSTEM OVERVIEW, INTERMITTENT WIPER OPERATION, REAR WINDOW (5D)
  1. Control module, DICE (628)
  2. Switch, rear window wiper (61a)
  3. Relay, intermittent wiper, rear window (83a)
  4. Motor, rear window wiper (62R)

Scheme 19

Scheme 19: PRINCIPAL COMPONENTS, INTERMITTENT WIPER OPERATION, REAR WINDOW (5D)
Scheme 19: PRINCIPAL COMPONENTS, INTERMITTENT WIPER OPERATION, REAR WINDOW (5D)

Scheme 20

Scheme 20: SYSTEM OVERVIEW, WIPER HEADLAMP
Scheme 20: SYSTEM OVERVIEW, WIPER HEADLAMP
  1. Control module, DICE (628)
  2. Switch, windscreen wipers (61)
  3. Relay, high pressure headlamp washer fluid pump (667)
  4. Motor, high pressure headlamp washer pump (668)

Scheme 21

Scheme 21: MAIN COMPONENTS, HEADLAMP WIPER
Scheme 21: MAIN COMPONENTS, HEADLAMP WIPER

Scheme 22

Scheme 22: SYSTEM OVERVIEW, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (CARS WITH ACC) (4D)
Scheme 22: SYSTEM OVERVIEW, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (CARS WITH ACC) (4D)
  1. Control module, DICE (628)
  2. Relay, electrically heated rear window (113)
  3. Electrically heated rear window, element (115)
  4. Electrically heated door mirrors, elements (207)
  5. Control module, ACC (216)
  6. Radio aerial amplifier (624)
  7. Aerial ground filter (644)

Scheme 23

Scheme 23: SYSTEM OVERVIEW, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (CARS WITH MCC) (4D)
Scheme 23: SYSTEM OVERVIEW, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (CARS WITH MCC) (4D)
  1. Control module, DICE (628)
  2. Electrically heated rear window, switch (116)
  3. Relay, electrically heated rear window (113)
  4. Electrically heated rear window, element (115)
  5. Electrically heated door mirrors, elements (207)
  6. MCC control panel (504)
  7. Radio aerial amplifier (624)
  8. Aerial ground filter (644)

Scheme 24

Scheme 24: MAIN COMPONENTS, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (4D)
Scheme 24: MAIN COMPONENTS, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (4D)

Scheme 25

Scheme 25: SYSTEM OVERVIEW, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (CARS WITH ACC) (5D)
Scheme 25: SYSTEM OVERVIEW, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (CARS WITH ACC) (5D)
  1. Control module, DICE (628)
  2. Relay, electrically heated rear window (113)
  3. Electrically heated rear window, element (115)
  4. Electrically heated door mirrors, elements (207)
  5. Control module, ACC (216)

Scheme 26

Scheme 26: SYSTEM OVERVIEW, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (CARS WITH MCC) (5D)
Scheme 26: SYSTEM OVERVIEW, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (CARS WITH MCC) (5D)
  1. Control module, DICE (628)
  2. Electrically heated rear window, switch (116)
  3. Relay, electrically heated rear window (113)
  4. Electrically heated rear window, element (115)
  5. Electrically heated door mirrors, elements (207)
  6. MCC control panel (504)

Scheme 27

Scheme 27: MAIN COMPONENTS, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (5D)
Scheme 27: MAIN COMPONENTS, ELECTRICALLY HEATED REAR WINDOW AND DOOR MIRRORS (5D)

Scheme 28

Scheme 28: SYSTEM OVERVIEW, RADIATOR FAN SYSTEM (CARS WITH A/C)
Scheme 28: SYSTEM OVERVIEW, RADIATOR FAN SYSTEM (CARS WITH A/C)
  1. Control module, DICE (628)
  2. Relay, 2-speed radiator fan, low speed (155)
  3. Relay, 2-speed radiator fan, high-speed (81)
  4. Relay, high speed, RH radiator fan (396)
  5. Motor, radiator fans (37LH, 37RH)
  6. Engine management system (430, 589, 595, 655)
  7. Main instrument panel (540)
  8. Engine coolant temperature sensor, engine management system (202)
  9. Pressure sensor, A/C (620)
  10. SID (541)

Scheme 29

Scheme 29: SYSTEM OVERVIEW, RADIATOR FAN SYSTEM (CARS WITHOUT A/C)
Scheme 29: SYSTEM OVERVIEW, RADIATOR FAN SYSTEM (CARS WITHOUT A/C)
  1. Control module, DICE (628)
  2. Relay, 2-speed radiator fan, low speed (155)
  3. Relay, 2-speed radiator fan, high-speed (81)
  4. Resistor, 2-stage radiator fan (367)
  5. Motor, radiator fan (37LH)
  6. Engine management system (430, 589, 595, 655)
  7. Main instrument panel (540)
  8. Engine coolant temperature sensor, engine management system (202)

Scheme 30

Scheme 30: MAIN COMPONENTS, RADIATOR FAN SYSTEM
Scheme 30: MAIN COMPONENTS, RADIATOR FAN SYSTEM

Scheme 31

Scheme 31: SYSTEM OVERVIEW, A/C FUNCTION (CARS WITH ACC)
Scheme 31: SYSTEM OVERVIEW, A/C FUNCTION (CARS WITH ACC)
  1. Control module, DICE (628)
  2. Control module, ACC (216)
  3. Evaporator temperature sensor, A/C (621)
  4. Pressure sensor, A/C (620)
  5. Relay, A/C compressor (156)
  6. A/C compressor (170)
  7. Engine management system (430, 589, 595, 655)
  8. Engine coolant temperature sensor, engine management system (202)

Scheme 32

Scheme 32: MAIN COMPONENTS, A/C FUNCTION
Scheme 32: MAIN COMPONENTS, A/C FUNCTION
