Diagnostic trouble code table
| Type | DTC | Malfunction/faulty component | For Further Information, See |
|---|---|---|---|
| B | 1100 | Low Speed Radiator Fan Relay. Short to B+ | Cooling system. See B1100; LOW SPEED RADIATOR FAN RELAY. SHORT TO B+; LOW SPEED RADIATOR FAN RELAY. OPEN CIRCUIT / SHORT TO GROUND . |
| B | 1100 | Low Speed Radiator Fan Relay. Open Circuit / Short to Ground | Cooling system. See B1100; LOW SPEED RADIATOR FAN RELAY. SHORT TO B+; LOW SPEED RADIATOR FAN RELAY. OPEN CIRCUIT / SHORT TO GROUND . |
| B | 1110 | Windscreen Wiper Relay. Short to B+ | WASH/WIPE SYSTEMS |
| B | 1110 | Windscreen Wiper Relay. Open Circuit / Short to Ground | WASH/WIPE SYSTEMS |
| B | 1115 | Rear Window Wiper Relay. Short to B+ | WASH/WIPE SYSTEMS |
| B | 1115 | Rear Window Wiper Relay. Open Circuit / Short to Ground | WASH/WIPE SYSTEMS |
| B | 1125 | Rear Window Heating Relay. Short to B+ | Glass, windows and mirrors |
| B | 1125 | Rear Window Heating Relay. Open Circuit / Short to Ground | Glass, windows and mirrors |
| B | 1145 | Rear Fog Light. Open Circuit / Short to B+ | Lighting and signalling systems. See LIGHTING AND SIGNALLING SYSTEMS . |
| B | 1145 | Rear Fog Light. Short to Ground | Lighting and signalling systems. See LIGHTING AND SIGNALLING SYSTEMS . |
| B | 1150 | Front Fog Lights Relay. Short to B+ | Lighting and signalling systems. See LIGHTING AND SIGNALLING SYSTEMS . |
| B | 1150 | Front Fog Lights Relay. Open Circuit / Short to Ground | Lighting and signalling systems. See LIGHTING AND SIGNALLING SYSTEMS . |
| B | 1160 | Main light Relay. Short to B+ | Lighting and signalling systems. See LIGHTING AND SIGNALLING SYSTEMS . |
| B | 1160 | Main light Relay. Open Circuit / Short to Ground | Lighting and signalling systems. See LIGHTING AND SIGNALLING SYSTEMS . |
| B | 1215 | Interior Light. Short to Ground | Lighting and signalling systems. See LIGHTING AND SIGNALLING SYSTEMS . |
| B | 1220 | Map Light. Short to Ground | Lighting and signalling systems. See LIGHTING AND SIGNALLING SYSTEMS . |
| B | 1235 | Trunk Light. Short to Ground | Lighting and signalling systems. See LIGHTING AND SIGNALLING SYSTEMS . |
| B | 1240 | Door Light. Short to Ground | Lighting and signalling systems. See LIGHTING AND SIGNALLING SYSTEMS . |
| B | 1525 | +15 missing when +54 is on | See B1525; +15 MISSING WHEN +54 IS ON . |
| B | 1530 | +B missing when +15 is on | See B1530; +B MISSING WHEN +15 IS ON . |
| B | 1605 | Internal Fault | See B1605; INTERNAL FAULT . |
| B | 1735 | Rheostat Light. Short to Ground | Lighting and signalling systems. See LIGHTING AND SIGNALLING SYSTEMS . |
| B | 2190 | High Speed Radiator Fan Relay 1. Short to B+ | Cooling system. See B2190; HIGH SPEED RADIATOR FAN RELAY 1. SHORT TO B+; HIGH SPEED RADIATOR FAN RELAY 1. OPEN CIRCUIT / SHORT TO GROUND . |
| B | 2190 | High Speed Radiator Fan Relay 1. Open Circuit / Short to Ground | Cooling system. See B2190; HIGH SPEED RADIATOR FAN RELAY 1. SHORT TO B+; HIGH SPEED RADIATOR FAN RELAY 1. OPEN CIRCUIT / SHORT TO GROUND . |
| B | 2195 | High Speed Radiator Fan Relay 2. Short to B+ | Cooling system. See B2195; HIGH SPEED RADIATOR FAN RELAY 2. SHORT TO B+; HIGH SPEED RADIATOR FAN RELAY 2. OPEN CIRCUIT / SHORT TO GROUND . |
| B | 2195 | High Speed Radiator Fan Relay 2. Open Circuit / Short to Ground | Cooling system. See B2195; HIGH SPEED RADIATOR FAN RELAY 2. SHORT TO B+; HIGH SPEED RADIATOR FAN RELAY 2. OPEN CIRCUIT / SHORT TO GROUND . |
| B | 2280 | High/Low Beam Relay. Short to B+ | Lighting and signalling systems. See LIGHTING AND SIGNALLING SYSTEMS . |
| B | 2280 | High/Low Beam Relay. Open Circuit / Short to Ground | Lighting and signalling systems. See LIGHTING AND SIGNALLING SYSTEMS . |
| B | 2355 | Evaporator Temperature Sensor. Short to Ground | Heating and ventilation, A/C. See B2355; EVAPORATOR TEMPERATURE SENSOR. SHORT TO GROUND; EVAPORATOR TEMPERATURE SENSOR. OPEN CIRCUIT / SHORT TO B+; EVAPORATOR TEMPERATURE SENSOR. OUT OF RANGE . |
| B | 2355 | Evaporator Temperature Sensor. Open Circuit / Short to B+ | Heating and ventilation, A/C. See B2355; EVAPORATOR TEMPERATURE SENSOR. SHORT TO GROUND; EVAPORATOR TEMPERATURE SENSOR. OPEN CIRCUIT / SHORT TO B+; EVAPORATOR TEMPERATURE SENSOR. OUT OF RANGE . |
| B | 2355 | Evaporator Temperature Sensor. Out of Range. | Heating and ventilation, A/C. See B2355; EVAPORATOR TEMPERATURE SENSOR. SHORT TO GROUND; EVAPORATOR TEMPERATURE SENSOR. OPEN CIRCUIT / SHORT TO B+; EVAPORATOR TEMPERATURE SENSOR. OUT OF RANGE . |
| B | 2360 | A/C Pressure Sensor. Short to Ground | Heating and ventilation, A/C. See PRESSURE SENSOR |
| B | 2360 | A/C Pressure Sensor. Open Circuit / Short to B+ | Heating and ventilation, A/C. See PRESSURE SENSOR . |
| B | 2480 | Intermittent Wiper Switch. Out of Range. | WASH/WIPE SYSTEMS |
DIAGNOSTIC TROUBLE CODE CHART
Scheme 33
Fault symptoms
If a fuse is missing, then SID and MIU are "black" and Trionic is shown as being a fused unit. Communication for diagnostics is still possible, however, even though a fuse is missing.
Diagnostic help
+15 can be read with scan tool.
Interior lighting does not come on when the key is removed from the ignition and no doors are opened.
+B can be read with the scan tool.
Varies depending on fault characteristics.
Table, fault symptoms
| Fault symptoms | For Further Information , See |
|---|---|
| No diagnostics communication | See NO DIAGNOSTICS COMMUNICATION . |
| Ventilation fan does not start until 20 seconds after the engine has been started. | See VENTILATION FAN DOES NOT START UNTIL 20 SECONDS AFTER THE ENGINE HAS BEEN STARTED . |
| Direction indicator function | See DIRECTION INDICATORS . |
| Headlamps | See HEADLAMPS . |
| Front fog lights | See FRONT FOG LIGHTS . |
| Rear fog lights | See REAR FOG LIGHTS . |
| Brake lights | See BRAKE LIGHTS . |
| Luggage compartment lighting | See LUGGAGE COMPARTMENT LIGHTING . |
| Reading lamps | See READING LIGHTS . |
| Courtesy lights | See COURTESY LIGHTS . |
| Reversing lights, man. | See REVERSING LIGHTS, MAN. . |
| Reversing lights, auto. | See REVERSING LIGHTS, AUTO . |
| Glove box light | See GLOVE BOX LIGHT . |
| Button illumination | See BUTTON ILLUMINATION . |
| Parking lights | See PARKING LIGHTS . |
| Parking lights (US/CA) | See PARKING LIGHTS (US/CA) . |
| Wiper or washer, with rain sensor. Defective | See WIPERS OR WASHERS WITH RAIN SENSOR. INCORRECT . |
| Wiper or washer, without rain sensor. Defective | See WIPER OR WASHER, WITHOUT RAIN SENSOR. DEFECTIVE . |
| Rear window wiper. Defective (5D) | See REAR WINDOW WIPER. DEFECTIVE (5D) . |
SYMPTOMS CHART
Scheme 34
No diagnostics communication.
Diagnostic procedure
See BUS AND DIAGNOSTICS COMMUNICATION
Ventilation fan does not start until 20 seconds after the engine has been started.
