Heating and Ventilation, A/c: Specifications Saab 9-5 I рестайлинг 2

Automatic HVAC System 11 illustrations ~131 words

Tightening Torques

Torque (Nm)Torque (lbf ft)Dimension
A/C compressor joint, RH structural member97
A/C hoses PAD connection to expansion valve86
A/C hoses to compressor2015
Expansion valve54
High pressure pipe to receiver97
High and low pressure pipes to expansion valve75
High pressure pipe PAD connection to compressor2015
Compressor retaining bolts2418M8
Compressor retaining bolts4030M10
Low pressure pipe to receiver97
Low pressure pipe PAD connection to compressor2015
PAD connection, evaporator86
PAD connection condenser86
PAD connection, heat exchanger3-42-3
PAD connections, receiver86
Connector to power steering cooling coil3022
Joint on low pressure pipe between expansion valve and compressor86
Joint on high pressure pipe between receiver and expansion valve86
Screw, electromagnetic clutch139
Power steering pump cooling coil64
Pressure sensor7-95-7

TIGHTENING TORQUES SPECIFICATION

Scheme 1

Scheme 1: Tech 2
Scheme 1: Tech 2
9000900-M93900/9-39-59-3 (9440)
XXXXX

SPECIAL TOOL COMPATIBILITY CHART

Scheme 2

Scheme 2: Equipment for Vacuum Pumping and Filling of Refrigerant
Scheme 2: Equipment for Vacuum Pumping and Filling of Refrigerant

Vacuum pumping and filling equipment WAECO RHS1100

Scheme 3

Scheme 3: 30 05 477 Cooling System Tester
Scheme 3: 30 05 477 Cooling System Tester

86 12 798 Toolboard T1 Service

Used together with 30 05 469 Adapter, cooling system tester

9000900-M93900/9-39-59-3 (9440)
XXXXX

SPECIAL TOOL COMPATIBILITY CHART

Scheme 4

Scheme 4: 30 07 739 Hose Pinch-Off Pliers
Scheme 4: 30 07 739 Hose Pinch-Off Pliers

Prevents runoff from cooling system hoses

9000900-M93900/9-39-59-3 (9440)
XXXXX

SPECIAL TOOL COMPATIBILITY CHART

Scheme 5

Scheme 5: 82 92 930 Leak Tester, R12 and R134a
Scheme 5: 82 92 930 Leak Tester, R12 and R134a
9000900-M93900/9-39-5
XXXX

SPECIAL TOOL COMPATIBILITY CHART

Scheme 6

Scheme 6: 82 92 948 Plugs, A/C System, Kit
Scheme 6: 82 92 948 Plugs, A/C System, Kit

Group: Body

9000900-M93900/9-39-59-3 (9440)
XXXXX

SPECIAL TOOL COMPATIBILITY CHART

Scheme 7

Scheme 7: 82 92 955 Spare Parts Kit, Plugs
Scheme 7: 82 92 955 Spare Parts Kit, Plugs

Group: Body

9000900-M93900/9-39-59-3 (9440)
XXXXX

SPECIAL TOOL COMPATIBILITY CHART

Scheme 8

Scheme 8: 83 95 212 Strap
Scheme 8: 83 95 212 Strap

Group: Engine

9000900-M93900/9-39-59-3 (9440)
XXXXX

SPECIAL TOOL COMPATIBILITY CHART

Scheme 9

Scheme 9: 85 80 144 Puller Windscreen Wiper Arm
Scheme 9: 85 80 144 Puller Windscreen Wiper Arm

86 12 798 Toolboard T1 Service

Group: Body

9000900-M93900/9-39-59-3 (9440)
XXX

SPECIAL TOOL COMPATIBILITY CHART

Scheme 10

Scheme 10: 86 11 261 Test Lead, 39-pin
Scheme 10: 86 11 261 Test Lead, 39-pin

ACC

Saab 9-5 Audio System, power amplifier

Group: Test equipment

9000900-M93900/9-39-5
XXX

SPECIAL TOOL COMPATIBILITY CHART

Scheme 11

Scheme 11: 86 11 857 Test lamp, red-green
Scheme 11: 86 11 857 Test lamp, red-green

Voltage range 8-16V

Group: Test equipment

9000900-M93900/9-39-59-3 (9440)
XXXXX

SPECIAL TOOL COMPATIBILITY CHART

More articles — Heating and Ventilation, A/c
